- 1 - User Manual VM101 Ver. 1.0 2009. 07. 20 Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “ Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Part 15 Class B Compliance This device and its accessories comply with part15 of FCC rules. Operation is subject to the following two conditions: (1) This device & its accessories may not cause harmful interference. (2) This device & its accessories must accept any interference received, including interference that may cause undesired operation. Body-worn Operation This device has been tested for typical body-worn operations with the distance of 0.79inches (2.0cm) from the user’s body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79inches(2.0cm) must be maintained from the user's body. Additionally, Belt clips, holsters & other body-worn accessories may not contain metallic components. - 10 - Getting Started Unlocking Your Phone If you received your VM101 in the mail, you may need to unlock it before making calls. 1. Press the END/PWR Switch for 2~3 seconds. 2. Press soft key Unlock. 3. Enter your four-digit lock code. For security purposes, the code will not be visible as you type. Note: If you can’t recall your lock code, try using the last four digits of your Social Security number, the last four digits of your Phone Number or 0000. View of Phone 1. END/PWR Switch: Lets you power the phone on or off. 2. Antenna: Retractable antenna provides optimum reception for 1900 MHz frequencies. 3. Headset Jack: Provides connection for an optional headset. 4. Volume Control Keys: Adjust the Ring Volume in the Main Menu or the Voice Volume during a call. The keys also scroll through mouths in the Calendar or pages in the MiniBrowser. 5. Mouse Key: Allows quick and easy scrolling through the menus. 6. OK: Lets you place a call, receive a call, end a call or select menu options. 7. CLR: Lets you clear an entry or back-up in the menu. Installing and Removing the Battery To install the battery, insert the bottom of the battery into the opening on the back of the phone. Then, push the battery down until the latch clicks. - 11 - To remove the battery, press down on the latch and remove the battery from the phone. Turning Your Phone On and Off To turn your phone on, move the On/Off Switch (near the antenna) to the ON position. Your phone performs a short self-test before letting you know it is operational. If your phone does not turn on, make sure the battery is installed correctly and is adequately charged or has external power (via the AC Adapter, Cigarette Lighter Adapter or Hands-Free Car Kit). To turn your phone off, move the On/Off Switch to the OFF position. Main Menu When your phone acquires Service, the Greeting (a banner of text), the current time and date and the Main Menu are displayed. If you are in authorized analog cellular provider’s service area, you are ready to send and receive calls. Power Save Mode When the phone is in an area without service for 15 minutes, it stops searching for service and enters into the power Save Mode. When your phone activates this feature, Power Save is displayed on your screen. The phone automatically checks for service periodically or you can check manually by pressing any key. - 12 - Menu Navigation The Mouse Key lets you scroll circularly through menus quickly and easily. As you navigate through a menu, the options are highlighted (Highlighted Test Example ) . Select an option by highlighting it and pressing . The scroll bar at the right of the menu keeps track of your position in the menu at all times. For example, if you want to view your last incoming call: 1. From the Main Menu, select RECENT History and press 8. If you have received any calls or message they are displayed on the screen. Entering Characters Using the Keypad(T9) To enter a letter, punctuation or number when creating Phone Book or Scheduler entries, press the corresponding key until the desired character appears. By default, the first letter of a word is capitalized and following letters are lowercase. Characters in the following order: 1 . ? , ‘ & - @ ( ) / ~ P Q R S 7 p q r s A B C 2 a b c 2 T U V 8 t u v 8 D E F 3 d e f 3 W X Y Z 9 w x y z 9 G H I 4 g h i 4 Next 0 J K L 5 j k l 5 Shift M N O 6 m n o 6 Space After a character is entered, the cursor automatically advances to the next space after two seconds. You can also advance the cursor by pressing or entering a character not on the same key. Recent History 1 7 PQRS 9WXYZ 8TUV 6MNO 5J 4G 3DEF ABC 1 * 0Space - 13 - If you make a mistake, press to move the cursor left or [CLR] to erase a character. To clear the entire entry, press and hold [CLR] for two seconds. - 14 - Display Icons Display icons are the symbols your phone uses to communicate important information. They are as follows: ICON DESCRIPTION 3G send 3G receive 3G send receive…
Text truncated - open the document above for the full version.
Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:LG Electronics Inc. FCC ID: BEJVM101 Part 20.19 Certification To Whom It May Concern: The following are the model designations and their associated key features for this FCC ID, according to requirement in the TCB Guidance issued on June 20, 2008. Date: August 12, 2009 Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics Inc. LGE CDMA Air Interfaces: GPS Key Features: PCS1900 Bands: 1x Wireless Technologies: VM101 Model(s): BEJVM101 FCC ID: LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632
Date: August 12, 2009 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 SUBJECT: LG Electronics Inc. FCC ID: BEJVM101 Part 20.19 Certification Gentlemen: We, LG Electronics USA, hereby declare the samples evaluated in this application are equivalent to production samples. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics Inc. LGE LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632
LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: August 12, 2009 Fe deral Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: BEJ VM101 Eq uipment Class: PCE: PCS Licensed Transmitter held to ear To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure PERMANENT 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee Ge neral Manager LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632
LG FCC ID: BEJVM101 Model: VM101 External Photos EUT Type: PCS CDMA Phone Page 1 of 4 © 2009 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS LG FCC ID: BEJVM101 Model: VM101 External Photos EUT Type: PCS CDMA Phone Page 2 of 4 © 2009 PCTEST Engineering Laboratory Inc. LG FCC ID: BEJVM101 Model: VM101 External Photos EUT Type: PCS CDMA Phone Page 3 of 4 © 2009 PCTEST Engineering Laboratory Inc. LG FCC ID: BEJVM101 Model: VM101 External Photos EUT Type: PCS CDMA Phone Page 4 of 4 © 2009 PCTEST Engineering Laboratory Inc.
Model No: VM101 FCC ID : BEJVM101 S/N : Made in Korea LG Electronics Inc. LGE
LG FCC ID: BEJVM101 Model: VM101 Internal Photos EUT Type: PCS CDMA Phone Page 1 of 9 © 2009 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS LG FCC ID: BEJVM101 Model: VM101 Internal Photos EUT Type: PCS CDMA Phone Page 2 of 9 © 2009 PCTEST Engineering Laboratory Inc. LG FCC ID: BEJVM101 Model: VM101 Internal Photos EUT Type: PCS CDMA Phone Page 3 of 9 © 2009 PCTEST Engineering Laboratory Inc. LG FCC ID: BEJVM101 Model: VM101 Internal Photos EUT Type: PCS CDMA Phone Page 4 of 9 © 2009 PCTEST Engineering Laboratory Inc. LG FCC ID: BEJVM101 Model: VM101 Internal Photos EUT Type: PCS CDMA Phone Page 5 of 9 © 2009 PCTEST Engineering Laboratory Inc. LG FCC ID: BEJVM101 Model: VM101 Internal Photos EUT Type: PCS CDMA Phone Page 6 of 9 © 2009 PCTEST Engineering Laboratory Inc. LG FCC ID: BEJVM101 Model: VM101 Internal Photos EUT Type: PCS CDMA Phone Page 7 of 9 © 2009 PCTEST Engineering Laboratory Inc. LG FCC ID: BEJVM101 Model: VM101 Internal Photos EUT Type: PCS CDMA Phone Page 8 of 9 © 2009 PCTEST Engineering Laboratory Inc. LG FCC ID: BEJVM101 Model: VM101 Internal Photos EUT Type: PCS CDMA Phone Page 9 of 9 © 2009 PCTEST Engineering Laboratory Inc.
Reviewed by: FCC ID: BEJVM101 CERTIFICATION REPORT Quality Manager Filename: Test Dates: EUT Type: 0908051474.BEJ 08/10/09 PCS CDMA Phone Page 1 of 26 © 2009 PCTEST Engineering Laboratory, Inc. REV 6.5 06/15/09 Applicant Name: Date of Testing: LG Electronics USA 08/10/09 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0908051474.BEJ F C C I D : BE J V M1 0 1 AP P L I C AN T : LG E LE CT RO N ICS US A EUT Type: PCS CDMA Phone Application Type: Certification FCC Rule Part(s): CFR §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] FCC Classification: Licensed Transmitter Held to Ear (PCE) Model(s): VM101 Tx Frequency: 1851.25 - 1908.75 MHz (PCS CDMA) Conducted Power: 24.63 dBm PCS CDMA Max. SAR Measurement: 1.16 W/kg PCS CDMA Head SAR / 1.03 W/kg PCS CDMA Body SAR Test Device Serial No.: Pre-Production [S/N: SAR] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003 and in applicable Industry Canada Radio Standards Specifications (RSS). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Reviewed by: FCC ID: BEJVM101 CERTIFICATION REPORT Quality Manager Filename: Test Dates: EUT Type: 0908051474.BEJ 08/10/09 PCS CDMA Phone Page 2 of 26 © 2009 PCTEST Engineering Laboratory, Inc. REV 6.5 06/15/09 T A B L E O F C O N T E N T S 1 INTRODUCTION ..............................................................................................................................3 2 TEST SITE LOCATION ....................................................................................................................4 3 SAR MEASUREMENT SETUP ........................................................................................................5 4 DASY E-FIELD PROBE SYSTEM ...................................................................................................7 5 PROBE CALIBRATION PROCESS .................................................................................................8 6 PHANTOM AND EQUIVALENT TISSUES.......................................................................................9 7 DOSIMETRIC ASSESSMENT & PHANTOM SPECS....................................................................10 8 DEFINITION OF REFERENCE POINTS .......................................................................................11 9 TEST CONFIGURATION POSITIONS ..........................................................................................12 10 RF EXPOSURE LIMITS .................................................................................................................15 11 MEASUREMENT UNCERTAINTIES .............................................................................................16 12 SYSTEM VERIFICATION...............................................................................................................17 13 FCC 3G MEASUREMENT PROCEDURES ...................................................................................19 14 SAR DATA SUMMARY ..................................................................................................................21 15 EQUIPMENT LIST..........................................................................................................................23 16 CONCLUSION................................................................................................................................24 17 REFERENCES ...............................................................................................................................25 Reviewed by: FCC ID: BEJVM101 CERTIFICATION REPORT Quality Manager Filename: Test Dates: EUT Type: 0908051474.BEJ 08/10/09 PCS CDMA Phone Page 3 of 26 © 2009 PCTEST Engineering Laboratory, Inc. REV 6.5 06/15/09 1 I N T R O D U C T I O N The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz[2] and Health Canada RF Exposure Guidelines Safety Code 6 [26]. The measurement procedure described in IEEE/ANSI C95.3-2002 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave [3] is used for guidance in measuring the Specific Absorption Rate (SAR) due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the International Committee for Non-Ionizing Radiation Protection (ICNIRP) in Biological Effects and Exposure Criteria for Radiofrequency Electromagnetic Fields,” Report No…
Text truncated - open the document above for the full version.
Reviewed by: FCC ID: BEJVM101 FCC Pt. 24 CDMA MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0908051473.BEJ August 7, 2009 PCS CDMA Phone Page 1 of 24 © 2009 PCTEST Engineering Laboratory, Inc. REV 8.0C 05/13/2009 Applicant Name: Date of Testing: LG Electronics USA August 7, 2009 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab., Columbia, MD, USA United States Test Report Serial No.: 0908051473.BEJ FCC ID: BEJVM101 APPLICANT: LG ELECTRONICS USA Application Type: Certification FCC Classification: PCS Licensed Transmitter Held to Ear (PCE) FCC Rule Part(s): §2; §24(E) EUT Type: PCS CDMA Phone Model(s): VM101 Tx Frequency Range: 1851.25 - 1908.75MHz (PCS CDMA) Max. RF Output Power: 0.459 W EIRP PCS CDMA (26.62 dBm) Emission Designator(s): 1M28F9W (PCS) Test Device Serial No.: identical prototype [S/N: N/A] This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is EIRP for Part 24. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 24 Certification Reviewed by: FCC ID: BEJVM101 FCC Pt. 24 CDMA MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0908051473.BEJ August 7, 2009 PCS CDMA Phone Page 2 of 24 © 2009 PCTEST Engineering Laboratory, Inc. REV 8.0C 05/13/2009 TABLE OF CONTENTS FCC PART 24 MEASUREMENT REPORT..................................................................................3 1.0 INTRODUCTION....................................................................................................................4 1.1 SCOPE..................................................................................................................................................................4 1.2 TESTING FACILITY............................................................................................................................................4 2.0 PRODUCT INFORMATION.....................................................................................................5 2.1 EQUIPMENT DESCRIPTION...........................................................................................................................5 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS....................................................................................5 2.3 LABELING REQUIREMENTS...........................................................................................................................5 3.0 DESCRIPTION OF TESTS......................................................................................................6 3.1 MEASUREMENT PROCEDURE......................................................................................................................6 3.2 OCCUPIED BANDWIDTH EMISSION LIMITS...............................................................................................6 3.3 PCS - BASE FREQUENCY BLOCKS..............................................................................................................6 3.4 PCS - MOBILE FREQUENCY BLOCKS.........................................................................................................7 3.5 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL...................................................7 3.6 RADIATED SPURIOUS AND HARMONIC EMISSIONS..............................................................................8 3.7 PEAK-AVERAGE RATIO...................................................................................................................................8 3.8 FREQUENCY STABILITY / TEMPERATURE VARIATION.........................................................................8 4.0 TEST EQUIPMENT CALIBRATION DATA...............................................................................9 5.0 SAMPLE CALCULATIONS....................................................................................................10 6.0 TEST RESULTS...................................................................................................................11 6.1 SUMMARY.........................................................................................................................................................11 6.2 EQUIVALENT ISOTROPIC RADIATED POWER OUTPUT DATA..........................................................12 6.3 PCS CDMA RADIATED MEASUREMENTS................................................................................................13 6.4 PCS CDMA FREQUENCY STABILITY MEASUREMENTS......................................................................16 7.0 PLOT(S) OF EMISSIONS.....................................................................................................18 8.0 CONCLUSION.....................................................................................................................24 Reviewed by: FCC ID: BEJVM101 FCC Pt. 24 CDMA MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0908051473.BEJ August 7, 2009 PCS CDMA Phone Page 3 of 24 © 2009 PCTEST Engineering Laboratory, Inc. REV 8.0C 05/13/2009 MEASUREMENT REPORT FCC Part 24 §2.1033 General Information APPLICANT:…
Text truncated - open the document above for the full version.
Reviewed by: FCC ID: BEJVM101 HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0908051475.BEJ August 5-8, 2009 PCS CDMA Phone Page 1 of 64 © 2009 PCTEST Engineering Laboratory, Inc. REV 8.1C 07/01/09 Applicant Name: Date of Testing: LG Electronics USA August 5-8, 2009 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0908051475.BEJ FCC ID: BEJVM101 APPLICANT: LG ELECTRONICS USA Application Type: Certification FCC Rule Part(s): § 20.19(b) HAC Standard: ANSI C63.19-2007 §6.3(v), §7.3(v); FCC Classification: Licensed Transmitter Held to Ear (PCE) EUT Type: PCS CDMA Phone Model(s): VM101 Tx Frequency: 1851.25 - 1908.75 MHz (PCS CDMA) Test Device Serial No.: Pre-Production Sample [S/N: HAC RFE] C63.19-2007 HAC Category: M4 (RF EMISSIONS CATEGORY) This wireless portable device has been shown to be hearing-aid compatible under the above rated category, specified in ANSI/IEEE Std. C63.19-2007 and had been tested in accordance with the specified measurement procedures. Hearing-Aid Compatibility is based on the assumption that all production units will be designed electrically identical to the device tested in this report. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com HEARING AID COMPATIBILITY CERTIFICATE Reviewed by: FCC ID: BEJVM101 HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0908051475.BEJ August 5-8, 2009 PCS CDMA Phone Page 2 of 64 © 2009 PCTEST Engineering Laboratory, Inc. REV 8.1C 07/01/09 TABLE OF CONTENTS 1. INTRODUCTION ............................................................................................................................. 3 2. TEST SITE LOCATION ................................................................................................................... 4 3. EUT DESCRIPTION ........................................................................................................................ 5 4. ANSI/IEEE C63.19 PERFORMANCE CATEGORIES..................................................................... 6 5. SYSTEM SPECIFICATIONS...........................................................................................................7 6. TEST PROCEDURE ..................................................................................................................... 13 7. SYSTEM CHECK .......................................................................................................................... 15 8. MODULATION FACTOR...............................................................................................................18 9. FCC 3G MEASUREMENTS .......................................................................................................... 20 10. OVERALL MEASUREMENT SUMMARY ..................................................................................... 21 11. EQUIPMENT LIST......................................................................................................................... 24 12. MEASUREMENT UNCERTAINTY ................................................................................................ 25 13. TEST DATA ................................................................................................................................... 26 14. CALIBRATION CERTIFICATES.................................................................................................... 31 15. CONCLUSION............................................................................................................................... 59 16. REFERENCES .............................................................................................................................. 60 17. TEST PHOTOGRAPHS ................................................................................................................62 Reviewed by: FCC ID: BEJVM101 HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0908051475.BEJ August 5-8, 2009 PCS CDMA Phone Page 3 of 64 © 2009 PCTEST Engineering Laboratory, Inc. REV 8.1C 07/01/09 1. INTRODUCTION On July 10, 2003, the Federal Communications Commission (FCC) adopted new rules requiring wireless manufacturers and service providers to provide digital wireless phones that are compatible with hearing aids. The FCC has modified the exemption for wireless phones under the Hearing Aid Compatibility Act of 1998 (HAC Act) in WT Docket 01-309 RM-8658 1 to extend the benefits of wireless telecommunications to individuals with hearing disabilities. These benefits encompass business, social and emergency communications, which increase the value of the wireless network for everyone. An estimated more than 10% of the population in the United States show signs of hearing impairment and of that fraction, almost 80% use hearing aids. Approximately 500 million people worldwide suffer from hearing loss. Compatibility Tests Involved: The standard calls for wireless communications devices to be measured for: RF Electric-field emissions RF Magnetic-field emissions T-coil mode, magnetic-signal strength in the audio band T-coil mode, magnetic-signal frequency response through the audio band T-coil mode, magnetic-signal and noise articulation index The hearing aid must be measured for: RF immunity in mi…
Text truncated - open the document above for the full version.
Reviewed by: FCC ID: BEJVM101 HAC (T-COIL) TEST REPORT Quality Manager Filename: Test Dates: EUT Type: 0908051476.BEJ 8/6/2009 PCS CDMA Phone Page 1 of 37 © 2009 PCTEST Engineering Laboratory, Inc. REV 6.2C 06/12/09 Applicant Name: Date of Testing: LG Electronics USA 8/6/2009 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0908051476.BEJ F C C I D : BE J V M1 0 1 AP P L I C AN T : LG E LE CT RO N ICS US A Scope of Test: Audio Band Magnetic Testing (T-Coil) Application Type: Certification FCC Rule Part(s): CFR § 20.19(b) HAC Standard: ANSI C63.19-2007 §6.3(v), §7.3(v) FCC Classification: Licensed Transmitter Held to Ear (PCE) EUT Type: PCS CDMA Phone Model(s): VM101 Tx Frequency: 1851.25 - 1908.75 MHz (PCS CDMA) Test Device Serial No.: Pre-Production Sample [S/N: T Coil] C63.19-2007 HAC Category: T4 (SIGNAL TO NOISE CATEGORY) This wireless portable device has been shown to be hearing-aid compatible under the above rated category, specified in ANSI/IEEE Std. C63.19-2007 and had been tested in accordance with the specified measurement …
Text truncated - open the document above for the full version.
6660-B Dobbin Road · Columbia, Maryland · United States
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 24E | 1.85 GHz - 1.91 GHz | 459.00 mW | 1M28F9W | 2.5000000000 ppm |
