Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
UHF WIRELESS SET WS-200/300 OPERATING INSTRUCTIONS Thank you for pur chasing TOA ’ s UHF Wireless Set. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment/ Thank you for pur chasing TOA ’ s UHF Wireless Set. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment/ Printed in Taiwan TOA instruction Manual ARTWORK_2 8/5/06 1:22 pm Page 1 CONTENTS Introduction and Safety TOA WS System Overview Receiver Nomenclature and Operation Handheld Nomenclature and Operation Lavalier Nomenclature and Operation General Set-up and Operating Hints and Fault Finding System Contents Description and System Part Numbers Technical Specifications 1. 2. 3. 4. 5. 7. 9. 10. 1 TOA instruction Manual ARTWORK_2 8/5/06 1:23 pm Page 3 When Installing the Unit (Applicable to the Wireless Tuners) > Do not expose the unit to rain or an environment where it may be splashed by water or other liquids, as doing so may result in fire or electric shock. > Use the unit only with the voltage specified on the unit. Using a voltage higher than that which is specified may result in fire or electric shock. > Do not cut, kink, otherwise damage nor modify the power supply cord. In addition, avoid using the power cord in close proximity to heaters, and never place heavy objects -- including the unit itself -- on the power cord, as doing so may result in fire or electric shock. > A void installing or mounting the unit in unstable locations, such as on a rickety table or a slanted surface. Doing so may result in the unit falling down and causing personal injury and/or property damage. When the Unit is in Use (Applicable to the Wireless Tuners) > Should the following irregularity be found during use, immediately switch off the power, disconnect the power supply plug from the AC outlet and contact your nearest TOA dealer. Make no further attempt to operate the unit in this condition as this may cause fire or electric shock. > If you detect smoke or a strange smell coming from the unit. > If water or any metallic objects get into the unit. > If the unit falls, or the unit case breaks. > If the power supply cord is damaged, (exposure of the core, disconnection, etc.) > If it is malfunctioning (no tone sounds.) > To prevent a fire or electric shock, never open nor remove the unit case as there are high voltage components inside the unit. Refer all ser vicing to qualified service personnel. > Do not place cups, bowls, or other containers of liquid or metallic objects on top of the unit. If they accidentally spill into the unit, this may cause a fir e or electric shock. (Common to all WS series) > T o pr event the electromagnetic wave from badly influencing medical equipment, make sure to switch off the units power when placing it in close proximity to the medical equipment. SAFETY PRECAUTIONS > Before installation or use, be sure to carefully read all the instructions in this section for correct and safe operation. > Be sure to follow all the precautionary instructions in this section, which contain important warnings and/or cautions regarding safety. > After reading, keep this manual handy for future reference. Safety Symbol and Message Conventions Safety symbols and messages described below are used in this manual to prevent bodily injury and property damage which could result from mishandling. Before operating your product, read this manual first and understand the safety symbols and messages so you are thoroughly aware of the potential safety hazards. WARNING CAUTION WARNING Indicates a potentially hazardous situation which, if mishandled, could result in death or serious personal injury. Indicates a potentially hazardous situation which, if mishandled, could result in in moderate or minor personal injury, and/or property damage. CAUTION When Installing the Unit (Applicable to the Wireless Tuners) > Never plug in nor remove the power supply plug with wet hands, as doing so may cause electric shock. > When unplugging the power supply cord, be sure to grasp the power supply plug; never pull on the cord itself. Operating the unit with damaged power supply cord may cause a fire or electric shock. > When moving the unit, be sure to remove its power supply cord from the wall outlet. Moving the unit with the power cords connected to the outlet may cause damage to the power cord, resulting in fire or electric shock. When removing the power cord, be sure to hold its to pull. > Avoid installing the unit in humid or dusty locations, in locations exposed to the direct sunlight, near the heaters, or in locations generating sooty smoke or steam as doing otherwise may result in fire or electric shock. > When the unit is in use (Applicable to the Wireless Tuners) > Use the specified AC adaptor for the unit. Note that the use of other adaptors may cause a fire. (Applicable to the Wireless Microphones) > When the unit is not in use for 10 days or more, be sure to take the batteries out of the unit because battery leakage may cause a fire, personal injury, or contamination of environment. > Make sure to observe the following handling precautions so that a fire or personal injury does not result from leakage or explosion of the battery. > Do not short, disassemble, heat nor put the battery into a fire. > Avoid using both new and old batteries together. > Never charge batteries of the type which are not rechargeable. > Do not solder a battery directly. > Be sure to use the specified type of batteries. > Note correct polarity (positive and negative orientation) when inserting a battery in the unit. > Avoid locations exposed to the direct sunlight, high temperature and high humidity when storing batteries. 23 TOA instruction Manual ARTWORK_2 8/5/06 1:23 pm Page 5 WS SYSTEM OVERVIEW The TOA WS is a high-quality UHF Wireless Microphone System. The WS has many features including:- >> 4 User Selectable Channels - that can be operated simultaneously. >> Diversity…
Text truncated - open the document above for the full version.
bbm A Division of TOA CORPORATION OF JAPAN Electronics Group Limited KESTREL HOUSE GARTH ROAD MORDEN SURREY SM4 4LP TEL : 44 (0) 20-8330 3111 FAX : 44 (0) 20-8330 3222 E - MAIL : [email protected] WEB SITE : www.trantec.co.uk Request for confidentiality Date 24 th May 2006 TRL Compliance Services Ltd Long Green Forthampton Gloucester GL19 4QH UK RE: Certification Application FCC ID: DLAWM-S200 To Whom It May Concern: Please be advised that the following information is to be held confidential on behalf of TOA Corporation and/or it’s subsidiarys. • All detailed schematic and Block diagrams . • All items containing detailed technical description of product. The application contains technical information which TOA Corporation deems to be trade secrets and propriety. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Yours faithfully For and on Behalf of TOA CORPORATION Steven Baker TOA CORPORATION 2-1 TAKAMATSU-CHO, TAKARAZUKA, HYOGO 665 JAPAN. 0797-71-2218
WS 200 Handheld AF US Version Revised: Thursday, May 18, 2006 B100-297.sch Revision: 1 TOA Corporation Bill Of Mat ePage1 ItemQuantityReferencePart ______________________________________________ 112 R1,JP1,IC1,C1,R12,R14,DNP R26,C26,R32,R38,R40,C202 24 C2,C11,C34,C3510n 311 C3,C10,C12,C15,C20,C23,100p C24,C32,C33,C200,C201 44 C4,C7,C17,C3110uF_T 53 C6,C8,C13100n 62 C9,C282u2_T 71 C14220p 81 C161N 93 C18,C19,C211uF_M 101 C2233p 111 C2547n 121 C27330n 132 C29,C302u2_M 141 D2RED_LEDSM 151 FET1ZVN4306A 161 IC2SM78L05 171 IC3MCP130T-4751/TT 181 IC416F54 191 IC5SA575DK 205 JP2,JP3,JP4,JP5,JP6HEADER1 211 JP7MIL-10-PIN 223 L1,L2,L382nH 231 R31M 241 R447 258 R5,R7,R8,R9,R11,R30,R34,10K R37 264 R13,R33,R35,R2000r 275 R15,R16,R17,R27,R3130K 281 R1839K 296 R19,R20,R21,R23,R28,R4215K 302 R22,R254K7 311 R2447K 321 R29470 331 R3633K 341 R41270K 351 R2012K2 361 SW1S-7060ETB 371 S1HORIZSW 3812 TP1,TP2,TP3,TP4,TP5,TP6,CON1 TP7,TP8,TP9,TP10,TP11, TP12 391 TR1KTC4075
WS-200 Handheld RF US Version Revised: Thursday, May 18, 2006 B100-295.SCH Revision: 2 TOA Corporation Bill Of Materials Page1 ItemQuantityReferencePart ______________________________________________ 11 C147pF 22 C2,C18100n 31 C3100p 410 C4,C5,C32,R33,R35,C39,DNP R44,C50,C52,C57 53 C6,C7,C542p0 62 C55,C847p 710 C9,C10,C11,C12,C13,C21,1n C22,C35,C51,C53 82 C17,C143p0 93 C15,C16,C435p0 101 C191p0 113 C20,C38,C5610n 123 C23,C36,C4022p 132 C34,C336p0 142 C37,C45220n 152 C41,C4233p 161 C464u7_T 172 C47,C4922uF_T 181 C485-20pF (RED) 191 C5810uF 202 D2,D3DA204U 211 IC1LMX2316 2214 TP1,JP1,TP2,JP2,TP3,TP4,HEADER1 TP5,TP6,TP7,TP8,TP9,TP10, TP11,TP12 231 JP3MIL-10-SOK 243 L1,L9,L10LL1608-10nH 251 L2LL1608-10n 263 L3,L4,L5LL1608-8n2 271 L6LL1608-6n8 283 L7,L8,L11LL1608-22nH 292 TR4,Q1KTA2014 302 R9,R247K 314 R3,R8,R12,R1718 322 R4,R522 332 R6,R3810 342 R7,R340r 352 R36,R1022K 361 R1110K 372 R13,R14330 381 R151K8 391 R161K2 402 R22,R23220 411 R2468 422 R25,R376K8 431 R263K3 441 R27470 452 R30,R281K5 461 R29150K 471 R31680 481 R39150 491 R40100 501 R415K6 512 R42,R4320KPOTSMS 521 TR1KTC4075 533 TR2,TR3,TR62SC3356 541 TR52SC4399-4 551 VCO1MVUS720 561 Y16.0MHz
File name BBM.103 PAGE 1 OF 43 QMF21J – 3; FCC CFR 47 PART 2 J OCT 2004; ISSUE 01 OCT 05 FCC Licensed Transmitter Test Report for Handheld Radio Mic S4.4MTX-UL Reference Standard 47CFR Part 2, Subpart J : Oct 2005 Manufacturer BBM Electronics For type of equipment and serial number, refer to section 3 Report Number 04-103/3088/1/06 Report Produced by: - R.N. Electronics Ltd. 1 Arnolds Court Arnolds Farm Lane Mountnessing Essex CM13 1UT U.K. www.rnelectronics.com Telephone +44 (0) 1277 352219 Facsimile +44 (0) 1277 352968 EMC & RADIO TEST SERVICES S RN Electronics ©2004 RN ELECTRONICS LIMITED REPORT NUMBER 04-103/3088/1/06 ALL RIGHTS RESERVED File name BBM.103 PAGE 2 OF 43 QMF21J – 3; FCC CFR 47 PART 2 J OCT 2004; ISSUE 01 OCT 05 This page has been left blank intentionally. ©2004 RN ELECTRONICS LIMITED REPORT NUMBER 04-103/3088/1/06 ALL RIGHTS RESERVED File name BBM.103 PAGE 3 OF 43 QMF21J – 3; FCC CFR 47 PART 2 J OCT 2004; ISSUE 01 OCT 05 1. Contents 1. CONTENTS............................................................................................................................................ 3 2. SUMMARY OF TEST RESULTS............................................................................................................... 4 3. INFORMATION ABOUT EQUIPMENT UNDER TEST................................................................................ 5 4. SPECIFICATIONS.................................................................................................................................... 6 4.1 Relevant Standards ................................................................................................................ 6 4.2 Measurement Uncertainty...................................................................................................... 6 4.2 Tests at Extremes of Temperature and Voltage..................................................................... 6 5. TESTS, METHODS AND RESULTS.......................................................................................................... 7 5.1 Carrier Power ........................................................................................................................ 7 5.2 Modulation Characteristics.................................................................................................... 9 5.3 Occupied Bandwidth ........................................................................................................... 11 5.4 Spurious Emissions at Antenna Terminals .......................................................................... 12 5.5 Field Strength of Spurious Radiation. ................................................................................. 14 5.6 Frequency Error................................................................................................................... 16 6. GRAPHICAL RESULTS......................................................................................................................... 17 7. PHOTOGRAPHS.................................................................................................................................... 35 7.1 EUT Front View ..................................................................................................................35 7.2 EUT Antenna Connector Port ............................................................................................. 36 7.3 EUT Display / Controls ....................................................................................................... 37 7.4 EUT Internal Construction .................................................................................................. 38 7.5 Test set-up, spurious emissions ........................................................................................... 39 8. SIGNAL LEADS.................................................................................................................................... 40 9. TEST EQUIPMENT CALIBRATION LIST................................................................................................ 41 10. AUXILIARY EQUIPMENT..................................................................................................................... 42 10.1 Supplied by BBM Electronics ............................................................................................. 42 10.2 Supplied by RN Electronics Limited ................................................................................... 42 11. MODIFICATIONS................................................................................................................................. 43 ©2004 RN ELECTRONICS LIMITED REPORT NUMBER 04-103/3088/1/06 ALL RIGHTS RESERVED File name BBM.103 PAGE 4 OF 43 QMF21J – 3; FCC CFR 47 PART 2 J OCT 2004; ISSUE 01 OCT 05 2. Summary of Test Results The Handheld Radio Mic S4.4MTX-UL was tested for compliance to the following standard for licensed transmitters: - 47CFR Part 2, Subpart J : Oct 2005 47CFR Part 74, Subpart H : Oct 2005 Title References Results conducted: PASSED 1. RF Power Output. 47CFR Part 2, Subpart J radiated: PASSED frequency response: PASSED 2. Modulation Characteristics. 47CFR Part 2, Subpart J modulation limiting: PASSED 3. Occupied Bandwidth 47CFR Part 2, Subpart J PASSED 4. Spurious Emissions at Antenna Terminals. 47CFR Part 2, Subpart J PASSED 5. Field Strength of Spurious Radiation. 47CFR Part 2, Subpart J PASSED 6. Frequency Stability. 47CFR Part 2, Subpart J PASSED This report relates to the equipment tested as identified by a unique serial number and at the time it was tested. It does not relate to any other similar equipment and performance of the product before or after the test cannot be guaranteed. The measurement uncertainty, where stated, is the expanded uncertainty based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95%. Date of Test:24th-28th April 2006 Test Engineer: Approved B…
Text truncated - open the document above for the full version.
Kestral House · Morden, Surrey · United Kingdom
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 74 | 719 MHz - 744 MHz | 20.00 mW | 200KF3E | 0.0004000000 % |

Wireless Microphone
Equipment Class
TBC - Licensed Broadcast Station Transmitter
UHF Wireless Transmitter
Equipment Class
TBT - Licensed Broadcast Transmitter Worn on Body
Wireless Transmitter
Equipment Class
TBT - Licensed Broadcast Transmitter Worn on Body
Wireless Microphone
Equipment Class
TNF - Licensed Non-Broadcast Transmitter Held to Face
Wireless Microphone
Equipment Class
TNF - Licensed Non-Broadcast Transmitter Held to Face
