BESTKP-910A900 MHz CORDLESS TELEPHONE

849 NW State Road 45 • P. O. Box 370 • Newberr y, Florida 32669 USA Telephone (352) 472-5500 • (888) 472-2424 • FAX (352) 472-2030 • email: [email protected] April 26, 2000 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: TAE KWANG INDUSTRIAL CO., LTD.’S FCC ID: BESTKP-910A Confirmation #: EA97404 To Whom It May Concern: The above mentioned application was submitted electronically on 4/19/00. The frequency range on the 731 for m was incorrect. This is a request that the 731 for m be corrected to read: 902.8-904.8 MHz 925.3-927.3 MHz Should you have any questions, please advise. Regards, S. S. Sanders SSS/sh

APPLICANT: TAEKWANG INDUSTRIAL CO., LTD. FCC ID: BESTKP-910A TABLE OF CONTENTS TEST REPORT CONTAINING: PAGE 1........15.214(d) - SECURITY CODING INFORMATION AND TEST PROC. PAGE 2........TEST PROCEDURE CONTINUED PAGE 3-4......CIRCUIT DESCRIPTIONS PAGE 5........RADIATION INTERFERENCE TEST DATA - BASE PAGE 6........RADIATION INTERFERENCE TEST DATA - HANDSET PAGE 7........OCCUPIED BANDWIDTH TEST DATA PAGE 8........POWERLINE CONDUCTED TEST DATA EXHIBITS CONTAINING: EXHIBIT 1.........POWER OF ATTORNEY LETTER EXHIBIT 2.........BLOCK DIAGRAM - BASE EXHIBIT 3.........BLOCK DIAGRAM - HANDSET EXHIBIT 4.........SCHEMATIC - BASE EXHIBIT 5.........SCHEMATIC - HANDSET EXHIBIT 6.........FCC ID LABEL SAMPLES EXHIBIT 7.........SKETCH OF FCC ID LABEL LOCATION - BASE/HANDSET EXHIBIT 8.........EXTERNAL PHOTO FRONT VIEW BASE/HANDSET EXHIBIT 9.........EXTERNAL PHOTO REAR VIEW BASE/HANDSET EXHIBIT 10........INTERNAL PHOTO - SOLDER BASE/HANDSET EXHIBIT 11........INTERNAL PHOTO - COMPONENT BASE/HANDSET EXHIBIT 12A-12L...INSTRUCTION MANUAL EXHIBIT 13A-13B...POWERLINE CONDUCTED INTERFERENCE PLOTS EXHIBIT 14A-14B...OCCUPIED BANDWIDTH PLOTS - HANDSET EXHIBIT 15A-15B...OCCUPIED BANDWIDTH PLOTS - BASE4 APPLICANT: TAEKWANG INDUSTRIAL CO., LTD. FCC ID: BESTKP-910A REPORT #: T:\CUS\T\TIC\TIC127A0\TIC127A0.RPT PAGE: TABLE OF CONTENTS SECURITY CODING INFORMATION 15.214(d) - THIS DEVICE COMPLIES WITH THE SECURITY CODE REQUIREMENTS OF 5.214(d)(1)(2) AND (3) BY MEANS OF THE FOLLOWING: THIS PHONE IS EQUIPPED WITH A DIGITAL SECURITY SYSTEM WITH OVER 1 MILLION CODE COMBINATIONS. WHEN MAKING A CALL, THE TELEPHONE SEARCHES THROUGH ITS 60 AVAILABLE CHANNELS AUTO CHANNEL SCAN TO FIND THE CLEAEREST ONE. THE RECEIVER PORTION OF THIS TELEPHONE, FCC ID: BESTKP-910A, WAS TESTED WITH PASSING RESULTS. A VERIFICATION REPORT HAS BEEN ISSUED PER FCC RULES PART 15.107. TEST EQUIPMENT LIST 1._X_Spectrum Analyzer: HP 8566B-Opt 462, S/N 3138A07786, w/ preselector HP 85685A, S/N 3221A01400, Quasi-Peak Adapter HP 8565OA, S/N 3303A01690 & Preamplifier HP 8449B-OPT H02, S/N 3008A00372 Cal. 10/17/99 2._X_Biconnical Antenna: Eaton Model 94455-1, S/N 1057 3._X_Log-Periodic Antenna: Electro-Metrics Model EM-6950, S/N 632 4._X_Double-Ridged Horn Antenna: Electro-Metrics Model RGA-180, 1-18 GHz, S/N 2319 Cal. 4/27/99 5.___Horn 40-60GHz: ATM Part #19-443-6R 6.___Line Impedance Stabilization Network: Electro-Metrics Model ANS-25/2, S/N 2604 Cal. 2/9/00 7.___Temperature Chamber: Tenney Engineering Model TTRC, S/N 11717-7 8.___Frequency Counter: HP Model 5385A, S/N 3242A07460 Cal 10/6/99 9.___Peak Power Meter: HP Model 8900C, S/N 2131A00545 Cal 7/19/99 10.___Open Area Test Site #1-3meters Cal. 12/22/99 11.___Signal Generator: HP 8640B, S/N 2308A21464 Cal. 9/23/99 12.___Signal Generator: HP 8614A, S/N 2015A07428 Cal. 5/29/99 13.___Passive Loop Antenna: EMCO Model 6512, 9KHz to 30MHz, S/N 9706-1211 Cal. 6/23/97 14.___Dipole Antenna Kit: Electro-Metrics Model TDA-30/1-4, S/N 153 Cal. 11/24/99 15.___AC Voltmeter: HP Model 400FL, S/N 2213A14499 Cal. 9/21/99 16.___Digital Multimeter: Fluke Model 8012A, S/N 4810047 Cal 9/21/99 17.___Digital Multimeter: Fluke Model 77, S/N 43850817 Cal 9/21/99 18.___Oscilloscope: Tektronix Model 2230, S/N 300572 Cal 9/23/99 APPLICANT: TAEKWANG INDUSTRIAL CO., LTD. FCC ID: BESTKP-910A REPORT #: T:\CUS\T\TIC\TIC127A0\TIC127A0.RPT PAGE #: 1 TEST PROCEDURE GENERAL: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-1992 using a HEWLETT PACKARD spectrum analyzer with a preselector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100KHz and the video bandwidth was 300KHz up to 1.0GHz. Above 1.0GHz the RBW = 1.0MHz and the VBW=3.0MHz. The ambient temperature of the UUT was 53oF with a humidity of 70%. ANSI STANDARD C63.4-1992 10.1.7 MEASUREMENT PROCEDURES: The UUT was placed on a table 80 cm high and with dimensions of 1m by 1.5m. The UUT was placed flush with the back of the table (1.5m side). The table used for radiated measurements is capable of continuous rotation. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and vertical planes. The situation was similar for the conducted measurement except that the table did not rotate. The EUT was setup as described in ANSIC63.4-1992 with the EUT 40 cm from the vertical ground wall. FORMULA OF CONVERSION FACTORS: The Field Strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBuV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correc- tion factors are stated in terms of dB. The gain of the Preselec- tor was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) METER READING + ACF = FS 33 20 dBuV + 10.36 dB = 30.36 dBuV/m @ 3m POWER LINE CONDUCTED INTERFERENCE: The procedure used was ANSI STANDARD C63.4-1992 using a 50uH LISN. Both lines were observed. The bandwidth of the spectrum analyzer was 10kHz with an appropriate sweep speed. The ambient temperature of the UUT was 53oF with a humidity of 70%. APPLICANT: TAEKWANG INDUSTRIAL CO., LTD. FCC ID: BESTKP-910A REPORT #: T:\CUS\T\TIC\TIC127A0\TIC127A0.RPT PAGE #: 2 APPLICANT: TAEKWANG INDUSTRIAL CO., LTD. FCC ID: BESTKP-910A CIRCUIT DESCRIPTION: BASE UNIT The incoming signal comes in on the antenna and is fed through the duplexer to the LNA, Q500 and then to a SAW bandpass filter,FL501. The frequency rang of the base receiver is 926- 928MHz. From the bandpass filter the signal is fed to the mixer, Q501 which converts the signal down to 26.05MHz. From Q501 the signal is fed to the IF filter FL502 and then to the in…
