BFLGL-T8100GL-T8100 LOW POWER NON-BRAODCAST TRANSMITTER

Glenayre Electronics Inc

Click to zoom

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Oct 18, 1998
Application Purpose: Original Equipment
Date of Application: Sep 02, 1998
Equipment Note: GL-T8100 LOW POWER NON-BRAODCAST TRANSMITTER
Frequency Range: 956.00000000 - 960.00000000
Company: Glenayre Electronics Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Print Date: 08/20/98Copyright © 1998 Glenayre GL-T8100Rev. A: 08/04/98 Specifications subject to change without notice Copyright © 1998 Glenayre All rights reserved. No part of this work may be reproduced or copied in any form or by any means -- graphic, electronic, or mechanical, including photocopying, recording, taping, or information-retrieval system -- without written permission of Glenayre. GL-T8100 System Manual Premilinary PN 9110.01196 Revision A GL-T8100Glenayre Document Number: 9110.01196 Document Change RecordRev. A: 08/04/98 Page iiCopyright © 1998 GlenayrePrint Date: 08/20/98 Document Change Record Issue:1, Revision A Date:08/04/98 Changes:None, Original Glenayre Document Number: 9110.01196GL-T8100 Rev. A: 08/04/98GENERAL g1196s10.fm Print Date: 08/24/98Copyright © 1998 GlenayrePage: 10-1 10 GENERAL Information expressed in this section is intended to keep the instruciton manual current with respect to recent product updates. The GL-T8100 is frequency-selectable by speci- fying the appropriate internal frequency-determining hardware and software. Refer to Table 10-2 for the correct part number. 10.1 Applicable Documents This manual is incomplete without the document shown in Table 10-1, Applicable Documents. 10.2 Additional Specifications Table 10-2, Part Numbers of VCO/RF Amplifier Boards, identifies transmitter model additions to the existing Table 3-1 in the DSP exciter user manual, 9110.01021. 10.3 Additional Hardware An external low-pass filter, Figure 10-1, Low-Pass Filter, is part of the GL-T8100 and is required to meet emission standards. Table 10-1 Applicable Documents DocumentPart numberDescription DSP Exciter user manual 9110.01021This manual describes the features of the DSP exciter. GL2728 Power Supply9110.00622This manual describes the features of the GL2728 power supply Table 10-2 Part Numbers of VCO/RF Amplifier Boards Transmitter model VCO/RF amplifier board frequency band (MHz) VCO board assembly part number GL-T8100924 - 936263-0082-053 GL-T8100Glenayre Document Number: 9110.01196 GENERALRev. A: 08/04/98 Page: 10-2Copyright © 1998 GlenayrePrint Date: 08/24/98 Figure 10-1 Low-Pass Filter Glenayre Document Number: 9110.01196GL-T8100 Rev. A: 08/04/98GENERAL g1196s10.fm Print Date: 08/24/98Copyright © 1998 GlenayrePage: 10-3 10.4 Simplified Block-Diagram Description Refer to Figure 10-2, Simplified Block Diagram, in the following discussion. Inputs from the transmitter controller usually are one or two data bits, two channel-select bits, and keying input. Outputs to the controller are keying output indicator, various fault outputs, forward-power sample, and reflected-power sample. Figure 10-2 Simplified Block Diagram GL-T8100Glenayre Document Number: 9110.01196 GENERALRev. A: 08/04/98 Page: 10-4Copyright © 1998 GlenayrePrint Date: 08/24/98 Print Date: 06/10/98Copyright © 1998 Glenayre DSP ExciterRev. B: 06/11/98 Specifications subject to change without notice Copyright © 1998 Glenayre All rights reserved. No part of this work may be reproduced or copied in any form or by any means -- graphic, electronic, or mechanical, including photocopying, recording, taping, or information-retrieval system -- without written permission of Glenayre. DSP Exciter (EC) User Manual RELEASED PN 9110.01021 Revision B DSP ExciterGlenayre Document Number: 9110.01021 Document Change RecordRev. B: 06/11/98 Copyright © 1998 GlenayrePrint Date: 06/10/98 Document Change Record Issue:1, Revision A Date:11/24/97 Changes:None, Original Issue:1, Revision B Date:06/11/98 Changes:made 88-us changes to text and figures, created intdex Glenayre Document Number: 9110.01021DSP Exciter Rev. B: 06/11/98Table of Contents d1021_ti.toc Print Date: 06/10/98Copyright © 1998 GlenayrePage: -i Table of Contents 1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 1.1 Manual Scope . . . . . . . . . . . . . . . . . . . . . . . . 1-1 1.2 Applicable Documents . . . . . . . . . . . . . . . . . . . . 1-1 1.3 Glenayre Locations . . . . . . . . . . . . . . . . . . . . . . 1-1 1.3.1 Product Warranty Information . . . . . . . . . . . . . . . . . . 1-2 1.3.2 Service Warranty Information . . . . . . . . . . . . . . . . . . 1-2 2 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1 3 DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 3.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 3.2 Physical Description . . . . . . . . . . . . . . . . . . . . . 3-1 3.3 Simplified Block-Diagram Description . . . . . . . . . . . . . . 3-1 4 INSTALLATION AND SETUP . . . . . . . . . . . . . . . . . . . . . . . . . 4-1 4.1 Precautions and Hazards . . . . . . . . . . . . . . . . . . . . 4-1 4.2 Test Equipment and Tools Required . . . . . . . . . . . . . . . 4-1 4.3 Component and Adjustment Locations . . . . . . . . . . . . . . 4-1 4.4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . 4-1 4.4.1 Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1 4.4.2 Power Requirement . . . . . . . . . . . . . . . . . . . . . . . . 4-1 4.4.3 Input/Output Connections . . . . . . . . . . . . . . . . . . . . 4-2 4.4.4 Signal Functions . . . . . . . . . . . . . . . . . . . . . . . . . 4-2 4.4.5 Switches and Jumpers . . . . . . . . . . . . . . . . . . . . . . 4-3 4.5 Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4 4.6 Ultimate Disposition . . . . . . . . . . . . . . . . . . . . . 4-4 4.7 Grounding . . . . . . . . . . . . . . . . . . . . . . . . . 4-4 5 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1 5.1 Front-Panel Controls and Indicators . . . . . . . . . . . . . . . 5-1 5.2 Operating Instructions . . . . . . . . . . . . . . . . . . . . . 5-1 6 THEORY OF OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1 6.1 Exciter/PA Control . . . . . . . . . . . . . . . . . . . . . . 6-1 6.1.1 Reference Source . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

ID Label/Location Info

October 7, 1998 Jaunice Green Federal Communications Commission Equipment Authorization Divisions 7435 Oakland Mills Road Columbia, Maryland 21046 Subject: FCC Reference – 3757, BFLGL-T8100 Type Acceptance Application Dear Ms. Green: I am enclosing a photograph depicting the location of the FCC ID on Glenayre’s GL-T8100 paging transmitter. This photograph should resolve the ambiguity or omission in our Type Acceptance application. Please contact me at 217-221-6416 or [email protected] if additional information is needed. Sincerely CHAMAN L. BHARDWAJ Lead Compliance Engineer enclosure cc:Ron Lile Wireless Messaging Group One Glenayre Way Quincy, IL 62301 USA 217-221-6773 Wireless Messaging Group One Glenayre Way Quincy, IL 62301 USA (217) 223-3211 Location of the FCC ID: BFLG-T8100

ID Label/Location Info

Test Report

GLENAYRE ELECTRONICS FCC ID: BFLGL-T8100 1 of 47 September 1, 1998 Federal Communications Commission Authorized and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: Please find enclosed the application and technical exhibits for Type Acceptance of Glenayre Electronics’ transmitter, FCC ID BFLGL-T8100. This transmitter is an FM land-mobile base unit for use in the 924 to 960 MHertz frequency range with an RF power output of 0.25 Watt. Digital signal processing (DSP) and direct digital synthesis (DDS) techniques are used at low signal levels for processing, modulation, and RF generation. This application demonstrates FCC compliance for digital modulation to 4800 Baud. Glenayre requests that this transmitter be authorized to operate with three optional devices. 1. TX control (TXC) which houses a 10 MHertz reference oscillator and replaces the internal 10 MHertz reference oscillator in the transmitter. This optional unit has been approved for use with other Glenayre transmitters using the same exciter by the FCC under FCC ID: BFLGL-T8600, BFLGL-T8500, BFLGL-T8501, BFLGL-T8601 (and others) . 2. The GL-C2000 is also an external 10 MHertz reference source and controller. The GL-C2000 uses Global Positioning Satellite receivers for precision frequency control of the 10 MHertz oven-controlled crystal oscillator and timing synchronism of the system. This optional unit has been approved for use with Glenayre transmitters using the same exciter by the FCC under FCC ID: BFLGL-T8600, BFLGL-T8500, BFLGL-T8501, BFLGL- T8601 (and others). 3. The Motorola C-Net™ Platinum Series controller. This controller houses the 10 MHertz oscillator, which is the RF reference for the transmitter. Glenayre has characterized the performance of this oscillator over the temperature range of –30 to +50 degrees Centigrade. The Model Number for this controller: C-Net™ Platinum. Glenayre takes the responsibility of ensuring the performance of this oscillator assembly as presented in the technical exhibits is maintained as in Part 2.931. GLENAYRE ELECTRONICS FCC ID: BFLGL-T8100 2 of 47 This optional unit has been approved for use with other Glenayre transmitters using the same exciter by the FCC under FCC ID: BFLGL-T8600-CN. The use of the optional external 10 MHertz reference oscillators in no way degrades the spectral character of the BFLGL-T8100 as presented in this Type Acceptance submission. Sincerely, Chaman L. Bhardwaj Lead Compliance Engineer GLENAYRE ELECTRONICS FCC ID: BFLGL-T8100 3 of 47 TYPE APPROVAL APPLICATION FOR MODEL:GL-T8100 FCC ID:BFLGL-T8100 TEST DATES: AUGUST 10 THROUGH SEPTEMBER 1, 1998 TEST REPORT PREPRED BY: .................................... Chaman L. Bhardwaj LEAD COMPLIANCE ENGINEER APPROVED BY: ....................................... Joseph E. Jones, Jr., P.E., NCE SR. MANAGER COMPLIANCE GROUP CERTIFICATION OF TEST DATA GLENAYRE ELECTRONICS FCC ID: BFLGL-T8100 4 of 47 I hereby certify that the test data identified below were taken by myself, or under my direct supervision; that the tests were conduced according to accepted good engineering practice; and that the data are true and correct, according to my knowledge and belief. Standards used for measurements for the transmitter is TIA/EIA-603 Signed ________________________________Date: September 3, 1998 GLENAYRE ELECTRONICS FCC ID: BFLGL-T8100 5 of 47 TABLE OF CONTENTS Exhibit 1FCC ID Label Exhibit 2Technical Description Exhibit 3Test Procedures and Results Exhibit 4Construction Photographs Exhibit 5Appendix I, GL-C2000 High Stability Oscillator Exhibit 6Appendix II, GL-XXXXX Standard Stability Oscillator Exhibit 7Appendix III, TXC Exhibit 8Appendix IV, Motorola CNET Exhibit 9Technical Manuals Exhibit 10Schematics GLENAYRE ELECTRONICS FCC ID: BFLGL-T8100 6 of 47 EXHIBIT 1: EQUIPMENT IDENTIFICATION LABEL (FCC 2.1003) ______________________________________________________________________ BFLGL-T8100 NOTES: 1. Color - Background Black. Blocks (3 Plcs) & lettering to be natural aluminum color. 2. Pressure sensitive adhesive backing to be 3m 467 or equivalent. 3. Positioned vertically on std. strip. 4. Block Sizes - (A) 0.6 cm X 5.4 cm (B) 0.6 cm X 4.0 cm 5. Label must have manufacturer’s Identifier Mark. 6. Affixed to Rear of EXCITER Chassis GLENAYRE ELECTRONICS FCC ID: BFLGL-T8100 7 of 47 EXHIBIT 2: TECHNICAL SPECIFICATION: 1Type of emission16K0F3E, 14K4F1D, 9K6F1D 2Frequency Range924 to 960 MHz 3Operating Power Range0.25 Watts 4Maximum occupied bandwidth16 kHz [22.359 (b)(2), 90.210(g)] 5Maximum Deviation+/- 4.8 kHz 6Maximum Digital Information Rate (Bits per second) 2 level modulation - 4800 bps 4 level modulation - 9600 bps 7Final amplifier voltage and current Powered by 18-30 volt power supply and draws 1 ampere 8Function of each active circuitSee Technical Manual / Instruction Book 9Complete circuit diagramSee EXHIBIT 10 10Technical manualSee EXHIBIT 9 11Tune up procedureSee Technical Manual - EXHIBIT 9 12Frequency stabilizing deviceThe carrier frequency is controlled by an oven controlled crystal oscillator (OXCO) in all modulation modes 13aSpurious suppression deviceIn all modes of operation the transmitter uses two local oscillators to convert a 100 kHz signal to the output frequency. Frequency stability is derived directly from the OCXO. The first intermediate frequency and the second intermediate frequency (carrier frequency) are filtered to remove mixing products. The final power amplifier is followed by a low-pass filter to attenuate harmonics that may be produced. 13bModulation limiting circuitsAnalog and digital modulation are accomplished by digital processing. For any audio signal within the specified audio range, deviation is monitored by the DSP circuits and not allowed to exceed the set limit. Digital modulation is determined by the data state of the TTL compatible input. The input only recognizes two data states (1 and 0) and cannot be overdriven to cause over-modulation. 13cPower limiting circuitsPower ge…
