CSQHG200CBI HomeGuary 200

BI HomeGuard 200™ Officer’s Reference Manual BI Part Number 8-90-00089-0 © 2001 BI Incorporated Revision C 8-90-00089-0, Revision Ci Preface Preface Notice HomeGuard 200 Officer’s Reference Manual Copyright © 2001 by BI Incorporated All Rights Reserved Printed in USA BI prepared this manual for use by BI customers only. All comments concerning the contents of this manual should be directed to BI’s Marketing Department, 6400 Lookout Road, Boulder, CO 80301, USA. No part of this work covered by copy- right may be reproduced in any form either graphically, elec- tronically, mechanically; including photocopying, recording, taping, or storage in an information retrieval system without prior written permission from BI. Trademarks and Patents The following are registered trademarks of BI Incorporated: • BI • BI logo • BI HomeGuard 200 Receiver • BI HomeGuard 200 Transmitter • BI HomeGuard Drive-BI • BI GuardWare Host System • BI 9010 Transmitter • BI K2 Host System • BI HES 600 Host System • BI Sobrietor Document History This document was created using Adobe FrameMaker 6 and PaintShop Pro 7. The body text is the Utopia typeface. This is Revision C, September 2001, BI Part No. 8-90-00089-0. HomeGuard 200 Officer’s Reference Manual ii8-90-00089-0, Revision C Technical Support For help related to client enrollment and schedules, report- ing, and host computer functions call your monitoring center. BI Incorporated has two monitoring centers, East and West. For technical assistance with BI Products, call BI Technical Support at (800) 241-9924 or your BI Account Service Represen- tative. Purpose This manual provides an officer with the information neces- sary to implement and use HomeGuard 200 radio frequency monitoring products. Scope The Officer’s Manual presents a tutorial for use of the HomeGuard 200 radio frequency monitoring system and a guide in acquainting clients with home arrest procedures. It provides all information required to: • learn to use HomeGuard 200 Receiver, Transmitter, and Drive-BI • teach clients to use the HomeGuard 200 Receiver and Tr a n s m i t t e r • install the HomeGuard 200 Receiver and Transmitter on site • set up monitoring requirements • troubleshoot and use the HomeGuard 200 products Note: Throughout this manual, the name HomeGuard 200 refers to the HomeGuard 200 radio frequency monitoring system. GuardCenter West BI Incorporated 6400 Lookout Road Boulder, CO 80301 USA (303) 218-1225 (800) 241-6768 FAX (303) 218-1250 GuardCenter East BI Incorporated One Citizen’s Plaza, Suite 501 Anderson, Indiana 46016 (765) 641-2496 (800) 825-1044 FAX (765) 649-3148 Preface 8-90-00089-0, Revision Ciii Preface Audience This manual is written for the attending officer who will train the client, set up the equipment, and monitor the client. United States FCC, Part 68 Compliance statement - This equipment complies with Part 68 of the FCC rules. On the bottom of the Receiver is a label that contains, among other information, the FCC registration num- ber and ringer equivalence number (REN) for this equipment. If requested, this information must be provided to the telephone company. Jack type needed - The Receiver connects to the telephone network with a USOC RJ11C jack. An FCC compliant telephone cord and modular plug is provided with this equipment. This equipment is designed to be connected to the telephone net- work or premises wiring using a compatible modular jack which is Part 68 compliant. Explanation of the Ringer Equivalence Number (REN) - The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive RENs on the tele- phone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENS should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total RENs, contact the telephone company to determine the maximum REN for the calling area. Temporary discontinuance of service - If the Receiver causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of ser- vice may be required. But if advance notice isn’t practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary. Telephone company changes - The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of the equipment. If this happens, the telephone company may provide advance notice in order for you to make the necessary modifications in order to maintain uninterrupted service. HomeGuard 200 Officer’s Reference Manual iv8-90-00089-0, Revision C Disconnection in case of trouble and location of repair cen- ter - If trouble is experienced with the Receiver, please contact BI Incorporated. If the equipment is causing harm to the tele- phone network, the telephone company may request that you disconnect the equipment from the network until the problem is resolved. Repairs customers can make - There are no customer-ser- viceable parts inside the BI HomeGuard Receiver. (Power and phone cords are replaceable on the BI HomeGuard Receiver.) Prohibitions - Connection to party lines or to telephone company coin service is prohibited. Industry Canada NOTICE: The Industry Canada label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational and safety requirements as prescribed in the Terminal Equipment Techni- cal Requirements document(s). The Department does not guar- antee the equipment will operate to the user’s satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local tele- communications company. The equipment must also be installed using an acceptable method of connec…

Text truncated - open the document above for the full version.

3 July 2007 Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Reference: KDB Tracking # 658320 Subject: FCCID# Report Filing with Wrong User’s Manual On January 27, 2003, a TCB acting in BI’s behalf submitted the documents that supported the certification of an intentional radiator with FCCID# CSQHG200C. Included in this document package was a complete user’s manual, titled “ BI HomeGuard 200 Officer’s Reference Manual”. Included in this manual is information that is not intended to be viewed by an offender on electronic house arrest or by competitors. The Manual is for use only by Officers and other authorized personnel using BI equipment. The original intent of BI Incorporated was that only the first seven pages, containing required FCC statements, copyright, and trademark information be included in the document package. Unfortunately, the entire document (130 pages) was included by the TCB. BI Incorporated is requesting that the full 130-page Officer’s Manual be removed from the files and be replaced with the attached short version that contains only the first seven pages of the manual. Sincerely, Bobby Clevenger VP of Internal Operations BI Incorporated 303-218-1000 (Telephone) BI Incorporated 6400 Lookout Road Boulder, Colorado 80301 303-218-1000 Fax 303-218-1250 http://www.bi.com

3 July 2007 Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Reference: KDB Tracking # 658320 Subject: FCCID# Report Filing with Wrong User’s Manual BI has recently become aware that an error was made when an FCCID# report was filed in 2003. On January 27, 2003, a TCB acting in BI’s behalf submitted the documents that supported the certification of an intentional radiator with FCCID# CSQHG200C. Included in this document package was a complete user’s manual, titled “ BI HomeGuard 200 Officer’s Reference Manual”. Included in this manual is information that is not intended to be viewed by an offender on electronic house arrest. The Manual is for use by Officers only. The original intent was that only the first seven pages, containing required FCC statements, be included in the document package. BI is aware that this manual has been available to the general public since January 27, 2003. We are requesting, via another letter, that the original 130-page manual be removed from the FCCID# website and replaced with an abbreviated manual that includes only the first seven pages. Sincerely, Bobby Clevenger VP of Internal Operations BI Incorporated 303-218-1000 (Telephone) BI Incorporated 6400 Lookout Road Boulder, Colorado 80301 303-218-1000 Fax 303-218-1250 http://www.bi.com

ANTENNA BOTTOM ANTENNA TOP CASE CONNECTOR SIDE CASE INSIDE CASE LABEL SIDE CASE LEFT SIDE RIGHT SIDE

FCC LABEL A drawing of the FCC label information that will be permanently affixed to the transmitter case is shown below. The location is on the bottom of the plastic case. Due to the small size of this device, it is not practical to place the complete label statement on the transmitter. Therefore, the information shown below is included in the instruction manual: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: CSQHG200C CANADA XXXX XXXXX BI INCORPORATED 1.5" .5"

ANTENNA BOTTOM ANTENNA TOP CASE CONNECTOR SIDE CASE INSIDE PCB ANTENNA MOUNTED PCB WITHOUT ANTENNA PCB BOTTOM
