BBP-PRSP1121Laser Printer

Read this manual carefully before you use this machine and keep it handy for future reference. For safe and correct use, be sure to read the Safety Information in this manual before using the machine. 5. 4. 3. 2. 1. Safety Labels of This Machine Safety During Operation Important Safety Instructions Laws and Regulations Information Safety Information English For information not in this manual, refer to the PDF files on the supplied CD-ROM. English 1 Information Introduction This manual contains detailed instructions and notes on the operation and use of this machine. For your safety and benefit, read this manual carefully before using the machine. Keep this manual in a handy place for quick reference. Power Source 120 V, 6 A, 50/60 Hz Be sure to connect the power cord to a power source as above. 2 Laws and Regulations Legal Prohibition Do not copy or print any item for which reproduction is prohibited by law. Copying or printing the following items is generally prohibited by local law: bank notes, revenue stamps, bonds, stock certificates, bank drafts, checks, pass- ports, driver's licenses. The preceding list is meant as a guide only and is not inclusive. We assume no responsibility for its completeness or accuracy. If you have any questions concerning the legality of copying or printing certain items, consult with your legal advisor. Laser Safety CDRH Regulations This machine complies with the requirements of 21 CFR Subchapter J for class I laser product. This machine contains AlGaAs laser diode, 11-milliwatt, 775- 790.7 nanometer wavelength for each emitter. The beam divergence angle is 25 degrees (minimum) and 36 degrees (maximum) in the vertical direction, and 7 degrees (minimum) and 12.5 degrees (maximum) in the horizontal direction, and laser beams are generated in Continuous Wave (CW) mode. Caution: Use of controls or adjustments or performance of procedures other than those specified in this manual might result in hazardous radiation exposure. 3 Notes to USA Users of FCC Requirements Part 15 of the FCC Rules Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc- tions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television recep- tion, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio /TV technician for help. Caution Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Part 68 of the FCC Rules FCC Requirements 1) This equipment complies with Part 68 of the FCC rules and requirements adopted by the ACTA. On the cover of this equipment is a label that contains, among other information, a product identifi er in the format US:AAAEQ##TXXXXX. If requested, this number must be provided to the telephone company. 2) This equipment uses the RJ11C USOC jack. 3) A plug and jack used to connect this equipment to the premises wiring and tele- phone network must comply with the applicable FCC Part 68 rules and require- ments adopted by the ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. See installation instructions for detail. 4) The REN is used to determine the number of devices that may be connected to a telephone line. Excessive RENs on a telephone line may result in the devices not ringing in response to an incoming call. In most but not all areas, the sum of RENs should not exceed fi ve (5.0). To be certain of the number of devices that may be connected to a line, as determined by the total RENs, contact the local telephone company. The REN for this product is part of the product identifi er that has the format US:AAAEQ##TXXXXX. The digits represented by ## are the REN without a decimal point (e.g., 03 is a REN of 0.3). ❖ • • • • ❖ ❖ 4 5) If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advance notice is not practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to fi le a complaint with the FCC if you believe it is necessary. 6) The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the operation of the equipment. If this happens the telephone company will provide advance notice in order for you to make necessary modifi cations to maintain uninterrupted service. 7) If trouble is experienced with this equipment, for repair or warranty informa- tion, please contact Ricoh Americas Corporation. CUSTOMER SUPPORT DEPT. at 1-800- FASTFIX. If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved. 8) In the event of operation problems (document jam, copy jam, communication error indication), refer to the solving problems section in this manual. 9) Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission fo…

Text truncated - open the document above for the full version.

TEST REPORT 47 CFR FCC Part 15 Subpart B (Class B) Radio Frequency Devices – Unintentional Radiators – Limits and methods of measurement ANSI C63.4: 2009 American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Report Reference No. .....................: TRE13030018 R/C:23790 FCC ID. .............................................: BBP-PRSP1121 Compiled by ( position+printed name+signature)..: File administrators Tim Zhang Supervised by ( position+printed name+signature)..: Test Engineer Eric Zhang Approved by ( position+printed name+signature)..: Manager Wenliang Li Date of issue.....................................: May 10, 2013 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address.............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Testing location/ procedure ..............: Full application of Harmonised standards Partial application of Harmonised standards Other standard testing methods Applicant’s name............................: RICOH Co., LTD. Address.............................................: 810 Shimoimaizumi,Ebina City, Kanagawa-Pref., 243-0460 Japan Test specification: Standard ...........................................: 47 CFR FCC Part 15 Subpart B (Class B) ANSI C63.4: 2009 Non-standard test method..............: / Test Report Form No. .....................: HTWEMCFCC_1A TRF Originator ..................................: Shenzhen Huatongwei International Inspection Co., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Laser Printer Trade Mark .......................................: Ricoh Model/Type reference.......................: SP 112/ SP 111 Listed Model..... ...............................: / Ratings..............................................: 120Vac 50/60Hz 6A 680W Result................................................: Positive Report No.: TRE13030018 Page 2 of 41 Issued:2013-05-10 FCC ID: BBP-PRSP1121 Shenzhen Huatongwei International Inspection Co., Ltd EMC -- T E S T R E P O R T Test Report No. : TRE13030018 May 10, 2013 ______________________________________________________________________________________________ Date of issue Equipment under Test : Laser Printer Model / Type : SP 112/ SP 111 Listed Model : / Applicant : RICOH Co., LTD. Address : 810 Shimoimaizumi,Ebina City, Kanagawa-Pref., 243- 0460 Japan Manufacturer : RICOH Co., LTD. Address : 3-6，Naka-magome 1-Chome Ohta-ku,Tokyo 143-8555 Japan Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE13030018 Page 3 of 41 Issued:2013-05-10 FCC ID: BBP-PRSP1121 Shenzhen Huatongwei International Inspection Co., Ltd Contents 1. TEST STANDARDS .................................................................... 4 2. SUMMARY............................................................................... 4 2.1. General Remarks: 4 2.2. Equipment under Test 4 2.3. Short description of the Equipment under Test (EUT) 4 2.4. EUT operation mode 4 2.5. EUT configuration 5 3. TEST ENVIRONMENT ................................................................. 6 3.1. Address of the test laboratory 6 3.2. Test Facility 6 3.3. Environmental conditions 7 3.4. Test Description 7 3.5. Statement of the measurement uncertainty 7 3.6. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS ............................................... 9 4.1. Radiated Emission 9 4.2. Conducted Disturbance 24 5. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ......................... 32 5.1. External photos of the EUT 32 5.2. Internal photos of the EUT 34 Report No.: TRE13030018 Page 4 of 41 Issued:2013-05-10 FCC ID: BBP-PRSP1121 Shenzhen Huatongwei International Inspection Co., Ltd 1. TEST STANDARDS The tests were performed according to following standards: 47 CFR FCC Part 15 Subpart B (Class B) Radio Frequency Devices – Unintentional Radiators – Limits and methods of measurement. ANSI C63.4: 2009 American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2. SUMMARY 2.1. General Remarks: Date of receipt of test sample : Mar 13, 2013 Testing commenced on : Mar 13, 2013 Testing concluded on : May 10, 2013 2.2. Equipment under Test Power supply system utilised Power supply voltage : o 230V / 50 Hz o 115V / 60Hz o 12 V DC o 24 V DC „ Other (specified in blank below) AC 120V/60Hz 2.3. Short description of the Equipment under Test (EUT) The EUT is a laser Printer. Model Difference: The SP 112 and SP 111 were differences for toner refill.The toner of SP 111 can be refilled, but SP 112 can not.Unless otherwise indicated, all tests were conducted on SP 112. Tests performed on SP 112 were considered to be representative of SP 111. There are two kinds of main motor, one is DC motor,the other is stepping motor. DC motor is spaced. 2.4. EUT operation mode The equipment under test was operated during the measurement under the following conditions: Test program (customer specific) Emissions tests.............: 47 CFR FCC Part 15 Subpart B (Class B) and ANSI C63.4 2009, searching for the highest distur…
