810 Shimoimaizumi,Ebina-city, Kanagawa 243-0460 Japan 022311 – 6 Request for Confidentiality Date: _ Jan 20,2014_____ Subject: Confidentiality Request for: BBP-PRSP213NW1 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 2 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term PermanentParts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ RICOH Co., LTD has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180 ) 3 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: Seiji Nakamura (Signature/Title 4 ) (Print name) 2 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 3 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 4 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

810 Shimoimaizumi,Ebina-city, Kanagawa 243-0460 Japan Product Similarity Declaration FCC ID: BBP-PRSP213NW1 Date: Jan 20 ,2014 To Whom It May Concern, We , Ricoh Company Ltd hereby declare that our (Printer) Model Number: SP 213Nw is same SP 212Nw (PCB,Schemartic,Hardware erc), SP 212Nw and SP 213Nw are named differently due to marketing purposes. Please contact me if you have any question. Sincerely, Sincerely, Print Name: Seiji Nakamura Title: Group Leader Company Name: Ricoh Company Ltd

810 Shimoimaizumi,Ebina-city, Kanagawa 243-0460 Japan 022311 – 6 Authority to Act as Agent Date: _Jan 2 4,2014 _____ American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Shenzhen Huatongwei International Inspection Co., Ltd is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date : 31th day of Dec, 2014 By: _ Seiji Nakamura (Signature 1 ) (Print name) Title: Group Leader On behalf of: RICOH Co., LTD (Company Name) Telephone: 0755-83264631 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

External photos of the EUT

Internal photos of the EUT

TEST REPORT 47 CFR FCC Part 15 Subpart B (Class B) Radio Frequency Devices – Unintentional Radiators – Limits and methods of measurement ANSI C63.4: 2009 American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Report Reference No. ..................... : TRE14010025 R/C:95572 FCC ID. ............................................. : BBP-PRSP213NW1 Compiled by ( position+printed name+signature) .. : File administrators Eric Wang Supervised by ( position+printed name+signature) .. : Test Engineer Yingchun Shan Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Jan 20,2014 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Testing location/ procedure .............. : Full application of Harmonised standards Partial application of Harmonised standards Other standard testing methods Applicant’s name ............................ : RICOH Co., LTD. Address............................................. : 810 Shimoimaizumi,Ebina City, Kanagawa-Pref., 243-0460 Japan Test specification .......................... : Standard ........................................... : 47 CFR FCC Part 15 Subpart B (Class B) ANSI C63.4: 2009 Non-standard test method..............: / Test Report Form No. ..................... : HTWEMCFCC_1A TRF Originator .................................. : Shenzhen Huatongwei International Inspection Co., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Printer Trade Mark ....................................... : RICOH Model/Type reference ....................... : SP 213Nw Listed Model..... . .............................. : SP 212Nw Ratings.............................................. : AC 120V/60Hz 8A 900W Result ................................................ : PASS Report No.: TRE14010025 Page 2 of 44 Issued:2014-01-20 FCC ID: BBP-PRSP213NW1 Shenzhen Huatongwei International Inspection Co., Ltd EMC - T E S T R E P O R T Test Report No. : TRE14010025 Jan 20,2014 ______________________________________________________________________________________________ Date of issue Equipment under Test : Printer Model / Type : SP 213Nw Listed Model : SP 212Nw Applicant : RICOH Co., LTD. Address : 810 Shimoimaizumi,Ebina City, Kanagawa-Pref., 243- 0460 Japan Manufacturer : RICOH Co., LTD. Address : 3-6，Naka-magome 1-Chome Ohta-ku,Tokyo 143-8555 Japan Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE14010025 Page 3 of 44 Issued:2014-01-20 FCC ID: BBP-PRSP213NW1 Shenzhen Huatongwei International Inspection Co., Ltd Contents 1. TEST STANDARDS .................................................................... 4 2. SUMMARY ............................................................................... 5 2.1. General Remarks: 5 2.2. Equipment under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. EUT configuration 5 3. TEST ENVIRONMENT ................................................................. 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Test Description 8 3.5. Statement of the measurement uncertainty 8 3.6. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS .............................................. 10 4.1. Radiated Emission 10 4.2. Conducted Disturbance 25 5. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ......................... 33 5.1. External photos of the EUT 33 5.2. Internal photos of the EUT 36 Report No.: TRE14010025 Page 4 of 44 Issued:2014-01-20 FCC ID: BBP-PRSP213NW1 Shenzhen Huatongwei International Inspection Co., Ltd 1. TEST STANDARDS The tests were performed according to following standards: 47 CFR FCC Part 15 Subpart B (Class B) Radio Frequency Devices – Unintentional Radiators – Limits and methods of measurement. ANSI C63.4: 2009 American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. Report No.: TRE14010025 Page 5 of 44 Issued:2014-01-20 FCC ID: BBP-PRSP213NW1 Shenzhen Huatongwei International Inspection Co., Ltd 2. SUMMARY 2.1. General Remarks: Date of receipt of test sample : Jan 14, 2014 Testing commenced on : Jan 14, 2014 Testing concluded on : Jan 20,2014 2.2. Equipment under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) AC 120V/60Hz 2.3. Short description of the Equipment under Test (EUT) The EUT is a laser printer，and there is a WIFI module in SP 213Nw and SP 212Nw and the WIFI module has been cinfirmed Model Difference: SP 213Nw and SP 212Nw are similar, but different from the mechanical structure which does not affect EMC. Unless otherwise indicated, all tests were conducted on SP 213Nw. Tests performed on SP 213Nw were considered to be representative of SP 212Nw. . 2.4. EUT operation mode The equipment under test was operated during the measurement under the following conditions: Test program (custome…
