BEJLG910GCellular/PCS GSM Phone with Bluetooth

LG 910G Quick Start Guide • Depending on the software installed or your service provider or country, some of the descriptions in this guide may not match your phone exactly. • Depending on your country, your phone and accessories may appear different from the picture in this guide. Bluetooth QD ID B000000 P/N: MMBB0000000 (1.0) H Installing the SIM and Battery Installing the SIM card Slide the SIM card into the SIM card holder. Make sure that the gold contact area on the card is facing downwards (as shown below). To remove the SIM card, pull it gently in the reverse direction. Installing the Battery To install the battery, align the battery contacts (1) with those in the battery compartment. Press the battery down until it clicks into place (2). With the battery in position in the phone, replace the battery cover on the back of your phone. 1. 2. Removing the Battery With your phone turned off , push the button above the battery cover in (1) and lift off the battery cover to remove it. Lift the battery up (1) and away (2) from the phone, as shown. WARNING: Do not remove the battery when the phone is switched on, as this may damage the phone. 1. 2. Charging your phone Pull out the cover of the charger slot on the top left side of your LG910G. Plug in the charger, making sure that the 'B' side is facing you (as displayed below), and plug the other end into a wall socket. Your LG910G will need to be charged until a message reading “Battery full” appears on screen. Installing the SIM and BatteryInstalling the SIM and Battery Phone Components & FeaturesPhone Components & Features Easy-to-read LCD screen with status icons. Messaging, voicemail, and caller ID. Speakerphone feature. Menu-driven interface with prompts for easy operation and configuration. Any Key answer, Auto Redial and Speed Dials (with 9 locations). Bilingual (English and Spanish) capabilities. Internal Antenna. • • • • • • • Earpiece Display screen Send key Alphanumeric keys Left soft key Microphone Right soft key PWR/END key Vibrate Mode key Standby mode is when you are not on a call or using a menu. You must be in Standby mode to enter a phone number to dial. Display Navigation key Status icons Main display area Soft key options Your phone displays the following status indicators at the top of the screen: Indicates the strength of the network signal. Indicates that GPRS service is available. Indicates the status of the battery charge. Indicates a call is in progress. Indicates the alarm has been set and is on. Indicates a Calendar event for the day. Indicates a new message. Indicates a new voicemail message. Indicates that the Normal Profile has been set. Indicates that the Silent Profile has been set. Indicates the TTY has been set and is on. Icon Description Turning the Phone On or Off Make sure a charged battery is installed. Then press until the LCD screen lights up. To turn off , press and hold until the display turns off . 1. 2. 3. Changing the display language Allows you to use the bilingual feature according to your preference. Choose between English and Spanish. In Standby mode, press the Left soft key Menu. Press J J . Use to highlight Automatic, English or, Español, then press Select. Making Callsx Make sure the phone is turned on. Enter the phone number (include the area code if needed). Press to dial. Press to end the call. 1. 2. 3. 1. 2. 3. 4. Recent Calls The Recent Calls menu displays a list of the last phone numbers or Contacts entries for calls missed, received, or dialed. It is continually updated as new numbers are added to the beginning of the list and the oldest entries are removed from the bottom of the list. Note: To view a quick list of all your recent calls, press Key while in standby mode. All Calls : Allows you to view the list of the most recent missed, received and dialed calls. Press the Left Soft Key , , , . 1. Sound Options to customize your phone's sounds: Ringers Press the Left Soft Key , , . Use to highlight the ringtone among Ringtone, Voice Record- ings or Default Sounds folder. Press Play to play the ringtone, or press the Left soft key Options and select Use As to set the ringtone to your phone. 1. 2. 3. Missed Calls : Allows you to view a list of the most recent missed calls. Press the Left Soft Key , , J Use to highlight an entry. Received Calls : Allows you to view a list of the most recent received calls. Press the Left Soft Key , , J Use to highlight an entry. Dialed Numbers : Allows you to view a list of the most recent dialed calls. Press the Left Soft Key , , J Use to highlight an entry. Call Duration : Allows you to view the duration of the calls, by type. Press the Left Soft Key , , J Use to highlight one of the call types (below). All Calls/ Dialed Calls/ Received Calls/ Last Call 2. 3. 4. 5. *Many of the features and services described are network dependent and may require additional subscription and/or usage charges. Not all features are available for purchase or use in all areas. Other conditions and restrictions may apply. See carrier for more information. © 2010 LG Electronics, Inc. SoundMenu map 1. Prepaid For more information about the Prepaid menu, please refer to the Quick Activation Guide. 2. Messages 2.1 Write Messages 2.2 Inbox 2.3 Conversation View 2.4 Drafts 2.5 Outbox 2.6 Sent 2.7 Saved Items 2.8 Template 2.9 Settings 2.10 Multimedia Message 2.11 Voicemail 2.12 Service Message 2.13 Save Sent Messages 2.14 Message Counter 3. Recent Calls 3.1 All Logs 3.2 Calls Only 3.3 Messages Logs 3.4 Missed Logs 3.5 Outgoing Logs 3.6 Incoming Logs 3.7 Call Duration 3.8 Data Voulume 5. Contacts 6. Games & Apps 6.1 Games 6.2 Applications 7. Music 7.1 MP3 Player 7.2 FM Radio 8. Organiser 8.1 Calendar 8.2 Tasks 8.3 Memo 8.4 Date Finder 9. Camera 9.1 Camera 9.2 Video Camera 9.3 Album 10. My Folder 9.1 All 9.2 Handset memory 9.3 External memory 11. Tools 11.1 Quick Menu 11.2 Alarm Clock 11.3 Calculator 11.4 Voice Recorder 11.5 Stopwatch 11.6 Unit Converter 11.7 World Clock 11.8 STK…

Text truncated - open the document above for the full version.

Date Febr ar 10 2011 LG Electronics Inc. LGE LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:LG Electronics Inc. FCC ID: BEJLG910G Date: February 10, 2011 Part 20.19 Certification To Whom It May Concern: The following are the model designations and their associated key features for this FCC ID, according to requirement in the TCB Guidance issued on June 20, 2008. FCC ID BEJLG910G FCC ID: BEJLG910G Air Interfaces: GSM Wireless Technologies: 2G Bands: GSM850 / GSM1900 MP3 Key Features: MP3 Camera Bluetooth Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA

Date: February 10, 2011 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 SUBJECT: LG Electronics Inc. FCC ID: BEJLG910G Part 20.19 Certification Gentlemen: We, LG Electronics USA, hereby declare the samples evaluated in this application are equivalent to production samples. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics Inc. LGE LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date:February 10, 2011 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: BEJLG910G Equipment Class: PCE: PCS Licensed Transmitter held to ear To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure PERMANENT 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G External Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 1 of 4 © 2011 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G External Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 2 of 4 © 2011 PCTEST Engineering Laboratory Inc. LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G External Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 3 of 4 © 2011 PCTEST Engineering Laboratory Inc. LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G External Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 4 of 4 © 2011 PCTEST Engineering Laboratory Inc.

Model No: LG910G FCC ID : BEJLG910G S/N : Made in Korea LG Electronics Inc. LGE

LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 1 of 10 © 2011 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 2 of 10 © 2011 PCTEST Engineering Laboratory Inc. LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 3 of 10 © 2011 PCTEST Engineering Laboratory Inc. LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 4 of 10 © 2011 PCTEST Engineering Laboratory Inc. LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 5 of 10 © 2011 PCTEST Engineering Laboratory Inc. LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 6 of 10 © 2011 PCTEST Engineering Laboratory Inc. LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 7 of 10 © 2011 PCTEST Engineering Laboratory Inc. LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 8 of 10 © 2011 PCTEST Engineering Laboratory Inc. LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 9 of 10 © 2011 PCTEST Engineering Laboratory Inc. LG ELECTRONICS FCC ID: BEJLG910G Model: LG910G Internal Photos EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth Page 10 of 10 © 2011 PCTEST Engineering Laboratory Inc.

Reviewed by: FCC ID: BEJLG910G SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1101130093.BEJ 01/17/11 - 01/18/11 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 1 of 31 © 2011 PCTEST Engineering Laboratory, Inc. REV 8.8M 01/04/2011 Applicant Name: Date of Testing: LG Electronics USA 01/17/11 - 01/18/11 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0Y1101130093.BEJ FCC ID: BEJLG910G APPLICANT: LG ELECTRONICS USA EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Application Type: Certification FCC Rule Part(s): CFR §2.1093; FCC/OET Bulletin 65 Supplement C [June 2001] FCC Classification: Licensed Transmitter Held to Ear (PCE) Model(s): LG910G Tx Frequency: 824.20 - 848.80 MHz (GSM 850) 1850.20 - 1909.80 MHz (GSM 1900) Conducted Power: 32.92 dBm GSM 850 29.92 dBm GSM 1900 Max. SAR Measurement: 0.70 W/kg GSM 850 Head SAR 0.50 W/kg GSM 850 Body SAR 0.50 W/kg GSM 1900 Head SAR 0.22 W/kg GSM 1900 Body SAR Test Device Serial No.: Pre-Production [S/N: FCC SAR] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001), IEEE 1528-2003 and in applicable Industry Canada Radio Standards Specifications (RSS); for North American frequency bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. +1.410.290.6652 / Fax +1.410.290.6554 http://www.pctestlab.com SAR COMPLIANCE EVALUATION REPORT Reviewed by: FCC ID: BEJLG910G SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1101130093.BEJ 01/17/11 - 01/18/11 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 2 of 31 © 2011 PCTEST Engineering Laboratory, Inc. REV 8.8M 01/04/2011 TABLE OF CONTENTS 1 INTRODUCTION ............................................................................................................................. 3 2 TEST SITE LOCATION ................................................................................................................... 4 3 SAR MEASUREMENT SETUP ....................................................................................................... 5 4 DASY E-FIELD PROBE SYSTEM .................................................................................................. 7 5 PROBE CALIBRATION PROCESS ................................................................................................ 8 6 PHANTOM AND EQUIVALENT TISSUES...................................................................................... 9 7 DOSIMETRIC ASSESSMENT & PHANTOM SPECS................................................................... 10 8 DEFINITION OF REFERENCE POINTS ...................................................................................... 11 9 TEST CONFIGURATION POSITIONS ......................................................................................... 12 10 FCC RF EXPOSURE LIMITS........................................................................................................ 15 11 FCC 3G MEASUREMENT PROCEDURES .................................................................................. 16 12 SYSTEM VERIFICATION.............................................................................................................. 17 13 SAR DATA SUMMARY ................................................................................................................. 19 14 FCC MULTI-TX AND ANTENNA SAR CONSIDERATIONS......................................................... 22 15 EQUIPMENT LIST......................................................................................................................... 23 16 MEASUREMENT UNCERTAINTIES ............................................................................................ 24 17 CONCLUSION............................................................................................................................... 25 18 REFERENCES .............................................................................................................................. 26 19 SAR TEST SETUP PHOTOGRAPHS ........................................................................................... 28 Reviewed by: FCC ID: BEJLG910G SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1101130093.BEJ 01/17/11 - 01/18/11 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Page 3 of 31 © 2011 PCTEST Engineering Laboratory, Inc. REV 8.8M 01/04/2011 1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices. [1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz [3] and Health Canada RF Exposure Guidelines Safet…
