BYM7002Nexeo AIO headset

Quick Reference Installation Guide HM ELECTRONICS, INC. 2848 Whiptail Loop, Carlsbad, CA 92010 USA Phone: 1-800-848-4468 Fax: 858-552-0172 Website: www.hme.com Email: [email protected] HME# PUB - 000xx Rev A 09/01/20 NEXEO AIO HS7000 HEADSET The AIO HS7000 Headset is an all-in-one headset for communicating with customers in a drive-th- ru lane environment and with fellow employees privately or in group chats. It uses one BAT70 lithium-ion battery. With moderate use in a normal environment, the headset will operate for approxi- mately six to eight hours on a single battery charge and will alert you when the battery charge is low. SETUP AND OPERATION Pairing your Headset (AIO HS7000): 1. Insert a fully charged BAT70 battery into the battery holder of the headset (see Fig. 1). The battery clicks securely into place. 2. Press the blue power button to turn on the headset (see Fig. 1). The Headset status LED (Fig. 1) turns on green and blinks, alternating between green and red, indi- cating you now need to pair the headset. 3. Hold the keypad side of the headset against the Headset Pairing Ring (solid blue circle) on the Base Station to pair. Pairing begins automatically as soon as the head- set is sensed. The circular blue light turns a swirling green to indicate pairing is in progress (see Fig. 2). 4. When the Headset Pairing Ring turns solid green, pairing is successful. The headset status LED also turns solid green. Registra- tion also happens automatically with the initial pairing. See note if pairing fails. 5. The Select Your Position screen appears (see Fig. 3). Tap on a pane to select your position. This selection assigns you to a channel. Note: If you are selecting DRIVE-THRU 1 (or DRIVE-THRU 2 for stores with two lanes), you also have the option of AUTO HANDS-FREE mode (see Fig. 3), which saves you from having to manually connect with a new customer by tapping the headset button. Fig. 1 Fig. 2 HME Power Button (blue) Battery HEADSET Front View HEADSET Side View Lane 1Lane 2 Status LED Volume Up/Unmute Volume Down/Mute Action Group Chat Battery Release Button (gray) * Battery not included Headset Sensor Headset Pairing Ring Headset Pairing Ring Headset Pairing Ring Swirling Green Pairing in progress Solid Blue: Sensor idle until headset is sensed Solid Green: Pairing successful. Begin using headset Swirling Red: Pairing unsuccessful. Try again BASE STATION Note: If pairing fails (assuming the headset is on, and the headset battery is fully charged), try again. Hold the headset steadily centered and flush against the Headset Pairing Ring (headset movement and distance from the Pairing Ring can cause pairing errors). © 2020 HM Electronics, Inc. All rights reserved. 2 Safety Notice CAUTION: Wear proper eye, ear, and body protection when grinding, drilling or working with tools. Follow the manufactur- er’s safety information and operational instructions for tools and materials. Be aware of your surroundings. Failure to heed such precautions can cause injury and/or property damage. Hygiene, Health, and Safety Part of this installation requires working within a restaurant/store where food is prepared, and customers dine. Please consult the restaurant/store manager, standard operating procedures and any additional restaurant safety/advisory protocols available before be- ginning work within the restaurant/store. Follow the instructions and guidelines provided. Fig. 3 When you check this AUTO HANDS-FREE mode box located below the DRIVE-THRU 1 pane, you are automatically connected with a customer when they arrive at the order point. You are then automatically disconnected when they leave the order point. This feature is only available for one headset per drive-thru lane. The headset remains in this mode until the headset is taken out of use and powered off. 6. Select Next, and a Success prompt appears (Fig. 4). Click OK to begin using your headset. Fig. 4 Keypad Layout Reference Table (Fig. 5) IconLabelStatus/Description Lane 1 Lane 2 For a dual lane drive-thru, tap a number to choose the corresponding lane. Volume Up & Unmute Tap to increase volume Press and hold (for 2 secs) to unmute Volume Down & Mute Tap to decrease volume Press and hold (for 2 secs) to mute GroupPress and hold to communicate with all in your group using that channel ActionUse to change channel, answer and end calls, etc. HME Power Button Battery HEADSET Front View HEADSET Side View Lane 1Lane 2 Status LED Volume Up/Unmute Volume Down/Mute Action Group Chat Battery Release Button Fig. 5 A copy of this guide and additional information can be found by scanning this QR code. HM ELECTRONICS, INC. 2848 Whiptail Loop, Carlsbad, CA 92010 USA Phone: 1-800-848-4468 Fax: 858-552-0172 Website: www.hme.com Email: [email protected] The HME logo and product names are regis- tered trademarks of HM Electronics, Inc. HEADSET KEYPAD OVERVIEW © 2020 HM Electronics, Inc. All rights reserved. 3 REGULATORY COMPLIANCE Applicant Name: HM Electronics, Inc. Applicant Address: 2484 Whiptail Loop, Carlsbad CA 92010, United States Manufacturer Name: HM Electronics, Inc. Manufacturer Address: 2484 Whiptail Loop, Carlsbad CA 92010, United States Country of Origin: USA Brand: HME Caution: All products are compliant with regulatory requirements detailed in this document when the user follows all installation instructions and operating conditions per HME specifications. Caution: Use of accessories and peripherals other than those recommended by HME may void the product's com- pliance as well as the user's authority to operate the equipment. Caution: All products are designed for use with the standard, integral or dedicated (external) antenna(s) that are shipped together with the equipment. Any product changes or modifications will invalidate all applicable regulatory certifications and approvals. Caution: The use of software or firmware not supported/provided by HME products may result that the equipment is no longer compliant with the regulatory requirements…

Text truncated - open the document above for the full version.

HM Electronics, Inc. | 2848 Whiptail Loop | Carlsbad, CA 92010 800.848.4468 | www.hme.com Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 11 /12/2020 SUBJECT: FCC Application for (FCC ID: BYM7002) To Whom It May Concern: We, the undersigned, hereby authorize David Zhang in Vista Laboratories, Inc. on our behalf, to apply to the Federal Communications Commission on our equipment with FCC ID BYM7000. Any and all lawful acts carried out by Vista Laboratories, Inc. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Client’s signature: Client’s name: Douglas Paul Sieh Client’s title: Electrical Compliance Engineering Supervisor Company Name: HM Electronics, Inc. Company Address: 2848 Whiptail Loop, Carlsbad, CA 92010, USA Main: +1-858-535-6000 Fax: +1-858-452-7207

HM Electronics, Inc. | 2848 Whiptail Loop | Carlsbad, CA 92010 800.848.4468 | www.hme.com Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: BYM7002 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Type of Confidentiality Requested Exhibit Type ☐Short Term ☑Permanent Block Diagrams ☑Short Term External Photos ☑Short Term ☐Permanent* Internal Photos ☐Short Term ☑Permanent Operation Description ☐Short Term ☑Permanent Parts List/BOM ☐Short Term ☑Permanent Schematics ☑Short Term Test Setup Photos ☑Short Term ☐Permanent* User manual *Requires further justification before permanent confidentiality will be allowed. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below for an initial period of 180 (ie - “45”, “90” or “180”) days. Sincerely, Client’s signature: Client’s name: Douglas Paul Sieh Client’s title: Electrical Compliance Engineering Supervisor Company Name: HM Electronics, Inc. Company Address: 2848 Whiptail Loop, Carlsbad, CA 92010, USA Main: +1-858-535-6000 Fax: +1-858-452-7207

EUT-External-Top EUT-External-Bottom EUT-External-Front EUT-External-Back EUT-External-Left EUT-External-Right

HM Electronics, Inc. | 2848 Whiptail Loop | Carlsbad, CA 92010 800.848.4468 | www.hme.com Regulatory label for model 7002

Internal - Open cover Internal - Main PCBA Top Internal - Main PCBA Bottom Headset keypad board - TOP Headset keypad board - BOTTOM Headset battery board - TOP Headset battery board - BOTTOM Headset MIC BOOM board - TOP Headset MIC BOOM board - BOTTOM

FCC RF Exposure Evaluation (FCC ID: BYM7002) RF Exposure Requirements: 47 CFR §1.1307(b) RF Radiation Exposure Limits: 47 CFR §1.1310 RF Radiation Exposure Guidelines: FCC OST/OET Bulletin Number 65 EUT Frequency Band: 2402-2480MHz 5150-5825MHz Equation: According to the procedure in KDB447498 (v05r02) section 4.3, 1g-SAR testing is excluded if the following criteria is met. (P/d)* √f ≤3.0 for 1-g SAR 10g-SAR testing is excluded if the following criteria is met. (P/d)* √f ≤7.5 for 10-g SAR Where P is the time averaged maximum conducted power in mW d minimum separation distance in mm f is the frequency in GHz ________________________________________________________________________________________________ The distance between the antenna and human body is 5 mm. The calculation was based on the distance of 5 mm. Radio Frequency (MHz) Max E.I.R.P (dBm) Max E.I.R.P (mW) Maximum Source- based Duty Cycle (%) Max source- based average output power (mW) Measurement distance (mm) Test Exclusion Threshold Result BLE 2402-2480 2.175 1.65 100% 1.65 5 0.520 5GHz 5180-5240 24.230 264.85 1.43 % 3.79 5 1.735 5GHz 5260-5320 22.430 174.98 1.43 % 2.50 5 1.153 5GHz 5500-5720 22.100 162.18 1.43 % 2.32 5 1.110 5GHz 5745-5825 23.430 220.29 1.43 % 3.15 5 1.521 The above results show that the device is excluded for both standalone 1g-SAR and 10g-SAR testing. Per KDB447498, section 4.3.2, b), the simultaneous transmission SAR test exclusion shall be considered. The standalone SAR value is estimated as follows, [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)]·[√f(GHz)/x] W/kg, for test separation distances ≤ 50 mm; where x = 7.5 for 1-g SAR and x = 18.75 for 10-g SAR For BLE, standalone 1g-SAR = (P/d)* (√f/7.5) = 0.069 w/kg standalone 10g-SAR = (P/d)* (√f/18.75) = 0.028 w/kg For 5GHz, standalone 1g-SAR = (P/d)* (√f/7.5) = 0.231 w/kg standalone 10g-SAR = (P/d)* (√f/18.75) = 0.093 w/kg So simultaneous 1g-SAR = 1g-SAR (BLE) + 1g-SAR (5GHz) = 0.30 w/kg < 1.6 W/kg simultaneous 10g-SAR = 10g-SAR (BLE) + 10g-SAR (5GHz) = 0.121 w/kg < 4 W/kg The above results show that the device is excluded for both simultaneous 1g-SAR and 10g-SAR testing. Completed By: David Zhang Vista Laboratories, Inc. 1261 Puerta Del Sol, San Clemente, CA 92673 Date: Oct 27th, 2020

Phone: +1 (949) 393-1123 Web: www.vista-compliance.com Email: [email protected] FCC ISED RF Test Report Test Report Number HME-20080441-LC-FCC-IC-DTS FCC ID BYM7002 ISED ID Applicant 1860A-7002 HM Electronics Inc Applicant Address 2848 Whiptail Loop, Carlsbad, CA 92010 USA Product Name Nexeo AIO headset Model (s) 7002 Date of Receipt 09/01/2020 Date of Test 09/01/2020 – 10/26/2020 Report Issue Date 10/27/2020 Test Standards 47 CFR Part 15.247 RSS-247 Issue 2, Feb 2017 Test Result PASS Issued by: Vista Compliance Laboratories 1261 Puerta Del Sol, San Clemente, CA 92673 USA www.vista-compliance.com Daniel Bruno (Test Technician) David Zhang (Technical Manager) This report is for the exclusive use of the applicant. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. Note that the results contained in this report pertain only to the test samples identified herein, and the results relate only to the items tested and the results that were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested and the results thereof based upon the information provided to us. The applicant has 60 days from date of issuance of this report to notify us of any material error or omission. Failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is not to be reproduced by any means except in full and in any case not without the written approval of Vista Laboratories. Report# HME-20040121-LC-FCC-IC-DTS Page 2 of 37 REVISION HISTORY Report Number Version Description Issued Date HME-20080441-LC-FCC-IC-DTS 01 Initial report 10/27/2020 Report# HME-20040121-LC-FCC-IC-DTS Page 3 of 37 TABLE OF CONTENTS 1 TEST SUMMARY ...................................................................................................................................................... 4 2 GENERAL INFORMATION ..................................................................................................................................... 5 2.1 Applicant .......................................................................................................................................................... 5 2.2 Product information ...................................................................................................................................... 5 2.3 Test standard and method .......................................................................................................................... 6 3 TEST SITE INFORMATION ..................................................................................................................................... 6 4 MODIFICATION OF EUT / DEVIATIONS FROM STANDARDS ....................................................................... 6 5 TEST CONFIGURATION AND OPERATION ....................................................................................................... 6 5.1 EUT Test Configuration ................................................................................................................................. 6 5.2 Supporting Equipment ................................................................................................................................. 7 6 UNCERTAINTY OF MEASUREMENT ................................................................................................................... 8 7 TEST RESULTS .......................................................................................................................................................... 9 7.1 Antenna Requirement .................................................................................................................................. 9 7.2 DTS (6 dB) Bandwidth ................................................................................................................................. 10 7.3 Occupied Bandwidth (99%) ........................................................................................................................ 13 7.4 Maximum Output Power............................................................................................................................ 16 7.5 Power Spectral Density ............................................................................................................................... 19 7.6 Conducted Band-Edge Measurement ..................................................................................................... 22 7.7 Radiated Band-Edge & Spurious Emissions into Restricted Frequency Bands .............................. 24 8 EUT AND TEST SETUP PHOTOS ......................................................................................................................... 36 9 TEST INSTRUMENT LIST ..................................................................................................................................... 37 Report# HME-20040121-LC-FCC-IC-DTS Page 4 of 37 1 Test Summary Test Item Test Requirement Test Method Result Antenna Requirement 47 CFR Part 15.247 RSS-247 Issue 2, Feb 2017 ANSI C63.10 (2013) Pass DTS …

Text truncated - open the document above for the full version.

Radiated Emission-Below 1GHz-Front Radiated Emission-Below 1GHz-Back Radiated Emission-Above 1GHz-Front Radiated Emission-Above 1GHz-Back
