BBP7080ACompact Disk Rewritable Drive

COMPACT DISC REWRITABLE DRIVE MP7080A SPECIFICATIONS (Preliminary) RICOH Company, Ltd. Oct. 10, 1999 DRC – 60x - 2xx NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device , pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates , uses and can radiate radio frequency energy and , if not installed and used in accordance with the instructions , may cause harmful interference to radio communication. However , there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception , which can be determined by turning the equipment off and on , the user is encouraged to try to correct the interference by one or more of the following measures : ---Reorient or relocate the receiving antenna. ---Increase the separation between the equipment and receiver. ---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ---Consult the dealer or an experienced radio / TV technician for help. FCC WARNING Changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. a) Pay careful attention not to let the invisible laser beam emitted from the optical pickup enter into your eyes. b) When you find a troubled state of the component in the optical pickup containing the laser diode , change to the specified new optical pickup. Do not open the optical pickup housings. Akustischer Geräuschpegel Dieser Drucker überschreitet einen Geräuschpegel von 70 dB (A) während dem Betrieb nicht. Declaration of Conformity “The Product complies with the requirements of the EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC.” Revision History No. Revised Data Revision Contents DescriptionPage Oct. 10, 1999 Preliminary CONTENTS I. OUTLINE------------------------------------------------------------------------------------------------- 1. Overview ...................................................................................................... I - 1 2. Features....................................................................................................... I - 1 II. CONSTRUCTION AND INSTALLATION ------------------------------------------------------ 1. Basic Construction and Connectors.............................................................. II - 1 III. SPECIFICATIONS ----------------------------------------------------------------------------------- 1. Functionality ............................................................................................... III - 1 2. Basic Specification ..................................................................................... III - 2 3. Audio Specification..................................................................................... III - 3 4. Performance Specification.......................................................................... III - 3 5. Condition for use and Safety standard........................................................ III - 3 6. Reliability and Usable Life .......................................................................... III - 6 7. Safety Standards........................................................................................ III - 6 8. Appearance................................................................................................ III - 7 9. Storage Conditions..................................................................................... III - 8 10. Emergency Eject ........................................................................................ III - 10 11. Disc ............................................................................................................ III - 11 12. Packet Command....................................................................................... III - 12 FIGURE II - 1.Front.................................................................................................... II - 1 II - 2.Back .................................................................................................... II - 1 II - 3.Device Configuration Jumper .............................................................. II - 2 III - 1.Installation Conditions ......................................................................... III - 5 III - 2.CD-R/RW Drive Dimension ................................................................. III - 7 III - 3.Packing Arrangement .......................................................................... III - 9 III - 4.Emergency Eject ................................................................................. III - 10 TABLE III - 1.Packet Command ................................................................................ II - 1 I. OUTLINE 1. Overview The Multimedia Printer Series Drive (the CD-R/RW Drive) can do much more than read and write the usual CD-R discs. When you load it with a rewritable CD-RW disc, you can record, read, and edit any kind of data, because these discs allow you to rewrite information that has already been recorded. 2. Features 1) Running OPC*1 gives a flatter writing signal that improves reliability. 2) An improved anti-heat design means that no cooling fan is needed. 3) Easy-to-use tray model. 4) Uses the world standard ATAPI interface. 5) Can read not only CD-R and CD-RW discs, but also video CDs, music CDs, and photo CDs. 6) Can read data at 32x speed and write data at 8x speed on CD-R, 4x speed on CD-RW discs. 7) The recorded CD-RW media can be played in a DVD player or multimedia CD- ROM player, maintaining future compatibility. 8) Supports packet…

Text truncated - open the document above for the full version.

T E S T R E P O R T REPORT NUMBER REPORT NUMBERREPORT NUMBER REPORT NUMBER: :: :AKL- AKL-AKL- AKL-199374 199374199374 199374 APPLICANT APPLICANTAPPLICANT APPLICANT: :: :RICOH COMPANY, LTD. RICOH COMPANY, LTD.RICOH COMPANY, LTD. RICOH COMPANY, LTD. MODEL NUM MODEL NUMMODEL NUM MODEL NUMBER BERBER BER: :: :MP7080A MP7080AMP7080A MP7080A FCC ID FCC IDFCC ID FCC ID: :: :BBP7080A BBP7080ABBP7080A BBP7080A R RR REGULATION EGULATIONEGULATION EGULATION: :: :FCC Part15B Class FCC Part15B Class FCC Part15B Class FCC Part15B Class B BB B Canada ICES-003 Canada ICES-003Canada ICES-003 Canada ICES-003 Class Class Class Class B BB B Conducted Emission Test Conducted Emission TestConducted Emission Test Conducted Emission Test Radiated Emission Test Radiated Emission TestRadiated Emission Test Radiated Emission Test 1, 1, 1, 1, Oaza Oaza Oaza Oaza Sunayama, Sunayama, Sunayama, Sunayama, Hasaki-machi, Hasaki-machi, Hasaki-machi, Hasaki-machi, Kashima-gun Kashima-gunKashima-gun Kashima-gun Ibaraki IbarakiIbaraki Ibaraki-ken, -ken, -ken, -ken, 314-0255 314-0255314-0255 314-0255 Japan Japan Japan Japan Te TeTe Tel. l.l. l.: +81 : +81 : +81 : +81 479 40 479 40 479 40 479 40 1097 10971097 1097 Fax.: +81 Fax.: +81 Fax.: +81 Fax.: +81 479 46 1788 479 46 1788479 46 1788 479 46 1788 Akzo Akzo Akzo Akzo Kashima Limited Kashima LimitedKashima Limited Kashima Limited EMC Division EMC DivisionEMC Division EMC Division Kashima Site Kashima SiteKashima Site Kashima Site NVLAP accreditation is valid only FCC Part15(Digital Devices), CISPR22, and AS/NZS 3548 test reports. Akzo Kashima Report No. AKL-199374FCC ID : BBP7080APage 2 of 25 pages (Version 4.1) TABLE OF CONTENTS TABLE OF CONTENTSTABLE OF CONTENTS TABLE OF CONTENTS Page ABBREVIATIONS...............................................................................................................................3 SECTION 1.TEST CERTIFICATION.......................................................................................... 4 SECTION 2.CONCLUSION ......................................................................................................... 5 SECTION 3.EQUIPMENT UNDER TEST .................................................................................. 6 SECTION 4.SUPPORT EQUIPMENT USED ............................................................................. 7 SECTION 5.CABLE (S) USED ..................................................................................................... 8 SECTION 6.CONSTRUCTION OF EQUIPMENT...................................................................... 9 SECTION 7.OPERATING CONDITIONS ................................................................................. 10 SECTION 8.TEST PROCEDURE(S).......................................................................................... 11 SECTION 9.EVALUATION OF TEST RESULTS..................................................................... 16 SECTION 10.PHOTOGRAPHS OF MAXIMUM EMISSION SET-UP....................................... 21 SECTION 11.INSTRUMENTS USED FOR FINAL TEST ......................................................... 22 SECTION 12.UNCERTAINTY OF MEASUREMENT................................................................ 23 SECTION 13.VALIDITY OF TEST REPORT.............................................................................. 24 SECTION 14.DESCRIPTION OF TEST LABORATORY ........................................................... 25 Akzo Kashima Report No. AKL-199374FCC ID : BBP7080APage 3 of 25 pages (Version 4.1) ABBREVIATIONS ABBREVIATIONSABBREVIATIONS ABBREVIATIONS LISN= Line Impedance Stabilization Network AMN= Artificial Mains Network ANT= Antenna BBA= Broad-band Antenna DIP= Dipole Antenna AMP= Amplifier ATT= Attenuator EUT= Equipment Under Test Q-P= Quasi-peak AVG= Average Akzo Kashima Report No. AKL-199374FCC ID : BBP7080APage 4 of 25 pages (Version 4.1) SECTION SECTION SECTION SECTION 1 11 1. .. . TEST CERTIFICATION TEST CERTIFICATIONTEST CERTIFICATION TEST CERTIFICATION APPLICANT INFORMATION APPLICANT INFORMATIONAPPLICANT INFORMATION APPLICANT INFORMATION Company: RICOH COMPANY, LTD. Address: 3-2-3, Shin-yokohama, Kohoku-ku, Yokohama-shi, Kanagawa-ken, 222-8530 Japan Telephone number: +81 45 477 1663 Fax number: +81 45 477 1649 DESCRIPTION OF TEST ITEM DESCRIPTION OF TEST ITEMDESCRIPTION OF TEST ITEM DESCRIPTION OF TEST ITEM Kind of equipment: Compact Disc Rewritable Drive Condition of equipment : Pre-Production Type: Table-Top (Built-in type) Trademark: RICOH FCC ID:BBP7080A Model number: MP7080A Serial number: DVT-21 TEST PERFORMED TEST PERFORMEDTEST PERFORMED TEST PERFORMED Location: Kashima No. 1 Test Site (FCC File No. : 31040/SIT) EUT received: October 12, 1999 Test started: October 13, 1999 Test completed: October 13, 1999 Purpose of test: FCC Docket 87-389 and Canadian Interference-Causing Equipment Regulations Regulation: FCC Part15B Class B and Canada ICES-003 Class B Unintentional Radiators Test setup: ANSI C63.4-1992 Report file number: AKL-199374 Report issue date: October 14, 1999 Test engineer: Kenichi Takagi Report approved by: Junichi Okada [Site Manager] This equipment complies with above standard or regulation under the test condition or test configuration shown on this test report. Akzo Kashima Report No. AKL-199374FCC ID : BBP7080APage 5 of 25 pages (Version 4.1) SECTION 2. SECTION 2.SECTION 2. SECTION 2. CONCLUSION CONCLUSIONCONCLUSION CONCLUSION This test report clearly shows that the EUT is in compliance with the FCC Part 15B Class B specification and the Canada ICES-003 Class B specification. Traceability to national standards of test result is achieved by means of calibration traceability to national standards. The minimum margins to the limits are as follows: Conduction measurement Write mode12.1 dBat5.1980 MHz Radiation measurement Write mode4.0 dBat801.86MHz Note : See Section 9 for details. Akzo Kashima Report No. AKL-199374FCC ID : BBP7080APage 6 of 25 pages (Version 4.1) SECTION SECTION SE…

Text truncated - open the document above for the full version.
