JAPAN QUALITY ASSURANCE ORGANIZATION 21-25, KINUTA 1-CHOME, SETAGAYA-KU, TOKYO 157-8573 JAPAN PHONE (03) 3416-0111, TELEX 242-2531 JQA J FAX (03) 3416-9691 JQA APPLICATION NO.: 80-81035 Issue Date : April 13, 1999 Page 1 of 15 REPORT OF MEASUREMENTS JQA APPLICATION NO.: 80-81035 Applicant : NIKKO CO., LTD. 1-7-14, Mizumoto, Katsushika-ku, Tokyo 125-0032, Japan Manufacturer : NIKKO TEC INTERNATIONAL LTD. Room 812, Houston Center, 63 Mody Road, Tsimshatsui, Kowloon, Hong Kong Description of Equipment : Radio Controlled Toy FCC ID : CVTTN6760H Trade Name : NIKKO Model No. : TN6760H Serial No. : None Operating Frequency : 49.830 MHz – 49.890 MHz Power Supply : 9.0 VDC Applicable Rule : FCC Rules & Regulations Part 15 Subpart C (June 23, 1989) Place of Measurement : JQA EMC Engineering Dept. Date of Measurement : April 1, 1999(Completed) Total Pages of This Report : 15 (including this page) I certify that I am authorized to sign for the report and that all the statement in this report and in the exhibits hereto are true and correct to the best my knowledge and belief. Shigeru Osawa, Engineer Testing Div. EMC Engineering Dept. JQA Application No. :80-81035 FCC ID :CVTTN6760H Model No. :TN6760H Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 2 of 15 JQA QUALITY ASSURANCE ORGANIZATION 1. Radiated Spurious Emissions: [§15.235(a),(b)] Measurement Method Employed: Measurements were made under the conditions specified ANSI C63.4. The field strength measurements of the equipment under test were made at the distance of 3 meters away from the device which was placed on the wooden turntable 0.8 meter in height. The receiving antenna polarized horizontally was varied from 1 to 4 meters and the wooden turntable was rotated through 360 degrees to obtain the highest reading on the field strength meter. The device was tested three orthogonal planes. These measurements were repeated with the receiving antenna polarized vertically. The internal pre-amplifier was used from 30 MHz up to 1000 MHz. Measurement Results: Operating Frequency : 49.860 MHz Distance of Measurement : 3.0 meters Antenna Meter Reading Field Strength at 3 m Frequency Factor Horiz. Vert. Horiz. Vert. (MHz) (dB) (dB/ m V) (dB/ m V) ( m V/m) ( m V/m) Fundamental 49.860 3.6 59.8 57.0 1479.1 1071.5 (Average) 49.860 3.6 66.3 64.0 3126.1 2398.8 (Peak) Harmonics & other Frequency components 99.720 9.9 15.8 17.0 19.3 22.1 149.580 13.7 4.6 1.6 8.2 5.8 199.440 16.4 2.6 < -5.0 8.9 < 3.7 249.300 18.5 3.8 6.0 13.0 16.8 299.160 20.3 < -5.0 < -5.0 5.8 or less 349.020 21.8 < -5.0 < -5.0 6.9 or less 398.880 23.1 < -5.0 < -5.0 8.0 or Less 448.740 24.3 < -5.0 < -5.0 9.2 or Less 498.600 25.4 < -5.0 < -5.0 10.5 or less 548.460 26.3 < -5.0 < -5.0 11.6 or less 598.320 27.2 < -5.0 < -5.0 12.9 or less 648.180 28.1 < -5.0 < -5.0 14.3 or less 698.040 29.0 < -5.0 < -5.0 15.8 or less 747.900 29.8 < -5.0 < -5.0 17.4 or less 797.760 30.6 < -5.0 < -5.0 19.1 or less 847.620 31.4 < -5.0 < -5.0 20.9 or less 897.480 32.2 < -5.0 < -5.0 22.9 or less 947.340 32.9 < -5.0 < -5.0 24.8 or less 997.200 33.6 < -5.0 < -5.0 26.9 or less JQA Application No. :80-81035 FCC ID :CVTTN6760H Model No. :TN6760H Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 3 of 15 JQA QUALITY ASSURANCE ORGANIZATION Note:1. The spectrum was checked from 30 MHz to 1000 MHz. All emissions not listed were found to be more than 20 dB below the limits. 2. The symbol of “<” means “or less”. 3. The cable loss was included in the antenna factor. 4. Sample calculation : at 49.860 MHz 10 (AF+Mr)/20 = 10 (3.6+59.8)/20 = 1479.1 m V/m Where, Af = Antenna Factor including the cable loss. Mr = Meter Reading 5. Measuring Instrument Setting: Fundamental Detector function : Average / Peak IF Bandwidth : 120 kHz Harmonics & other frequency components Detector function : CISPR quasi-peak IF Bandwidth : 120 kHz JQA Application No. :80-81035 FCC ID :CVTTN6760H Model No. :TN6760H Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 4 of 15 JQA QUALITY ASSURANCE ORGANIZATION JQA Application No. :80-81035 FCC ID :CVTTN6760H Model No. :TN6760H Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 5 of 15 JQA QUALITY ASSURANCE ORGANIZATION MEASUREMENT SET-UP FOR RADIATED EMISSIONS Turn Table EUT 3 m 1 m 0.8 m Half-wave Dipole Antenna Field Strength Meter Ground Plane 4 m JQA Application No. :80-81035 FCC ID :CVTTN6760H Model No. :TN6760H Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 6 of 15 JQA QUALITY ASSURANCE ORGANIZATION Configuration of EUT for horizontal plane for vertical plane JQA Application No. :80-81035 FCC ID :CVTTN6760H Model No. :TN6760H Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 7 of 15 JQA QUALITY ASSURANCE ORGANIZATION 2. Emission appearing ±25 kHz frequency band centered on the carrier frequency: [§15.235(b)] Measurement Method Employed: By using a spectrum analyzer with a vertical antenna for picking up the signal, the measurements of the emission within ±25 kHz band centered carrier frequency were made under the following transmitting modes of the EUT. Measurements Results : Refer to the attached graphs. JQA Application No. :80-81035 FCC ID :CVTTN6760H Model No. :TN6760H Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 8 of 15 JQA QUALITY ASSURANCE ORGANIZATION JQA Application No. :80-81035 FCC ID :CVTTN6760H Model No. :TN6760H Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 9 of 15 JQA QUALITY ASSURANCE ORGANIZATION JQA Application No. :80-81035 FCC ID :CVTTN6760H Model No. :TN6760H Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 10 of 15 JQA QUALITY ASSURANCE ORGANIZATION JQA Application No. :80-81035 FCC ID :CVTTN6760H Model No. :TN6760H Issue Date :April 13 1999 Standard :CFR 47 FCC Rules Part 15 Page 11 of 15 JQA QUALITY ASSURANCE ORGANIZATION JQA Application No. :80-81035 FCC ID :CVTTN6760H Model No. :TN6760H Issue Date :April 13 1999 Standard :CFR 47 FCC Ru…
