CFS8DL5800MINIVWireless Alarm Transmitter

5800MINIV Single-Zone Door/Window Sensor Installation & Setup Guide FEATURES The 5800MINIV is a single-zone, wireless door/window sensor with a cover and wall tamper. It is intended for use with Control Panels that support 5800 series devices The sensor consists of two primary components: a transmitter assembly and a magnet assembly. •Compatible with alarm systems that support 5800 series wireless devices. •Built-in serial number which must be enrolled into the Control Panel. •Refer to the Control Panel installation instructions for programming details. Mini 005_cover-01 MOUNTING •Choose a mounting location where the transmitter is stationary, and the magnet is mounted to the moving part of the door or window. •Verify adequate signal strength by using the Control Panel Go/No Go test (see Control Panel instructions) before mounting permanently. •Avoid mounting in areas where the device will be exposed to moisture or where the operating temperature of 32 to 120ºF (0 to 50ºC) will be exceeded. •Keep the transmitter and magnet away from metal or metallic surfaces such as foil wallpaper. •Avoid mounting the device in areas with a large quantity of metal or electrical wiring, such as a furnace or utility room. 1.Separate the transmitter front cover from the rear mounting plate. Note: The magnet can be mounted on either the left or right side of the transmitter; however, for proper operation, the grooved lines in transmitter front cover and the magnet front cover must be aligned with each other. 2.Mount the rear mounting plate to a stationary surface and secure with the supplied double-faced adhesive tape and/or the three screws (provided). 3.Mount the magnet to the moveable surface (with the proper magnet gap adjustment) and secure with supplied double-faced adhesive tape and/or the two screws (provided). Note: See the Specifications section for the magnet mounting gap settings. 4.If necessary, install the battery (with “+” side up) or pull out the battery tab. 5.Replace the front cover. PROGRAMMING Refer to the Control Panel installation instructions for programming and enrolling the device. 1.Enter Programming mode at the Control Panel. 2.Assign a zone number to loop 1 and assign as Input Type 3 (Supervised RF). 3.To enroll the serial number, activate the transmitter by moving the magnet close to and away from the transmitter two times. 4.Alternatively, enter the device serial number manually when prompted. BATTERY REPLACEMENT 1.Separate the transmitter front cover from the rear mounting plate. 2.Remove battery, wait 10 seconds, and then insert a new battery (with “+” side up). Note: See the Specifications section for recommended replacement batteries. 3.Replace the front cover. BATTERY CAUTION: Risk of fire, explosion, and burns. Do not recharge, disassemble, heat above 212°F (100°C), or incinerate. Dispose of used batteries properly. Keep away from children. Note: Constant exposure to high or low temperature or high humidity may reduce battery life. SPECIFICATIONS Dimensions:Transmitter: 0.45”H x 1.25”W x 2.44”L (11.5mm H d x 32mm W x 62mm L) Magnet: 0.38”H x 0.41”W x 1.49”L (9.5mm H x 10.5mm W x 37.9mm L) Operating Conditions: 32°F (0°C) to 120°F (50°C) Relative Humidity 95%, (non-condensing); UL Tested at 85% RF Frequency: 345 MHz Tamper Cover and Wall Magnet Gap Maximum Mounting Gap •Wood Surfaces: 1.15" (29.2mm) •Metal Surfaces: 0.5" (13.2mm) Battery 1 x 3VDC Coin Cell Resideo BL3-0004 (CR2450); Duracell DL2450; Panasonic CR2450; Energizer CR2450 (Use of another battery may present the risk of fire or explosion) FEDERAL COMMUNICATIONS COMMISSION STATEMENTS The user shall not make any changes or modifications to the equipment unless authorized by the Installation Instructions or User Manual. Unauthorized changes or modifications could void the user's authority to operate the equipment. FCC/IC STATEMENT This device complies with Part 15 of the FCC Rules, and Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation. Cet appareil est conforme à la partie 15 des règle s de la FCC et exempt de licence RSS d’Industrie Canada. Son fonctionnement est soumis aux conditions suivantes: (1) Cet appareil ne doit pas causer d'interférences nuisibles. (2) Cet appareil doit accepter toute interférence reçue y compris les interférences causant une réception indésirable. RF Exposure Warning - The antenna(s) used for this device must be installed to provide a separation distanceof at least 20 cm from all personsand must not be co-located or operating in conjunction with any other transmitter or antenna. Avertissement - Les antennes utilisées pour ces émetteurs doivent etre installées de manière à garantir une distance minimale de 20 cm entre elles et toutes personnes. Elles ne doivent pas etre placées au même endroit ni fonctionner en conjonction avec d'autres antennes ou émetteurs. Responsible Party / Issuer of Supplier’s Declaration of Conformity: Ademco Inc., a subsidiary of Resideo Technologies, Inc., 2 Corporate Center Drive., Melville, NY 11747, Ph: 516-577-2000. REFER TO THE INSTALLATION INSTRUCTIONS FOR THE CONTROL WITH WHICH THIS DEVICE IS USED FOR DETAILS REGARDING LIMITATIONS OF THE ENTIRE ALARM SYSTEM. The product should not be disposed of with other household waste. Check for the nearest authorized collection centers or authorized recyclers. The correct disposal of end-of-life equipment will help prevent potential negative consequences for the environment and human health. Product must be tested at least once each year Any attempt to reverse-engineer this device by decoding proprietary protocols, de-compiling firmware, or any similar actions is strictly prohibited. SUPPORT & WARRANTY For the latest documentation, online support information, and warranty information, please go to: www.resideo.com …

Text truncated - open the document above for the full version.

Form: RFT-AMER-TCB-OP-19o Revision: 1 Page 1 of 1 Date: 1/25/2023 Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to 47 CFR part §2.911(d)(7) of the FCC rules FCC ID: CFS8DL5800MINIV To whom it may concern, This letter is to certify that Resideo LLC. (“Applicant”) accepts responsibilities to act as its own agent pursuant to 47 CFR part §2.911(d)(7) of the FCC rules for service of process. I consent to the obligation to accept service of process on behalf of the Applicant for all certification applications to the FCC. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC and Intertek if there is any change in the status identified above. Applicant Company Name : Resideo LLC. Contact Name : Christian Fouth Address : 2 Corporate Center Dr., Melville, NY 11747 Telephone No : 516-577-2000 Email : [email protected] Applicant FRN : 0004071130 Signature: ____________________________________ Date: 12/04/2025

Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: Resideo LLC. FCC ID: CFS8DL5800MINIV To whom it may concern, Resideo LLC. (“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is n ot identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. Applicant further certifies that no Cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software is installed in the equipment being certified. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change in the status identified above. Christian Fouth Sr. Wireless Certification Engineer Resideo LLC. 11/12/2025 Form: RFT-AMER-TCB-OP-19n Revision: 1 Page 1 of 1 Date: 1/25/2023

Date: 11/12/2025 Intertek Testing Services NA inc. 70 Codman Hill Rd Boxborough, MA 01719, United States Attention: FCC Office of Engineering and Technology Subject: Request for Confidentiality FCC ID: CFS8DL5800MINIV To Whom it May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission's rule (47 CFR §§ 0.457, 0.459), we are requesting the Bureau to withhold the following attachments as confidential document from public disclosure indefinitely. • Schematic Diagram • Block Diagram • Operational Description Above mentioned documents contain detailed system and equipment description considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Best Regards, Christian Fouth Sr. Wireless Certification Engineer Resideo LLC. / Resideo Technologies

CFS8DL5800MINIV / 573F-5800MINIV 10/27/2025 EXTERNAL PHOTOS Figure 1 Top view Figure 2 Back view CFS8DL5800MINIV / 573F-5800MINIV 10/27/2025 Figure 3 Side view from left Figure 4 Side view from right HS9-TH6320ZW04 / 573R-TH6320ZW04 10/27/2025 Figure 5 Side view from top Figure 6 Side view from bottom

CFS8DL5800MINIV/573F-5800MINIV LABEL AND LABEL LOCATION Figure 1 Label AND label location

CFS8DL5800MINIV / 573R-5800MINIV 11/26/2025 Internal Photos Figure 1 PCB top view CFS8DL5800MINIV / 573R-5800MINIV 11/26/2025 Figure 2 Top View without Antenna 2 CFS8DL5800MINIV / 573R-5800MINIV 11/26/2025 Figure 3 PCB front side Figure 4 PCB inside cover with battery CFS8DL5800MINIV / 573R-5800MINIV 11/26/2025 Figure 5 PCB inside cover without battery

ANT1 (Trace on PCB) ANT2 (Physical part solder into PCB)

5800MINIV Report #: RESI-26003 FCC ID: CFS8DL5800MINIV RF EXPOSURE EVALUATION 5800 Wireless Alarm transmitter Issue Date: 2025-11-26 Prepared by and for: Resideo LLC. 2 Corporate Center Dr. Suite 100 PO Box 9040 Melville, NY 11747 Testing NVLAP Lab Code: 600110 Report# RESI-26003 Test Report Revision History Revision Prepared By Reviewed By Revision Detail Release Date V0 Jose Badia Christian Fouth Original Release 2025-11-26 Report# RESI-26003 Contents ATTESTATION OF TEST RESULTS .................................................................................................................................................... 1 1. FCC RULES CONCERNING MAXIMUM PERMISSIBLE RF EXPOSURE .................................................................... 1 § CFR 47 1.1310 Radiofrequency radiation exposure limits ........................................................................................................... 1 2. UUT POWER OUTPUT AND ANTENNA GAIN .................................................................................................................. 1 2.1. MPE CALCULATIONS ......................................................................................................................................................... 2 Report# RESI-26003 ATTESTATION OF TEST RESULTS Company Name: Ademco Inc., 2 Corporate Center Dr., Melville, NY 11747, USA EUT Description: Wireless Alarm Transmitter Model: 5800MINIV Serial Number: Non-Serialized units Standards Specification FCC §1.1310 Report Prepared By: Reviewed & Approved By: Name: Jose Badia Name: Christian Fouth Title: Regulatory Certification Engineer Title: Sr. Wireless Certification Engineer Ademco Inc. Ademco Inc. Report# RESI-26003 1. FCC RULES CONCERNING MAXIMUM PERMISSIBLE RF EXPOSURE: § CFR 47 1.1310 Radiofrequency radiation exposure limits. The criteria listed in table 1 shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in § 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of § 2.1093 of this chapter. Further information on evaluating compliance with these limits can be found in the FCC’s OST/OET Bulletin Number 65, ‘‘Evaluating Compliance with FCC-Specified Guidelines for Human Exposure to Radiofrequency Radiation.’’ NOTE TO INTRODUCTORY PARAGRAPH: These limits are generally based on recommended exposure guidelines published by the National Council on Radiation Protection and Measurements (NCRP) in ‘‘Biological Effects and Exposure Criteria for Radiofrequency Electromagnetic Fields,’’ NCRP Report No. 86, Sections 17.4.1, 17.4.1.1, 17.4.2 and 17.4.3. Copyright NCRP, 1986, Bethesda, Maryland 20814. In the frequency range from 100 MHz to 1500 MHz, exposure limits for field strength and power density are also generally based on guidelines recommended by the American National Standards Institute (ANSI) in Section 4.1 of ‘‘IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz,’’ ANSI/IEEE C95.1–1992, Copyright 1992 by the Institute of Electrical and Electronics Engineers. 2. UUT POWER OUTPUT AND ANTENNA GAIN The maximum radiated output power is measured as 87.28 dBuV/m at 3 meters which corresponds to a EIRP of -7.95 dBm at 345 MHz. The max antenna gain is -20.2 dBi The power density limit at 345 MHz is 0.229 mW/cm 2 Report# RESI-23004 2.1. MPE CALCULATIONS: FCC GENERAL POPULATION / UNCONTROLED EXPOSURE LIMITS: FOR 300 MHz to 1,500 MHz use F / 1500 mW/cm 2 FOR 1,500 to 100,000 MHz use 1 mW/cm 2 EQUATIONS: MAX AVG EIRP (mW) = 10 {(MAX COND PWR. + ANT GAIN + DUTY FACTOR)/10)} THE FRIIS TRANSMISSION EQUATION = EIRP X DUTY CYCLE / (4 X PI X 20 cm 2 ) BANDS AND FCC IDs BAND FCC ID 345 CF8DL5800MINIV BAND: CH No: FREQ (Mhz) TRP (dBm) MAX COND. PWR (dBm) ANTENNA GAIN (dBi): DUTY FACTOR (dB) MAX AVG EIRP (mW) FRISS mW/CM 2 EXP LIMIT mW/CM 2 % OF LIMIT 345 MHz N/A 345 N/A N/A -20.2 0.097 0.000032 0.229 0.0139 MAXIMUM MPE OF THE Z-Wave MODULE AS % OF LIMIT IS: 0.0139 RESULTS: TEST RESULT: PASS In the configuration tested the EUT complied with the standards specified above.

Prepared by: Josef Grygar Printed / Downloaded copies of this document are uncontrolled for use. https://resideo.myeqms.com/ Template BCF3820 Rev.1 Ademco CZ s.r.o. Testing Laboratory Tuřanka 1460/106a, Brno, 627 00, Czech Republic Testing laboratory no. 1695; accredited by CAI according to ČSN EN ISO/IEC 17025:2018 Report No. 25121-RP Antenna gain and pattern measurement report Page 1 of 9 Customer: Applicant ́s Name Resideo LLC. Applicant ́s Address 2 Corporate Center Dr City, ZIP, Country Melville, NY 11747 Equipment Under Test: Product Door/Window Sensor Manufacturer ́s Name Resideo Model 5800MINIV FCC/IC ID: CFS8DL5800MINIV / 573F-5800MINIV Test Information: Date of test 11/21/2025 Data of issue 11/25/2025 Environmental Conditions: Ambient temperature +15 °C to + 35 °C Relative humidity 20 % to 75 % Atmospheric Pressure 86 kPa – 106 kPa Approval: Created and tested by Josef Grygar, Test Engineer ................................. Approved by Libor Palíšek, Head of TL ................................. Report No. 25121-RP Page 2 of 9 Table of Contents General information.......................................................................................................................................................... 3 Equipment Under Test ...................................................................................................................................................... 4 Test facility and methodology ........................................................................................................................................... 5 Test results ........................................................................................................................................................................ 7 3D PLOTS ........................................................................................................................................................................... 8 ANTENNA A ................................................................................................................................................................... 8 Report No. 25121-RP Page 3 of 9 General information This device has been tested by Ademco CZ s.r.o. testing laboratory on address: Tuřanka 1460/106a, Brno, 627 00, Czech Republic. Ademco CZ s.r.o. testing laboratory is accredited by CAI according to ČSN EN ISO/IEC 17025:2018. Laboratory number: 1695 Ademco CZ s.r.o. testing laboratory is FCC recognized to perform compliance testing. Designation Number: CZ0004 Registration Number: 860869 Scope: FCC Part15, Subpart B; FCC Part15, Subpart C Test results are applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of Ademco CZ s.r.o. testing laboratory Measurement Uncertainty and Test Equipment The measurement uncertainty was calculated according to EN 55016-4-2, ETSI TR 100 028-1, ETSI TR 100 028-2. The reported expanded uncertainty of measurement is stated as the standard uncertainty of measurement multiplied by the coverage factor k = 2 such that the coverage probability corresponds to approximately 95 %. Measurement Uncertainties were not taken into account and are published for informational purposes only. Test Standard Uncertainty Radio frequency ± 1x 10 -7 RF power - conducted ± 0.75 dB Effective radiated power ± 3.5 dB Radiated emissions ± 5.6 dB Radiated emissions- Substitution ± 4.3 dB Conducted Spurious emissions ± 3.3 dB Occupied Bandwidth ± 0.006 % Temperature ± 0.6 °C Humidity ± 3 % The measuring equipment utilized to perform the tests documented in this report have been calibrated in accordance with the manufacturer’s recommendations and is traceable to recognized national standards. Asset No. Manufacturer Model Description Cal. date Cal. Due date 950775 Rohde & Schwarz ESR7 Receiver 6/2025 6/2027 950777 ETS Lindgren 7000-010 EMCenter 1 N/A N/A 950778 ETS Lindgren 7000-010 EMCenter 2 N/A N/A 950783 ETS Lindgren 3142E Antenna (Biconilog) 2/2024 2/2027 Report No. 25121-RP Page 4 of 9 Equipment Under Test Product Name Antenna of Wireless Door/Window Sensor Test Model 5800MINIV Serian number MEL-1192 HW, SW - Power supply 1X CR2450 battery Continuous radiation power setting 344.94 MHz EUT antennas Antenna type Frequency (MHz) Antenna A Meander Antenna 344.94 MHz Figure 1 EUT – Front side Figure 2 EUT- back side Figure 3 EUT inside Report No. 25121-RP Page 5 of 9 Figure 4 SAR/FAR chamber Test facility and methodology Test facility: Total EIRP value was measured in the FAR chamber as a summary of EIRP for both horizontal and vertical measurement polarization. FAR chamber is equipped with turntable, which rotates the EUT by 360° in azimuth with incremment of 30°. EUT was also manually rotated in elevation with increment of 30°. Measurement distance is 3m. Chamber (SAR/FAR) • 9 kHz – 40 GHz • Shielding effectiveness: 80 – 100 dB • 9 m x 7 m x 6 m(3 m measurement distance) • NSA / VSWR compliant (Accredited test site validation performed by Seibersdorf Laboratories (Last validation: 23.02.2024) Test Methodology: Antenna gain is measured in active way. EUT has a test FW, which is capable of continuous transmission. Antenna gain is obtained as the result of subtraction of Total Effective radiated power (EIRP) and conducted power on antenna input. For conducted power measurement was EUT connected with signal analyzer and antenna input power was recorded. Cable attenuation was taken into account. Figure 5 EUT zero position and orientation Y Z X Report No. 25121-RP Page 6 of 9 Figure 6 EUT zero position and orientation X Y Z Report No. 25121-RP Page 7 of 9 Test results ANTENNA A Frequency [MHz] Conducted Power to antenna [dBm] Total EIRP [dBm] Ant. Gain [dBi] 344.94 11.3 -8.9 -20.2 Ant. Gain (dBi) = Total EIRP (dBm) – Conducted power to antenna (dBm) Figure 7 EUT Antennas ANTENNA A Report No. 25121-RP Page 8 of 9 3D PLOTS ANTENNA A Report No. 25121-RP Page 9 of …

Text truncated - open the document above for the full version.

5800MINIV Report #: RESI-26001 FCC ID: CFS8DLMINIV IC: 573F-5800MINIV FCC 15.231 RSS-210 issue 11 Intrusion Detection Sensor Issue Date: 2025-01-27 Prepared by and for: Resideo LLC. 2 Corporate Center Dr. Suite 100 PO Box 9040 Melville, NY 11747 Testing NVLAP Lab Code: 600110 Report #: RESI-26001 Page 2 of 19 Resideo LLC. 2 Corporate Center Dr., Melville, NY 11747 TEL: (516) 577-2000 This report shall not be reproduced except in full, without the written approval of Resideo LLC. Test Report Revision History Revision Prepared By Reviewed By Revision Detail Release Date Jose Badia Christian Fouth Original Release 2025-10-16 1.0 Jose Badia Christian Fouth Added 99% OBW plot; added message timing and duty cycle; added average spurious and fundamental 2026-01-20 2.0 Jose Badia Christian Fouth Removed message timing description. Fixed a few typos 2026-01-27 Report #: RESI-26001 Page 3 of 19 Resideo LLC. 2 Corporate Center Dr., Melville, NY 11747 TEL: (516) 577-2000 This report shall not be reproduced except in full, without the written approval of Resideo LLC. Contents Test Report Revision History ........................................................................................................................................ 2 Attestation of test results ............................................................................................................................................... 4 Test result summary ....................................................................................................................................................... 5 Deviations from test standard .................................................................................................................................... 5 Accreditations and authorizations .................................................................................................................................. 6 Measurement uncertainty............................................................................................................................................... 6 Sample Calculation ................................................................................................................................................... 6 Test Setup ...................................................................................................................................................................... 7 Measurement Bandwidths ......................................................................................................................................... 7 Antenna Port conducted measurements ..................................................................................................................... 7 Radiated Emission measurements ............................................................................................................................. 8 Equipment under test ..................................................................................................................................................... 9 Test Item Description ................................................................................................................................................ 9 Test Sample Identification ......................................................................................................................................... 9 Worse-Case Configuration & Mode .......................................................................................................................... 9 Power setting ............................................................................................................................................................. 9 Antenna description ....................................................................................................................................................... 9 Test & measurement equipment .................................................................................................................................... 9 Message Timing and Duty Cycle ................................................................................................................................ 11 5800 Message timing .............................................................................................. Error! Bookmark not defined. Message protocol, timing and duty cycle calculation ......................... Error! Bookmark not defined. 5800MINIV Supervision Message timing Diagrams .......................... Error! Bookmark not defined. Antenna Port measurements ........................................................................................................................................ 11 Duty Cycle .............................................................................................................................................................. 11 20dB Bandwidth ...................................................................................................................................................... 11 99% Occupied Bandwidth ....................................................................................................................................... 13 Radiated Emissions...................................................................................................................................................... 15 Fundamental ............................................................................................................................................................ 15 Spurious Radiated Emissions .................................................................................................................................. 16 Below 1GHz ........................................................................................................................................ 17 1-10GHz ................................................…

Text truncated - open the document above for the full version.

5800MINIV Setup Photos Antenna Port Tests 5800MINIV Radiated Emissions below 1GHz 5800MINIV Radiated Emissions above 1GHz
