BEJLAN5910WRRADIO-CAR

Car AVN User Manual Model Name : LAN5910WR (2) Specifications *Product ItemCategories Specifications Specification ProductNameRADIO-CAR ModelLAN5910WR DimensionsRefer to image Weight DAB(X): 1.5±0.15kg DAB(O): 1.6±0.16kg Power sourceDC12V Operational temperature range -20 °C ~ 85 °C 1. Overview and Specifications (1) Overview 1)The Infotainment system provides infotainment in a car, using the latest technology. See your dealer to have the system or software updated and upgraded. 2)The radio can be easily used by registering up to 25 FM or AM with the PRESET button[1 to 5] per every 5 pages. 3)The Infotainment system can play the USB storage device or iPod/iPhone products. 4)The Bluetooth phone connection function allows for the use of wireless hands-free Phone calls, as well as a phone music player. 5)Connect a portable music player to the auxiliary sound input to enjoy the rich sound of the Infotainment system. < Basic Design Concept > X52 PY1B *RF specifications [ BT ] Item RBFA-B121A (BT Only) Unit Frequency2402 ~ 2480MHz Modulation Type GFSK, π/4 DQPSK, 8 DPSK BT Power Average power : 2dBm (-6 ~ 4dBm) (BT Class2) dBm Data rate1 ~ 3Mbps Channel spacing1MHz BT versionBT4.2 + EDRMHz Max. Conducted RF Output Power: 4.983dBm (3.15mW) 2. Component X52 PY1B 3. Operation (1) Item (#No.)Descriptions (1) POWER button Press and hold(5sec) this button to turn the power on/off. (2) Volume upPress this button to increasevolume. (3) Volume down Press this button to decrease volume. (4) HOME buttornPress this buttonto go home menu. (5) Vehicle setting(for X52)Rotate the Volume knob to adjust the volume. (5) AVM (forPY1B)Press this button to turn on AVM(Around View Monitor) (2) (3) (4) (5) * Touch *Fling/Swipe *Pinch & Spread (8) Touch Gestures * Only supported for Android Auto * Only supported for Android Auto and Apple Carplay 4. Precautions 1) Always operate the vehicle in a safe manner. Do not become distracted by the vehicle while driving and always be fully aware of all driving conditions. Do not change settings or any functions. Pull over in a safe and legal manner before attempting such operations. To promote safety, certain functions are disabled unless the parking brake is on. 2) To reduce the risk of electric shock, do not remove the cover or back of this product. There are no user-serviceable parts inside. Refer servicing to qualified service personnel. 3) To reduce the risk of fire or electric shock, do not expose this product to dripping or splashing water, rain, or moisture. 4) When driving your vehicle, be sure to keep the volume of the unit low enough to allow you to hear sounds coming from the outside. 5) Do not drop it and avoid heavy impacts at anytime. 6) The driver should not watch the monitor while driving. If the driver watches the monitor while driving, it may lead to carelessness and cause an accident. 5. Statements Anychangesormodificationsnotexpresslyapprovedbytheparty responsibleforcompliancecouldvoidtheuser'sauthoritytooperatethis equipment. Thisdevicemustnotbeco -locatedoroperatingin conjunction withanyotherantennaor transmitter. Theantenna(s)mustbeinstalledsuchthata minimumseparationdistanceof at least20cmis maintainedbetweentheradiator(antenna)andall personsat all times.

DA TE : Dec 26, 2019 To : Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD T o whom it may concern: Subject: Declaration of the front design changes FCC ID: BEJLAN5910WR We , LG Electronics USA, declare that the device, FCC ID: BEJLAN5910WR has the front design changes depend on customer request which does not effect on RF parameters. PCB and circuit design are identical. I f you have any question or comment regarding this declaration, Please contact us. Sin cerely, S igned by Kyung-Su Han / Director, NA Regulatory and Environmental Affairs [email protected] 1-201-266-2215 LG Electronics USA, 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632

Date : Nov. 9, 2017 Rev : 2.3 HACS-F004 FCC Agent Authorization Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 1 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC FCC Agent Authorization Letter Date : Nov. 9, 2017 Rev : 2.3 HACS-F004 FCC Agent Authorization Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 2 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC REVISION TABLE Rev Description of Change Date Approved 1.0 Original Release(Obsolete) 06/14/2012 QM 2.0 Updated template(Obsolete) 10/01/2012 QM 2.1 Updated address(Obsolete) 01/10/2014 QM 2.2 Updated address 11/18/2016 QM 2.3 Fixed Typo “Agent” 11/09/2017 QM LG Electronics USA HACS-F004 FCC Agent Authorization Letter Rev : 2.3 DATE : December 24, 2019 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To whom it may concern: Subject : FCC Agent Authorization Letter for FCC ID : BEJLAN5910WR We, the undersigned, hereby authorize HCT CO., LTD. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by HCT CO., LTD. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). We recognize that we are still responsible for the terms and conditions outlined in the HCT America Client Services Agreement. This authorization is valid until further written notice from the applicant. Sincerely, Signed by: (Name / Title) Kyung-Su Han / Director, NA Regulatory and Environmental Affairs (Email Address) [email protected] (Phone number) 1-201-266-2215 (Address) LG Electronics USA, 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632

Date : Nov. 09, 2017 Rev : 3.0 HACS-F003 FCC Confidentiality Request Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 1 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC FCC Confidentiality Request Letter Date : Nov. 09, 2017 Rev : 3.0 HACS-F003 FCC Confidentiality Request Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 2 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC REVISION TABLE Rev Description of Change Date Approved 1.0 Original Release(Obsolete) 06/14/2012 QM 2.0 Updated template(Obsolete) 10/01/2012 QM 2.1 Updated address(Obsolete) 01/10/2014 QM 2.2 Updated address 11/18/2016 QM 3.0 Updated LTC and STC Confidentiality table 11/09/2017 QM LG Electronics USA HACS-F003 FCC Confidentiality Request Letter Rev : 3.0 DATE : 12/24/2019 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD SUBJECT: Request for Confidentiality for FCC ID: BEJLAN5910WR We hereby request confidential treatment of the information accompanying this application as outlined below: LONG-TERM AND SHORT-TERM CONFIDENTIAL LIST LONG-TERM CONFIDENTIAL Exhibit Description 1 Block Diagram 2 Operational Description 3 Parts List 4 Schematics SHORT-TERM CONFIDENTIAL (180 DAYS) 5 External Photos 6 Internal Photos 7 Test-Setup Photos 8 User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signed by: (Name / Title) Kyung-Su Han / Director, NA Regulatory and Environmental Affairs (Email Address) [email protected] (Phone number) 1-201-266-2215 (Address) LG Electronics USA, 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632

FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 9 EXTERNAL PHOTOGRAPHS FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 9 ■ EXTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 9 ■ EXTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 9 ■ EXTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 9 ■ EXTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 9 ■ EXTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 9 ■ EXTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ８ of 9 ■ EXTERNAL PHOTO(PY1B) FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ９ of 9 Note: The front design changes depending on vehicle variants of additional photos (PY1B and HBC) in this document does not effect on RF parameters. All PCB and circuit designs are identical. ■ EXTERNAL PHOTO(HBC)

PART NAME PART CODE SUPPLIER CODE MODEL NO : RADIO - CAR : XXXX XXXXXX --X : XXX XXX : LAN5910WR DC 12 V 3.5 A DATE : YYYY.MM.DD LG Electronics MADE IN VIETNAM Config : XXXXXX HW Ver : XX.X.XX SW Ver : X.X.X ※LAN5910WR BTA REGISTERED No. : nnnnnn X X X AGREE PAR L’ANRT MAROC Numérod’agrément: MR 0000 ANRT 0000 Date d’agrément: DD/MM/YY XXXXXXX XXXX/XX NR:XXXX-XX-X-XXXXXX There is not an exclusive commercial representative in Paraguay and the product can be imported freely by any importer/commerce. Saudi Arabia : FM 87.5-108MHz, M W(AM) 531-1602kHz XXX XX APPROVED TA XXXX-YYYY TRA Registered No. :XXNNNNNN/NN Dealer No. :XXNNNNN/NN CNC I D: XX-XXXXX ETA No. : XX-ETA/XXXX TRC/GPS/XXXX/XXXX IFT : XXXXXXXXXXXXX FCC ID : BEJLAN5910WR This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. ZMB/ZICTA/TA/YYYY/MM/SS This product has been Type Approved by Jamaica SMA- model no. XXX-XXXXXXX Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados. LG Electronics European Shared Service Center B.V. Krijgsman 1, 1186 DM Amstelveen, The Netherlands XXXXX/SDPPI/XXXX XXXX XXXXX-XX-XXXXX BEJLAN5910WR Label&Location

FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 10 INTERNAL PHOTOGRAPHS FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 10 ■ INTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 10 ■ INTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 10 ■ INTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 10 ■ INTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 10 ■ INTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 10 ■ INTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ８ of 10 ■ INTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ９ of 10 ■ INTERNAL PHOTO FCC ID: BEJLAN5910WR HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １０ of 10 ■ INTERNAL PHOTO

HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 634 6300 F ax. +82 31 645 6401 On your side FCC MPE Test for LAN5910WR Certification APPLICANT LG Electronics Inc. REPORT NO. HCT-RF-1911-FC019-R2 DATE OF ISSUE January 03, 2020 Report No. HCT-RF-1911-FC019-R2 F-TP22-03 (Rev. 01) Page 3 of 5 REVISION HISTORY The revision history for this test report is shown in table. Revision No. Date of Issue Description 0 November 21, 2019 Initial Release 1 December 24, 2019 Deleted the Additional Model. 2 January 03, 2020 Revised the Ant gain on page 5 The measurements shown in this report were made in accordance with the procedures specified in §2.947. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. HCT CO., LTD. Certifies that no party to this application has subject to a denial of Federal benefits that includes FCC benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 1998,21 U.S. C.853(a) The front design of LAN5910WR is changed by applied RENAULT vehicle variant without PCB and circuit design Report No. HCT-RF-1911-FC019-R2 F-TP22-03 (Rev. 01) Page 4 of 5 RF Exposure Statement 1. Limit According to §1.1310, §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength (V/m) Magnetic field Strength (A/m) Power density (mW/cm²) Averaging time (minutes) 0.3 - 1.34 1.34 - 30 30 - 300 300 - 1500 1500 - 100.000 614 824/f 27.5 ... ... 1.63 2.19/f 0.073 ... ... *(100) *(180/ f²) 0.2 f/1500 1.0 30 30 30 30 30 F = frequency in MHz * = Plane-wave equivalent power density 2. Maximum Permissible Exposure Prediction Prediction of MPE limit at a given distance ଶ S = Power density P = Power input to antenna G = Power gain to the antenna in the direction of interest relative to an isotropic radiator R = Distance to the center of radiation of the antenna Report No. HCT-RF-1911-FC019-R2 F-TP22-03 (Rev. 01) Page 5 of 5 3. RESULTS 3-1. Bluetooth Average output Power at antenna input terminal 4.00 dBm Average output Power at antenna input terminal 2.512 mW Prediction distance 20.00 cm Prediction frequency 2402 ˊ 2480 MHz Antenna Gain(typical) 2.80 dBi Antenna Gain(numeric) 1.905 - Power density at prediction frequency( S) 0.0010 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 1.000 mW/cm 2 2.1091 EIRP 6.8 (dBm) ERP 4.65 (dBm) ERP 0.003 (W) ERP Limit 3.00 (W) MARGIN 30.12 (dB)

HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 634 6300 F ax. +82 31 645 6401 On your side FCC BT Test for LAN5910WR Certification APPLICANT LG Electronics Inc. REPORT NO. HCT-RF-1911-FC018-R3 DATE OF ISSUE January 03, 2020 Report No. HCT-RF-1911-FC018-R3 F-TP22-03 (Rev. 01) Page 3 of 78 REVISION HISTORY The revision history for this test report is shown in table. Revision No. Date of Issue Description 0 November 21, 2019 Initial Release 1 December 02, 2019 Revised the Power Supply Voltage 2 December 24, 2019 Deleted the Additional Model. Added the note on page 5. 3 January 03, 2020 Revised the Ant gain on page 5 The result shown in this test report refer only to the sample(s) tested unless otherwise stated. Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of the FCC Rules under normal use and maintenance The front design of LAN5910WR is changed by applied RENAULT vehicle variant without PCB and circuit design Report No. HCT-RF-1911-FC018-R3 F-TP22-03 (Rev. 01) Page 4 of 78 CONTENTS 1. EUT DESCRIPTION 5 2. Requirements for Bluetooth transmitter(15.247) 6 3. TEST METHODOLOGY 7 EUT CONFIGURATION 7 EUT EXERCISE 7 GENERAL TEST PROCEDURES 7 DESCRIPTION OF TEST MODES 8 4. INSTRUMENT CALIBRATION 8 5. FACILITIES AND ACCREDITATIONS 8 FACILITIES 8 EQUIPMENT 8 6. ANTENNA REQUIREMENTS 9 7. MEASUREMENT UNCERTAINTY 10 8. DESCRIPTION OF TESTS 11 9. SUMMARY OF TEST RESULTS 28 10. TEST RESULT 29 10.1 PEAK POWER 29 10.2 BAND EDGES 35 10.3 FREQUENCY SEPARATION / OCCUPIED BANDWIDTH (99% BW) 42 10.4 NUMBER OF HOPPING FREQUENCY 50 10.5 TIME OF OCCUPANCY (DWELL TIME) 54 10.6 SPURIOUS EMISSIONS 60 10.6.1 CONDUCTED SPURIOUS EMISSIONS 60 10.6.2 RADIATED SPURIOUS EMISSIONS 68 10.6.3 RADIATED RESTRICTED BAND EDGES 73 11. LIST OF TEST EQUIPMENT 76 12. ANNEX A_ TEST SETUP PHOTO 78 Report No. HCT-RF-1911-FC018-R3 F-TP22-03 (Rev. 01) Page 5 of 78 1. EUT DESCRIPTION Model LAN5910WR EUT Type RADIO - CAR Power Supply DC 12 V Frequency Range 2402 MHz - 2480 MHz Max. RF Output Power 4.983 dBm (3.15 mW) BT Operating Mode Normal, EDR, AFH Modulation Type GFSK(Normal), π/4DQPSK and 8DPSK(EDR) Modulation Technique FHSS Number of Channels 79 Channels, Minimum 20 Channels(AFH) Antenna Specification Antenna type: Multilayer Chip Antenna Peak Gain : 2.8 dBi Date(s) of Tests November 11, 2019 ~ November 21, 2019 Note : The front design of LAN5910WR is changed by applied RENAULT vehicle variant without PCB and circuit design. Report No. HCT-RF-1911-FC018-R3 F-TP22-03 (Rev. 01) Page 6 of 78 2. Requirements for Bluetooth transmitter(15.247) This Bluetooth module has been tested by a Bluetooth Qualification Lab, and we confirm the following: 1) This system is hopping pseudo-randomly. 2) Each frequency is used equally on the average by each transmitter. 3) The receiver input bandwidths that match the hopping channel bandwidths of their corresponding transmitters 4) The receiver shifts frequencies in synchronization with the transmitted signals. ▪ 15.247(g): The system, consisting of both the transmitter and the receiver, must be designed to comply with all of the regulations in this Section 15.247 should the transmitter be presented with a continuous data (or information) stream. ▪ 15.247(h): The coordination of frequency hopping systems in any other manner for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters is not permitted. The coordination of frequency hopping systems in any other manner for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters is not permitted. Report No. HCT-RF-1911-FC018-R3 F-TP22-03 (Rev. 01) Page 7 of 78 3. TEST METHODOLOGY The measurement procedure described in the American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Device (ANSI C63.10-2013, KDB 558074) is used in the measurement of the test device. EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. EUT EXERCISE The EUT was operated in the engineering mode to fix the Tx frequency that was for the purpose of the measurements. According to its specifications, the EUT must comply with the requirements of the Section 15.207, 15.209 and 15.247 under the FCC Rules Part 15 Subpart C. GENERAL TEST PROCEDURES Conducted Emissions The EUT is placed on the turntable, which is 0.8 m above ground plane. According to the requirements in Section 6.2 of ANSI C63.10. (Version :2013) Conducted emissions from the EUT measured in the frequency range between 0.15 MHz and 30MHz using CISPR Quasi-peak and average detector modes. Radiated Emissions The EUT is placed on a turn table, which is 0.8 m above ground plane below 1GHz. Above 1GHz with 1.5m using absorbers between the EUT and receive antenna. The turntable shall rotate 360 degrees to determine the position of maximum emission level. EUT is set 3.75 m away from the receiving antenna, which varied from 1 m to 4 m to find out the highest emission. And also, each emission was to be maximized by changing the polarization of receiving antenna both horizontal and vertical. In order to find out the max. emission, the relative positions of this hand-held transmitter (EUT) was rotated through three orthogonal axes according to the requirements in Section 6.6.5 of ANSI C63.10. (Version: 2…
