COMES-56556BTBluetooth Speaker

FCC ID:COMES-56556BT Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. (audio power)

Differences Description We SHENZHEN AOB ELECTRONICS CO.,LTD state: Product： Bluetooth Speaker Model Name： ES-56556BT, VS-BTS-ASST Trade Name: N/A FCC ID: COMES-56556BT The electrical circuit design, layout, components used and internal wiring for above models are identical, only the model name is different. Signatory Date 2015-1-4 Signature Name: Steven Shen Title: Boss Company: SHENZHEN AOB ELECTRONICS CO.,LTD Address: BldgA4, Third Industry Area, Huang Ma Bu Village, Xixiang Town, Bao An District, Shenzhen, China

SHENZHEN AOB ELECTRONICS CO.,LTD Jan.04, 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID:_____ COMES-56556BT Product Name:__ Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Jan.04, 2015 By: Signature Title: Manager On behalf of : SHENZHEN AOB ELECTRONICS CO.,LTD Telephone: 13502852256 Bluetooth speaker Steven Shen COMES-56556BT Bluetooth Speaker

External Photos ALL VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT VIEW OF EUT (PORT)

FCC ID Label Location FCC ID:COMES-56556BT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos OPEN VIEW OF EUT INTERNAL VIEW OF EUT-1 Antenna INTERNAL VIEW OF EUT-2 INTERNAL VIEW OF EUT-3

RF exposure letter RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ʇ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ș[ɰf(GHz)] ʇ 3.0 for 1-g SAR and ʇ 7.5 for 10-g extremity SAR, where ș f(GHz) is the RF channel transmit frequency in GHz ș Power and distance are rounded to the nearest mW and mm before calculation ș The result is rounded to one decimal place for comparison Worse case is as below: [2480 MHz 0 dBmͧ1 mWͨ output power] (1mW /5mm) ș[ɰ2.441(GHz)]=0.3150 <3.0 for 1-g SAR Then SAR evaluation is not required 2441MHz -0.11dBm0.975mW

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F, Building B, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China TEL: +86-755 3688 6288FAX: +86-755 3688 6277E-mail:[email protected] FCC TESTREPORT Report No: STS1502023FE03 Issued for SHENZHEN AOB ELECTRONICS CO., LTD. BldgA4, Third Industry Area, Huang Ma Bu Village, Xixiang Town, Bao An District, Shenzhen, China Product Name: Bluetooth Speaker Brand Name: N/A Model No.: ES-56556BT Series Model: VS-BTS-ASST FCC ID: COMES-56556BT Test Standard: FCC Part 15.247 S T L A B S Page 2 of69Report No.:STS1502023FE03 TEST RESULT CERTIFICATION Applicant’s name ................. : SHENZHEN AOB ELECTRONICS CO., LTD. Address ................................. : BldgA4, Third Industry Area, Huang Ma Bu Village, Xixiang Town, Bao An District, Shenzhen, China Manufacture's Name ............ : SHENZHEN AOB ELECTRONICS CO., LTD. Address ................................. : BldgA4, Third Industry Area, Huang Ma Bu Village, Xixiang Town, Bao An District, Shenzhen, China Product description Product name ........................... : Bluetooth Speaker Band name ................................ : N/A Model and/or type reference ............................. : ES-56556BT, VS-BTS-ASST Ratings ................................... DC 3.7V by Battery Standards ............................. : FCC Part15.247 Test procedure ............................... : ANSI C63.4-2009 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : Dec.17,2014 to Dec.18,2014 Date of Issue.......................................... : Dec.19,2014 Test Result ............................................. : Pass Testing Engineer : (Tony Liu) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) Page 3 of69Report No.:STS1502023FE03 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.1 DESCRIPTION OF TEST MODES 9 2.2 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS 11 2.5EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 TEST SETUP 14 3.1.4 EUT OPERATING CONDITIONS 14 3.1.5TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS 21 4. CONDUCTED SPURIOUS EMISSIONS 38 4.1 REQUIREMENT 38 4.2TEST PROCEDURE 38 4.3 TEST SETUP 38 4.4 EUT OPERATION CONDITIONS 38 4.5 TEST RESULTS 39 5. NUMBER OF HOPPING CHANNEL 42 5.1 APPLIED PROCEDURES / LIMIT 42 5.2 TEST PROCEDURE 42 5.3 TEST SETUP 42 5.4 EUT OPERATION CONDITIONS 42 Page 4 of69Report No.:STS1502023FE03 Table of Contents Page 5.5 TEST RESULTS 43 6. AVERAGE TIME OF OCCUPANCY 47 6.1 APPLIED PROCEDURES / LIMIT 47 6.2 TEST PROCEDURE 47 6.3 TEST SETUP 47 6.4 EUT OPERATION CONDITIONS 47 6.5 TEST RESULTS 48 7. HOPPING CHANNEL SEPARATION MEASUREMEN 50 7.1 APPLIED PROCEDURES / LIMIT 50 7.2 TEST PROCEDURE 50 7.3 TEST SETUP 50 7.4 EUT OPERATION CONDITIONS 50 7.5 TEST RESULTS 51 8. BANDWIDTH TEST 52 8.1 APPLIED PROCEDURES / LIMIT 52 8.2 TEST PROCEDURE 52 8.3 TEST SETUP 52 8.4 EUT OPERATION CONDITIONS 52 8.5 TEST RESULTS 53 9. OUTPUT POWER TEST 59 9.1 APPLIED PROCEDURES / LIMIT 59 9.2 TEST PROCEDURE 59 9.3 TEST SETUP 59 9.4 EUT OPERATION CONDITIONS 59 9.5 TEST RESULTS 60 10. ANTENNA REQUIREMENT 66 10.1 STANDARD REQUIREMENT 66 10.2 EUT ANTENNA 66 APPENDIX-PHOTOS OF TEST SETUP 67 Page 5 of69Report No.:STS1502023FE03 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(d) Conducted Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of69Report No.:STS1502023FE03 1.1 TEST FACILITY Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building 2, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China. FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±3.18dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.71dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of69Report No.:STS1502023FE03 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Bluetooth Speaker Trade Name N/A Model Name ES-56556BT Serial Model VS-BTS-ASST Model Difference There are only different of model Channel List Please refer to the Note 2. …
