BYMAM30CAMS AM1011 Base Transceiver Board, Model 180094

TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 103937-03 (FCC ID: BYMAM30H) Page 13 Rev.No 1.0 7ATTESTAION STATEMENT: All tests according to CFR 47, Part 15, Paragraphs 15.207 and 15.209 were n - Performed The Equipment Under Test n - Fulfills the general requirements of CFR 47, Part 15, Paragraphs 15.207 and 15.209. _______________________ - TÜV PRODUCT SERVICE, INC. - Responsible Engineer: Jim Owen (EMC Engineer)

COM XCVR BOARD ANTENNA SIDE 1 WITHOUT FILTERS COM XCVR BOARD ANTENNA SIDE 1 COM XCVR BOARD SIDE 2 PCB VIEW WITH ANTENNAS REMOVED PCB VIEW WITH ANTENNAS AND CERAMIC FILTERS REMOVED VIEW OF PCB WITH ANTENNAS REMOVED

TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 103937-03 (FCC ID: BYMAM30H) Page 1 Rev.No 1.0 MEASUREMENT AND TECHNICAL REPORT HM ELECTRONICS 6675 Mesa Ridge Road San Diego, CA 92121-2937 DATE: 4 June 2001 This Report Concerns:Original Grant: XClass II Change: Equipment Type:AMS AM1011 Base Transceiver Board, Model 180094 Deferred grant requested per 47 CFR 0.457(d)(1)(ii)?Yes: Defer until: No: X Company Name agrees to notify the Commission by:N/A of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37?Yes:*No: X (*) FCC Part 15, Paragraphs 15.109(a), 15.209 and 15.223 Report Prepared by: TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 546 3999 Fax: 858 546 0364 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 103937-03 (FCC ID: BYMAM30H) Page 2 Rev.No 1.0 TABLE OF CONTENTS Pages 1 GENERAL INFORMATION3 1.1Product Description3 1.2Related Submittal Grant3 1.3Tested System Details3 1.4Test Methodology3 2 SYSTEM TEST CONFIGURATION5 2.1Justification5 2.2EUT Exercise Software5 2.3Special Accessories5 2.4Equipment Modifications5 2.5Configuration of Tested System5 3 CONDUCTED MEASUREMENT EQUIPMENT/DATA6 4RADIATED MEASUREMENTEQUIPMENT/DATA7 4.1Field Strength Calculation12 5Attestation Statement13 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 103937-03 (FCC ID: BYMAM30H) Page 3 Rev.No 1.0 1 GENERAL INFORMATION 1.1Product Description NAME, MODEL, SERIAL # OF EUT:AMS AM1011 Base Transceiver Board, Model 180094 DESCRIPTION OF EUT:AM Transceiver Board for use in COM430 and COM930 OPERATING MODE(S):Normal POWER INTERFACE FREQUENCY/AC/DC VOLTAGE:Battery power DC PHASES:1 OSCILLATOR FREQUENCIES:32.768 kHz on Y1; Crystal reference POWER SUPPLY TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 103937-03 (FCC ID: BYMAM30H) Page 4 Rev.No 1.0 1.2Related Submittal/Grant None 1.3Tested System Details The FCC IDs for all equipment, plus descriptions of all cables used in the tested system are: None 1.4Test Methodology Purpose of Test:To demonstrate compliance with the ANSI C63.4 setup. Test Performed:1. Conducted Emissions, FCC Part 15.207 2. Radiated Emissions, EN55022: 1992 Class B limit, 30 - 1,000 MHz, 10 meters X3. Radiated Emission per FCC Part 15.109(a), 15.209 and 15.223 4. Engineering evaluations 1.5Test Facility The open area test site and conducted measurement data were tested by: TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 546 3999 Fax: 858 546 0364 The Test Site Data and performance comply with ANSI 63.4 and are registered with the FCC, 7435 Oakland Mills Rd, Columbia Maryland 21046. All Measurement Data is acquired according to the content of FCC Measurement Procedure and ANSI C63.4, unless supplemented with additional requirements as noted in the test report. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 103937-03 (FCC ID: BYMAM30H) Page 5 Rev.No 1.0 2.SYSTEM TEST CONFIGURATION 2.1Justification The was initially tested for FCC emission in the following configuration: See Block Diagram. 2.2EUT Exercise Software None 2.3Special Accessories None 2.4Modification None 2.5Configuration of Tested System See Block Diagram. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 103937-03 (FCC ID: BYMAM30H) Page 6 Rev.No 1.0 3CONDUCTED EMISSION DATA EUT is battery powered. HME ELECTRONICS See following page(s). TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 103937-03 (FCC ID: BYMAM30H) Page 7 Rev.No 1.0 4RADIATED MEASUREMENT EQUIPMENT LIST Emissions Test Conditions: RADIATED EMISSIONS (Electric Field) The EQUIVALENT RADIATED EMISSIONS measurements were performed at the following test location : o - Test not applicable Test Site: Canyon Site Parking Lot, Carroll Canyon, San Diego Test Equipment Used : Model No.Property No.DescriptionManufacturerSerial NumberCal Date HP8568B430Spectrum AnalyzerHewlett Packard3303A00365 HFH2-Z2208Loop AntennaRohde & Schwarz880* Remarks:(*) Verified prior to use. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 103937-03 (FCC ID: BYMAM30H) Page 8 Rev.No 1.0 6RADIATED EMISSION DATA The following data lists the significant emission frequencies, measured levels, correction factor (which includes cable and antenna corrections), the corrected reading, and the limit. See following page(s). 4 May 01 EUT: AMS AM1011 Base Xcvr Board Sire SR4 3 m30LimitMargin Freq.Meas. PeakCorr. Factor29.53 meters MHz dBμVdBμV 40 Part 15, Para. 15.223 1.8062 3.6124 5.4186 7.2248 9.031 33.1 17.9 16.6 17.7 16.5 20 20 20 20 20 29.5 29.5 29.5 29.5 29.5 60 60 60 60 60 -6.9 -22.7 -23.4 -22.6 -23.5 Noise floor Noise floor Noise floor Noise floor Noise floor 4 May 01 EUT: AMS AM1011 Base Xcvr Board Canyon 1 Part 15, Para. 15.209 10.8372 12.6434 14.4496 16.2558 18.062 16.9 17.5 16.0 16.2 16.7 20 20 20 20 20 29.5 29.5 29.5 29.5 29.5 69.5 69.5 69.5 69.5 69.5 32.6 32.0 33.5 33.3 32.8 Noise floor Noise floor Noise floor Noise floor Noise floor Temp: 23C Humidity: 35 Atm. Press: 101.8 kPa Equipment: Spectrum analyzer, #74 HP 8568B s/n 2304A04531 Antenna: Rohde & Schwarz 9 kHz - 30 MHz Loop #208 S/N 88.458/25 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 103937-03 (FCC ID: BYMAM30H) Page 12 Rev.No 1.0 6.1Field Strength Calculation If a preamplifier was used during the Radiated Emission Testing, it is required that the amplifier gain must be subtracted from the Spectrum Analyzer (Meter) Reading. In addition, a correction f…
