JAPAN QUALITY ASSURANCE ORGANIZATION 21-25, KINUTA 1-CHOME, SETAGAYA-KU, TOKYO 157-8573 JAPAN PHONE (03) 3416-0111, TELEX 242-2531 JQA J FAX (03) 3416-9691 JQA APPLICATION NO.: 80-81034 Issue Date : April 13, 1999 Page 1 of 15 REPORT OF MEASUREMENTS JQA APPLICATION NO.: 80-81034 Applicant : NIKKO CO., LTD. 1-7-14, Mizumoto, Katsushika-ku, Tokyo 125-0032, Japan Manufacturer : NIKKO TEC INTERNATIONAL LTD. Room 812, Houston Center, 63 Mody Road, Tsimshatsui, Kowloon, Hong Kong Description of Equipment : Radio Controlled Toy FCC ID : CVTTN6760 Trade Name : NIKKO Model No. : TN6760 Serial No. : None Operating Frequency : 26.995 MHz – 27.255 MHz Power Supply : 9.0 VDC Applicable Rule : FCC Rules & Regulations Part 15 Subpart C (June 23, 1989) Place of Measurement : JQA EMC Engineering Dept. Date of Measurement : April 1, 1999(Completed) Total Pages of This Report : 15 (including this page) I certify that I am authorized to sign for the report and that all the statement in this report and in the exhibits hereto are true and correct to the best my knowledge and belief. Shigeru Osawa, Engineer Testing Div. EMC Engineering Dept. JQA Application No. :80-81034 FCC ID :CVTTN6760 Model No. :TN6760 Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 2 of 15 JQA QUALITY ASSURANCE ORGANIZATION 1. Radiated Spurious Emissions: [§15.227(a),(b)] Measurement Method Employed: Measurements were made under the conditions specified ANSI C63.4. The field strength measurements of the equipment under test were made at the distance of 3 meters away from the device which was placed on the wooden turntable 0.8 meter in height. The receiving antenna polarized horizontally was varied from 1 to 4 meters and the wooden turntable was rotated through 360 degrees to obtain the highest reading on the field strength meter. The device was tested three orthogonal planes. These measurements were repeated with the receiving antenna polarized vertically. The internal pre-amplifier was used from 27 MHz up to 1000 MHz. Measurement Results: Operating Frequency : 27.145 MHz Distance of Measurement : 3.0 meters Antenna MeterReading Field StreNgth at 3 m Frequency Factor Horiz. Vert. Horiz. Vert. (MHz) (dB) (dB/ m V) (dB/ m V) ( m V/m) ( m V/m) Fundamental 27.145 -2.0 46.2 57.9 162.2 623.7 (Average) 27.145 -2.0 53.3 64.8 367.3 1380.4 (Peak) Harmonics & other Frequency components 54.290 4.3 14.3 11.8 8.5 6.4 81.435 8.1 1.6 2.6 3.1 3.4 108.580 10.7 1.1 0.8 3.9 3.8 135.725 12.8 < -5.0 < -5.0 2.5 or Less 162.870 14.5 0.4 < -5.0 5.6 < 3.0 190.015 15.9 < -5.0 < -5.0 3.5 or Less 217.160 17.2 1.3 < -5.0 8.4 < 4.1 244.305 18.3 < -5.0 < -5.0 4.6 or Less 271.450 19.4 < -5.0 < -5.0 5.2 or Less 298.595 20.3 < -5.0 < -5.0 5.8 or Less 325.740 21.1 < -5.0 < -5.0 6.4 or Less 352.885 21.9 < -5.0 < -5.0 7.0 or Less 380.030 22.6 < -5.0 < -5.0 7.6 or Less 407.175 23.3 < -5.0 < -5.0 8.2 or Less 434.320 24.0 < -5.0 < -5.0 8.9 or Less 461.465 24.6 < -5.0 < -5.0 9.5 or Less 488.610 25.1 < -5.0 < -5.0 10.1 or Less 515.755 25.7 < -5.0 < -5.0 10.8 or Less 542.900 26.2 < -5.0 < -5.0 11.5 or Less 579.045 26.7 < -5.0 < -5.0 12.2 or Less 597.190 27.2 < -5.0 < -5.0 12.9 or Less 624.335 27.7 < -5.0 < -5.0 13.6 or Less 651.480 28.2 < -5.0 < -5.0 14.5 or Less 678.625 28.6 < -5.0 < -5.0 15.1 or Less JQA Application No. :80-81034 FCC ID :CVTTN6760 Model No. :TN6760 Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 3 of 15 JQA QUALITY ASSURANCE ORGANIZATION Antenna MeterReading Field Strength at 3 m Frequency Factor Horiz. Vert. Horiz. Vert. (MHz) (dB) (dB/ m V) (dB/ m V) ( m V/m) ( m V/m) 705.770 29.1 < -5.0 < -5.0 16.0 or Less 732.915 29.6 < -5.0 < -5.0 17.0 or Less 760.060 30.0 < -5.0 < -5.0 17.8 or Less 787.205 30.4 < -5.0 < -5.0 18.6 or Less 814.350 30.9 < -5.0 < -5.0 19.7 or Less 841.495 31.3 < -5.0 < -5.0 20.7 or Less 868.640 31.7 < -5.0 < -5.0 21.6 or Less 895.785 32.1 < -5.0 < -5.0 22.6 or Less 922.930 32.5 < -5.0 < -5.0 23.7 or Less 950.075 32.9 < -5.0 < -5.0 24.8 or Less 977.220 33.3 < -5.0 < -5.0 26.0 or Less Note:1. The spectrum was checked from 27 MHz to 1000 MHz. All emissions not listed were found to be more than 20 dB below the limits. 2. The symbol of “<” means “or less”. 3. The cable loss was included in the antenna factor. 4. Sample calculation : at 27.145 MHz 10 (AF+Mr)/20 = 10 (-2.0+57.9)/20 = 623.7 m V/m Where, Af = Antenna Factor including the cable loss. Mr = Meter Reading 5. Measuring Instrument Setting: Fundamental Detector function : Average / Peak IF Bandwidth : 120 kHz Harmonics & other frequency components Detector function : CISPR quasi-peak IF Bandwidth : 120 kHz JQA Application No. :80-81034 FCC ID :CVTTN6760 Model No. :TN6760 Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 4 of 15 JQA QUALITY ASSURANCE ORGANIZATION JQA Application No. :80-81034 FCC ID :CVTTN6760 Model No. :TN6760 Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 5 of 15 JQA QUALITY ASSURANCE ORGANIZATION MEASUREMENT SET-UP FOR RADIATED EMISSIONS Turn Table EUT 3 m 1 m 0.8 m Half-wave Dipole Antenna Field Strength Meter Ground Plane 4 m JQA Application No. :80-81034 FCC ID :CVTTN6760 Model No. :TN6760 Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 6 of 15 JQA QUALITY ASSURANCE ORGANIZATION Configuration of EUT for horizontal plane for vertical plane JQA Application No. :80-81034 FCC ID :CVTTN6760 Model No. :TN6760 Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 7 of 15 JQA QUALITY ASSURANCE ORGANIZATION 2. Radiated Emission, Additional Provisions : [§15.215(c)] Measurement Method Employed: By using a spectrum analyzer with a vertical antenna for picking up the signal, the measurements of the fundamental frequency component were made under the following transmitting modes of the EUT. Measurements Results : This device comply with §15.215 (c) recommendation. Refer to the attached graphs. JQA Application No. :80-81034 FCC ID :CVTTN6760 Model No. :TN6760 Issue Date :April 13 1999 S…
