  1. Home/
  2. LG Electronics USA, Inc./
  3. BEJ47VL10

BEJ47VL10LCD MONITOR

LG Electronics USA, Inc.
LCD MONITOR - FCC ID BEJ47VL10 - LG Electronics USA, Inc.
Click to zoom

Application Details

Equipment Class
JBP - Part 15 Class B Computing Device Peripheral
Date of Grant
Mar 20, 2011
Application Purpose
Original Equipment
Date of Application
Mar 20, 2011
Equipment Note
LCD MONITOR
Company
LG Electronics USA, Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

G Order Number : GETEC-C1-11-053 FCC Part 15 subpart B Test Report Number : GETEC-E3-11-014 Page 1 / 1 EUT Type: LCD Monitor FCC ID.: BEJ47VL10 APPENDIX G : USER’S MANUAL www.lg.com OWNER’S MANUAL MONITOR SIGNAGE 47VL10 Please read this manual carefully before operating the your set and retain it for future reference. MONITOR SIGNAGE MODELS ENG ENGLISH 2 ENG ENGLISH TABLE OF CONTENTS CONTENTS 3 ASSEMBLING AND PREPAR- ING 3 Unpacking 4 Separate purchase 5 Parts and buttons 6 Connecting the stand 6 Connecting the Speakers 8 Connecting stand hole cover 8 To install Portrait 9 Installing on a wall 10 REMOTE CONTROL 11 USING THE MONITOR SET 11 Connecting to a PC 11 - HDMI connection 12 - DVI/HDMI connection 12 - RGB connection 13 CUSTOMIZING SETTINGS 13 Accessing main menus 14 - PICTURE settings 17 - AUDIO settings 18 - TIME settings 19 - OPTION settings 21 - INFORMATION settings 22 MAKING CONNECTIONS 23 Connecting to a HD receiver, DVD or VCR player 23 - HDMI connection 23 - DVI - HDMI connection 24 - AV connection 24 Connecting to the LAN 24 - LAN connection 25 TROUBLESHOOTING 25 General 28 SPECIFICATIONS 3 ENG ENGLISH ASSEMBLING AND PREPARING ASSEMBLING AND PREPARING Unpacking Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories.  Do not use any pirated items to ensure the safety and product life span.  Any damages or injuries by using pirated items are not covered by the warranty.  The accessories supplied with your product may vary depending on the model.  Product specifications or contents in this manual may be changed without prior notice due to upgrade of product functions. Remote control and Batteries Power Cord CD (Owner's Manual) / Card D-Sub Signal Cable CAUTION NOTE ScrewsStand hole cover 4 ENG ENGLISH ASSEMBLING AND PREPARING Separate purchase Without prior notice, optional accessories are subject to change to improve the performance of the product, and new accessories may be added. The illustrations in this manual may differ from the actual product and accessories.  Cable holder/Cable tie may not be available in some areas or for some models. Stand kit Speaker kit StandScrews cable management Cable holder/ Cable Tie Screws/Cable Speaker NOTE 5 ENG ENGLISH ASSEMBLING AND PREPARING  You can set the Power indicator to on or off by selecting OPTION in the main menus. Parts and buttons Screen Marks Description INPUTChanges the input source. MENUAccesses the main menus, or saves your input and exits the menus. Adjust the up and down. Adjusts the volume level. AUTO/SET Auto in progress for optimal display change change resolution. / I Turns the power on or off. IR ReceiverThis is where the unit receives signals from the remote control. Power IndicatorThis Indicator lights up blue when the display operates normally(on mode). If the display is in sleep (Energy Saving) mode, this indicator color changes to amber. All of the buttons are touch sensitive and can be operated through simple touch with your finger. Connection panel ( See p.23 to p.24 ) Screen Buttons NOTE Screen Marks 6 ENG ENGLISH ASSEMBLING AND PREPARING  You can set the Power indicator to on or off by selecting OPTION in the main menus. Connecting the stand - Only on some models. 1 Take the parts for the stand out of the box and assemble them as shown in the picture. Connecting the Speakers - Only on some models. 1 Mount the product onto the speaker by using a screw as shown in the following connect the speaker cable. 2 Place a soft cloth on the table and put the product with the screen facing downward. Connect the stand as shown in the following picture. 2 After installing your speakers, use holders and cable ties to organize the speaker cables. (This feature is not available in all model.) 3 Use the screws to secure the stand on the rear side of the product as shown in the diagram. Stand Screws cable management NOTE 7 ENG ENGLISH ASSEMBLING AND PREPARING  Do not use the cable management as a handle for the Monitor.  The illustrations in this manual may differ from actual cable interfaces. Cable Management - Only on some models. 1 Arrange the cables in the center as shown in the following picture. 2 Fit the cable guide to the back to help manage the cables. 3 Hold the Cable management with both hands and pull it downward. Using the Kensington security system The Kensington security system connector is located at the back of the Monitor set. For more information of installation and using, refer to the manual supplied with the Kensington security system or visit http://www.kensington.com. Connect the Kensington security system cable between the Monitor set and a table.  The Kensington security system is optional. You can obtain additional accessories from most electronics stores. NOTE NOTE 8 ENG ENGLISH ASSEMBLING AND PREPARING To install Portrait - Only on some models. When installing Portrait, rotate it clockwise based on its front.  When using the wall mounting bracket or the portrait scene mode, the opening can be covered by the stand hole cover. Connecting stand hole cover 1 Take the parts for the stand out of the box and assemble them as shown in the picture. 2 Place a soft cloth on the table and put the product with the screen facing downward. Connect the stand hole cover as shown in the following picture. 3 Use the screws to secure the stand hole cover on the rear side of the product as shown in the diagram. ScrewsStand hole cover NOTE 9 ENG ENGLISH ASSEMBLING AND PREPARING  Disconnect the power cord first, and then move or install the Monitor set. Otherwise electric shock may occur.  If you install the Monitor set on a ceiling or slanted wall, it may fall and result in severe injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel.  Do not over tighten the screws as this may …
