May 9, 2001 Federal Communications Commission 7435 Oakland Mills Road – Gate A Columbia, Maryland 21046 Subject: 6dB for Both Resolution and Video Bandwidth for the Conducted Output Power Measurement To Whom It May Concern: We used the 1 MHz for both resolution and video bandwidth for the conducted output power measurements when we tested LG’s product GT-8310C. I understood that the ET Docket No.96-0 is using the number from 6 dB bandwidth of the spread spectrum. I also went to the FCC database and found out a lot of applications using 1 MHz resolution, such as, FCC ID: DNY160995, FCC ID: J5XTPASSTX, and FCC ID: OWS-900. Some granted FCC ID even didn't have the conducted output power measurement, for example, FCC ID: HOLCL980CR, BW3DB-8214, and BW3DB-8225. I gave out these examples only for reference. Due to the fact, we have difficulty to re-measure the product. Could this case be treated as an exception? We will use 6dB bandwidth for the resolution for all further tests. If you have any other questions about this issue, please call me at (408) 732-9162*11 or email me at [email protected]. Yours truly, John Y. Chan Engineering Manager Bay Area Compliance Laboratory 230 Commercial St. Ste. Sunnyvale, CA 94085 Tel: (408)732-9162 Fax: (408)732-9164 http://www.baclcorp.com

Note: This report may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC PART 15 Subpart C EUT External Photos FOR LG ELECTRONICS INC. LG Kangseo B/D 36, Munlae-Dong, 6-Ga, Youngdungpo-Gu, Seoul, 150-096, Korea FCC ID: BEJGT8310C October 27, 2000 This Report Concerns: Original Report Equipment Type: Digital Spread Spectrum Cordless Phone – Household Appliances Test Engineer: Hien Pham Test Date: October 12, 2000 Reviewed By: John Y. Chan – Engineering Manager Prepared By: Bay Area Compliance Laboratory Corporation 230 Commercial Street, Suite 2 Sunnyvale, CA 94086 Tel: (408) 732-9162 Fax: (408) 732-9164 LG Electronics Inc. FCC ID: BEJGT8310C Report # EUT External photo Page 2 of 10 FCC Part 15 Subpart C Test Report TABLE OF CONTENTS 1 - GENERAL INFORMATION.................................................................................................................................................3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)........................................................................................3 1.2 OBJECTIVE................................................................................................................................................................................3 1.3 RELATED SUBMITTAL(S)/GRANT(S).....................................................................................................................................3 1.4 TEST METHODOLOGY..............................................................................................................................................................3 1.5 TEST FACILITY.........................................................................................................................................................................4 1.6 TEST EQUIPMENT LIST............................................................................................................................................................4 1.7 EQUIPMENT UNDER TEST (EUT)...........................................................................................................................................5 1.8 EUT CONFIGURATION DETAILS AND LIST...........................................................................................................................5 1.9 EXTERNAL I/O CABLING........................................................................................................................................................5 2 – EUT PHOTOGRAPHS...........................................................................................................................................................6 2.1 EUT – BASE TOP VIEW..........................................................................................................................................................6 2.2 EUT – HANDSET FRONT VIEW..............................................................................................................................................7 2.3 EUT OVERALL VIEW WITH POWER ADAPTER....................................................................................................................8 APPENDIX A – AGENT AUTHORIZATION LETTER....................................................................................................9 LG Electronics Inc. FCC ID: BEJGT8310C Report # EUT External photo Page 3 of 10 FCC Part 15 Subpart C Test Report 1 - GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) The LG Electronic Inc., FCC ID BEJGT8310C or the "EUT" as referred to in this report is a Digital Spread Spectrum Cordless Phone which has 20 channel possible in the 904-926 MHz Bandwidth, and the transmission range up to 1 Km in open sight (longer range than analog 900MHz cordless phone). The EUT was composed of two parts: one is the handset which measures 9” L x 2.125” W x 1.675” H, the other is the base which measures 7” L x 5.5” W x 2.25” H. 1.2 Objective This type approval report is prepared on behalf of LG Electronics Inc., in accordance with Part 2, Subpart J, Part 15, Subparts A and B of the Federal Communication Commissions rules. The objective of the manufacturer is to demonstrate compliance with FCC rules for Output Power, 6 dB Bandwidth, Power Density, Band Edge, Spurious Emission, Processing Gain, Antenna Gain, and Conducted and Radiated Emission. 1.3 Related Submittal(s)/Grant(s) No Related Submittals 1.4 Test Methodology All measurements contained in this report were conducted with ANSI C63.4 –1992, American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. All radiated and conducted emissions measurement was performed at Bay Area Compliance Laboratory, Corp. The radiated testing was performed at an antenna-to-EUT distance of 3 meters. LG Electronics Inc. FCC ID: BEJGT8310C Report # EUT External photo Page 4 of 10 FCC Part 15 Subpart C Test Report 1.5 Test Facility The Open Area Test Site used by Bay Area Compliance Laboratory Corporation to collect radiated and conducted emission measurement data is located in the back parking lot of the building at 230 Commercial Street, Suite 2, Sunnyvale, California, USA. Test site at Bay Area Compliance Laboratory Corporation has been fully described in reports submitted to the Federal Communication Commission (FCC) and Voluntary Control Council for Interference (VCCI). The details of these reports has been found to be in compliance with the requirements of Section 2.948 of the FCC Rules on February 11 and December 10, 1997 and Article 8 of the VCCI regulations on December 25, 1997. The facility also complies with the radiated and AC line conducted test site criteria set forth in ANSI C63.4-1992. The Federal Communications Commission and Vo…

Text truncated - open the document above for the full version.

FCC ID: BEJGT8310C Proposed Label Location on EUT 230 Commercial St. Ste. Sunnyvale, CA 94086 Tel: (408)732-9162 Fax: (408)732-9164 http://www.baclcorp.com EUT Base Bottom View FCC ID : BEJGT8310C This Device complies with Part 15 of the FCC Rules. Operation is subject to the folloing two conditions:(1)this device may not cause harm- ful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communciations may not be ensured when using this phone. FCC Label Location EUT Handset Rear View FCC Label Location FCC ID : BEJGT8310C This Device complies with Part 15 of the FCC Rules. Operation is subject to the folloing two conditions:(1)this device may not cause harm- ful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communciations may not be ensured when using this phone.

Note: This report may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC PART 15 Subpart C EUT Internal Photos FOR LG ELECTRONICS INC. LG Kangseo B/D 36, Munlae-Dong, 6-Ga, Youngdungpo-Gu, Seoul, 150-096, Korea FCC ID: BEJGT8310C October 27, 2000 This Report Concerns: Original Report Equipment Type: Digital Spread Spectrum Cordless Phone – Household Appliances Test Engineer: Hien Pham Test Date: October 12, 2000 Reviewed By: John Y. Chan – Engineering Manager Prepared By: Bay Area Compliance Laboratory Corporation 230 Commercial Street, Suite 2 Sunnyvale, CA 94086 Tel: (408) 732-9162 Fax: (408) 732-9164 LG Electronics Inc. FCC ID: BEJGT8310C Report # EUT Internal photo Page 2 of 11 FCC Part 15 Subpart C Test Report TABLE OF CONTENTS 1 - GENERAL INFORMATION.................................................................................................................................................3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)........................................................................................3 1.2 OBJECTIVE................................................................................................................................................................................3 1.3 RELATED SUBMITTAL(S)/GRANT(S).....................................................................................................................................3 1.4 TEST METHODOLOGY..............................................................................................................................................................3 1.5 TEST FACILITY.........................................................................................................................................................................4 1.6 TEST EQUIPMENT LIST............................................................................................................................................................4 1.7 EQUIPMENT UNDER TEST (EUT)...........................................................................................................................................5 1.8 EUT CONFIGURATION DETAILS AND LIST...........................................................................................................................5 1.9 EXTERNAL I/O CABLING........................................................................................................................................................5 2 – EUT PHOTOGRAPHS...........................................................................................................................................................6 2.1 EUT BASE – ENCLOSURE OFF VIEW....................................................................................................................................6 2.2 EUT BASE ENCLOSURE OFF BOARD VIEW.......................................................................................................................7 2.3 EUT HANDSET ENCLOSURE OFF VIEW................................................................................................................................8 2.4 EUT HANDSET ENCLOSURE OFF BOARD VIEW..................................................................................................................9 APPENDIX A – AGENT AUTHORIZATION LETTER..................................................................................................10 LG Electronics Inc. FCC ID: BEJGT8310C Report # EUT Internal photo Page 3 of 11 FCC Part 15 Subpart C Test Report 1 - GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) The LG Electronic Inc., FCC ID BEJGT8310C or the "EUT" as referred to in this report is a Digital Spread Spectrum Cordless Phone which has 20 channel possible in the 904-926 MHz Bandwidth, and the transmission range up to 1 Km in open sight (longer range than analog 900MHz cordless phone). The EUT was composed of two parts: one is the handset which measures 9” L x 2.125” W x 1.675” H, the other is the base which measures 7” L x 5.5” W x 2.25” H. 1.2 Objective This type approval report is prepared on behalf of LG Electronics Inc., in accordance with Part 2, Subpart J, Part 15, Subparts A and B of the Federal Communication Commissions rules. The objective of the manufacturer is to demonstrate compliance with FCC rules for Output Power, 6 dB Bandwidth, Power Density, Band Edge, Spurious Emission, Processing Gain, Antenna Gain, and Conducted and Radiated Emission. 1.3 Related Submittal(s)/Grant(s) No Related Submittals 1.4 Test Methodology All measurements contained in this report were conducted with ANSI C63.4 –1992, American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. All radiated and conducted emissions measurement was performed at Bay Area Compliance Laboratory, Corp. The radiated testing was performed at an antenna-to-EUT distance of 3 meters. LG Electronics Inc. FCC ID: BEJGT8310C Report # EUT Internal photo Page 4 of 11 FCC Part 15 Subpart C Test Report 1.5 Test Facility The Open Area Test Site used by Bay Area Compliance Laboratory Corporation to collect radiated and conducted emission measurement data is located in the back parking lot of the building at 230 Commercial Street, Suite 2, Sunnyvale, California, USA. Test site at Bay Area Compliance Laboratory Corporation has been fully described in reports submitted to the Federal Communication Commission (FCC) and Voluntary Control Council for Interference (VCCI). The details of these reports has been found to be in compliance with the requirements of Section 2.948 of the FCC Rules on February 11 and December 10, 1997 and Article 8 of the VCCI regulations on December 25, 1997. The facility also compli…

Text truncated - open the document above for the full version.

Antenna Mounting From the EUT external and internal photographs, the antenna was soldered to the main board of EUT and then screwed down the main board. So no end user can replace it. It hence complies with the FCC 15.203 requirement. 230 Commercial St. Ste. Sunnyvale, CA 94086 Tel: (408)732-9162 Fax: (408)732-9164 http://www.baclcorp.com

Table 1. Applicable Methods to Ensure Compliance for Spread Spectrum Transmitters. Transmitter or Device Type 16 EIRP 17 Applicable Methods to Ensure Compliance Cordless phone handsets and most other transmitters using monopole or dipole type antennas as an integral part of the device. ≤0.3Wat 915 MHz or ≤0.2Wat 2450 MHz These transmitters generally are not expected to exceed MPE limits (0.61 mW/cm 2 at 915 MHz and 1.0 mW/cm 2 at 2450 MHz); special instructions or warnings are normally not necessary to ensure compliance. Cordless phone handsets and other transmitters that are carried next to the body of the user or operate at distances closer than approximately 5 cm to the body of users or nearby persons. >0.3Wat 915 MHz or >0.2Wat 2450 MHz Generally at above 300 mW EIRP (200 mW at 2450 MHz), the potential for exceeding MPE and/or SAR limits is dependent on the design of the antenna and device operating conditions. Warning instructions and warning labels may be used to limit the exposure durations and/or conditions to ensure compliance. However, if manufacturers believe that such warning instructions and labels will not be effective in keeping persons at the specified distances necessary to ensure compliance, it may be necessary to demonstrate compliance with respect to SAR limits; especially when the output is greater than 400-500 mW EIRP. 16 The applicable methods for ensuring compliance are divided into transmitter groups according to their output power levels. 17 The EIRP indicated in the above table is the product of the maximum output power available at the antenna terminal of the transmitter, the gain of the antenna and the applicable duty factor described in this section. It is important that the normal usage conditions for the particular transmitter/antenna must be defined in order for the above procedures to be applicable. 22 Antenna Gain and EIRP Antenna Gain was zero under this report. EIRP was calculated according to the following equation: P = (E.D) 2 /30G  8 dBìV/M = 10 mW. 230 Commercial St. Ste. Sunnyvale, CA 94086 Tel: (408)732-9162 Fax: (408)732-9164 http://www.baclcorp.com

3.579545Mhz

Note: This report may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC PART 15 Subpart C EMI MEASUREMENT AND TEST REPORT FOR LG ELECTRONICS, INC. LG Kangseo B/D, 36 Munlae-Dong, 6-Ga, Youngdungpo-Gu, Seoul, 150-096, Korea FCC ID: BEJGT-8310C October 27, 2000 This Report Concerns: Original Report Equipment Type: Digital Spread Spectrum Cordless Phone – Household Appliances Test Engineer: Hien Pham Test Date: October 12, 2000 Reviewed By: John Y. Chan – Engineering Manager Prepared By: Bay Area Compliance Laboratory Corporation 230 Commercial Street, Suite 2 Sunnyvale, CA 94086 Tel: (408) 732-9162 Fax: (408) 732-9164 Exhibit 6 0021 LG Electronics, Inc. FCC ID: BEJGT-8310C Report #r0010091 FCC Part 15 Subpart C Test Report Page 2 of 66 TABLE OF CONTENTS 1 - GENERAL INFORMATION................................................................................................................................................. 3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ........................................................................................3 1.2 OBJECTIVE................................................................................................................................................................................3 1.3 RELATED SUBMITTAL(S)/GRANT(S).....................................................................................................................................3 1.4 TEST METHODOLOGY..............................................................................................................................................................3 1.5 TEST FACILITY.........................................................................................................................................................................4 1.6 TEST EQUIPMENT LIST............................................................................................................................................................4 1.7 EQUIPMENT UNDER TEST (EUT)...........................................................................................................................................5 1.8 EUT CONFIGURATION DETAILS AND LIST...........................................................................................................................5 1.9 EXTERNAL I/O CABLING........................................................................................................................................................5 2 - SYSTEM TEST CONFIGURATION.................................................................................................................................. 6 2.1 JUSTIFICATION..........................................................................................................................................................................6 2.2 BLOCK DIAGRAM.....................................................................................................................................................................6 2.3 TEST SETUP BLOCK DIAGRAM...............................................................................................................................................7 2.4 EQUIPMENT MODIFICATIONS.................................................................................................................................................8 3.0 S UMMARY OF TEST RESUL TS....................................................................................................................................... 9 3.1.0 PEAK OUTPUT POWER.........................................................................................................................................................9 3.2.0 6DB BANDWIDTH.............................................................................................................................................................17 3.3.0 POWER DENSITY.................................................................................................................................................................24 3.4.0 BAND EDGES TESTING.......................................................................................................................................................31 3.5.0 SPURIOUS EMISSIONS.........................................................................................................................................................38 3.6.0 FIELD STRENGTH OF SPURIOUS RADIATION (30 MHZ-9000MHZ) ............................................................................51 3.7.0 PROCESSING GAIN.............................................................................................................................................................57 4 - CONDUCTED EMISSIONS TEST DATA...................................................................................................................... 62 4.1 MEASUREMENT UNCERTAINTY...........................................................................................................................................62 4.2 EUT SETUP.............................................................................................................................................................................62 4.3 SPECTRUM ANALYZER SETUP..............................................................................................................................................62 4.4 TEST PROCEDURE..................................................................................................................................................................63 4.5 SUMMARY OF TEST RESULTS...............................................................................................................................................63 4.6 CONDUCTED EMISSIONS TE…

Text truncated - open the document above for the full version.

LG Electronics, Inc. FCC ID: BEJGT-8310C Report #r0010091 FCC Part 15 Subpart C Test Report Page 38 of 66 3.5.0 Spurious Emissions Requirements : FCC 15.247 (2) (c). The harmonics and other signals must be at least 20 dB less than the highest emissions level within the operation band. 3.5.1 Test Procedure The RF output of the transceiver was connected to a spectrum analyzer through appropriate attenuation. The resolution bandwidth of the spectrum analyzer was set at 100 kHz. Sufficient scans were taken to show any out of band emissions up to 10 th harmonic. 3.5.2 Test Equipment Hewlett Packard HP8566B Spectrum Analyzer Hewlett Packard HP 7470A Plotter 3.5.3 Test Results Refer to the attached plots. BASE Spurious Emission High Channel Page 45, 46 Middle Channel Page 47, 48 Low Channel Page 49, 50 HANDSET Spurious Emission High Channel Page 39, 40 Middle Channel Page 41, 42 Low Channel Page 43, 44 Exhibit 6 0021 LG Electronics, Inc. FCC ID: BEJGT-8310C Report #r0010091 FCC Part 15 Subpart C Test Report Page 39 of 66 Exhibit 6 0021 LG Electronics, Inc. FCC ID: BEJGT-8310C Report #r0010091 FCC Part 15 Subpart C Test Report Page 40 of 66 Exhibit 6 0021 LG Electronics, Inc. FCC ID: BEJGT-8310C Report #r0010091 FCC Part 15 Subpart C Test Report Page 41 …
