BEJLG420GCellular/PCS GSM Phone with Bluetooth

LG420G User Guide - English This guide will help you understand your new mobile phone. It will provide you with useful explanations of features on your phone. Some of the contents in this manual may diff er from your phone depending on the software of the phone or your service provider. Disposal of your old appliance 1 When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC. 2 All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local a uthorities. 3 The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health. 4 For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product. Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “ Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Part 15 Class B Compliance This device and its accessories comply with part15 of FCC rules. Operation is subject to the following two conditions: (1) This device & its accessories may not cause harmful interference. (2) This device & its accessories must accept any interference received, including interference that may cause undesired operation. Body-worn Operation This device has been tested for typical body-worn operations with the distance of 0.79inches (2.0cm) from the user’s body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79inches(2.0cm) must be maintained from the user's body. Additionally, Belt clips, holsters & other body-worn accessories may not contain metallic components. 2 Volum 1) In s Vol 2) In s pre Lon to S tak 3) Du ad j 4) Du vol Char g Hand Mem Getting to know your phone Call key Dials a phone number and answers incoming calls. End/Power key Ends or rejects a call. Turns the phone on/off . Returns to the standby screen when you use the menu. Main screen Goes to Go to menu Goes to Music Opens the music player Goes to Camera mode Goes to O2 Active Navigation keys • In standby mode: up- Go to, Down - Names, left-Profi les, Right -Messaging. • In menu: Navigates between menus. 3 Volume key / Side keys 1) In standby mode ( Opened) : Volume adjustment 2) In standby mode (closed): Short press - The sub LCD backlight on. Long press ( Down key only) -Go to Self Camera mode and you can take a photo. 3) During a call : Earpiece volume adjustment 4) During playing MP3 music: Audio volume Installing a memory card Lift the memory card cover and insert a micro SD card with the golden contact area facing downwards. Close the memory card cover so that it clicks shut. To remove the memory card, gently push it as shown in the diagram. Note: A memory card is an optional accessory. Formatting the memory card Press Menu and Select Settings. Choose Memory manager, select External memory and press Format. WARNING: When you format your memory card, all the content will be wiped. If you do not want to lose the data on your memory card, back it up first. Charger, cable slot, Handsfree connector Memory card slot s the he use 4 Installing the SIM Card and Charging the Battery Installing the SIM Card When you subscribe to a cellular network, you are provided with a plug-in SIM card loaded with your subscription details, such as your PIN, any optional services available and many others. Important! › The plug-in SIM card and its contacts can be easily damaged by scratches or bending, so be careful when handling, inserting or removing the card. Keep all SIM cards out of the reach of small children. Illustrations 1 Open battery cover 2 Remove the battery 3 Insert your SIM 4 Insert the battery 5 Close the battery cover 6 Charge your battery WARNING: Do not remove the battery when the phone is switched on, as this may damage the phone. Men Orga 1. Ala 2. Ca 3. To 4. No 5. Se 6. Ca 7. Sto 8. Da 9. Co 10. W 11. G 12. O 13. S Mess 1. Cre 2. Inb 3. My 4. Dr 5. O u 6. Se 7. Sa 8. E m 9. Me Settin 1. Pro 2. Dis 3. Da 4. Co 5. Ca 6. Ph 7. Ne 8. Int 9. Ac 10. P 11. S 12. M 13. R 5 with . ing, ut of Menu map Organiser 1. Alarm clock 2. Calendar 3. To-do list 4. Notes 5. Secret notes 6. Calculator 7. Stopwatch 8. Date finder 9. Converter 10. World time 11. Go to 12. O2 13. Settings Games & Apps 1. My games & apps 2. Settings Gallery 1. My memory card 2. My images 3. My sounds 4. My videos 5. My games & apps 6. Others Call log 1. Call log 2. Missed calls 3. Received calls 4. Dialled numbers 5. Call duration 6. Packet data counter 7. Call costs Messaging 1. Create message 2. Inbox 3. My mailbox 4. Drafts 5. Outbox 6. Sent items 7. Saved itmes 8. Emoticons 9. Message settings Settings 1. Profiles 2. Display 3. Date & Tim…

Text truncated - open the document above for the full version.

Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG Electronics Inc. FCC ID: BEJLG420G Part 20.19 Certification To Whom It May Concern: The following are the model designations and their associated key features for this FCC ID, according to requirement in the TCB Guidance issued on June 20, 2008. Date: September 29, 2009 Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics Inc. LGE Camera Bluetooth GSM Air Interfaces: Key Features: GSM850 / GSM1900 Bands: 2G Wireless Technologies: LG420G Model(s): BEJLG420G FCC ID: LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

Date: September 29, 2009 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 SUBJECT: LG Electronics Inc. FCC ID: BEJLG420G Part 20.19 Certification Gentlemen: We, LG Electronics USA, hereby declare the samples evaluated in this application are equivalent to production samples. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics Inc. LGE LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date:Septemer 29, 2009 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: BEJLG420G Equipment Class: PCE: PCS Licensed Transmitter held to ear To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure PERMANENT 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee Ge neral Manager LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G External Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 1 of 5 © 2009 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G External Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 2 of 5 © 2009 PCTEST Engineering Laboratory Inc. LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G External Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 3 of 5 © 2009 PCTEST Engineering Laboratory Inc. LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G External Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 4 of 5 © 2009 PCTEST Engineering Laboratory Inc. LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G External Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 5 of 5 © 2009 PCTEST Engineering Laboratory Inc.

Model No: LG420G FCC ID : BEJLG420G S/N : Made in Korea LG Electronics Inc. LGE

LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 1 of 12 © 2009 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 2 of 12 © 2009 PCTEST Engineering Laboratory Inc. LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 3 of 12 © 2009 PCTEST Engineering Laboratory Inc. LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 4 of 12 © 2009 PCTEST Engineering Laboratory Inc. LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 5 of 12 © 2009 PCTEST Engineering Laboratory Inc. LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 6 of 12 © 2009 PCTEST Engineering Laboratory Inc. LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 7 of 12 © 2009 PCTEST Engineering Laboratory Inc. LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 8 of 12 © 2009 PCTEST Engineering Laboratory Inc. LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 9 of 12 © 2009 PCTEST Engineering Laboratory Inc. LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 10 of 12 © 2009 PCTEST Engineering Laboratory Inc. LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 11 of 12 © 2009 PCTEST Engineering Laboratory Inc. LG ELECTRONICS CO. FCC ID: BEJLG420G Model: LG420G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 12 of 12 © 2009 PCTEST Engineering Laboratory Inc.

Reviewed by: FCC ID: BEJLG420G CERTIFICATION REPORT Quality Manager Filename: Test Dates: EUT Type: 0909151709.BEJ 09/29/09 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 1 of 28 © 2009 PCTEST Engineering Laboratory, Inc. REV 6.6 07/13/09 Applicant Name: Date of Testing: LG Electronics USA 09/29/09 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0909151709.BEJ FCC ID: BEJLG420G APPLICANT: LG ELECTRONICS USA EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Application Type: Certification FCC Rule Part(s): CFR §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] FCC Classification: Licensed Transmitter Held to Ear (PCE) Model(s): LG420G Tx Frequency: 824.20 - 848.80 MHz (Cellular GSM) 1850.20 - 1909.80 MHz (GSM PCS) Conducted Power: 33.2 dBm GSM 850 / 30.3 dBm GSM 1900 Max. SAR Measurement: 0.73 W/kg GSM 850 Head SAR / 0.85 W/kg GSM 850 Body SAR 1.13 W/kg GSM 1900 Head SAR / 0.4 W/kg GSM 1900 Body SAR Test Device Serial No.: Pre-Production [S/N: SAR] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001), IEEE 1528-2003 and in applicable Industry Canada Radio Standards Specifications (RSS); for North American frequency bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Reviewed by: FCC ID: BEJLG420G CERTIFICATION REPORT Quality Manager Filename: Test Dates: EUT Type: 0909151709.BEJ 09/29/09 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 2 of 28 © 2009 PCTEST Engineering Laboratory, Inc. REV 6.6 07/13/09 TABLE OF CONTENTS 1 INTRODUCTION ............................................................................................................................. 3 2 TEST SITE LOCATION ................................................................................................................... 4 3 SAR MEASUREMENT SETUP ....................................................................................................... 5 4 DASY E-FIELD PROBE SYSTEM .................................................................................................. 7 5 PROBE CALIBRATION PROCESS ................................................................................................ 8 6 PHANTOM AND EQUIVALENT TISSUES...................................................................................... 9 7 DOSIMETRIC ASSESSMENT & PHANTOM SPECS................................................................... 10 8 DEFINITION OF REFERENCE POINTS ...................................................................................... 11 9 TEST CONFIGURATION POSITIONS ......................................................................................... 12 10 RF EXPOSURE LIMITS ................................................................................................................ 15 11 MEASUREMENT UNCERTAINTIES ............................................................................................ 16 12 SYSTEM VERIFICATION.............................................................................................................. 17 13 FCC MULTI-TX AND ANTENNA SAR CONSIDERATIONS......................................................... 19 14 FCC 3G MEASUREMENT PROCEDURES .................................................................................. 20 15 SAR DATA SUMMARY ................................................................................................................. 21 16 EQUIPMENT LIST......................................................................................................................... 25 17 CONCLUSION............................................................................................................................... 26 18 REFERENCES .............................................................................................................................. 27 Reviewed by: FCC ID: BEJLG420G CERTIFICATION REPORT Quality Manager Filename: Test Dates: EUT Type: 0909151709.BEJ 09/29/09 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 3 of 28 © 2009 PCTEST Engineering Laboratory, Inc. REV 6.6 07/13/09 1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz[2] and Health Canada RF Exposure Guidelines Safety Code 6 [26]. The measurement procedure described in IEEE/ANSI C95.3-2002 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave [3] is used for guidance in measuring t…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: BEJLG420G FCC Pt. 22/24 GSM / GPRS MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0909151710.BEJ September 28 - 29, 2009 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 1 of 34 © 2009 PCTEST Engineering Laboratory, Inc. REV 7.2G 05/13/2009 Applicant Name: Date of Testing: LG Electronics USA September 28 - 29, 2009 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0909151710.BEJ FCC ID: BEJLG420G APPLICANT: LG ELECTRONICS USA Application Type: Certification FCC Classification: PCS Licensed Transmitter Held to Ear (PCE) FCC Rule Part(s): §2; §22(H), §24(E) EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Model(s): LG420G Tx Frequency Range: 824.20 - 848.80MHz (Cell. GSM) / 1850.20 - 1909.80MHz (PCS GSM) Max. RF Output Power: 1.282 W ERP Cell. GSM (31.08 dBm) / 1.507 W EIRP PCS GSM (31.78 dBm) Emission Designator(s): 246KGXW (Cellular GSM), 247KGXW (PCS GSM) Test Device Serial No.: identical prototype [S/N: N/A] This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. This device also contains functions that are not operational in U.S. territories. This report is applicable only to U.S. operations. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 22 & 24 Certification Reviewed by: FCC ID: BEJLG420G FCC Pt. 22/24 GSM / GPRS MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0909151710.BEJ September 28 - 29, 2009 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 2 of 34 © 2009 PCTEST Engineering Laboratory, Inc. REV 7.2G 05/13/2009 TABLE OF CONTENTS FCC PART 22 & 24 MEASUREMENT REPORT............................................................................3 1.0 INTRODUCTION ..............................................................................................................................4 1.1 SCOPE ................................................................................................................................................ 4 1.2 TESTING FACILITY............................................................................................................................. 4 2.0 PRODUCT INFORMATION..............................................................................................................5 2.1 EQUIPMENT DESCRIPTION .............................................................................................................. 5 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ........................................................................... 5 2.3 LABELING REQUIREMENTS.............................................................................................................. 5 3.0 DESCRIPTION OF TESTS ..............................................................................................................6 3.1 MEASUREMENT PROCEDURE......................................................................................................... 6 3.2 OCCUPIED BANDWIDTH EMISSION LIMITS .................................................................................... 6 3.3 CELLULAR - BASE FREQUENCY BLOCKS....................................................................................... 6 3.4 CELLULAR - MOBILE FREQUENCY BLOCKS ................................................................................... 7 3.5 PCS - BASE FREQUENCY BLOCKS .................................................................................................. 7 3.6 PCS - MOBILE FREQUENCY BLOCKS .............................................................................................. 7 3.7 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL.............................................. 7 3.8 RADIATED SPURIOUS AND HARMONIC EMISSIONS ..................................................................... 8 3.9 PEAK-AVERAGE RATIO ..................................................................................................................... 8 3.10 FREQUENCY STABILITY / TEMPERATURE VARIATION ................................................................. 8 4.0 TEST EQUIPMENT CALIBRATION DATA ......................................................................................9 5.0 SAMPLE CALCULATIONS ............................................................................................................10 6.0 TEST RESULTS .............................................................................................................................11 6.1 SUMMARY......................................................................................................................................... 11 6.2 EFFECTIVE RADIATED POWER OUTPUT DATA ........................................................................... 12 6.3 EQUIVALENT ISOTROPIC RADIATED POWER OUTPUT DATA .................................................... 13 6.4 CELLULAR GSM RADIATED MEASUREMENTS ............................................................................. 14 6.5 PCS GSM RADIATED M…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: BEJLG420G HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0909151712.BEJ September 21-24, 2009 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 1 of 72 © 2009 PCTEST Engineering Laboratory, Inc. REV 8.1G 08/19/09 Applicant Name: Date of Testing: LG Electronics USA September 21-24, 2009 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0909151712.BEJ FCC ID: BEJLG420G APPLICANT: LG ELECTRONICS USA Application Type: Certification FCC Rule Part(s): § 20.19(b) HAC Standard: ANSI C63.19-2007 §6.3(v), §7.3(v) FCC Classification: Licensed Transmitter Held to Ear (PCE) EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Model(s): LG420G Tx Frequency: 824.20 - 848.80 MHz (Cellular GSM) 1850.20 - 1909.80 MHz (GSM PCS) Test Device Serial No.: Pre-Production Sample [S/N: HAC RFE] C63.19-2007 HAC Category: M3 (RF EMISSIONS CATEGORY) This wireless portable device has been shown to be hearing-aid compatible under the above rated category, specified in ANSI/IEEE Std. C63.19-2007 and had been tested in accordance with the specified measurement procedures. Hearing-Aid Compatibility is based on the assumption that all production units will be designed electrically identical to the device tested in this report. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com HEARING AID COMPATIBILITY Reviewed by: FCC ID: BEJLG420G HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0909151712.BEJ September 21-24, 2009 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 2 of 72 © 2009 PCTEST Engineering Laboratory, Inc. REV 8.1G 08/19/09 TABLE OF CONTENTS 1. INTRODUCTION ............................................................................................................................. 3 2. TEST SITE LOCATION ................................................................................................................... 4 3. EUT DESCRIPTION ........................................................................................................................ 5 4. ANSI/IEEE C63.19 PERFORMANCE CATEGORIES..................................................................... 6 5. SYSTEM SPECIFICATIONS...........................................................................................................7 6. TEST PROCEDURE ..................................................................................................................... 13 7. SYSTEM CHECK .......................................................................................................................... 15 8. MODULATION FACTOR...............................................................................................................18 9. OVERALL MEASUREMENT SUMMARY ..................................................................................... 20 10. EQUIPMENT LIST......................................................................................................................... 23 11. MEASUREMENT UNCERTAINTY ................................................................................................ 24 12. TEST DATA ................................................................................................................................... 25 13. CALIBRATION CERTIFICATES.................................................................................................... 34 14. CONCLUSION............................................................................................................................... 67 15. REFERENCES .............................................................................................................................. 68 16. TEST PHOTOGRAPHS ................................................................................................................70 Reviewed by: FCC ID: BEJLG420G HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0909151712.BEJ September 21-24, 2009 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 3 of 72 © 2009 PCTEST Engineering Laboratory, Inc. REV 8.1G 08/19/09 1. INTRODUCTION On July 10, 2003, the Federal Communications Commission (FCC) adopted new rules requiring wireless manufacturers and service providers to provide digital wireless phones that are compatible with hearing aids. The FCC has modified the exemption for wireless phones under the Hearing Aid Compatibility Act of 1998 (HAC Act) in WT Docket 01-309 RM-8658 1 to extend the benefits of wireless telecommunications to individuals with hearing disabilities. These benefits encompass business, social and emergency communications, which increase the value of the wireless network for everyone. An estimated more than 10% of the population in the United States show signs of hearing impairment and of that fraction, almost 80% use hearing aids. Approximately 500 million people worldwide suffer from hearing loss. Compatibility…
