BYMBS850BASE STATION TRANSCEIVER

HME# 400520 Rev − 7/7/03 PRO850 Wireless Intercom Operating Instructions Table of Contents SECTION 1. INTRODUCTION ....................................................................................................................1 EQUIPMENT FEATURES ................................................................................................................................2 Base Station Front Panel Features ..................................................................................................................2 Base Station Rear Panel Features ...................................................................................................................2 Beltpac Top Panel Features ............................................................................................................................3 Beltpac Bottom Panel Features.......................................................................................................................3 BLOCK DIAGRAMS ........................................................................................................................................4 Base Station ....................................................................................................................................................4 Beltpac............................................................................................................................................................4 EQUIPMENT SPECIFICATIONS ....................................................................................................................5 Base Station ....................................................................................................................................................5 Beltpac............................................................................................................................................................6 SECTION 2. EQUIPMENT SETUP..............................................................................................................7 BASE STATION SETUP...................................................................................................................................7 Checking Status .......................................................................................................................................11 Monitoring Audio Levels ........................................................................................................................12 Base Transmitter Configuration ..............................................................................................................13 Base Receiver Configuration...................................................................................................................14 Base Configuration..................................................................................................................................15 Beltpac Configuration .............................................................................................................................18 Saving and Loading Settings ...................................................................................................................21 Advanced Settings ...................................................................................................................................21 Displaying Information ...........................................................................................................................25 Diagnostics ..............................................................................................................................................25 SECTION 3. PRO850 OPERATION............................................................................................................9 BASE STATION OPERATION ........................................................................................................................9 Uses of Front Panel Controls, Indicators and Connectors ..............................................................................9 Display Screen Navigation ...........................................................................................................................10 Display Screen Functions and System Settings ............................................................................................11 BELTPAC OPERATION.................................................................................................................................26 Controls and Buttons ....................................................................................................................................26 Indicator Lights ............................................................................................................................................27 Connectors and Adjustment..........................................................................................................................28 Batteries........................................................................................................................................................29 Infrared Window ..........................................................................................................................................29 SECTION 4. PC850 SOFTWARE ...............................................................................................................30 PC850 Installation ........................................................................................................................................30 PC850 Operation ..........................................................................................................................................31 END-USER LICENSE AGREEMENT FOR HME PC850 SOFTWARE...................................................33 Copyright HM Electronics, Inc. - July 2003 FCC LICENSING The HME PRO850 is …

Text truncated - open the document above for the full version.

August 25, 2003 HM Electronics, Inc. PRO850 Base Station (BS850) FCC ID label:

FCC ID: BYMBS850 MFA p0370003, d0380027 Transmitter Certification of FCC ID: BYMBS850 Model: BS850 to Federal Communications Commission Rule Part 74H, Confidentiality Date of report: August 18, 2003 On the Behalf of the Applicant: HM Electronics, Inc. At the Request of: P.O. Part of 20213 HM Electronics, Inc. 14110 Stowe Drive Poway, CA 92064 Attention of: (858) 535-6000 Corporate Tom Riches, Engineering Services manager (858) 535-6098; FAX: -9019 email: [email protected] Supervised by: Morton Flom, P. Eng. FCC ID: BYMBS850 MFA p0370003, d0380027 List of Exhibits (FCC Certification (Transmitters) - Revised 9/28/98) Applicant: HM Electronics, Inc. FCC ID: BYMBS850 By Applicant: 1. Letter of Authorization x 2. Identification Drawings, 2.1033(c)(11) x Label x Location of Label x Compliance Statement x Location of Compliance Statement 3. Photographs, 2.1033(c)(12) x 4. Documentation: 2.1033(c) (3) User Manual x (9) Tune Up Info x (10) Schematic Diagram x (10) Circuit Description x Block Diagram x Parts List x Active Devices x 5. Part 90.203(e) & (g) Attestation By M.F.A. Inc.: A. Testimonial & Statement of Certification B. Statement of Qualifications FCC ID: BYMBS850 MFA p0370003, d0380027 The Applicant has been cautioned as to the following: 15.21 Information to the User. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) Special Accessories. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. FCC ID: BYMBS850 MFA p0370003, d0380027 Table of Contents Rule Description Page . Test Report 1 2.1033(c) General Information Required 2 2.1033(c)(14) Rule Summary 5 . Standard Test Conditions and Engineering Practices 6 2.1046(a) Carrier Output Power (Conducted) 7 2.1046(a) ERP Carrier Power (Radiated) 9 2.1053(a) Field Strength of Spurious Radiation 10 2.1049(c)(1) Emission Masks (Occupied Bandwidth) 14 2.1055(a)(1) Frequency Stability (Temperature Variation) 20 2.202(g) Necessary Bandwidth and Emission Bandwidth 23 FCC ID: BYMBS850 MFA p0370003, d0380027 Page Number 1 of 23. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0380027 d) Client: HM Electronics, Inc. 14110 Stowe Drive Poway, CA 92064 e) Identification: FCC ID: BYMBS850 EUT Description: Base Station f) EUT Condition: Not required unless specified in individual tests. g) Report Date: August 18, 2003 EUT Received: July 14, 2003 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. FCC ID: BYMBS850 MFA p0370003, d0380027 Page Number 2 of 23. List of General Information Required for Certification In Accordance with FCC Rules and Regulations, Volume II, Part 2 and to 74H Sub-part 2.1033 (c)(1): Name and Address of Applicant: HM Electronics, Inc. 14110 Stowe Drive Poway, CA 92064 Manufacturer: Applicant (c)(2): FCC ID: BYMBS850 Model Number: BS850 (c)(3): Instruction Manual(s): Please see attached exhibits (c)(4): Type of Emission: 190KF9W (c)(5): Frequency Range, MHz: 470 to 608 614 to 740 (c)(6): Power Rating, Watts: 0.25 Switchable Variable x N/A (c)(7): Maximum Power Rating, Watts: 250 mW DUT Results: Passes x Fails FCC ID: BYMBS850 MFA p0370003, d0380027 Page Number 3 of 23. M. Flom Associates, Inc. is accredited by the American Association for Laboratory Association (A2LA) as shown in the scope below. "This laboratory is accredited by the American Association for Laboratory Accreditation (A2LA) and the results shown in this report have been determined in accordance with the laboratory's terms of accreditation unless stated otherwise in the report." Should this report contain any data for tests for which we are not accredited, or which have been undertaken by a subcontractor that is not A2LA accredited, such data would not covered by this laboratory's A2LA accreditation. FCC ID: BYMBS850 MFA p0370003, d0380027 Page Number 4 of 23. Subpart 2.1033 (continued) (c)(8): Voltages & currents in all elements in final RF stage, including final transistor or solid-state device: Collector Current, A = per manual Collector Voltage, Vdc = per manual Supply Voltage, Vac = 115 (c)(9)…

Text truncated - open the document above for the full version.

FCC ID: BYMBS850 MFA p0370003, d0380067 For MFA internal use only Please keep this page with the report in out files. Applicant: HM Electronics, Inc. Model: BS850 FCC ID: BYMBS850 Formulaire: L:\\Project\\Formulaire\\FCC.MPE.rtf Last Modified: 2000-Oct-17 Purpose: Environmental Assessment (MPE) MFA Project ID: p0370003 Client ID: HMELECTRONICS MFA Document ID: d0380067 Date: August 27, 2003 This Printing 2003-Aug-29 Fri Writer: MF/cva ___ < Check here if this report has been manually modified. ___ < Check here if this report was made from another report. Original document: ___ < Check here if this report varies significantly from the formulaire FCC ID: BYMBS850 MFA p0370003, d0380067 Date: August 27, 2003 Applicant: HM Electronics, Inc. 14110 Stowe Drive Poway, CA 92064 Attention of: (858) 535-6000 Corporate Tom Riches, Engineering Services manager (858) 535-6098; FAX: -9019 email: [email protected] Equipment: BS850 FCC ID: BYMBS850 P.O. Number: Part of 20213 FCC Rules: Radiofrequency Radiation Exposure Limits 47 CFR 1.1310 MPE - Mobiles Fixed Based Station x Gentlemen: Enclosed please find your copy of the Calculated Test Data Report, the whole for Environmental Assessment (MPE) of the referenced equipment as shown. Should you need any clarification, just fax or phone. Thank you again for this order - it has been a pleasure to be of service. Sincerely yours, Morton Flom, P. Eng. enclosure(s) MF/cva FCC ID: BYMBS850 MFA p0370003, d0380067 Environmental Assessment for Mobiles/Fixed Base Station for FCC ID: FCC ID: BYMBS850 Model:BS850 to Federal Communications Commission 47 Cfr 1.1310 (MPE) Radiofrequency Radiation Exposure Limits Date Of Report: August 27, 2003 On the Behalf of the Applicant: HM Electronics, Inc. At the Request of: P.O. Part of 20213 HM Electronics, Inc. 14110 Stowe Drive Poway, CA 92064 Attention of: (858) 535-6000 Corporate Tom Riches, Engineering Services manager (858) 535-6098; FAX: -9019 email: [email protected] Supervised By: Morton Flom, P. Eng. FCC ID: BYMBS850 MFA p0370003, d0380067 Table of Contents Rule Description Page . Test Report 1 . Identification of the Equipment Under Test 2 . Standard Test Conditions and Engineering Practices 4 1.1310 Environmental Assessment 5 FCC ID: BYMBS850 MFA p0370003, d0380067 Page Number 1 of 5. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report (Supplemental) b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0380067 d) Client: HM Electronics, Inc. 14110 Stowe Drive Poway, CA 92064 e) Identification: BS850 FCC ID: BYMBS850 Description: Base Station Transceiver f) EUT Condition: Not required unless specified in individual tests. g) Report Date: August 27, 2003 EUT Received: 2003-Jul-14 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. FCC ID: BYMBS850 MFA p0370003, d0380067 Page Number 2 of 5. Identification of the Equipment Under Test (EUT) Name and Address of Applicant: HM Electronics, Inc. 14110 Stowe Drive Poway, CA 92064 Manufacturer: Applicant FCC ID: BYMBS850 Model Number: BS850 Description: Base Station Transceiver Type of Emission: 190KF9W Frequency Range, MHz: 470 to 608 614 to 740 Power Rating, Watts: 0.250 Switchable Variable x N/A Modulation: AMPS TDMA CDMA x OTHER Antenna: Helical Monopole Whip x Other Note: For RF Safety test antenna gain taken at the upper range of expected gain (i.e. 0 dBd) and RF Power set to highest nominal power across all channels. FCC ID: BYMBS850 MFA p0370003, d0380067 Page Number 3 of 5. M. Flom Associates, Inc. is accredited by the American Association for Laboratory Association (A2LA) as shown in the scope below. "This laboratory is accredited by the American Association for Laboratory Accreditation (A2LA) and the results shown in this report have been determined in accordance with the laboratory's terms of accreditation unless stated otherwise in the report." Should this report contain any data for tests for which we are not accredited, or which have been undertaken by a subcontractor that is not A2LA accredited, such data would not covered by this laboratory's A2LA accreditation. FCC ID: BYMBS850 MFA p0370003, d0380067 Page Number 4 of 5. Standard Test Conditions and Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.4-1992/2000, section 6.1.9, and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104 °F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Prior to testing, the EUT was tuned up in accordance with the manufacturer's alignment procedures. All external gain controls were maintained at the position of maximum and/or optimum gain throughout the testing. Measurement results, unless otherwise noted, are worst-case measurements. FCC ID: BYMBS850 MFA p0370003, d0380067 Page Number 5 of 5. Name of Test: Environmental Assessment Specification: FCC: 47 CFR 1.1310 Measurement Guide: ANSI/IEEE C95.1 1992 Calculation of MPE Frequency = 508.250 MHz R.F. Power Output = 0.250 Watts Limit = 0.338 mw/cm 2 Minimum Safe Distance, Rm = [0.25/(12.56 x 0.3388)] 1/2 = 0.2424 meter = 24.24 cm Supervised By: Morton Flom, P. Eng. FCC ID: BYMBS850 MFA p0370003, d0380067 (The following will be placed in the Instruction Manual) Mandatory Safety Instructions to Installers & Users Use only ma…

Text truncated - open the document above for the full version.
