DEO-MT-FLIP01Transmitter Assy - Folding Key

MOTOTECH CO., LTD. Title Certification Request Document Project Name X100 Drawn 2014-05-13 Model Name Released 2014-07-14 Made by J. H. SHIN 1 PRODUCT SPECIFICATION AND MANUAL 2014.07 BUYER / PROJECT SYMC / X100 / MT FLIP 01 BUYER MODEL PCB PACKAGE ASSAY - FOLDINGKEY PART No. COMPANY Mototech Co,. MAKER/NATION Mototech Co,./Republic of Korea DRAFT PART Research Center DRAFTER J. H. SHIN MOTOTECH CO., LTD. Title Certification Request Document Project Name X100 Drawn 2014-05-13 Model Name Released 2014-07-14 Made by J. H. SHIN 2 Table of Contents 1. CONTENTS ............................................................................................................ 3 2. ELECTRONIC SPEC.............................................................................................. 3 3. SPECIFICATION .................................................................................................... 4 4. REPAIR OF UNIT & CIRCUIT EXPLANATION ...................................................... 4 5. THE METHOD OF UNIT OPERATING ................................................................... 5 6. THE SYSTEM OF EACH UNIT CODE DISCRIMINATION .................................... 6 MOTOTECH CO., LTD. Title Certification Request Document Project Name X100 Drawn 2014-05-13 Model Name Released 2014-07-14 Made by J. H. SHIN 3 1. Contents TYPE Wireless controller about wireless electronic equipment of specific low output radio station MODEL NAME USE Vehicle of door keyless controller what use 433.92 MHz frequency SUMMARY 1. This equipment use semiconductor and integrated circuit, so it designs to get high reliability. 2. This equipment use oscillation circuit of crystal, so it designs to satisfy about legally frequency an allowable error and bandwidth of exclusive frequency. 3. The transmitter has each other specific identification code. 4. The power use Li-ion coin Battery (DC 3.0V) COMPOSITION 1. RF Transmitter part 2. Pattern Antenna 2. ELECTRONIC SPEC UNIT List FOLDINGKEY Rated voltage DC 3.0V Voltage range UNIT 2.1 ~ 3.6V ( except Battery influence) Operating Temperature range -10 ~ +60°C Storage temperature range -20 ~ +70°C Dark current Lower than 1uA MOTOTECH CO., LTD. Title Certification Request Document Project Name X100 Drawn 2014-05-13 Model Name Released 2014-07-14 Made by J. H. SHIN 4 3. Specification TYPE PCB PACKAGE ASSAY - FOLDINGKEY NAME Wireless controller about wireless electronic equipment of specific low output radio station Equipment List RF Transmission Frequency 433.920MHz Antenna composition Pattern ANTENNA Oscillation method Crystal oscillation Modulation method FSK Communication method One-Way Communication Frequency multiplier 32 multiplier 4. Repair of Unit & Circuit Explanation 4.1 Repair of Unit Exchange an old unit. 4.2 Circuit Explanation If User presses specific Switch of transmitter, MCU makes inherent serial value and Encryption value, so it print what CPU make data, at the same time RF IC get to be ENABLE. Printing data are falsified into TxIC and it synthesize through CRYSTAL. Compound frequency are amplified by TxIC and it transmit through antenna from matching circuit diagram of output. MOTOTECH CO., LTD. Title Certification Request Document Project Name X100 Drawn 2014-05-13 Model Name Released 2014-07-14 Made by J. H. SHIN 5 5. The Method of Unit Operating PICTURE OF UNIT FUNCTION SWITCH FUNCTION LOCK BUTTON DOOR LOCK SHORT PRESSING LOCK BUTTON UNDER 0.5s - LED flicker only once as long time ESCORT (DOM ONLY) LONG PRESSING LOCK BUTTON OVER 0.5s - LED flicker twice as short time UNLOCK BUTTON DOOR UNLOCK SHORT PRESSING UNLOCK BUTTON UNDER 0.5s - LED flicker only once as long time PANIC BUTTON PANIC LONG PRESSING PANIC BUTTON OVER 2s - LED flicker twice as short time RELEASE BUTTON LOCK BUTTON UNLOCK BUTTON PANIC BUTTON KEY RING KEY BLADE MOTOTECH CO., LTD. Title Certification Request Document Project Name X100 Drawn 2014-05-13 Model Name Released 2014-07-14 Made by J. H. SHIN 6 6. The System of Each Unit Code Discrimination 6.1 STRUCTURE OF DATA (“1", "0”) 송신 “1” “0” 400us 400us 400us 400us 6.2 FOLDINGKEY PROTOCOL FORMAT (1) ONE TIME TRANSMITTING DATA CONSIST OF 10 FRAMES (2) EACH FRAME DATA THANSMISSION INTERVAL IS 6.8 ± 1ms (3) ALL OF BIT (0 AND 1) DIFFERENTIATE THE PULSE FORM (4) CODE WORD TRANSMISSION SEQUENCE (73.6msec) Preamble Hea -der EncryptFixedPreambleGuard Hea -der 16bit4TE32bit32bit16TE 66.8ms9.3ms 1 CODE WORD (5) TRANSMISSION FORMAT (MANCHESTER) 1 2 16 PreambleHeader Encrypted Portion Fixed Code Portion Guard Time STOP bit bit 2 bit 1 bit 0 START bit MOTOTECH CO., LTD. Title Certification Request Document Project Name X100 Drawn 2014-05-13 Model Name Released 2014-07-14 Made by J. H. SHIN 7 (6) CODE WORD TRANSMISSION DATA FORMAT Fixed Code Portion (32 bits)Encrypted Portion (32bits) BUT. 4bits Not used 4bits SERIAL NUMBER 24bits BUT. 4bits Not used 4bits 0x5A DISC 4bits Synchronization Counter 16 bits 15 0 S2S1S0S3S2S1S0S3

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 Sep. 26, 2014 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, MOTOTECH Co., Ltd. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Transmitter Assy - Folding Key, MT FLIP 01 , FCC ID : DEO-MT-FLIP01) Sincerely, Ban-seok Choi Research Engineer MOTOTECH Co., Ltd. #68-26, Mannyeon-ro, Jeongnam-myeon, Hwasong-si, Gyeonggi-do, Korea

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 3.0 Sep. 26, 2014 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: DEO-MT-FLIP01 We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Ban-seok Choi / Research Engineer Contact information / address: 031-305-0682 / #68-26, Mannyeon-ro, Jeongnam-myeon, Hwaseong-si, Gyeonggi-do, Korea SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 3.0 Sep. 26, 2014 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: DEO-MT-FLIP01 To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days (please check one). - e.g. User Manual - e.g. Ext Photo - e.g. Int Photo - e.g. Test Photo The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Client’s signature : Client’s name / title : Ban-seok Choi / Research Engineer Contact information / address: 031-305-0682 / #68-26, Mannyeon-ro, Jeongnam-myeon, Hwaseong-si, Gyeonggi-do, Korea

MOTOTECH Co., Ltd. #68-26, Mannyeon-ro, Jeongnam-myeon, Hwaseong-si, Gyeonggi-do, Korea Date: Sep. 26, 2014 SIEMIC 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Letter of Authorization We, the undersigned, hereby authorize Harvey Sung of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCCID: DEO- MT-FLIP01 including signing of all documents relating to these matters. Any and all acts carried out by Harvey Sung of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from MOTOTECH Co., Ltd. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Ban-seok Choi Research Engineer

FCCID: DEO-MT-FLIP01 Copyright Ⓒ 2014, DT&C Co., Ltd. Page 1 / 3 View 1 FCCID: DEO-MT-FLIP01 Copyright Ⓒ 2014, DT&C Co., Ltd. Page 2 / 3 View 2 FCCID: DEO-MT-FLIP01 Copyright Ⓒ 2014, DT&C Co., Ltd. Page 3 / 3 View 3

FCC ID: DEO-MT-FLIP01 Copyright Ⓒ 2014, DT&C Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label. - The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the user's manual. TRANSMITTER ASSY- FOLDING KEY MODEL : MT FLIP 01 FCC ID : DEO-MT-FLIP01 LOT NO Made by Huf Korea Ltd. Made in Korea REAR OF EUT

FCCID: DEO-MT-FLIP01 Copyright Ⓒ 2014, DT&C Co., Ltd. Page 1 / 3 View 1 FCCID: DEO-MT-FLIP01 Copyright Ⓒ 2014, DT&C Co., Ltd. Page 2 / 3 View 2 FCCID: DEO-MT-FLIP01 Copyright Ⓒ 2014, DT&C Co., Ltd. Page 3 / 3 View 3

DEMC1407-03023 DRTFCC1409-1241 TRF-RF-218(00)120326 Page 2 / 15 Copyright ○ C 2014, DT&C Co., Ltd. Test Report Version Test Report No. Date Description DRTFCC1409-1241 Sep. 29, 2014 Initial issue DEMC1407-03023 DRTFCC1409-1241 TRF-RF-218(00)120326 Page 3 / 15 Copyright ○ C 2014, DT&C Co., Ltd. CONTENTS 1. Equipment information ............................................................. 4 1.1 Equipment description ............................................................ 4 1.2 Ancillary equipment ................................................................ 4 2. Information about test items .................................................... 5 2.1 Operating mode ..................................................................... 5 2.2 Tested frequency .................................................................... 5 2.3 Auxiliary equipment ................................................................ 5 2.4 Tested environment ................................................................ 5 2.5 EMI Suppression Device(s)/Modifications .............................. 5 3. Test Report ................................................................................ 6 3.1 Summary of tests ................................................................... 6 3.2 Transmitter requirements........................................................ 7 3.2.1 20dB bandwidth ................................................................. 7 3.2.2 Field strength of fundamental and spurious emissions ....... 8 3.2.3 Automatically deactivate ................................................... 10 3.2.4 Duty Cycle Correction Factor ............................................ 11 3.2.5 AC power line conducted emission................................... 12 3.2.6 Antenna requirement ........................................................ 13 APPENDIX I ................................................................................. 14 DEMC1407-03023 DRTFCC1409-1241 TRF-RF-218(00)120326 Page 4 / 15 Copyright ○ C 2014, DT&C Co., Ltd. 1. Equipment information 1.1 Equipment description FCC Equipment Class Part 15 Low Power Transmitter Equipment type Transmitter Assy - Folding Key Fundamental Frequency 433.92 MHz Equipment model name MT FLIP 01 Modulation FSK Equipment serial no. Identical prototype Power DC 3 V(Battery) Antenna type Pattern Antenna 1.2 Ancillary equipment Equipment Model No. Serial No. Manufacturer Note - - - - - - - - - - DEMC1407-03023 DRTFCC1409-1241 TRF-RF-218(00)120326 Page 5 / 15 Copyright ○ C 2014, DT&C Co., Ltd. 2. Information about test items 2.1 Operating mode Operating Mode 1 This device was tested with continuous TX mode for field strength of fundamental and spurious emissions measurements. Operating Mode 2 Normal operating mode was used for 20 dB BW and less than 5 second requirements. 2.2 Tested frequency Mode Frequency(MHz) Transmitting mode 433.92 - - - - 2.3 Auxiliary equipment Equipment Model No. Serial No. Manufacturer Note - - - -. - 2.4 Tested environment Temperature : 24 o C Relative humidity content : 48 ~ 52 % R.H. Details of power supply : DC 3 V(Battery) 2.5 EMI Suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing → None DEMC1407-03023 DRTFCC1409-1241 TRF-RF-218(00)120326 Page 6 / 15 Copyright ○ C 2014, DT&C Co., Ltd. 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Test Condition Status Note 1 I. Test Items 15.205 Restricted bands of operation Radiated C 15.209 Radiated emission limits, general requirements C 15.231(a) Automatically deactivate C 15.231(b) Field strength of fundamental and spurious emissions C 15.231(c) 20dB bandwidth C 15.207 AC Power Line Conducted Emission AC Line Conducted NA Note 2 15.203 Antenna Requirements - C Note 1: C=Comply NC=Not Comply NT=Not Tested NA=Not Applicable Note 2: This device is used Battery for power supplying. Therefore this test item was not performed. The sample was tested according to the following specification: ANSI C-63.4-2009 DEMC1407-03023 DRTFCC1409-1241 TRF-RF-218(00)120326 Page 7 / 15 Copyright ○ C 2014, DT&C Co., Ltd. 3.2 Transmitter requirements 3.2.1 20dB bandwidth - Procedure: The Transmitter output is connected to the spectrum analyzer. 20dB Bandwidth: The RBW is set to 3 kHz. The VBW is set to 9.1 kHz. The sweep time is coupled. Bandwidth is determined at the points 20 dB down from the modulated carrier. - Measurement Data: Comply Frequency (MHz) 20dB Bandwidth (kHz) Limit (kHz) 433.92 21.010 1084.8 - Limit: § 15.209(c) The bandwidth of the emission shall be no wider than 0.25% of the center frequency for devices operating above 70 MHz and below 900 MHz. For devices operating above 900 MHz, the emission shall be no wider than 0.5% of the center frequency. Bandwidth is determined at the points 20 dB down from the modulated carrier. DEMC1407-03023 DRTFCC1409-1241 TRF-RF-218(00)120326 Page 8 / 15 Copyright ○ C 2014, DT&C Co., Ltd. 3.2.2 Field strength of fundamental and spurious emissions - Procedure: 1. The EUT was placed on the top of a rotating table 0.8 meters above the ground at a 3 meter semi-anechoic chamber test site. The table was rotated 360 degrees to determine the position of the highest radiation. 2. During performing radiated emission below 1 ㎓, the EUT was set 3 meters away from the interference receiving antenna, which was mounted on the top of a variable-height antenna tower. During performing radiated emission above 1 ㎓, the EUT was set 3 meter away from the interference-receiving antenna. 3. The antenna is a broadband antenna, and its height is varied from one meter to four meters above the ground to determine the maximum value of the field strength. Both horizontal and vertical polarizations of the antenna are set to make the measurement. 4. For each suspected emission, the EUT was arranged to its worst case and then the antenna was tuned to heights from 1 meter to 4 meters and the table was turned from 0 de…

Text truncated - open the document above for the full version.

FCC ID: DEO-MT-FLIP01 Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup photographs EUT Position: X-axis EUT Position: Y-axis EUT Position: Z-axis FCC ID: DEO-MT-FLIP01 Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (0.009 ~ 30MHz) FCC ID: DEO-MT-FLIP01 Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (below 1000MHz) FCC ID: DEO-MT-FLIP01 Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (Above 1GHz)
