CFS8DLWTS800Wireless Alarm Transmitter

Model WTS800 Wireless Touchscreen Installation and Setup Guide GENERAL INFORMATION The WTS800 is a wireless touchscreen that allows you to perform system arming and disarming functions, as well as monitoring the status of your security system. The Touchscreen is used in conjunction with the ADT2X16AIO and ADT7AIO Control Panels. Up to a total of eight (8) Touchscreens can be used on the system. • The Touchscreen must be enrolled in the Control Panel before it can be used. • The WTS800 requires Control Panel Firmware Version 4.9 or later. 1 Microphone 2 Camera 3 LED Status 4 Battery Charge LED STATUS INDICATIONS LED Function Red System Armed Red - Flashing Alarm condition or in Programming mode Amber System trouble Amber - Flashing Device trouble • System cannot be armed Green Ready to Arm Green - Flashing Device trouble • System can be armed Off Not ready to Arm OPERATING THE TOUCHSCREEN For operating instructions, see the User Guide for the Control Panel being used with this Touchscreen. MOUNTING THE TOUCHSCREEN 1. From the bottom of the Touchscreen, remove screw [A] that secures the front cover assembly [B] to the rear mounting plate [C]. Note: It is important to remove the front cover assembly from the rear mounting plate and not inadvertently remove the LCD panel from the front cover assembly. See the illustration to identify the slots to access with the screwdriver. 2. Using a screwdriver in the proper slots, carefully pry the front cover assembly [B] from the rear mounting plate [C]. 3. Select a desired location to mount the wireless Touchscreen. To prevent heat damage to the Touchscreen and reduce glare and eye strain, it is recommended to mount the touchscreen out of direct sunlight and at a proper height for optimal viewing. 4. Refer to the Wire Table to determine the proper gauge and length of the wires to use for your installation. 5. Carefully route the wires through the opening in the rear mounting plate [C] and while observing proper polarity, connect the wires to the + and - terminals [D] on the printed circuit board [E]. Wire Table AWG Wire Length AWG Wire Length #16 wire 411 ft (125m) #20 wire 162 ft (49m) #18 wire 258 ft (78m) #22 wire 102 ft (31m) 6. While observing polarity, connect the unattached end of the wires to the Power Supply [F]. 7. Mount the rear mounting plate [C] directly on a wall or secured to an electrical junction box (single or double width) as follows: Note: The tamper breakout portion of the rear mounting plate MUST be secured to a stud, solid wood, or with a robust wall anchor. ( * = tamper screw locations). • For wall mounting, while observing the bubble in the green level display [G], ensure the rear mounting plate is level and secure it to the wall with four screws [H]. • For junction box mounting, secure the rear mounting plate to the junction box with either two screws [I] (single width box) or four screws [H] (double width box). 8. Insert the battery pack [J] into the slot on the back of the front case assembly [B] and snap it in to secure in place. 9. Secure the battery wires in the retainer clip [K] and plug the wire connector [L] into the receptacle [M] on the printed circuit board [E]. 10. Being careful not to damage the wires, align the tabs on the top of the front case assembly [B] with the slots on the rear mounting plate [C] and snap the two pieces together. Secure with locking screw [A]. 11. Plug the Power Supply [F] into a non-switchable 110VAC, 60Hz outlet. After a few seconds, the splash screen comes on, followed by a steady green LED light to indicate power is applied. Allow 24 hours for the battery to become fully charged. BATTERY PACK REPLACEMENT Replace the battery pack as follows: 1. From the bottom of the Touchscreen, remove screw [A] that secures the front cover assembly [B] to the rear mounting plate [C]. Note: It is important to remove the front cover assembly from the rear mounting plate and not inadvertently remove the LCD panel from the front cover. See the illustration to identify the slots to access with the screwdriver. 2. Using a screwdriver in the proper slots, carefully pry the front cover [B] from the rear mounting plate [C]. 3. Disconnect the battery wire connector [L] from the receptacle [M] on the printed circuit board [E]. 4. Remove the battery pack. 5. Insert the replacement battery pack [J] into the slot on the back of the front case assembly [B] and snap it in to secure in place. 6. Secure the battery wires in the retainer clip [K] and plug the wire connector [L] into the receptacle [M] on the printed circuit board [E]. 7. Being careful not to damage the wires, align the tabs on the top of the front case assembly [B] with the slots on the rear mounting plate [C] and snap the two pieces together. Secure with locking screw [A]. CAUTION: Risk of explosion if the battery is replaced by an incorrect type. Dispose of used batteries according to the instructions ENROLLING THE TOUCHSCREEN The Touchscreen must be enrolled in the Control Panel before it can be used. The Touchscreen communicates directly to the Control Panel via the ADTZWM series Wi-Fi module; and does not require a network router. Enroll the Touchscreen as follows: 1. After powering up the Touchscreen, it will display "Starting Up, Please Standby" and then enters the Pairing Mode. 2. Use the Alarm.com MobileTech tool and select "Add as Peripheral". 3. When the Control Panel is in the "Learn Mode", select "Pair" on the Touchscreen and it will attempt to pair with the Control Panel. 4. If it is not paired during power up, it continues to display "Starting Up, Please Standby". From the "Pairing Menu", select "Pair". • After successful pairing, it will display the home screen with status of the Control Panel. • If pairing is unsuccessful, press Cancel, move the Touchscreen closer to the Control Panel, ensure that no other Wi-Fi devices are in WPS mode, and then restart the pairing process. IMPORTANT: Once enrolled, the Touchscreen cannot be used with a…

Text truncated - open the document above for the full version.

Form: RFT-AMER-TCB-OP-19o Revision: 1 Page 1 of 1 Date: 1/25/2023 Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to 47 CFR part §2.911(d)(7) of the FCC rules FCC ID: CFS8DLWTS800 To whom it may concern, This letter is to certify that Resideo LLC. (“Applicant”) accepts responsibilities to act as its own agent pursuant to 47 CFR part §2.911(d)(7) of the FCC rules for service of process. I consent to the obligation to accept service of process on behalf of the Applicant for all certification applications to the FCC. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC and Intertek if there is any change in the status identified above. Applicant Company Name : Resideo LLC. Contact Name : Christian Fouth Address : 2 Corporate Center Dr., Melville, NY 11747 Telephone No : 516-577-2000 Email : [email protected] Applicant FRN : 0004071130 Signature: ____________________________________ Date: 12/30/2025

Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: Resideo LLC. FCC ID: CFS8DLWTS800 To whom it may concern, Resideo LLC. (“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is not identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. Applicant further certifies that no Cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software is installed in the equipment being certified. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change in the status identified above. Christian Fouth Sr. Wireless Certification Engineer Resideo LLC. 12/29/2025 Form: RFT-AMER-TCB-OP-19n Revision: 1 Page 1 of 1 Date: 1/25/2023

Date: 12/29/2025 Intertek Testing Services NA inc. 70 Codman Hill Rd Boxborough, MA 01719, United States Attention: FCC Office of Engineering and Technology Subject: Request for Confidentiality FCC ID: CFS8DLWTS800 To Whom it May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission's rule (47 CFR §§ 0.457, 0.459), we are requesting the Bureau to withhold the following attachments as confidential document from public disclosure indefinitely. • Schematic Diagram • Block Diagram • Operational Description Above mentioned documents contain detailed system and equipment description considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Best Regards, Christian Fouth Sr. Wireless Certification Engineer Resideo LLC. / Resideo Technologies

CFS8DLWTS800 12/27/2025 EXTERNAL PHOTOS Figure 1 Top view Figure 2 Back view CFS8DLWTS800 12/27/2025 Figure 3 Side view from top Figure 4 Side view from bottom CFS8DLWTS800 12/27/2025 Figure 5 Side view from left Figure 6 Side view from right

CFS8DLWTS800 LABEL AND LABEL LOCATION Figure 1 Label Figure 2 Label location

CFS8DLWTS800 12/27/2025 Internal Photos Figure 1 Top view PCB Antenna External Antenna ports CFS8DLWTS800 12/27/2025 Figure 2 PCB top view without metal shield There are no components underneath the "cross bars". CFS8DLWTS800 12/27/2025 Figure 3 PCB top view without the cross bars CFS8DLWTS800 12/27/2025 Figure 4 PCB back view CFS8DLWTS800 12/27/2025 Figure 5 PCB back view without metal shield CFS8DLWTS800 12/27/2025 Figure 6 PCB inside cover with battery CFS8DLWTS800 12/27/2025 Figure 7 PCB inside cover without battery

WTS800 Report #: RESI-27003 FCC ID: CFS8DLWTS800 RF EXPOSURE EVALUATION 2.4 GHz WLAN wireless touchscree Issue Date: 2025-12-27 Prepared by and for: Resideo LLC. 2 Corporate Center Dr. Suite 100 PO Box 9040 Melville, NY 11747 Testing NVLAP Lab Code: 600110 Report# RESI-27003 Test Report Revision History Revision Prepared By Reviewed By Revision Detail Release Date V0 Jose Badia Christian Fouth Original Release 2025-12-27 Report# RESI-27003 Contents ATTESTATION OF TEST RESULTS .................................................................................................................................................... 1 1. FCC RULES CONCERNING MAXIMUM PERMISSIBLE RF EXPOSURE .................................................................... 1 § CFR 47 1.1310 Radiofrequency radiation exposure limits ........................................................................................................... 1 2. UUT POWER OUTPUT AND ANTENNA GAIN .................................................................................................................. 1 2.1. MPE CALCULATIONS ......................................................................................................................................................... 2 Report# RESI-27003 ATTESTATION OF TEST RESULTS Company Name: Resideo LLC., 2 Corporate Center Dr., Melville, NY 11747, USA EUT Description: 2.4 GHz WLAN Wireless Touchscreen Model: WTS800 Serial Number: Non-Serialized units Standards Specification FCC §1.1310 Report Prepared By: Reviewed & Approved By: Name: Jose Badia Name: Christian Fouth Title: Regulatory Certification Engineer Title: Sr. Wireless Certification Engineer Resideo LLC. Resideo LLC. Report# RESI-27003 1. FCC RULES CONCERNING MAXIMUM PERMISSIBLE RF EXPOSURE: § CFR 47 1.1310 Radiofrequency radiation exposure limits. The criteria listed in table 1 shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in § 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of § 2.1093 of this chapter. Further information on evaluating compliance with these limits can be found in the FCC’s OST/OET Bulletin Number 65, ‘‘Evaluating Compliance with FCC-Specified Guidelines for Human Exposure to Radiofrequency Radiation.’’ NOTE TO INTRODUCTORY PARAGRAPH: These limits are generally based on recommended exposure guidelines published by the National Council on Radiation Protection and Measurements (NCRP) in ‘‘Biological Effects and Exposure Criteria for Radiofrequency Electromagnetic Fields,’’ NCRP Report No. 86, Sections 17.4.1, 17.4.1.1, 17.4.2 and 17.4.3. Copyright NCRP, 1986, Bethesda, Maryland 20814. In the frequency range from 100 MHz to 1500 MHz, exposure limits for field strength and power density are also generally based on guidelines recommended by the American National Standards Institute (ANSI) in Section 4.1 of ‘‘IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz,’’ ANSI/IEEE C95.1–1992, Copyright 1992 by the Institute of Electrical and Electronics Engineers. 2. UUT POWER OUTPUT AND ANTENNA GAIN The maximum conducted output power is measured as 23.13 dBm at antenna port and the max antenna gain is 2.59 dBi. This corresponds to a EIRP of 25.72 dBm at 2.4 GHz. The power density limit at 2.4 GHz is 1 mW/cm 2 Report# RESI-23004 2.1. MPE CALCULATIONS: FCC GENERAL POPULATION / UNCONTROLED EXPOSURE LIMITS: FOR 300 MHz to 1,500 MHz use F / 1500 mW/cm 2 FOR 1,500 to 100,000 MHz use 1 mW/cm 2 EQUATIONS: MAX AVG EIRP (mW) = 10 {(MAX COND PWR. + ANT GAIN + DUTY FACTOR)/10)} THE FRIIS TRANSMISSION EQUATION = EIRP X DUTY CYCLE / (4 X PI X 20 cm 2 ) BANDS AND FCC IDs BAND FCC ID 2.4 GHz CF8DLWTS800 BAND: CH No: FREQ (Mhz) TRP (dBm) MAX COND. PWR (dBm) ANTENNA GAIN (dBi): DUTY FACTOR (dB) MAX AVG EIRP (mW) FRISS mW/CM 2 EXP LIMIT mW/CM 2 % OF LIMIT 2.4 GHz N/A 2.4 GHz N/A 23.13 2.59 0.0743 1 7.43 MAXIMUM MPE OF THE Wi-Fi chip AS % OF LIMIT IS: 7.43 RESULTS: TEST RESULT: PASS In the configuration tested the EUT complied with the standards specified above.

RESIDEO CONFIDENTIAL 1 Antenna Gain and Pattern Measurement Report Model Name: WTS800 DATA TESTED: Nov 10 th , 2025. REPORT ISSUED: Nov 10 th , 2025. Prepared By RESIDEO TECHNOLOGIES INC. Room428, Building1, No.899 Dangui Rd., Zhangjiang Hi-tech Park, Pudong New Area, Shanghai, P.R.C 201203 RESIDEO CONFIDENTIAL 2 Test Report Revision History Revision Tested and prepared by Reviewed and Approved By Revision Detail Release Date A Luo Yi Anthony Xu Original Release Nov 10th, 2025 Tested and prepared by: Luo Yi Reviewed and Approved By: Anthony xu. Luo Yi RESIDEO CONFIDENTIAL 3 Table of Contents 1. Test Methodology ................................................................................................................................ 4 2. Test and Measurement Equipment ..................................................................................................... 4 3. Device Under Test Information ............................................................................................................ 4 4. Result Summary ................................................................................................................................... 5 5. Plots ...................................................................................................................................................... 5 5.1 Antenna 1 – 2412 MHz 3D Passive ............................................................................................... 5 5.2 Antenna 1– 2437 MHz 3D Passive ............................................................................................... 7 5.3 Antenna 1– 2462 MHz 3D Passive ............................................................................................... 9 5.4 Antenna 2 – 2412 MHz 3D Passive ............................................................................................. 16 5.5 Antenna 2– 2437 MHz 3D Passive ............................................................................................. 19 5.6 Antenna 2– 2462 MHz 3D Passive ............................................................................................. 22 6. Test Setup ........................................................................................................................................... 25 Figure 1.WTS800 Antenna1 2412 MHz Front View ...................................................................................... 5 Figure 2.WTS800 Antenna1 2412 MHz Back View ........................................................................................ 6 Figure 3.WTS800 Antenna1 2412 MHz Top View ......................................................................................... 6 Figure 4.WTS800 Antenna1 2412 MHz Bottom View ................................................................................... 6 Figure 5.WTS800 Antenna1 2412 MHz Left Side View ................................................................................. 7 Figure 6.WTS800 Antenna1 2412 MHz Right Side View ............................................................................... 7 Figure 7.WTS800 Antenna1 2437 MHz Front View ...................................................................................... 7 Figure 8.WTS800 Antenna1 2437 MHz Back View ........................................................................................ 8 Figure 9.WTS800 Antenna1 2437 MHz Top View ......................................................................................... 8 Figure 10.WTS800 Antenna1 2437 MHz Bottom View ................................................................................. 8 Figure 11.WTS800 Antenna1 2437 MHz Left View ....................................................................................... 9 Figure 12.WTS800 Antenna1 2437 MHz Right View ..................................................................................... 9 Figure 13.WTS800 Antenna1 2462 MHz Front View .................................................................................... 9 Figure 14.WTS800 Antenna1 2462 MHz Back View .................................................................................... 10 Figure 15.WTS800 Antenna1 2462 MHz Top View ..................................................................................... 10 Figure 16.WTS800 Antenna1 2462 MHz Bottom View ............................................................................... 10 Figure 17.WTS800 Antenna1 2462 MHz Left View ..................................................................................... 11 Figure 18.WTS800 Antenna1 2462 MHz Right View .................................................................................. 11 Figure 19.WTS800 Antenna2 2412 MHz Front View .................................................................................. 11 Figure 20.WTS800 Antenna2 2412 MHz Back View .................................................................................... 12 Figure 21.WTS800 Antenna2 2412 MHz Top View ..................................................................................... 12 Figure 22.WTS800 Antenna2 2412 MHz Bottom View ............................................................................... 12 Figure 23.WTS800 Antenna2 2412 MHz Left Side View ............................................................................. 13 Figure 24.WTS800 Antenna2 2412 MHz Right Side View ........................................................................... 13 Figure 25.WTS800 Antenna2 2437 MHz Front View .................................................................................. 13 RESIDEO CONFIDENTIAL 4 Figure 26.WTS800 Antenna2 2437 MHz Back View .................................................................................... 14 Figure 27.WTS800 Antenna2 2437 MHz Top View ..................................................................................... 14 Figure 28.WTS800 Antenna2 2437 MHz Bottom View ...........................................…

Text truncated - open the document above for the full version.

ADT WTS800 Report #: RESI-27001 FCC ID: CFS8DLWTS800 FCC 15.247 Wireless Touchscreen 2.4 GHz WLAN Transmitter Issue Date: 2026-01-06 Prepared by and for: Resideo LLC. 2 Corporate Center Dr. Suite 100 PO Box 9040 Melville, NY 11747 Testing NVLAP Lab Code: 600110 Report #: RESI-27001 Page 2 of 82 Resideo LLC. 2 Corporate Center Dr., Melville, NY 11747 TEL: (516) 577-2000 This report shall not be reproduced except in full, without the written approval of Resideo LLC. Test Report Revision History Revision Prepared By Reviewed By Revision Detail Release Date V0 Jose Badia Christian Fouth Original Release 2025-12-17 V1 Jose Badia Christian Fouth Updated with tabular data for Spurious Radiated in for frequencies in elevated noise floor range 2026-01-06 V2 Jose Badia Christian Fouth Updated with 1-10 GHz prescan; added explanation for ambient signal 2026-01-10 Report #: RESI-27001 Page 3 of 82 Resideo LLC. 2 Corporate Center Dr., Melville, NY 11747 TEL: (516) 577-2000 This report shall not be reproduced except in full, without the written approval of Resideo LLC. Contents ATTESTATION OF TEST RESULTS .................................................................................................................................... 6 TEST RESULT SUMMARY ................................................................................................................................................ 7 Deviations from test standard ................................................................................................................................... 7 ACCREDITATIONS AND AUTHORIZATIONS .................................................................................................................... 8 USA ................................................................................................................................................................................ 8 MEASUREMENT UNCERTAINTY ..................................................................................................................................... 8 Sample Calculation .................................................................................................................................................... 8 Test Setup Diagram ....................................................................................................................................................... 9 Measurement Bandwidths ........................................................................................................................................ 9 Antenna Port conducted measurements .................................................................................................................. 9 Radiated Emission measurements .......................................................................................................................... 10 30 MHz – 1000 MHz ............................................................................................................................ 10 Above 1 GHz ........................................................................................................................................ 10 AC conducted measurements ................................................................................................................................. 11 EQUIPMENT UNDER TEST ............................................................................................................................................ 11 Test Item Description .............................................................................................................................................. 11 Test Sample Identification ....................................................................................................................................... 11 Antenna description .................................................................................................................................................... 11 TEST & MEASUREMENT EQUIPMENT .......................................................................................................................... 12 6 dB Emission Bandwidth (DTS Bandwidth) ............................................................................................................ 14 Test Information ................................................................................................................................. 14 Worst case scenario ............................................................................................................................ 14 Test Results ......................................................................................................................................... 14 99% Occupied Bandwidth ....................................................................................................................................... 24 Test Information ................................................................................................................................. 24 Worst case scenario ............................................................................................................................ 24 Test Results ......................................................................................................................................... 25 Maximum Conducted Output Power ...................................................................................................................... 35 Test Description .................................................................................................................................. 35 Test Criteria ......................................................................................................................................... 35 Test Information ................................................................................................................................. 36 Test…

Text truncated - open the document above for the full version.

WTS800 Setup Photos Antenna Port Tests WTS800 Radiated Emissions below 1GHz WTS800 Radiated Emissions above 1GHz WTS800 Powerline Conducted
