E23/2250S(Novtek) Block diagram INPUT: 120V 60Hz FUNDAMENTAL OPERATION FREQUENCY IS 0.030-0.083 MHz . L V D SL V D S Analog I(R/G/B) D-Sub 3.3V ule EEPROM (EDID) 1920X1080@60Hz 148.5Mhz Display Processing Engine Response Time Enhancement LVDS Panel Interface NT68668U Vcc5V Modu (EDID) Dual Interface Engine DRAM KEY OSD Clock Generator MCU SDA/SCL EEPROM ( S y stem ) Flash ROM Crystal 14.318MHz Adapter 5V Re g ulator 3.3V (y ) 3.3V 3.3V DC to DC 12 V 5V g 1.8V LED drive LED LED B+ Crystal ： HLX-U-F ; HC-49/U (alternate) Regulation ： 14.31818MHz+/- 30PPM

Power of Attorney Federal Communication Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 We, Company: LG Electronics U.S.A., Inc. Address: 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 Would like to inform you that we nominated Audix Technology (Shanghai) Co., Ltd, Mr. Byron Kwo to act on behalf of our LG Electronics Inc. to apply FCC ID for the LCD Monitors with LG brand. Kind Regards, Place, date Signature 2009-12-21 Jae Cheon Lee ________________ ________________

Statement FCC ID: BEJE2350SV Data: Dec 21, 2009 We LG Electronics U.S.A., Inc. declare under our own responsibility that the product LCD Monitor to which this declaration refers conforms with all electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marked. 2009.12.21 [Data] [Name and Signature of person responsible]

FIGURE 1 LCD MONITOR (M/N: E2350SV) GENERAL APPEARANCE (FRONT VIEW) F IGURE 2 LCD MONITOR (M/N: E2350SV) GENERAL APPEARANCE (BACK VIEW) FIGURE 3 LCD MONITOR (M/N: E2350SV) PORTS F IGURE 4 LCD MONITOR (M/N: E2350SV) D-SUB CABLE #1 FIGURE 5 LCD MONITOR (M/N: E2350SV) D-SUB CABLE #2 F IGURE 6 LCD MONITOR (M/N: E2350SV) POWER CORD FIGURE 7 LCD MONITOR (M/N: E2350SV) ADAPTER (GENERAL APPEARANCE) F IGURE 8 LCD MONITOR (M/N: E2350SV) ADAPTER (POWER PORT) FIGURE 9 LCD MONITOR (M/N: E2350SV) ADAPTER (LABEL) FIGURE 10 LCD MONITOR (M/N: E2350SV) ADAPTER (COVER REMOVED) FIGURE 11 LCD MONITOR (M/N: E2350SV) ADAPTER (MAIN BOARD – COMPONENT SIDE) F IGURE 12 LCD MONITOR (M/N: E2350SV) ADAPTER (MAIN BOARD –SOLDERED SIDE)

LG Electronics U.S.A., Inc. FCC ID: BEJE2350SV 1 Equipment Description The Equipment Under Test (EUT) is the LG Electronics U.S.A., Inc. LCD Monitor. General Specification LG Electronics U.S.A., Inc. FCC ID: BEJE2350SV 2 EUT Operating Conditions a. Setup the EUT and Peripherals as shown in Sec. 3.2 of the test report. b. Turn on the power of all equipment and the EUT. c. Set the contrast & brightness of EUT to maximum. d. PC system ran the self-test program “EMC Test” by windows XP and sent “H” characters to EUT through graphic card, the EUT’s screen displayed and filled with “H” pattern by its resolution (Via D-Sub Input). e. Repeat above procedure from c to d for difference test mode. f. The other peripherals devices were driven and operated during the test. g. The test modes are as follows: Test Mode D-Sub 640*480@60Hz D-Sub 1024*768@60Hz D-Sub 1680*1050@60Hz D-Sub 1920*1080@60Hz

PDF created with pdfFactory Pro trial version www.pdffactory.com PDF created with pdfFactory Pro trial version www.pdffactory.com PDF created with pdfFactory Pro trial version www.pdffactory.com

LG Electronics U.S.A., Inc. FCC ID: BEJE2350SV Page 1 of 25 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F09135 Prepared For : LG Electronics U.S.A., Inc. 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632, United States Prepared By : Audix Technology (Shanghai) Co., Ltd. 3F 34Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai 200233, China Tel: +86-21-64955500 Fax: +86-21-64955491 Report No. : ACI-F09135 Date of Test : Dec 25, 2009 Date of Report : Dec 26, 2009 Application for FCC Certificate On Behalf of LG Electronics U.S.A., Inc. LCD Monitor Model No.: E2350SV Serial No.: E2009121402 FCC ID : BEJE2350SV LG Electronics U.S.A., Inc. FCC ID: BEJE2350SV Page 2 of 25 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F09135 TABLE OF CONTENTS Page 1 SUMMARY OF STANDARDS AND RESULTS .......................................................................... 4 1.1 Description of Standards and Results ......................................................................................... 4 2 GENERAL INFORMATION .......................................................................................................... 5 2.1 Description of Equipment Under Test ........................................................................................ 5 2.2 Peripherals .................................................................................................................................. 6 2.3 Description of Test Facility ........................................................................................................ 7 2.4 Measurement Uncertainty .......................................................................................................... 7 3 CONDUCTED EMISSION TEST .................................................................................................. 8 3.2 Block Diagram of Test Setup ..................................................................................................... 8 3.3 Conducted Emission Limit [FCC Part 15 Subpart B 15.107(a)] ................................................ 9 3.4 Test Configuration ...................................................................................................................... 9 3.5 Operating Condition of EUT .................................................................................................... 10 3.6 Test Procedures ........................................................................................................................ 10 3.7 Test Results .............................................................................................................................. 11 4 RADIATED EMISSION TEST ..................................................................................................... 16 4.1 Test Equipment ......................................................................................................................... 16 4.2 Block Diagram of Test Setup ................................................................................................... 16 4.3 Radiated Emission Limit [FCC Part 15 Subpart B 15.109(a)] ................................................. 17 4.4 Test Configuration .................................................................................................................... 17 4.5 Operating Condition of EUT .................................................................................................... 18 4.6 Test Procedures ........................................................................................................................ 18 4.7 Test Results .............................................................................................................................. 19 5 DEVIATION TO TEST SPECIFICATIONS .............................................................................. 24 6 DEBUG DESCRIPTION ............................................................................................................... 25 LG Electronics U.S.A., Inc. FCC ID: BEJE2350SV Page 3 of 25 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F09135 TEST REPORT FOR FCC CERTIFICATE Applicant : LG Electronics U.S.A., Inc. Manufacturer : LG Electronics Nanjing Display Co., Ltd. EUT Description : LCD Monitor (A) Model No. : E2350SV (B) Serial No. : E2009121402 (C) Power Supply : 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 15 SUBPART B CLASS B OCTOBER 2008 AND ANSI C63.4-2003 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart B (Class B) and ICES-003, Issue 4 February 2004 (CISPR 22:2002) limits both radiated and conducted emissions. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. This report shows that the EUT (M/N: Refer to Sec. 2.1; S/N: Refer to Sec. 2.1) which was tested in 3m anechoic chamber Dec 25, 2009 is technically compliance with the FCC official limits also. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report contains data that are not covered by the NVLAP accreditation. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Date of Test : Dec 25, 2009 Date of Report : Dec 26, 2009 Producer : ZENO GU / Assistant Review : DIO YANG / Deputy Assistant Manager Signatory : SAMMY CHEN / Assistant Manager LG Electronics U.S.A., Inc. FCC ID: BEJE2350SV Page 4 of 25 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F09135 1 SUMMARY OF STANDARDS AND RESULTS 1.1 Description of Standards and Results The EUT have been tested according to the applicable standards as referenced …

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test F RONT VIEW B ACK VIEW 2. Radiated Electromagnetic Emission Test FRONT VIEW OF RADIATED EMISSION TEST BACK VIEW OF RADIATED EMISSION TEST SETUP WITH MAXIMUM DETECTED EMISSION AT HORIZONTAL POLARIZATION (TEST MODE: D-SUB 640*480@60HZ) SETUP WITH MAXIMUM DETECTED EMISSION AT VERTICAL POLARIZATION (TEST MODE: D-SUB 640*480@60HZ)
