BBOESD9221ESD-9221 WX RADAR DECTECTOR

Radar/Laser Detector Model ESD-9220 WX Operating Instructions for your Cobra® 9 Band® Extra Sensory Detection® Nothing comes close to a Cobra™ NOAA Dim City/ Wx WX Mute X L K Ka V W Wx Cty band 360 lazer Introduction A1 Introduction Congratulations! You have just purchased the most sophisticated RADAR/LASER DETECTOR available today. This booklet contains instructions and information designed so that you will be able to understand how the Cobra® ESD-9220 WX works and how radar and (LIDAR) laser are used. Enjoy your Cobra® ESD-9220 WX Radar/Laser Detector and drive safely. Federal Law Governing Use of Radar Detectors It is not against Federal Law to receive radar transmissions on your COBRA® Radar Detector. The Communications Act of 1934 guarantees your right to receive radio transmissions on any frequency. Local laws that contravene the Communications Act of 1934, while illegal, may be enforced by your local law enforcement officials until and unless they are prohibited from doing so by Federal Court action. WARNING:Before leaving your car, make sure that you conceal your radar detector. This will reduce the possibility of break-in and theft of your unit. Included with your ESD-9220 WX 1.Windshield Bracket 2.Hook and Loop Material 3.Power Cord and Strobe Alert™ Use of this product is not intended to, and does not ensure that the motorist and any passenger will not be involved in a traffic accident. It is only intended to alert the motorist that an emergency or service vehicle equipped with a CODE 3, Strobe (Opticom* or Tomar Preemption System) or Cobra® Safety Alert® Transmitter is in the area as defined by the range of the product. Please call your local Fire/Police department to verify if coverage exists in your area. Motorists are expected to exercise all due caution while using this product, and to observe and follow all applicable traffic laws. Operators of emergency or service vehicles are also expected to exercise all due caution while using this product, and to observe and follow all applicable traffic laws. *Opticom is a registered trademark of 3M Corporation 1. 2. 3. How to Use Your Cobra ® ESD Radar/Laser Detector 1 Features of This Product •10 Channel Weather Radio •Weather Alert •Voice Alert™ •Safety Alert® Traffic Warning System •360 º Strobe Alert ™ •Separate Visual and Audio Alarms •Signal Strength Indicators •LaserEye® 360 ̊ Detection •VG-2 Undetectable •Auto and Manual Muting •3 Level Dim Button •Superior Audio Volume •Adjustable Windshield Mounting Bracket Contents Introduction.......................................................................A1 Safety Alert®/Strobe Alert™ Federal Law Governing Radar Detectors Included Accessories Controls & Indicators.....................................................A2 Our Thanks to You...........................................................A3 Customer Support ........................................................A3 Features..................................................................................1 Installation............................................................................2 Quick Start.............................................................................5 LED Displays.......................................................................6 Operation...............................................................................9 Turning On .........................................................................9 Dim Button ......................................................................10 Highway/City Mode......................................................11 Muting Mode ..................................................................12 Memory Set .....................................................................12 Weather Radio ................................................................13 Detection.............................................................................13 Band Detection ..............................................................14 Audible Alarm Indicator..............................................14 Radar ..................................................................................15 VG-2 Undetectable .......................................................16 Safety Alert®/Strobe Alert™ ......................................17 Laser Detection ..............................................................17 Radar/VG-2/Laser Alerts..............................................18 Facts About Safety Alert®/Strobe Alert™ .............19 Radar Frequencies.........................................................20 Facts About Lidar (Laser) ............................................20 Maintenance......................................................................21 Specifications....................................................................22 Limited One Year Warranty........................................23 Optional Accessories.....................................................24 Order Form.........................................................................25 If You Think You Need Service.................Back Cover Installation 3 Installation 2 Note Adjust the bracket so that the tip of the antenna is at least an inch away from the dashboard. Dim City Wx Wx Mute BA N D Attach cups to bracket. Attach detector to bracket. Plug power cord into detector. Attach bracket to windshield. Bend bracket for correct detection angle (if needed). Plug power cord into cigarette lighter. Place antenna in upright position for optimum reception of weather stations. Place antenna facing towards dashboard if windshield angle prevents you from placing it upright. 5 6 7 8 Location Selecting the proper location to mount the Cobra® ESD-9220 WX is very important for optimum performance. Both radar and laser transmissions pass through glass but not through other objects. For this reason the Cobra® ESD-9220 WX lenses must not be blocked. It should have a view of th…

Text truncated - open the document above for the full version.

APPLICANT: COBRA ELECTRONICS CORPORATION FCC ID : BBOESD9221 REPORT #: C\COBRA\943UT3\943UT3TestReport.doc TABLE OF CONTENTS LIST TABLE OF CONTENTS LIST APPLICANT: COBRA ELECTRONICS CORPORATION FCC ID: BBOESD9221 TEST REPORT CONTAINING: PAGE 1-4....TEST EQUIPMENT LIST PAGE 5-6....TEST PROCEDURES PAGE 7......RADIATION INTERFERENCE TEST DATA PAGE 8......VERTICAL MEASUREMENT PLOT PAGE 9......HORIZONTAL MEASURMENT PLOT EXHIBITS CONTAINING: EXHIBIT 1............CONFIDENTIALITY LETTER EXHIBIT 2............LABEL SAMPLE EXHIBIT 3............LABEL LOCATION EXHIBIT 4............BLOCK DIAGRAM EXHIBIT 5............SCHEMATIC EXHIBIT 6............USERS MANUAL EXHIBIT 7............EXTERNAL PHOTOGRAPHS EXHIBIT 8............INTERNAL PHOTOGRAPHS EXHIBIT 9............CIRCUIT DESCRIPTION EXHIBIT 10...........TEST SET UP PHOTOGRAPHS APPLICANT: COBRA ELECTRONICS CORPORATION FCC ID : BBOESD9221 REPORT #: C\COBRA\943UT3\943UT3TestReport.doc Page 1 of 9 EMC Equipment List Last Update: 7/8/03 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS 3-Meter OATS TEI N/A N/A Listed 1/13/03 1/13/06 3/10-Meter OATS TEI N/A N/A Listed 3/26/01 3/26/04 Receiver, Beige Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 8/31/01 8/31/03 RF Preselector HP 85685A 3221A01400 CAL 8/31/01 8/31/03 Quasi-Peak Adapter HP 85650A 3303A01690 CAL 8/31/01 8/31/03 Preamplifier HP 8449B- H02 3008A00372 CHAR 3/4/01 3/4/03 Receiver, Blue Tower Spectrum Analyzer HP 8568B 2928A04729 2848A18049 CAL 4/15/03 4/15/05 RF Preselector HP 85685A 2926A00983 CAL 4/15/03 4/15/05 Quasi-Peak Adapter HP 85650A 2811A01279 CAL 4/15/03 4/15/05 Receiver, Silver/Grey Tower Spectrum Analyzer HP 8566B Opt 462 3552A22064 3638A08608 CAL 10/14/02 10/14/04 RF Preselector HP 85685A 2620A00294 CAL 10/14/02 10/14/04 Quasi-Peak Adapter HP 85650A 3303A01844 CAL 10/14/02 10/14/04 Preamplifier HP 8449B 3008A01075 CHAR 1/28/02 1/28/04 Biconnical Antenna Electro-Metrics BIA- 25 1171 CAL 4/26/01 4/26/03 Biconnical Antenna Eaton 94455-1 1096 CAL 10/1/01 10/1/03 Biconnical Antenna Eaton 94455-1 1057 CAL 3/18/03 3/18/05 BiconiLog Antenna EMCO 3143 9409- 1043 Log-Periodic Antenna Electro-Metrics LPA-25 1122 CAL 10/2/01 10/2/03 Log-Periodic Antenna Electro-Metrics EM- 6950 632 CHAR 10/15/01 10/15/03 Log-Periodic Antenna Electro-Metrics LPA-30 409 CAL 3/4/03 3/4/05 APPLICANT: COBRA ELECTRONICS CORPORATION FCC ID : BBOESD9221 REPORT #: C\COBRA\943UT3\943UT3TestReport.doc Page 2 of 9 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Log-Periodic Antenna Eaton 96005 1243 CAL 5/8/03 5/8/05 Dipole Antenna Kit Electro-Metrics TDA- 30/1- 4 152 CAL 3/21/01 3/21/04 Dipole Antenna Kit Electro-Metrics TDA- 30/1- 4 153 CAL 9/26/02 9/26/05 Double- Ridged Horn Antenna Electro-Metrics RGA-180 2319 CAL 2/17/03 2/17/05 Horn Antenna *(at 3 meters) Electro-Metrics EM- 6961 6246 CAL 3/31/03 3/31/05 Horn Antenna *(at 10 meters) Electro-Metrics EM- 6961 6246 CAL 6/4/03 6/4/05 Horn Antenna ATM 19 -443- 6R None No Cal Required Passive Loop Antenna EMC Test Systems EMCO 6512 9706- 1211 CHAR 7/10/01 7/10/03 Harmonic Mixer with Horn Antenna Oleson Microwave Labs M08HW/A F30425- 1 CHAR 4/25/03 4/25/05 Harmonic Mixer with Horn Antenna Oleson Microwave Labs M12HW/A E30425- 1 CHAR 4/25/03 4/25/05 Line Impedance Stabilization . . . Electro-Metrics ANS- 25/2 2604 CAL 10/9/01 10/9/03 Line Impedance Stabilization . . . Electro-Metrics EM- 7820 2682 CAL 3/12/03 3/12/05 Termaline Wattmeter Bird Electronic Corporation 611 16405 CAL 5/25/99 5/25/01 Termaline Wattmeter Bird Electronic Corporation 6104 1926 CHAR 9/7/01 9/7/03 Oscilloscope Tektronix 2230 300572 CAL 7/3/03 7/3/05 System One Audio Precision System One SYS1-45868 CHAR 4/25/02 4/25/04 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 1/22/02 1/22/04 AC Voltmeter HP 400FL 2213A14499 CAL 10/9/01 10/9/03 AC Voltmeter HP 400FL 2213A14261 CHAR 10/15/01 10/15/03 AC Voltmeter HP 400FL 2213A14728 CHAR 10/15/01 10/15/03 Digital Multimeter Fluke 77 35053830 CHAR 1/8/02 1/8/04 Digital Multimeter Fluke 77 43850817 CHAR 1/8/02 1/8/04 Digital Multimeter HP E2377A 2927J05849 CHAR 1/8/02 1/8/04 Multimeter Fluke FLUKE- 77- 3 79510405 CHAR 9/26/01 9/26/03 APPLICANT: COBRA ELECTRONICS CORPORATION FCC ID : BBOESD9221 REPORT #: C\COBRA\943UT3\943UT3TestReport.doc Page 3 of 9 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Peak Power Meter HP 8900C 2131A00545 CAL 7/2/03 7/2/05 Power Sensor Agilent Technologies 84811A 2551A02705 CAL 7/2/03 7/2/05 Power Meter HP 432A 1141A07655 CAL 4/15/03 4/15/05 Power Sensor HP 478A 72129 CAL 4/15/03 4/15/05 Power Meter And Sensor Bird 4421- 107 4022 0166 0218 CAL 4/16/03 4/16/05 Digital Thermometer Fluke 2166A 42032 CAL 1/16/02 1/16/04 Thermometer Traulsen SK- 128 CHAR 1/22/02 1/ 22/04 Thermometer Extech 4028 14871-2 CAL 3/7/03 3/7/05 Hygro-Thermometer Extech 445703 0602 CAL 10/4/02 10/4/04 Frequency Counter HP 5352B 2632A00165 CAL 11/28/01 11/28/03 Frequency Counter HP 5385A 2730A03025 CAL 3/7/03 3/7/05 Service Monitor IFR FM/AM 500A 5182 CAL 11/22/00 11/22/02 Comm. Serv. Monitor IFR FM/AM 1200S 6593 CAL 5/12/02 5/12/04 Signal Generator HP 8640B 2308A21464 CAL 2/15/02 2/15/04 Sweep Generator Wiltron 6648 101009 CAL 4/15/03 4/15/05 Sweep Generator Wiltron 6669M 007005 CAL 3/3/03 3/3/05 Modulation Analyzer HP 8901A 3435A06868 CAL 9/5/01 9/5/03 Modulation Meter Boonton 8220 10901AB CAL 4/15/03 4/15/05 Near Field Probe HP HP11940A 2650A02748 CHAR 2/1/01 2/1/03 BandReject Filter Lorch Microwave 5BR4-2400/ 60 -N Z1 CHAR 4/17/03 4/17/05 BandReject Filter Lorch Microwave 6BR6-2442/ 300- N Z1 CHAR 4/17/03 4/17/05 BandReject Filter Lorch Microwave 5BR4-10525/ 900- S Z1 CHAR 4/12/03 4/12/05 Notch Filter Lorch Microwave 5BRX-850/ X100- N AD-1 CHAR 4/17/03 4/17/05 High Pass Filter Unk 3768(5)-400 041 CHAR 12/17/02 12/17/04 APPLICANT: COBRA ELECTRONICS CORPORATION FCC ID : BBOESD9221 REPORT #: C\COBRA\943UT3\943UT3TestReport.doc Page 4 of 9 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS High Pass Filter Microlab…

Text truncated - open the document above for the full version.
