BYM1408Base Transceiver

User Guide FreeSpeakEdge™ User Guide Part Number: 399G304 Rev A Date: April 22, 2020 FreeSpeak Edge | User Guide Document reference FreeSpeak Edge™ User Guide 399G304 Rev A Legal disclaimers Copyright © 2020 HME Clear-Com Ltd All rights reserved Clear-Com, the Clear-Com logo, and Clear-Com Concert are trademarks or registered trademarks of HM Electronics, Inc. The software described in this document is furnished under a license agreement and may be used only in accordance with the terms of the agreement. The product described in this document is distributed under licenses restricting its use, copying, distribution, and decompilation / reverse engineering.No part of this document may be reproduced in any form by any means without prior written authorization of Clear-Com, an HME Company. Clear-Com Offices are located in California, USA; Cambridge, UK; Dubai, UAE; Montreal, Canada; and Beijing, China. Specific addresses and contact information can be found on Clear- Com’s corporate website: www.clearcom.com Clear-Com contacts: Americas and Asia-Pacific Headquarters California, United States Tel: +1 510 337 6600 Email: [email protected] Europe, Middle East, and Africa Headquarters Cambridge, United Kingdom Tel: +44 1223 815000 Email: [email protected] China Office Beijing Representative Office Beijing, P.R. China Tel: +8610 65811360/65815577 Page 2 FreeSpeak Edge | User Guide Table ofcontents 1Important Safetyinstructions6 1.1 Safetysymbols7 2Introduction to FreeSpeakEdge™8 2.1 FreeSpeakEdge5 GHz8 2.2 Systemcapacity9 3InstallingFreeSpeakEdge10 3.1 InstallingtheFreeSpeakEdgetransceiver10 3.2 Clear-Comcablerecommendations12 3.3 Daisy-chaintransceivers13 3.4 InstallingandremovinganE-IPA-HX card14 3.5 AddinganE-IPA-HX cardto thesoftware 14 3.6 ConfiguringtheE-IPA-HX cardforFreeSpeakEdge15 3.7 BeltpackroamingbetweenE-IPA-HX cards16 3.8 ConnectingtheFreeSpeakEdgetransceivers to a matrix17 3.9 Addingtransceivers to thematrix21 3.10 Beltpackroles27 3.11 Registeringthebeltpackto a matrix29 3.12 Connectthebeltpacks31 3.13 Radio Frequency(RF) channelselectionandpowersettings31 3.14 De-registerbeltpacks froma system32 4Sitesurveyfeatures34 4.1 Transceiverstandalonemode34 4.2 LocalRF scanusinga beltpack35 5RF channel selection 5GHz37 5.1 Radio Frequency(RF) channelselectionandpowersettings 39 5.2 Channelselection40 5.3 Channelre-use41 5.4 UsingDynamicFrequencySelection(DFS) channels43 5.5 RadarscanninginDFSchannels44 5.6 Transceiver-excludedchannels45 5.7 Wireless RegulatoryRegion(WRR)46 5.8 ChangeRF channels ontheEdgetransceiver47 6OperatingtheEdgebeltpack 49 6.1 Topcontrols anddisplay 49 Page 3 FreeSpeak Edge | User Guide 6.2 Frontcontrols50 6.3 Beltpackbottomconnectors50 6.4 Beltpackbatteries andpower50 6.5 Menumode52 6.6 Use/persistlocalsettings (beltpacks)52 6.7 Edgebeltpackmenuaccess53 6.8 FreeSpeakEdgebeltpackmenus55 7OperatingtheEdgetransceiver70 7.1 IPrating(ProtectionMarking)70 7.2 FreeSpeakEdgetransceiverconnectorpanel71 7.3 Poweringthetransceiver71 7.4 Edgetransceiverstatus LEDs72 7.5 Resetthetransceiverto default75 7.6 Portsecuritysettings75 7.7 Networkandsynchronization76 7.8 Generalnetworkandswitchingrules76 7.9 Spareparts77 8UpgradingFreeSpeakEdge 78 8.1 UpgradingFreeSpeakEdgetransceivers 78 8.2 UpgradingFreeSpeakEdgebeltpacks79 9Specifications 81 9.1 FreeSpeakEdgebeltpack 81 9.2 FreeSpeakEdgetransceiver83 9.3 FreeSpeakEdgebatterychargerandbattery84 9.4 Transceivermodels (regionalvariations)84 9.5 Transmissionmethod85 9.6 Noticeaboutspecifications85 10Regulatorycompliance86 10.1 Partnumbers andregulatorymodels87 10.2 FCCnotice87 10.3 FCC/IC/ECRF exposurewarning88 10.4 Industrycanada compliancestatement88 10.5 Koreannotice89 10.6 Japannotice89 10.7 Australia compliancestatement89 10.8 New Zealandcompliancestatement90 Page 4 FreeSpeak Edge | User Guide 10.9 EuropeanUnion(CE mark)90 10.10 WasteElectricalandElectronicEquipment(WEEE)91 10.11 GeneralBatterySafetyInstructions forBatteryModels:BAT41,BAT50,BAT60, BAT70,BAT8091 10.12배터리 모델에 대한 일반 배터리 안전 지침:BAT41,BAT50,BAT60,BAT70, BAT8093 10.13 BAT41,BAT50,BAT60,BAT70,BAT8095 Page 5 FreeSpeak Edge | User Guide 1Important Safetyinstructions The following safety instructions apply: lRead these instructions. lKeep these instructions. lHeed all warnings. lFollow all instructions. lDo not use this apparatus near water. lClean only with dry cloth. lDo not block any ventilation openings.Install in accordance with the manufacturer’s instructions. lDo not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. lDo not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. lProtect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. lOnly use attachments/accessories specified by the manufacturer. lUse only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. lUnplug this apparatus during lightning storms or when unused for long periods of time. lRefer all servicing to qualified service personnel.Servicing is required when the apparatus has been damaged in any way, such as power-cord supply or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. lUse only chargers provided by HME/Clear-Com to charge the battery packs or beltpacks: lBAT80 Battery pack and beltpack charger manufactured by HME/Clear-Com lThe beltpack can also be char…

Text truncated - open the document above for the full version.

HM Electronics, Inc. | 2848 Whiptail Loop | Carlsbad, CA 92010 800.848.4468 | www.hme.com Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: BYM1408 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Type of Confidentiality Requested Exhibit Type ☐Short Term ☑Permanent Block Diagrams ☐Short Term External Photos ☑Short Term ☐Permanent* Internal Photos ☐Short Term ☑Permanent Operation Description ☐Short Term ☐Permanent Parts List/BOM ☐Short Term ☑Permanent Schematics ☐Short Term Test Setup Photos ☐Short Term ☐Permanent* User manual *Requires further justification before permanent confidentiality will be allowed. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below for an initial period of 180 (ie - “45”, “90” or “180”) days. Sincerely, Client’s signature: Client’s name: Douglas Paul Sieh Client’s title: Electrical Compliance Engineering Supervisor Company Name: HM Electronics, Inc. Company Address: 2848 Whiptail Loop, Carlsbad, CA 92010, USA Main: +1-858-535-6000 Fax: +1-858-452-7207

HM Electronics, Inc. | 2848 Whiptail Loop | Carlsbad, CA 92010 800.848.4468 | www.hme.com External photos for model 1408-US FRONT VIEW REAR VIEW HM Electronics, Inc. | 2848 Whiptail Loop | Carlsbad, CA 92010 800.848.4468 | www.hme.com LEFT VIEW RIGHT VIEW HM Electronics, Inc. | 2848 Whiptail Loop | Carlsbad, CA 92010 800.848.4468 | www.hme.com TOP VIEW BOTTOM VIEW

HM Electronics, Inc. | 2848 Whiptail Loop | Carlsbad, CA 92010 800.848.4468 | www.hme.com Base Transceiver model 1408-US Label

HM Electronics, Inc. | 2848 Whiptail Loop | Carlsbad, CA 92010 800.848.4468 | www.hme.com Internal photos for model 1408-US MAIN BOARD – TOP VIEW HM Electronics, Inc. | 2848 Whiptail Loop | Carlsbad, CA 92010 800.848.4468 | www.hme.com MAIN BOARD – BOTTOM VIEW

FCC MPE Evaluation (FCC ID: BYM1408) RF Exposure Requirements: 47 CFR §1.1307(b) RF Radiation Exposure Limits: 47 CFR §1.1310 RF Radiation Exposure Guidelines: FCC OST/OET Bulletin Number 65 EUT Frequency Band: 2402-2480MHz Limits for General Population/Uncontrolled Exposure in the band of: 300 - 1500 MHz, Power Density Limit: f/1500 mW/cm2 Limits for General Population/Uncontrolled Exposure in the band of: 1500 - 100,000 MHz Power Density Limit: 1 mW / cm 2 Equation: S = PG / 4R 2 or R = √PG / 4S Where, S = Power Density P = Power Input to Antenna G = Antenna Gain R = distance to the center of radiated antenna ____________________________________________________________________________________________________________ Prediction distance 20 cm EUT: Base Transceiver Radio Frequency (MHz) Max Conducted Output Power (dBm) Antenna Gain (dBi) Separation distance (cm) Power Density (mW/ cm 2 ) MPE Limit (mW/ cm 2 ) BLE 2402-2480 7.074 2.5 20 0.0018 1 5GHz 5180-5240 24.04 4 20 0.1267 1 5GHz 5260-5320 22.35 4 20 0.0858 1 5GHz 5500-5720 21.98 4 20 0.0788 1 5GHz 5745-5825 24.00 4 20 0.1255 1 The BLE is able to transmit simultaneously with WLAN. The ratio = 0.0018/1 + 0.1267/1 = 0.1285 < 1.0 The above results show that the device complies with the MPE requirement. Completed By: David Zhang Vista Laboratories, Inc. 1261 Puerta Del Sol, San Clemente, CA 92673 Date: May 12th, 2020
