BEJGU290Cellular/PCS GSM/WCDMA/EDGE Phone with Bluetooth

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: May 10, 2010
Application Purpose: Original Equipment
Date of Application: May 10, 2010
Equipment Note: Cellular/PCS GSM/WCDMA/EDGE Phone with Bluetooth
Frequency Range: 1852.40000000 - 1907.60000000
Company: LG Electronics USA, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

+9: 9WIV+YMHI Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “ Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Part 15 Class B Compliance This device and its accessories comply with part15 of FCC rules and ICES-003 Class B digital apparatus requirements for Industry Canada. Operation is subject to the following two conditions: (1) This device & its accessories may not cause harmful interference. (2) This device & its accessories must accept any interference received, including interference that may cause undesired operation. Body-worn Operation This device has been tested for typical body-worn operations with the distance of 0.79inches (2.0cm) from the user’s body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79inches(2.0cm) must be maintained from the user's body. Additionally, Belt clips, holsters & other body-worn accessories may not contain metallic components. +IXXMRKXSORS[]SYVTLSRI 'EPPOI] (MEPWETLSRIRYQFIV ERHERW[IVWMRGSQMRK GEPPW )RH4S[IVOI] )RHWSVVINIGXWEGEPP8YVRW XLITLSRISRSJJ 6IXYVRWXSXLI,SQIWGVIIR [LIR]SYYWIXLIQIRY 1EMRWGVIIR 2EZMKEXMSROI]W •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w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wVWX 1IQSV]GEVH =SYV,SQIWGVIIR 8LIWXEXYWFEV 8LIWXEXYWFEVYWIWZEVMSYWMGSRWXS MRHMGEXIXLMRKWPMOIWMKREPWXVIRKXL RI[QIWWEKIWERHFEXXIV]PMJIEW [IPPEWXIPPMRK]SY[LIXLIV]SYV &PYIXSSXLGSRRIGXMSRMWEGXMZI 8LIXEFPIFIPS[I\TPEMRWXLI QIERMRKSJMGSRW]SYtVIPMOIP]XSWII MRXLIWXEXYWFEV -GSR (IWGVMTXMSR 2IX[SVOWMKREP WXVIRKXL RYQFIVSJ FEVW[MPPZEV] 2SRIX[SVOWMKREP +467EZEMPEFPI +EZEMPEFPI )(+)EZEMPEFPI *PMKLXQSHIMWEGXMZEXIH 'EPPWEVIHMZIVXIH 6SEQMRKWIVZMGI &PYIXSSXL MWEGXMZEXIH ;%4WIVZMGIMW GSRRIGXIH -GSR (IWGVMTXMSR 1YPXMXEWOMRKEZEMPEFPI 1IQSV]GEVHMRWXEPPIH 4YWLQIWWEKI %REPEVQMWWIX 7GLIHYPI 2I[QIWWEKI 2I[ZSMGIQIWWEKI 2SVQEPTVSwPIMRYWI 7MPIRXTVSwPIMRYWI 3YXHSSVTVSwPIMRYWI ,IEHWIXTVSwPIMRYWI 6IQEMRMRKFEXXIV]PMJI &EXXIV]IQTX] 8-4=SYGERUYMGOP]E…

Text truncated - open the document above for the full version.

Cover Letter(s)

From: 한봉효 Sent: Tuesday, May 11, 2010 5:17 AM To: PCTEST TCB/CB; HCT - Ji-Young Lim Subject: Re : Questions Regarding FCC ID: BEJGU290 Importance: High Hello PCTEST TCB, Thank you for your e-mail. Please see below and find the attachments. I added the IC standard's name on the User manual. For details, please find the attachment. Thank you! Best regards Han. ----- Original Message ----- From: PCTEST TCB/CB To: HCT - Ji-Young Lim Sent: Saturday, May 08, 2010 12:04 PM Subject: Questions Regarding FCC ID: BEJGU290 To: Ms. Ji-Young Lim / HCT From: Mr. Mark Czumak / PCTEST TCB RE: FCC ID: BEJGU290 Applicant: LG Electronics USA Correspondence Reference Number: BEJ100538 Confirmation Number: 1Y1005060538-40 Date of Original Email: May 7, 2010 Subject: Request for additional information In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1.On page 12 of the Operational Description Document there is mention of a 26 MHz VCXO clock in the GSM/EDGE transceiver turned on when required. Please verify that it is not operational for the EUT and if it is then please include in the Block Diagram and schematic diagrams. → It's not operational for the EUT. 2.Per the conducted power data provided in the SAR report, cellular EDGE slot 3 data is required. Please provide this data. → We already test it because there is a possibility you request. Please find the attachment. 3. The right touch slide-up and slide down SAR data for UMTS II mid channel is greater than 0.8 W/kg and does not qualify for test reduction. Please provide test data for the low and high channels per OET Bulletin 65 Supplement C. → It's a typo. Please find the attachment. 4. The data table on page 28 of the SAR test report does not specify the number of GPRS transmit slots. Please revise to include this information. → Please find the attachment. The item indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Mark Czumak Certification Engineer PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you.

Cover Letter(s)

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: May 4, 2010 Federal Communications Commission Author ization and Evaluation Division 7435 Oakland Mills Road, Columb ia, MD 21046 RE: Req uest of Confidentiality for FCC ID: BEJGU290 Equipment Class: PC E: PCS Licensed Transmitter held to ear To Whom It May Conce rn: P ursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure PERMANENT 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

External Photos

ID Label/Location Info

Model No: GU290V FCC ID : BEJGU290 S/N : Made in Korea LG Electronics Inc. LGE

Internal Photos

Report No.: HCTR1005FR02 FCC ID: BEJGU290/ IC: 2703C-GU290 DATE: May 06, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １ of 12 INTERNAL PHOTOGRAPHS Report No.: HCTR1005FR02 FCC ID: BEJGU290/ IC: 2703C-GU290 DATE: May 06, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ２ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR02 FCC ID: BEJGU290/ IC: 2703C-GU290 DATE: May 06, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ３ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR02 FCC ID: BEJGU290/ IC: 2703C-GU290 DATE: May 06, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ４ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR02 FCC ID: BEJGU290/ IC: 2703C-GU290 DATE: May 06, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ５ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR02 FCC ID: BEJGU290/ IC: 2703C-GU290 DATE: May 06, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ６ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR02 FCC ID: BEJGU290/ IC: 2703C-GU290 DATE: May 06, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ７ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR02 FCC ID: BEJGU290/ IC: 2703C-GU290 DATE: May 06, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ８ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR02 FCC ID: BEJGU290/ IC: 2703C-GU290 DATE: May 06, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ９ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR02 FCC ID: BEJGU290/ IC: 2703C-GU290 DATE: May 06, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １０ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR02 FCC ID: BEJGU290/ IC: 2703C-GU290 DATE: May 06, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １１ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR02 FCC ID: BEJGU290/ IC: 2703C-GU290 DATE: May 06, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １２ of 12 ■ INTERNAL PHOTO

RF Exposure Info

MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 1 of 124 MCCL SAR TEST REPORT Specific Absorption Rate Issued under the authority of E. S. Park / Technical Manager MCCL Reviewed by J. S. Jang / Vice Technical Manager MCCL This report may not be reproduced other than in full, except with the prior written approval by MCCL Test Report No : MCCL-3-10-070 Product : Cellular / PCS GSM / EDGE / WCDMA Phone with Bluetooth Model Name(s) :GU290V, GU295g Manufacturer :LG Electronics, Inc. Applicant : Application Type : LG Electronics, Inc. Certification Device Category :Licensed Portable Transmitter Held to Ear (PCE) Standards : §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Date of Sample Receipt :March 17, 2010 Date of Issue : Test Device Serial No. : April 22, 2010 Pre-Production Sample [S/N: #1] Test Result :PASS SUMMARY This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI / IEEE C95.1(2005) and had been tested in accordance with the measurement procedures specified in FCC/OET bulletin 65 Supplement C (2001) , ANSI / IEEE 1528 – Dec. 2003 and in applicable Industry Canada Radio Standards specifications (RSS) ※ The test results in this test report apply only to sample(s) tested. Prepared by H. S. Shim / Test Engineer MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 2 of 124 MCCL TABLE OF CONTENTS 1. TEST RESULT SUMMARY ········································································································3 2. DESCRIPTION OF THE DEVICE UNDER TEST·························································· 4 2.1 Antenna Description·································································································· 4 2.2 Device Description···································································································· 4 3. INTRODUCTION············································································································· 5 4. SAR MEASUREMENT SYSTEM ·················································································· 6 4.1 SAR Measurement Setup·························································································6 4.2 DASY4 E-Field Probe System·················································································· 7 4.3 Phantom···················································································································· 9 4.4 Brain & Muscle Simulating Mixture Characterization ···········································10 4.5 Device Holder for Transmitters··············································································· 11 4.6 Validation Dipole ···································································································· 11 5. SAR MEASUREMENT PROCEDURE········································································· 12 6. DEFINITION OF REFERENCE POINT········································································ 13 6.1 EAR Reference Point······························································································ 13 6.2 Handset Reference Points······················································································ 14 7. TEST CONFIGURATION POSITIONS········································································ 15 7.1 Positioning for Cheek/Touch··················································································· 15 7.2 Positioning for Ear / 15 ° Tilt···················································································· 16 7.3 Body Holster /Belt Clip Configuration······························································· 17 8. MEASUREMENT UNCERTAINTY··············································································· 18 9. ANSI/IEEE C95.1–2005 RF EXPOSURE LIMITS ····················································· 19 10. SYSTEM VERIFICATION··························································································· 20 11. SAR Evaluation Considerations for Handsets with Multiple Transmitters and Antennas ························································································································································ 22 12. RF CONDUCTED POWER ····················································································· 23 12.1 Procedures Used To Establish Test Signal··································································· 23 12.2 SAR Measurement Conditions for UMTS························································ 23 13. MEASUREMENT RESULTS ····················································································· 26 14. TEST EQUIPMENT····································································································· 30 15. REFERENCES············································································································ 31 APPENDIX A: Validation Test Data······································································ 32 APPENDIX B: SAR Test Data··············································································· 38 APPENDIX C: Calibration Certificates·································································103 MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 3 of 124 MCCL 1.TEST RESULT SUMMARY Maximum Results Found During SAR Evaluation 1. Head Configuration 2. Body Worn Configuration 3. Measurement Uncertainty ANSI / IEEE C95.1(2005) - SAFETY LIMIT Spatial Peak Uncontrolled Exposure/General Population 1.6 W/kg averaged over 1 gram ANSI / IEEE C95.1(2005) - SAFETY LIMIT Spatial Peak Uncontr…

Text truncated - open the document above for the full version.

RF Exposure Info

MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 103 of 124 MCCL APPENDIX C: Calibration Certificates MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 104 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 105 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 106 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 107 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 108 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 109 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 110 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 111 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 112 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 113 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 114 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 115 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 116 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 117 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 118 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 119 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 120 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 121 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 122 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 123 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 124 of 124 MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No : MCCL-3-10-070 Page 125 of 124 MCCL

Test Report

FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1005FR02 Date of Issue: May 06, 2010 EUT Type: Cellular/ PCS GSM/ EDGE /WCDMA Phone with BT FCC ID: BEJGU290 IC: 2703C-GU290 Page 2 of 62 Version TEST REPORT NO. DATE DESCRIPTION HCTR1005FR03 May 06, 2010 First Approval Report FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1005FR02 Date of Issue: May 06, 2010 EUT Type: Cellular/ PCS GSM/ EDGE /WCDMA Phone with BT FCC ID: BEJGU290 IC: 2703C-GU290 Page 3 of 62 Table of Contents 1. GENERAL INFORMATION ........................................................................................................................... 4 2. INTRODUCTION ........................................................................................................................................... 5 2.1. EUT DESCRIPTION............................................................................................................................ 5 2.2. MEASURING INSTRUMENT CALIBRATION .................................................................................... 5 2.3. TEST FACILITY .................................................................................................................................. 5 3. DESCRIPTION OF TESTS ........................................................................................................................... 6 3.1 Effective Radiated Power/Equivalent Isotropic Radiated Power................................................... 6 3.2 Peak- to- Average Ratio ..................................................................................................................... 7 3.3 Occupied bandwidth. ......................................................................................................................... 8 3.4 Spurious and Harmonic Emissions at Antenna Terminal. ............................................................. 9 3.5 Radiated Spurious and Harmonic Emissions ............................................................................... 10 3.6 Frequency stability / variation of ambient temperature ................................................................11 4. LIST OF TEST EQUIPMENT ...................................................................................................................... 12 5. SUMMARY OF TEST RESULTS ................................................................................................................ 13 6. SAMPLE CALCULATION ........................................................................................................................... 14 7. TEST DATA ................................................................................................................................................. 15 7.1 Conducted Output Power ................................................................................................................ 15 7.2 Peak-to-Average Ratio ..................................................................................................................... 16 7.3 Occupied Bandwidth........................................................................................................................ 17 7.4 Conducted Spurious Emissions ..................................................................................................... 18 7.4.1 Band Edge .............................................................................................................................. 18 7.5 Effective Radiated Power Output (GSM / WCDMA)....................................................................... 19 7.6 Equivalent Isotropic Radiated Power (GSM / WCDMA) ................................................................ 20 7.7 Radiated Spurious Emissions......................................................................................................... 21 7.7.1 Radiated Spurious Emissions (GSM850)............................................................................. 21 7.7.2 Radiated Spurious Emissions (GSM1900)........................................................................... 22 7.7.3 Radiated Spurious Emissions (WCDMA850)....................................................................... 23 7.7.4 Radiated Spurious Emissions (WCDMA1900)..................................................................... 24 7.8 Frequency stability / variation of ambient temperature ............................................................... 25 7.8.1 FREQUENCY STABILITY (GSM850).................................................................................. 25 7.8.2 FREQUENCY STABILITY (GSM1900)................................................................................ 26 7.8.3 FREQUENCY STABILITY (WCDMA850)............................................................................ 27 7.8.4 FREQUENCY STABILITY (WCDMA1900).........................................................................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

David Kim(Team leader, LGEUS NA Policy & Regulatory Affairs)

[email protected]201-470-2696Fax: 201-816-2003

Technical Contact

PCTEST Engineering Laboratory, Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Test Firm

HCT Co., LTDSang Lee

[email protected]82-31-645-6420Fax: 82-31-645-6401

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
6	24E	1.85 GHz - 1.91 GHz	682.00 mW	4M16F9W	2.5 ppm

Confidentiality

Long Term

Grant Notes

Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operation is based on a separation distance of 2.0 cm between the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters not listed in this filing may not contain metallic components. The highest reported SAR values are: Part 22 - Head: 0.68 W/kg; Body-worn: 0.55 W/kg; Part 24 - Head: 1.19 W/kg; Body-worn: 0.54 W/kg. This device also contains functions that are not operational in U.S. Territories. This filing is only applicable for US operations.
