BEJVM510PCS CDMA Phone with Bluetooth

- 1 - User Manual VM510 Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “ Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Part 15 Class B Compliance This device and its accessories comply with part15 of FCC rules. Operation is subject to the following two conditions: (1) This device & its accessories may not cause harmful interference. (2) This device & its accessories must accept any interference received, including interference that may cause undesired operation. Body-worn Operation This device has been tested for typical body-worn operations with the distance of 0.79inches (2.0cm) from the user’s body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79inches(2.0cm) must be maintained from the user's body. Additionally, Belt clips, holsters & other body-worn accessories may not contain metallic components. - 2 - Getting Started Unlocking Your Phone If you received your VM510 in the mail, you may need to unlock it before making calls. 1. Press the END/PWR Switch for 2~3 seconds. 2. Press soft key Unlock. 3. Enter your four-digit lock code. For security purposes, the code will not be visible as you type. Note: If you can’t recall your lock code, try using the last four digits of your Social Security number, the last four digits of your Phone Number or 0000. Turning Your Phone On and Off To turn your phone on, move the On/Off Switch (near the antenna) to the ON position. Your phone performs a short self-test before letting you know it is operational. If your phone does not turn on, make sure the battery is installed correctly and is adequately charged or has external power (via the AC Adapter, Cigarette Lighter Adapter or Hands-Free Car Kit). To turn your phone off, move the On/Off Switch to the OFF position. Main Menu When your phone acquires Service, the Greeting (a banner of text), the current time and date and the Main Menu are displayed. If you are in authorized analog cellular provider’s service area, you are ready to send and receive calls. Power Save Mode - 3 - When the phone is in an area without service for 15 minutes, it stops searching for service and enters into the power Save Mode. When your phone activates this feature, Power Save is displayed on your screen. The phone automatically checks for service periodically or you can check manually by pressing any key. - 4 - Entering Characters Using the Keypad(T9) To enter a letter, punctuation or number when creating Phone Book or Scheduler entries, press the corresponding key until the desired character appears. By default, the first letter of a word is capitalized and following letters are lowercase. Characters in the following order: 1 . ? , ‘ & - @ ( ) / ~ P Q R S 7 p q r s A B C 2 a b c 2 T U V 8 t u v 8 D E F 3 d e f 3 W X Y Z 9 w x y z 9 G H I 4 g h i 4 Next 0 J K L 5 j k l 5 Shift M N O 6 m n o 6 Space After a character is entered, the cursor automatically advances to the next space after two seconds. You can also advance the cursor by pressing or entering a character not on the same key. If you make a mistake, press to move the cursor left or [CLR] to erase a character. To clear the entire entry, press and hold [CLR] for two seconds. 1 7PQRS 9WXYZ 8TUV 6MNO 5J 4G 3DEF ABC 1 * 0Space - 5 - Display Icons Display icons are the symbols your phone uses to communicate important information. They are as follows: ICON DESCRIPTION 3G Icon DO Icon Alarm Battery Antenna No service Location On/Off Voice Privacy Ringer Roaming TTY - 6 - Antenna The antenna on your phone provides maximum reception by extending of retracting it. !!! WARNING – CHOKING HAZARD – ANTENNA MAY BECOME DISLODGED Attempting to remove or repeated twisting of the antenna will loosen the materials securing it into antenna. Once the antenna is loosened or removed, only an authorized service provider Representative can restore the antenna’s original integrity. Do not attempt to remove or twist the antenna. Signal Strength The quality of each call you make or receive depends on the signal strength on your area. The number of bars in the Signal Strength icon informs you of the current strength. The more bars, the stronger the signal. Battery Capacity Your phone is equipped with a Lithium Polymer battery. It allows you to recharge your battery before it is fully drained. The battery provides approximately 180 minuets of continuous digital talk time or approximately 110 hours of continuous digital standby time. Note: Long backlight settings affect the battery’s talk and standby times. When the battery reaches 5% of its capacity, the battery icon blinks. When there is about one minute of talk time left, the phone sounds an audible alert every 30 seconds and then powers down. If the battery’s charge is completely run down, it takes 2 to 3 hours to fully recharge. It is not necessary to let the battery completely run do…

Text truncated - open the document above for the full version.

Date March 10 2010 LG Electronics Inc. LGE LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:LG Electronics Inc. FCC ID: BEJVM510 Part2019Certification Date: March 10, 2010 Part20.19Certification To Whom It May Concern: The following are the model designations and their associated key features for this FCC ID, according to requirement in the TCB Guidance issued on June 20, 2008. FCC ID: BEJVM510 Model(s): VM510, LG-VM510 Air Interfaces: PCS 1900 Wireless Technologies: CDMA 1x/EvDO Bands: PCS1900 MP3 player S Key Features: py Qwerty Keypad Camera Bluetooth GPS Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA

Date: March 10, 2010 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 SUBJECT: LG Electronics Inc. FCC ID: BEJVM510 Part 20.19 Certification Gentlemen: We, LG Electronics USA, hereby declare the samples evaluated in this application are equivalent to production samples. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics Inc. LGE LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

Date: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: Equipment Class: To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for days after the grant as outlined in Public Notice DA 04-1705. This provision will give temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

From: 한봉효 Sent: Thursday, March 11, 2010 12:22 AM To: PCTEST TCB/CB Subject: Re : Questions Regarding FCC ID: BEJVM510 Importance: High Hello PCTEST TCB, Thank you for your e-mail. Please see response below and find the attachments. Thank you! Best regards Han. ----- Original Message ----- From: PCTEST TCB/CB To: LGE - Bong Hyo Han 한봉효 Sent: Thursday, March 11, 2010 8:12 AM Subject: Questions Regarding FCC ID: BEJVM510 To: Mr. Bong Hyo Han / LG Electronics Inc. From: Mr. Mark Czumak / PCTEST TCB RE: FCC ID: BEJVM510 Applicant: LG Electronics Inc. Correspondence Reference Number: BEJ100212 Confirmation Number: 1Y1002230212-14 Date of Original Email: March 10, 2010 Subject: Request for additional information In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1.The application is missing a EUT operational description document. Please provide an operational description per section 2.1033 of CFR Title 47. → Please find the attachment(0perational description). As you know, this EUT supports PCS1900 band only. 2.The VM 510 User Manual describes WLAN EUT capability. Please confirm that this capability is not implemented in the EUT. → I confirm that this capability is not implemented in the EUT. 3.The frequency of the X1601 and U1603 oscillators in the Bluetooth module section of the schematic diagrams is not provided. Please update to include the frequency of the oscillators. → Please find the attachment(Circuit diagram). 4.AWS transmit frequencies are listed in the schematic diagram. Please confirm that this band is not implemented in the EUT. → I confirm that AWS capability is not implemented in the EUT. 5.The HAC Key Features document does not provide the air interfaces to aid in the HAC compliance counts. Please provide. → Please find the attachment(HAC key feature letter). The item indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Mark Czumak Certification Engineer PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you.

LG Electronics USA FCC ID: BEJVM510 Model: VM510 External Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 1 of 5 © 2009 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS LG Electronics USA FCC ID: BEJVM510 Model: VM510 External Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 2 of 5 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 External Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 3 of 5 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 External Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 4 of 5 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 External Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 5 of 5 © 2009 PCTEST Engineering Laboratory Inc.

Model No: VM510 FCC ID : BEJVM510 S/N : Made in Korea LG Electronics Inc. LGE

LG Electronics USA FCC ID: BEJVM510 Model: VM510 Internal Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 1 of 13 © 2009 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS LG Electronics USA FCC ID: BEJVM510 Model: VM510 Internal Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 2 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 Internal Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 3 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 Internal Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 4 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 Internal Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 5 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 Internal Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 6 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 Internal Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 7 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 Internal Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 8 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 Internal Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 9 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 Internal Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 10 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 Internal Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 11 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 Internal Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 12 of 13 © 2009 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJVM510 Model: VM510 Internal Photos EUT Type: PCS CDMA/EvDO Phone w/ BT Page 13 of 13 © 2009 PCTEST Engineering Laboratory Inc.

FCC ID: BEJVM510 SAR COMPLIANCE REPORT Reviewed by: Quality Manager Filename: Test Dates: EUT Type: Page 1 of 31 0Y1002230300.BEJ 02/23/10 - 02/24/10 PCS CDMA/EvDO Phone with Bluetooth © 2010 PCTEST Engineering Laboratory, Inc. REV 7.7M 2/18/2010 Applicant Name: Date of Testing: LG Electronics USA 02/23/10 - 02/24/10 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0Y1002230300.BEJ FCC ID: BEJVM510 APPLICANT: LG ELECTRONICS USA EUT Type: PCS CDMA/EvDO Phone with Bluetooth Application Type: Certification FCC Rule Part(s): CFR §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] FCC Classification: Licensed Transmitter Held to Ear (PCE) Model(s): VM510, LG-VM510 Tx Frequency: 1851.25 - 1908.75 MHz (PCS CDMA) Conducted Power: 24.58 dBm PCS CDMA Max. SAR Measurement: 1.21 W/kg PCS CDMA Head SAR 0.43 W/kg PCS CDMA Body SAR Test Device Serial No.: Pre-Production [S/N: SAR1] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001), IEEE 1528-2003 and in applicable Industry Canada Radio Standards Specifications (RSS); for North American frequency bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com SAR COMPLIANCE EVALUATION REPORT FCC ID: BEJVM510 SAR COMPLIANCE REPORT Reviewed by: Quality Manager Filename: Test Dates: EUT Type: Page 2 of 31 0Y1002230300.BEJ 02/23/10 - 02/24/10 PCS CDMA/EvDO Phone with Bluetooth © 2010 PCTEST Engineering Laboratory, Inc. REV 7.7M 2/18/2010 TABLE OF CONTENTS 1 INTRODUCTION ..............................................................................................................................3 2 TEST SITE LOCATION ....................................................................................................................4 3 SAR MEASUREMENT SETUP ........................................................................................................5 4 DASY E-FIELD PROBE SYSTEM ...................................................................................................7 5 PROBE CALIBRATION PROCESS .................................................................................................8 6 PHANTOM AND EQUIVALENT TISSUES .......................................................................................9 7 DOSIMETRIC ASSESSMENT & PHANTOM SPECS................................................................... 10 8 DEFINITION OF REFERENCE POINTS ...................................................................................... 11 9 TEST CONFIGURATION POSITIONS ......................................................................................... 12 10 RF EXPOSURE LIMITS ................................................................................................................ 15 11 MEASUREMENT UNCERTAINTIES ............................................................................................ 16 12 SYSTEM VERIFICATION .............................................................................................................. 17 13 FCC MULTI-TX AND ANTENNA SAR CONSIDERATIONS ......................................................... 19 14 FCC 3G MEASUREMENT PROCEDURES .................................................................................. 20 15 SAR DATA SUMMARY ................................................................................................................. 22 16 EQUIPMENT LIST ......................................................................................................................... 24 17 CONCLUSION ............................................................................................................................... 25 18 REFERENCES .............................................................................................................................. 26 19 SAR TEST SETUP PHOTOGRAPHS ........................................................................................... 28 FCC ID: BEJVM510 SAR COMPLIANCE REPORT Reviewed by: Quality Manager Filename: Test Dates: EUT Type: Page 3 of 31 0Y1002230300.BEJ 02/23/10 - 02/24/10 PCS CDMA/EvDO Phone with Bluetooth © 2010 PCTEST Engineering Laboratory, Inc. REV 7.7M 2/18/2010 1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz[2] and Health Canada RF Exposure Guidelines Safety Code 6 [26]. The measurement procedure described in IEEE/ANSI C95.3-2002 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave [3] is used for guidance …
