FCC ID.: BJM-TH1WD Date: August 20, 2021 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: Type of Confidentiality Requested Exhibit ☒ Permanent Block Diagrams ☐ Short Term External Photos ☐ Short Term Internal Photos ☒ Permanent Operation Description/Theory of Operation ☐ Permanent Parts List & Placement/BOM ☐ Permanent Tune-Up Procedure ☒ Permanent Schematics ☐ Short Term Test Setup Photos ☐ Short Term User’s Manual The above materials contain trade secrets and proprietary information not customarily Released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Sincerely, ------------------------------------------------------ Name: Chung Chang Title: Director Company name: Tatung Company

Report No.: 2161098R-E3032110120 Page: 1 of 8 Appendix 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo Report No.: 2161098R-E3032110120 Page: 2 of 8 (3) EUT Photo (4) EUT Photo Report No.: 2161098R-E3032110120 Page: 3 of 8 (5) EUT Photo (6) EUT Photo Report No.: 2161098R-E3032110120 Page: 4 of 8 (7) EUT Photo

Tatung Company FCC ID.: BJM-TH1WD 22 Chungshan N Road Sec 3 ,Taipei 10451 ,Taiwan Tel : 886-2-2592-5252 FCC ID Label

Tatung Company FCC ID.: BJM-TH1WD 22 Chungshan N Road Sec 3 ,Taipei 10451 ,Taiwan Tel : 886-2-2592-5252 The FCC ID will be placed on the equipment as shown in the photograph below.

Report No.: 2161098R-E3032110120 Page: 5 of 8 (8) EUT Photo (9) EUT Photo Report No.: 2161098R-E3032110120 Page: 6 of 8 (10) EUT Photo (11) EUT Photo Report No.: 2161098R-E3032110120 Page: 7 of 8 (12) EUT Photo (13) EUT Photo Report No.: 2161098R-E3032110120 Page: 8 of 8 (14) EUT Photo

Report No.: 2161098R-E3082100014 Page: 1 of 5 RF Exposure Evaluation Report Product Name : TUF GAMING H1 WIRELESS DONGLE Model No. : TUF GAMING H1 WIRELESS DONGLE FCC ID : BJM-TH1WD Applicant : Tatung Company Address : 22 Chungshan N Road Sec 3 ,Taipei 10451,Taiwan Date of Receipt : Jun. 27, 2021 Date of Declaration : Aug. 06, 2021 Report No. : 2161098R-E3082100014 Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of DEKRA Testing and Certification Co., Ltd. Measurement uncertainties evaluated for each testing system and associated connections are given here to provide the system information for reference. Compliance determinations do not take into account measurement uncertainties for each testing system, but are based on the results of the compliance measurement. Report No.: 2161098R-E3082100014 Page: 2 of 5 Issued Date: Aug. 06, 2021 Report No.: 2161098R-E3082100014 Product Name TUF GAMING H1 WIRELESS DONGLE Applicant Tatung Company Address 22 Chungshan N Road Sec 3 ,Taipei 10451,Taiwan Manufacturer Tatung Company Model No. TUF GAMING H1 WIRELESS DONGLE FCC ID. BJM-TH1WD Trade Name ASUS Applicable Standard KDB 447498 D01 v06 Minimum test separation distance ≥ 20 cm For low power devices Test Result Complied Documented By : ( Project Specialist / Ida Tung ) Tested By : ( Supervisor / Wen Lee ) Approved By : ( Manager / Tim Sung ) Report No.: 2161098R-E3082100014 Page: 3 of 5 Revision History Report No. Ve r s i o n Description Issued Date 2161098R-E3082100014 V1.0 Initial issue of report. Aug. 06, 2021 Report No.: 2161098R-E3082100014 Page: 4 of 5 1. GENERAL INFORMATION 1.1. EUT Description Product Name TUF GAMING H1 WIRELESS DONGLE Trade Name ASUS Model No. TUF GAMING H1 WIRELESS DONGLE FCC ID. BJM-TH1WD Frequency Range 2403.35MHz~2477.35MHz Channel Number 38CH Type of Modulation Pi/4 DQPSK Channel Control Auto Antenna Type Chip Antenna Antenna Gain Refer to the table “Antenna List” Channel Control Auto 1.2. Antenna List No. Manufacturer Part No. Antenna Type Peak Gain 1 Advanced Ceramic X Corp. AT3216-B2R7HAA_ Chip Antenna 0.5dBi for 2.4GHz Report No.: 2161098R-E3082100014 Page: 5 of 5 2. RF Exposure Evaluation 2.1. Standard Applicable According to 1.1307 (b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. 2.2. Measurement Result: According to KDB Publication 447498 D01, section 4.3.1, per the calculations of item 1 (Power(mW)/separation (mm)*sqrt(f(GHz)≤3.0), SAR is required as shown in the table below where calculated values are greater than 3.0: 1.) Operation frequency = 2450MHz and antenna separation distance = 5mm, SAR Test Exclusion Threshold = 10mW Frequency Band Maximum Peak EIRP power SAR Test Exclusion Threshold Calculated Threshold Value (≦3.0 SAR is not required) (dBuV/3m) (mW) (mW) 2403.35MHz 101.25 4 10 1.240 Note1: The SAR/MPE measurement is not necessary. Note2: The Maximum Peak EIRP power is refer to report No.: 2161098R-E3032110120 from the DEKRA.

Report No.: 2161098R-E3032110120 Page : 1 of 40 FCC Test Report Product Name TUF GAMING H1 WIRELESS DONGLE Model No. TUF GAMING H1 WIRELESS DONGLE FCC ID BJM-TH1WD Applicant Tatung Company Address 22 Chungshan N Road Sec 3 ,Taipei 10451,Taiwan Date of Receipt Jun. 27, 2021 Issued Date Aug. 02, 2021 Report No. 2161098R-E3032110120 Report Version V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of DEKRA Testing and Certification Co., Ltd. Measurement uncertainties evaluated for each testing system and associated connections are given here to provide the system information for reference. Compliance determinations do not take into account measurement uncertainties for each testing system, but are based on the results of the compliance measurement. Report No.: 2161098R-E3032110120 Page : 2 of 40 Test Report Issued Date: Aug. 02, 2021 Report No.: 2161098R-E3032110120 Product Name TUF GAMING H1 WIRELESS DONGLE Applicant Tatung Company Address 22 Chungshan N Road Sec 3 ,Taipei 10451,Taiwan Manufacturer Tatung Company Model No. TUF GAMING H1 WIRELESS DONGLE FCC ID BJM-TH1WD EUT Rated Voltage DC 5V (Power by USB) EUT Test Voltage DC 5V (Power by USB) Trade Name ASUS Applicable Standard FCC CFR Title 47 Part 15 Subpart C ANSI C63.4: 2014, ANSI C63.10: 2013 Test Result Complied Documented By : ( Project Specialist / Ida Tung ) Tested By : ( Senior Engineer / Ivan Chuang ) Approved By : ( Senior Engineer / Alan Chen ) Report No.: 2161098R-E3032110120 Page : 3 of 40 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ..................................................................................................... 5 1.1. EUT Description ............................................................................................................................ 5 1.2. Tested System Datails.................................................................................................................... 7 1.3. Configuration of Test System ........................................................................................................ 7 1.4. EUT Exercise Software ................................................................................................................. 7 1.5. Test Facility ................................................................................................................................... 8 1.6. List of Test Equipment .................................................................................................................. 9 1.7. Uncertainty .................................................................................................................................. 10 2. Conducted Emission .................................................................................................................. 11 2.1. Test Setup .................................................................................................................................... 11 2.2. Limits .......................................................................................................................................... 11 2.3. Test Procedure ............................................................................................................................. 12 2.4. Test Result of Conducted Emission ............................................................................................. 13 3. Radiated Emission ..................................................................................................................... 15 3.1. Test Setup .................................................................................................................................... 15 3.2. Limits .......................................................................................................................................... 16 3.3. Test Procedure ............................................................................................................................. 17 3.4. Test Result of Radiated Emission ................................................................................................ 18 4. Band Edge .................................................................................................................................. 32 4.1. Test Setup .................................................................................................................................... 32 4.2. Limits .......................................................................................................................................... 32 4.3. Test Procedure ............................................................................................................................. 33 4.4. Test Result of Band Edge ............................................................................................................ 34 5. Duty Cycle .................................................................................................................................. 38 5.1. Test Setup .................................................................................................................................... 38 5.2. Test Result of Duty Cycle ............................................................................................................ 39 6. EMI Reduction Method During Compliance Testing ............................................................ 40 Appendix 1: EUT Test Photographs Appendix 2: EUT Detailed Photographs Report No.: 2161098R-E3032110120 Page : 4 of 40 Revision History Report No. Ve r s i o n Description Issued Date 2161098R-E3032110120 …

Text truncated - open the document above for the full version.

Report No.: 2161098R-E3032110120 Page : 1 of 2 Appendix 1: EUT Test Setup Photographs Front View of Conducted Test Back View of Conducted Test Report No.: 2161098R-E3032110120 Page : 2 of 2 Front View of Radiated Test Front View of Radiated Test (Horn)
