BV8M7200M7200 700/800 MHz Mobile Radio

Operator’s Manual MM23016 Sep-05 M7200 Series Digital Mobile Radio MANUAL REVISION HISTORY REVISION DATE REASON FOR CHANGE - Sep. 2005 Initial Release. M/A-COM Technical Publications would particularly appreciate feedback on any errors found in this document and suggestions on how the document could be improved. Submit your comments and suggestions to: Wireless Systems Business Unit or fax your comments to: (434) 455-6851 M/A-COM, Inc. Technical Publications or e-mail us at: [email protected] 221 Jefferson Ridge Parkway Lynchburg, VA 24501 CREDITS This device is made under license under one or more of the following US patents: 4,590,473; 4,636,791; 5,148,482; 5,185,796; 5,271,017; 5,377,229; 4,716,407; 4,972,460; 5,502,767; 5,146,497; 5,164,986; 5,185,795. The voice coding technology embodied in this product is protected by intellectual property rights including patent rights, copyrights, and trade secrets of Digital Voice Systems, Inc. The user of this technology is explicitly prohibited from attempting to decompile, reverse engineer, or disassemble the Object Code, or in any other way convert the Object Code into human-readable form. OpenSky is a registered trademark of M/A-COM, Inc. All other brand and product names are trademarks, registered trademarks or service marks of their respective holders. NOTICE! This manual covers M/A-COM products manufactured and sold by M/A-COM, Inc. Repairs to this equipment should be made only by an authorized service technician or facility designated by the supplier. Any repairs, alterations or substitutions of recommended parts made by the user to this equipment not approved by the manufacturer could void the user's authority to operate the equipment in addition to the manufacturer's warranty. This manual is published by M/A-COM, Inc., without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by M/A-COM, Inc., at any time and without notice. Such changes will be incorporated into new editions of this manual. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose, without the express written permission of M/A-COM, Inc. Copyright © 2005, M/A-COM, Inc. All rights reserved. 2 3 TABLE OF CONTENTS Page 1 SAFETY SYMBOL CONVENTION.......................................................6 2 RF ENERGY EXPOSURE INFORMATION ........................................7 2.1 RF ENERGY EXPOSURE AWARENESS, CONTROL INFORMATION, AND OPERATION INSTRUCTIONS FOR FCC OCCUPATIONAL USE REQUIREMENTS .............................7 2.1.1 Federal Communications Commission Regulations...........8 2.2 COMPLIANCE WITH RF EXPOSURE STANDARDS....................8 2.2.1 Mobile Antennas................................................................9 2.2.2 Approved Accessories .....................................................10 2.2.3 Contact Information .........................................................10 3 OPERATION SAFETY RECOMMENDATIONS...............................11 3.1 TRANSMITTER HAZARDS ...........................................................11 3.2 SAFE DRIVING RECOMMENDATIONS ......................................11 4 OPERATING RULES AND REGULATIONS.....................................13 4.1 OPERATING TIPS ...........................................................................14 5 PRODUCT DESCRIPTION ..................................................................15 5.1 VOICE OPERATION .......................................................................16 5.2 DATA OPERATION ........................................................................16 5.3 REMOTE CONTROL HEAD OPERATION ...................................16 5.4 INTERCOM OPERATION...............................................................17 5.5 PERSONALITY................................................................................17 5.5.1 Profiles.............................................................................17 5.5.2 Talk Groups .....................................................................18 5.6 GPS OPTION....................................................................................18 5.7 FRONT PANEL ................................................................................19 5.8 TRANSCEIVER REAR PANEL ......................................................20 5.9 CONTROL HEAD REAR PANEL...................................................21 6 OPERATION ..........................................................................................22 6.1 CH-103 FRONT PANEL COMPONENTS ......................................22 6.2 DISPLAY OVERVIEW....................................................................24 6.2.1 Network Connectivity Icon ..............................................24 6.2.2 Volume Level Icon ..........................................................24 6.2.3 Display’s Top Line..........................................................25 6.2.4 Display’s Bottom Line .....................................................25 6.2.5 Dwell Display ..................................................................25 6.2.6 Menu Display and Control Area ......................................28 6.2.7 Dwell Display User-Selectable ........................................28 6.3 BASIC RADIO OPERATION ..........................................................29 6.3.1 Turning the Radio On ......................................................29 6.3.2 Self-Test...........................................................................32 6.3.3 “Logging In” to the Network ...........................................32 6.3.4 Logging off the Network..................................................33 6.3.5 Turning the Radio Off......................................................33 6.3.6 Receiving and Transmitting V…

Text truncated - open the document above for the full version.

Installation Manual MM-007024-001 Sep-05 M7200 Series Mobile Radio Trunk-Mount Full-Duplex Mobile Radio with Control Head for OpenSky Radio Networks MM-007024-001 2 MANUAL REVISION HISTORY REVISION DATE REASON FOR CHANGE — September 2005 Initial release. M/A-COM Technical Publications would particularly appreciate feedback on any errors found in this document and suggestions on how the document could be improved. Submit your comments and suggestions to: Wireless Systems Business Unit M/A-COM, Inc. or fax your comments to: (434) 455-6851 Technical Publications 221 Jefferson Ridge Parkway or e-mail us at: [email protected] Lynchburg, VA 24501 CREDITS M/A-COM, OpenSky and EDACS are registered trademarks of M/A-COM, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other brand and product names are trademarks, registered trademarks, or service marks of their respective holders. NOTICE This device is made under license under one or more of the following U.S. Patents: 4,590,473; 4,636,791; 5,148,482; 5,185,796; 5,271,017; 5,377,229; 4,716,407; 4,972,460; 5,502,767; 5,146,497; 5,164,986; 5,185,795. The voice coding technology embodied in this product is protected by intellectual property rights including patent rights, copyrights, and trade secrets of Digital Voice Systems, Inc. The user of this technology is explicitly prohibited from attempting to decompile, reverse engineer, or disassemble the Object Code, or in any other way convert the Object Code into human-readable form. This manual covers M/A-COM products manufactured and sold by M/A-COM, Inc. Repairs to this equipment should be made only by an authorized service technician or facility designated by the supplier. Any repairs, alterations or substitution of recommended parts made by the user to this equipment not approved by the manufacturer could void the user’s authority to operate the equipment in addition to the manufacturer’s warranty. The software contained in this device is copyrighted by M/A-COM, Inc. Unpublished rights are reserved under the copyright laws of the United States. This manual is published by M/A-COM, Inc. without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by M/A-COM, Inc., at any time and without notice. Such changes will be incorporated into new editions of this manual. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose, without the express written permission of M/A-COM, Inc. Copyright © 2005, M/A-COM, Inc. All rights reserved. MM-007024-001 3 TABLE OF CONTENTS Page 1 SAFETY INFORMATION .......................................................................................................... 5 1.1 SYMBOLS USED IN THIS MANUAL................................................................................... 5 1.2 RF ENERGY EXPOSURE AWARENESS AND CONTROL INFORMATION FOR FCC OCCUPATIONAL USE REQUIREMENTS ................................................................... 5 1.2.1 Federal Communications Commission Regulations .................................................................. 6 1.3 COMPLIANCE WITH RF EXPOSURE STANDARDS......................................................... 6 1.3.1 Mobile Antennas ........................................................................................................................ 7 1.3.2 Approved Accessories ................................................................................................................ 7 1.3.3 Contact Information ................................................................................................................... 7 1.4 OCCUPATIONAL SAFETY GUIDELINES AND SAFETY TRAINING INFORMATION....... 7 1.5 COMMON HAZARDS ......................................................................................................... 8 2 SPECIFICATIONS ..................................................................................................................... 9 2.1 GENERAL ........................................................................................................................... 9 2.2 TRANSCEIVER................................................................................................................... 9 2.3 REGULATORY ................................................................................................................. 10 3 INTRODUCTION ..................................................................................................................... 11 3.1 GENERAL DESCRIPTION................................................................................................ 11 3.2 RELATED DOCUMENTS.................................................................................................. 13 3.3 CONTACTING M/A-COM FOR TECHNICAL ASSISTANCE ............................................ 13 4 UNPACKING AND CHECKING EQUIPMENT........................................................................ 14 4.1 MATERIALS ......................................................................................................................14 4.2 MATERIAL INSPECTION ................................................................................................. 17 5 PLANNING THE INSTALLATION........................................................................................... 18 5.1 GENERAL INFORMATION ............................................................................................... 18 5.2 TOOLS REQUIRED .......................................................................................................... 18 5.3 LOCATING COMPONENTS ............................................................................................. 20 6 MOUNTING THE MOBILE RADIO IN THE TRUNK ......................…

Text truncated - open the document above for the full version.

M/A-COM, Inc. 221 Jefferson Ridge Parkway Lynchburg, VA 24501 Telephone: 434.455.9527 FAX: 434.455.6851 [email protected] www.macom.com September 26, 2005 American TCB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 Subject: FCC ID: BV8M7200 Original submission M/A-COM seeks Equipment Authorization Grant for M7200 700/800 MHz mobile radio equipment. Exhibits include photographs, schematics, parts list, block diagram, tune up procedure, FCC Part 90 and 15 compliance verification reports, antenna data sheets, and measurement data. An Operator’s and mobile radio installation manual is included in the exhibit submission as well as an attestation addressing AFC operation as required in the 700 MHz band rules. Modes of operation for this dual band radio are both digital and analog, with trunked and conventional capability. Channelization assignment is provided at the time of factory configuration and over-the- air assignment. NPSPAC operation and talk around capability are included as well. This portable radio is intended to be Granted operation in both the old and new configurations of the 800 MHz band. Emissions designators reflect this as applied across the band. Confidentiality letter and Rhein Tech Laboratories, Inc. agent authorization letter to act on M/A-COM’s behalf for this original submission, have been provided as exhibits also. Thank you for your kind consideration and timely review for this new product entry to the M/A-COM trunked LMR product family. Sincerely, Daryl Popowitch Regulatory Manager, Engineering Project Manager M/A-COM, Inc. – Lynchburg, VA

M/A-COM, Inc. 221 Jefferson Ridge Parkway Lynchburg, VA 24501 Telephone: 434.455.9527 FAX: 434.455.6851 [email protected] www.macom.com September 26, 2005 American TCB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 Subject: FCC ID: BV8M7200 Original submission CONFIDENTIALITY M/A-COM, Inc. wishes to submit this confidentiality letter for the record on FCC ID: BV8M7200, M7200 700/800 MHz mobile radio equipment. M/A-COM, Inc. is requesting that schematic diagrams, parts lists, block diagrams, tune up procedure, and operational descriptions, including operational attestations, for this original submission not be made routinely available for public inspection. M/A-COM, Inc. considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457 and Section 0.459 of the FCC rules. Thank you for your attention to this matter. Daryl Popowitch Regulatory Manager Engineering Project Manager M/A-COM, Inc. – Lynchburg, VA

Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 89 of 93 APPENDIX O: EXTERNAL PHOTOGRAPHS PHOTOGRAPH 6: FRONT VIEW OF EUT PHOTOGRAPH 7: REAR VIEW OF EUT

Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 79 of 93 APPENDIX F: LABEL INFORMATION PHOTOGRAPH 1: FCC ID/IC ID LABEL SAMPLE PHOTOGRAPH 2: RF LABEL SAMPLE Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 80 of 93 PHOTOGRAPH 3: ID AND RF LABEL LOCATIONS ON REAR OF UNIT FCC ID/IC ID Label Location RF Label Sample Here

Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 90 of 93 APPENDIX P: INTERNAL PHOTOGRAPHS PHOTOGRAPH 8: RF BOARD TOP VIEW

Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 91 of 93 PHOTOGRAPH 9: RF BOARD BOTTOM VIEW

Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 92 of 93 PHOTOGRAPH 10: PK BOARD TOP VIEW Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 93 of 93 PHOTOGRAPH 11: PK BOARD BOTTOM VIEW

Engineering and Testing for EMC and Safety Compliance 360 Herndon Parkway Suite 1400 Herndon, VA 20170 Phone: 703-689-0368 Fax: 703-689-2056 T T Y Y P P E E C C E E R R T T I I F F I I C C A A T T I I O O N N R R E E P P O O R R T T M/A-COM, Inc. 221 Jefferson Ridge Parkway Lynchburg, VA 28061 Daryl Popowitch Phone: (434) 455-9527 E-Mail: [email protected] MODEL: M7200 Series Mobile Radio 700/800 MHz FCC ID: BV8M7200 IC: 3670A-M7200 September 20, 2005 STANDARDS REFERENCED FOR THIS REPORT PART 2: 2003 FREQUENCY ALLOCATIONS AND RADIO TREATY MATTERS; GENERAL RULES AND REGULATIONS PART 15: 2003 RADIO FREQUENCY DEVICES - §15.109: RADIATED EMISSIONS LIMITS PART 90: 2003 PRIVATE LAND MOBILE RADIO SERVICES ANSI C63.4-2003 A MERICAN NATIONAL STANDARD FOR METHODS OF MEASUREMENT OF RADIO NOISE EMISSIONS FROM LOW –VOLTAGE ELECTRICAL AND ELECTRONIC EQUIPMENT IN THE RANGE OF 9 KHZ – 40 GHZ ANSI/TIA/EIA603 - 2002 L AND MOBILE FM OR PM COMMUNICATIONS EQUIPMENT – MEASUREMENT AND PERFORMANCE STANDARDS ANSI/TIA/EIA –102.CAAA; 2002 D IGITAL C4FM/CQPSK TRANSCEIVER MEASUREMENT METHODS RSS-119; Issue 6; 2000 LAND MOBILE AND FIXED RADIO TRANSMITTERS AND RECEIVERS 27.41 TO 960.0 MHZ ICES-003: 1997 SPECTRUM MANAGEMENT; INTERFERENCE-CAUSING EQUIPMENT STANDARD – DIGITAL APPARATUS REPORT PREPARED BY TEST ENGINEER: DANIEL BIGGS Document Number: 2005131/QRTL05-217 This report may not be reproduced, except in full, without the full written approval of Rhein Tech Laboratories, Inc. Test results relate only to the item tested. Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 2 of 93 Frequency Range (MHz) Measured Output Power (W) Conducted Frequency Tolerance (ppm) Modulation Mode Emission Designator 806-824 14.3 1.5 P25 (digitized data) Trunked/Conventional 8K4F1D 806-824 14.6 1.5 P25 (digitized voice) Trunked/Conventional 8K4F1E 851-869 14.4 1.5 P25 (digitized data) T/A 8K4F1D 851-869 14.3 1.5 P25 (digitized voice) T/A 8K4F1E 806-824 14.2 1.5 OTP SMR/NPSPAC Trunked 12K1F9W 806-809 15.2 1.5 Analog FM (NPSPAC) Trunked/Conventional 14K0F3E 806-821 15.1 1.5 Analog FM (SMR) Trunked/Conventional 16K0F3E 821-824 15.4 1.5 Analog FM (SMR) Trunked/Conventional 16K0F3E 821-824 15.2 1.5 Analog FM (NPSPAC) Trunked/Conventional 14K0F3E 851-854 14.8 1.5 Analog FM (NPSPAC) T/A 14K0F3E 851-869 14.4 1.5 Analog FM (SMR) T/A 16K0F3E 866-869 14.3 1.5 Analog FM (NPSPAC) T/A 14K0F3E 806-809 14.4 1.5 2-level (digitized data) NPSPAC Trunked/Conventional 11K9F1D 806-809 14.4 1.5 2-level (digitized voice) NPSPAC Trunked/Conventional 11K9F1E 806-809 14.3 1.5 2-level (digitized data) SMR Trunked/Conventional 14K2F1D 806-809 14.3 1.5 2-level (digitized voice) SMR Trunked/Conventional 14K2F1E 809-824 14.2 1.5 2-level (digitized data) SMR Trunked/Conventional 14K2F1D 809-824 14.2 1.5 2-level (digitized voice) SMR Trunked/Conventional 14K2F1E 821-824 14.2 1.5 2-level (digitized data) NPSPAC Trunked/Conventional 11K9F1D 821-824 14.2 1.5 2-level (digitized voice) NPSPAC Trunked/Conventional 11K9F1E 851-854 15.2 1.5 2-level (digitized data) NPSPAC T/A 11K9F1D 851-854 15.2 1.5 2-level (digitized voice) NPSPAC T/A 11K9F1E 851-854 15.1 1.5 2-level (digitized data) SMR T/A 14K2F1D 851-854 15.1 1.5 2-level (digitized voice) SMR T/A 14K2F1E 854-866 15.1 1.5 2-level (digitized data) SMR T/A 14K2F1D 854-866 15.1 1.5 2-level (digitized voice) SMR T/A 14K2F1E 866-869 15.2 1.5 2-level (digitized data) SMR T/A 14K2F1D 866-869 15.2 1.5 2-level (digitized voice) SMR T/A 14K2F1E 866-869 15.4 1.5 2-level (digitized data) NPSPAC T/A 11K9F1D 866-869 15.4 1.5 2-level (digitized voice) NPSPAC T/A 11K9F1E Frequency Range (MHz) Measured Output Power (W) Conducted Frequency Tolerance (ppb) Modulation Mode Emission Designator 764-767, 773-776, 794-797, 803-806 14.0 400 P25 (digitized data) T/A, Trunked/Conventional 8K4F1D 764-767, 773-776, 794-797, 803-806 14.0 400 P25 (digitized voice) T/A, Trunked/Conventional 8K4F1E 794-797, 803-806 14.0 400 OTP Trunked 12K1F9W 764-767, 773-776, 794-797, 803-806 15.0 400 Analog FM (12.5kHz spaced) T/A, Trunked/Conventional 11K0F3E Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 3 of 93 T ABLE OF CONTENTS 1 GENERAL INFORMATION ......................................................................................................................................... 8 1.1 TEST FACILITY ..................................................................................................................................................................... 8 1.2 RELATED SUBMITTAL(S)/GRANT(S) ................................................................................................................................... 8 2 CONFORMANCE STATEMENT ................................................................................................................................. 9 3 TESTED SYSTEM DETAILS .................................................................................................................................... 11 4 FCC RULES AND REGULATIONS PART 2 §2.1033(C)(8) VOLTAGES AND CURRENTS THROUGH THE FINAL AMPLIFYING STAGE ....................................................................................................................................................... 13 5 FCC RULES AND REGULATIONS PART 2 §2.1046(A): RF POWER OUTPUT: CONDUCTED; PART 90 §90.541(C): TRANSMITTING POWER LIMITS; RSS-119 §6.2: OUTPUT POWER TEST............................................. 14 5.1 TEST PROCEDURE ............................................................................................................................................................ 14 5.2 TEST DATA ..........................…

Text truncated - open the document above for the full version.

Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 42 of 93 9 FCC RULES AND REGULATIONS PART 2 §2.1049(C)(1): OCCUPIED BANDWIDTH; PART 90 §90.543(D): AUTHORIZED BANDWIDTH; RSS-119 §6.4: EMISSIONS MASKS Occupied Bandwidth - Compliance with the Emission Masks 9.1 Test Procedure ANSI/TIA/EIA-603-2002, section 2.2.11 and TIA/EIA-102.CAAA-2002 section 2.2.5 Device with digital modulation: Modulated to its maximum extent using a pseudo-random data sequence – 19,200 bps for OTP and 9,600 bps for P25 and EDACS modes. 9.2 Test Data PLOT 9-1: OCCUPIED BANDWIDTH – 806.0125 MHZ; OCF; NPSPAC (MASK B) Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 43 of 93 PLOT 9-2: OCCUPIED BANDWIDTH – 806.0125 MHZ; OCF; SMR (MASK B) PLOT 9-3: OCCUPIED BANDWIDTH – 823.9875 MHZ; OCF; NPSPAC (MASK B) Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 44 of 93 PLOT 9-4: OCCUPIED BANDWIDTH – 823.9875 MHZ; OCF; SMR (MASK B) PLOT 9-5: OCCUPIED BANDWIDTH – 851.0125 MHZ; OCF; NPSPAC (MASK B) Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 45 of 93 PLOT 9-6: OCCUPIED BANDWIDTH – 851.0125 MHZ; OCF; SMR (MASK B) PLOT 9-7: OCCUPIED BANDWIDTH – 868.9875 MHZ; OCF; NPSPAC; (MASK B) Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 46 of 93 PLOT 9-8: OCCUPIED BANDWIDTH – 868.9875 MHZ; OCF; SMR; (MASK B) PLOT 9-9: OCCUPIED BANDWIDTH – 794.0125 MHZ; OCF; (MASK B) Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 47 of 93 PLOT 9-10: OCCUPIED BANDWIDTH – 805.9875 MHZ; OCF; (MASK B) PLOT 9-11: OCCUPIED BANDWIDTH – 764.0125 MHZ; OCF; (MASK B) Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 48 of 93 PLOT 9-12: OCCUPIED BANDWIDTH – 775.9875 MHZ; OCF; (MASK B) PLOT 9-13: OCCUPIED BANDWIDTH – 806.0125 MHZ; OTP; NPSPAC; (MASK H) Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 49 of 93 PLOT 9-14: OCCUPIED BANDWIDTH – 806.0125 MHZ; OTP; SMR; (MASK G) PLOT 9-15: OCCUPIED BANDWIDTH – 823.9875 MHZ; OTP; NPSPAC; (MASK H)

Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 50 of 93 PLOT 9-16: OCCUPIED BANDWIDTH – 823.9875 MHZ; OTP; SMR; (MASK G) PLOT 9-17: OCCUPIED BANDWIDTH – 806.0125 MHZ; P25; NPSPAC; (MASK H) Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 51 of 93 PLOT 9-18: OCCUPIED BANDWIDTH – 806.0125 MHZ; P25; SMR; (MASK G) PLOT 9-19: OCCUPIED BANDWIDTH – 823.9875 MHZ; P25; NPSPAC; (MASK H) Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 52 of 93 PLOT 9-20: OCCUPIED BANDWIDTH – 823.9875 MHZ; P25; SMR; (MASK G) PLOT 9-21: OCCUPIED BANDWIDTH – 851.0125 MHZ; P25 TALKAROUND; NPSPAC; (MASK H) Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 53 of 93 PLOT 9-22: OCCUPIED BANDWIDTH – 851.0125 MHZ; P25 TALKAROUND; SMR; (MASK G) PLOT 9-23: OCCUPIED BANDWIDTH – 868.9875 MHZ; P25 TALKAROUND; NPSPAC; (MASK H) Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 54 of 93 PLOT 9-24: OCCUPIED BANDWIDTH – 868.9875 MHZ; P25 TALKAROUND; SMR; (MASK G) PLOT 9-25: OCCUPIED BANDWIDTH – 851.0125 MHZ; EDACS; NPSPAC; (MASK H) Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 55 of 93 PLOT 9-26: OCCUPIED BANDWIDTH – 851.0125 MHZ; EDACS; SMR; (MASK G) PLOT 9-27: OCCUPIED BANDWIDTH – 868.9875 MHZ; EDACS; NPSPAC; (MASK H) Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 56 of 93 PLOT 9-28: OCCUPIED BANDWIDTH – 868.9875 MHZ; EDACS; SMR; (MASK G) TABLE 9-1: TEST EQUIPMENT USED FOR TESTING OCCUPIED BANDWIDTH RTL Asset # Manufacturer Model Part Type Serial Number Calibration Date 901215 Hewlett Packard 8596EM EMC Analyzer (9 kHz - 12.8 GHz) 3826A00144 09/08/05 00067 Hewlett Packard 8564E Portable Spectrum Analyzer (9 kHz - 40 GHz) 3643A00657 07/16/06 TEST PERSONNEL: Daniel Biggs August 8, 17, 18, 2005 Test Technician/Engineer Signature Dates Of Test

Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: M7200 Series Mobile Radio Suite 1400 FCC ID: BV8M7200 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Report #: 2005131 57 of 93 10 FCC RULES AND REGULATION PART 2 §2.1055: FREQUENCY STABILITY; PART 90 §90.539: FREQUENCY STABILITY; RSS-119 §7: FREQUENCY STABILITY 10.1 Test Procedure ANSI/TIA/EIA-603-2002, section 2.2.2 The carrier frequency stability is the ability of the transmitter to maintain an assigned carrier frequency. The EUT was evaluated over the temperature range -30°C to +60°C. The temperature was initially set to -30°C and a 2-hour period was observed for stabilization of the EUT. The frequency stability was measured within one minute after application of primary power to the transmitter. The temperature was raised at intervals of 10 degrees centigrade through the range. A ½-hour period was observed to stabilize the EUT at each measurement step and the frequency stability was measured within one minute after application of primary power to the transmitter. Additionally, the power supp…
