DMOEM2G4WERack Receiver

Identify Change device App Control ewD1 Quick Guide Kurzanleitung | Guide rapide | Guida rapida | Instrucciones resumidas | Guida rápido | Beknopte handleiding | Краткая инструкция | | | | B 10 SK D1 B 30 NT 12-4C NT 2-3 2G4 OR OR OR OR ! No Link! 3 s Pair EM D1 Menu up Navigate Set Battery Setup AA esc OR 6.3 mm XLR SHORT = ON 3 s = OFF SHORT Pair Paired 3 s Pair MUTE MIK SKM-S D1 SKM D1 App Mute Mic Sennheiser electronic GmbH & Co. KG Am Labor 1, 30900 Wedemark, Germany www.sennheiser.com Printed in Germany, Publ. 11/14, 554635/A02

ew D1 Technische Daten Specifications Caractéristiques techniques Dati tecnici Especificaciones técnicas Dados técnicos Technische specificaties        (ᄂ)㚰⍃㓱 (ᄂ)埔˻̫˳ 韥ꯕ鴥넩뫥 BB TechDat ewD1_554641_A5.indb 128.10.2014 13:20:45 EM D1 212 mm 168 mm 43 mm SKM D1/SKM-S D1 215 mm 40 mm SK D1 100 mm 65 mm 24 mm BB TechDat ewD1_554641_A5.indb 228.10.2014 13:20:46 KO EN FR IT PT NL RU ZH ES DE JA LICENSE 1 ew D1 Technische Daten System NF-Übertragungsbereich20 bis 20.000 Hz Dynamikbereich> 135 dB (A) THD (1 kHz)typ. < 0,1 % Audio Sampling24 bit/48 kHz Signal/Rauschabstand 105 dB (A) HF-Frequenzbereiche2.400 bis 2.483,5 MHz ModulationGFSK mit Datenrückkanal ÜbertragungssystemTDMA, Time diversity, Frequenz diversity, Fast switching antenna diversity Latenz3,9 ms Audio CodecAPT-X Live relative Luftfeuchtemax. 95 % Temperaturbereichim Betrieb: –10 °C bis +55 °C Lagerung: –20 °C bis +70 °C * Die Batterie-Eigenschaften beeinflussen diesen Temperaturbereich. EM D1 HF-Empfindlichkeit 90 dBm Sendeleistung Rückkanal10 mW/100 mW (länderspezifisch) Audio Output Level Gain Mic/Line level switch: –24 dB/0 dB XLR, symmetrisch: max +18 dBu Klinke, un-/symmetrisch: max +12 dBu / max +18 dBu Audio-EffekteLow Cut: –3 dB bei 120 Hz Equalizer: 7-Band-Graphic-Equalizer De-Esser: multi-frequency targets Automatic Gain Control (AGC): Kompression/Expansion mit automatischer Make-Up-Gain-Funktion DisplayOLED NF-AnschlussbuchsenXLR/6,3 mm Klinke Antennenbuchsen2 x Rev-SMA NetzwerkbuchseRJ45 NetzwerkprotokollMedia Control Protocol, TCP/IP IPv4 (DHCP, Manual)/IPv6 Spannungsversorgung12 V DC Hohlklinke Stromaufnahme350 mA Gewichtca. 824 g BB TechDat ewD1_554641_A5.indb 128.10.2014 13:20:46 2 SKM D1 Sendeleistungadaptiv bis zu 100 mW (länderspezifisch) NF-Übertragungsbereich50 bis 20.000 Hz EingangsempfindlichkeitAutomatic Sensitivity Adjustment SpannungsversorgungBatterien: 2 x Mignon AA (1,5 V) Akkupack*: BA 10 (Li-Ion, 3,7 V) BatterielaufzeitBatterien: typ. 6 h Akkupack*: typ. 11 h DisplayLCD Gewicht (ohne Batterien)ca. 280 g inkl. Kapsel * optionales Zubehör SK D1 Sendeleistungadaptiv bis zu 100 mW (länderspezifisch) NF-Übertragungsbereich Mic: 50 bis 20.000 Hz Line: 20 bis 20.000 Hz Max. EingangspegelMic: 2,2 V RMS Line : 3,3 V RMS Eingangsimpedanz Line1 M EingangsempfindlichkeitAutomatic Sensitivity Adjustment SpannungsversorgungBatterien: 2x Mignon AA (1,5V) Akkupack*: BA 30 (Li-Ion, 3.7V) BatterielaufzeitBatterien: typ. 6 h Akkupack*: typ. 11 h NF-Anschlussbuchse3,5 mm-Klinkenbuchse, verschraubbar Line Mic Gewicht (ohne Batterien)ca. 85 g * optionales Zubehör BB TechDat ewD1_554641_A5.indb 228.10.2014 13:20:47 KO EN FR IT PT NL RU ZH ES DE JA LICENSE 3 835-1845-1935-1945-1 Mikrofontypdynamisch Empfindlichkeit2,1 mV/Pa1,6 mV/Pa2,5 mV/Pa1,8 mV/Pa RichtcharakteristikNiereSuperniereNiereSuperniere Max. Schalldruckpegel154 dB SPL154 dB SPL130 dB SPL150 dB SPL MMD ME ME 2ME 3 Mikrofontypdauerpolarisiertes Kondensatormikrofon Empfindlichkeit20 mV/Pa 1,6 mV/Pa RichtcharakteristikKugelNiere Max. Schalldruckpegel130 dB SPL150 dB SPL Anforderungen werden erfüllt für: Europa Funk EMV Sicherheit RoHS EN 300328 EN 301489-1/-17 EN 60950-1, EN 62311 (SAR) EN 50581 USAFCC 47 CFR 15 KanadaIndustry Canada RSS 210, CAN ICES-3(B)/NMB-3(B) Australien/NeuseelandAS/NZS 4268 Zugelassen für: USAEM SKM SK FCC ID: DMOEM2G4WE FCC ID: DMOSKM2G4WE FCC ID: DMOSK2G4WE KanadaEM SKM SK IC: 2099AEM2G4WE IC: 2099ASKM2G4WE IC: 2099ASK2G4WE Australien/Neuseeland Japan R 202-SMC048 EM R 202-SMC049 SKM R 202-SMC050 SK BB TechDat ewD1_554641_A5.indb 328.10.2014 13:20:48 4 Netzteile NT 12-4CNT 2-3 Nenneingangspannung 100 bis 240 V~ Netzfrequenz50 oder 60 Hz Eingangsstrommax. 120 mA Nennausgangsspannung 12 V Stand-by-Leistungsaufnahme 0,3 W Energie-Effizienz-KlasseVIV Betriebstemperatur–10 °C bis +55 °C Lagertemperatur–20 °C bis +70 °C Relative Luftfeuchtemax. 95 % Gewichtca. 100 gca. 105 g Anforderungen werden erfüllt für: Europa EMV Sicherheit RoHs EN 55022, EN 55024 EN 60065 EN 50581 Energie Effizienz Verordnung Nr.1275/2008 USA/KanadaEMV Sicherheit FCC 47 CFR 15 B ICES 003, CAN ICES-3(B)/NMB-3(B) UL 60065 CAN/CSA-C22.2 No. 60065 ChinaEMV Sicherheit RoHs GB13837, GB17625 GB8898 Australien/NeuseelandEMV Sicherheit AS/NZS CISPR 22 AS/NZS 60065 BB TechDat ewD1_554641_A5.indb 428.10.2014 13:20:48 KO EN FR IT PT NL RU ZH ES DE JA LICENSE 5 Zertifiziert nach: EuropaVDF_GS (NT2-3) ENEC 22 SIQ (NZ12-4) USA/Kanada Australien/Neuseeland Japan China(nur NT 2-3) KoreaKTL SU 10524-13002 (nur NT 2-3) Russland ME95 Akkupacks BA 10BA 30 Ladekapazität2200 mAh2030 mAh Ausgangsspannung3,6 V3,7 V BB TechDat ewD1_554641_A5.indb 528.10.2014 13:20:50 6 Garantie  Sennheiser electronic GmbH & Co. KG übernimmt für dieses Produkt eine Garantie von 24 Monaten.  Die aktuell geltenden Garantiebedingungen können Sie über das Internet www.sennheiser.com oder Ihren Sennheiser-Partner beziehen. In Übereinstimmung mit folgenden Anforderungen  WEEE-Richtlinie (2012/19/EU) Bitte entsorgen Sie die Produkte am Ende ihrer Nutzungsdauer bei Ihrer örtlichen kommu- nalen Sammelstelle oder im Recycling Center.  Batterierichtlinie (2006/66/EG) Die mitgelieferten Akkus oder Batterien sind recyclingpflichtig. Bitte entsorgen Sie Akkus bzw. Batterien über offizielle Sammelstellen oder den Fachhandel. Entsorgen Sie nur leere Batterien oder Akkus, um den Umweltschutz zu gewährleisten. CE-Konformität  0682  R&TTE-Richtlinie (1999/5/EG)  RoHS-Richtlinie (2011/65/EU)  EMV-Richtlinie (2014/30/EU)  Niederspannungs-Richtlinie (2014/35/EU) Die Erklärungen stehen im Internet unter www.sennheiser.com zur Verfügung. Vor Inbetriebnah- me sind die jeweiligen länderspezifischen Vorschriften zu beachten. Herstellererklärungen Anforderungen werden erfüllt für: Europa EMV Sicherheit EN 301489-1/-6/-17 IEC/EN 62133 USA/KanadaAkkuzellen Akkupack UL 1642 UL 2054 JapanDENAN Ordinance Article 1; Appendix 9 Lithium Ion KoreaSicherheitK 62133 UN Transporttest gemäß UN-Prüfhandbuch Teil III…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 January 09, 2015 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Company requests confidentiality for the following products: FCC ID Number Product Title/Model DMOEM2G4WE EM D1 For the product stated above, we request that the following information be held confidential: 1. Circuit diagrams, BOM, and PCBs submitted as Equipment Authorization Electronic Filing attachment: "schematics”. 2. Block diagram submitted as Equipment Authorization Electronic Filing attachment: “blockdiagram”. 3. Operational description submitted as Equipment Authorization Electronic Filing attachment: “operational description” 4. Tune Up Info submitted as Equipment Authorization Electronic Filing attachment: “tune up info” The above exhibits contain Company trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our mobile handset. This material is not customarily available to the general public and we request that it be withheld from public inspection. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Marco Happ Company: Sennheiser electronic GmbH & Co. KG Address: Am Labor 1 D-30900 Wedemark (Germany) Phone: 49-5130-600-2621 Email: [email protected]

Test report no.: 1-5753/12-01-01_AnnexA 2014-07-01 Page 1 of 6 Annex A This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorised: Marco Bertolino Testing Manager Test report no.: 1-5753/12-01-01_AnnexA 2014-07-01 Page 2 of 6 External ph ot os o f t he EU T Photo 1: Photo 2: Test report no.: 1-5753/12-01-01_AnnexA 2014-07-01 Page 3 of 6 Photo 3: Photo 4: Test report no.: 1-5753/12-01-01_AnnexA 2014-07-01 Page 4 of 6 Photo 5: Photo 6: Test report no.: 1-5753/12-01-01_AnnexA 2014-07-01 Page 5 of 6 Photo 7: Photo 8: Test report no.: 1-5753/12-01-01_AnnexA 2014-07-01 Page 6 of 6 Docu men t his to r y Version Applied changes Date of release Initial release 2014-07-01

Test report no.: 1-5753/12-01-01_AnnexB 2014-07-01 Page 1 of 5 Annex B This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorised: Marco Bertolino Testing Manager Test report no.: 1-5753/12-01-01_AnnexB 2014-07-01 Page 2 of 5 Inter nal p ho tos of the E UT Photo 1: Photo 2: Test report no.: 1-5753/12-01-01_AnnexB 2014-07-01 Page 3 of 5 Photo 3: Photo 4: Test report no.: 1-5753/12-01-01_AnnexB 2014-07-01 Page 4 of 5 Photo 5: Photo 6: Test report no.: 1-5753/12-01-01_AnnexB 2014-07-01 Page 5 of 5 Docu men t his to r y Version Applied changes Date of release Initial release 2014-07-01

FCC ID: DMOEM2G4WE IC: 2099A-EM2G4WE Model: EM D1 Prediction of MPE limit at given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG / 4π R 2 where: S = Power density P = Power input to the antenna G = Antenna gain R = Distance to the center of radiation of the antenna The table below is excerpted from Table 1B of 47 CFR 1.1310 titled “Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure” Frequency Range (MHz) Power Density (mW/cm 2 ) Averaging Time (minutes) 300 -1500 f/1500 30 1500 - 100000 1.0 30 where f = Frequency (MHz) Prediction: P Max power input to the antenna: 15.0 dBm / 31.6 mW R Distance: 20 cm S MPE limit for uncontrolled exposure: 1 mW/cm 2 G Antenna gain: 1.46 numerical Calculated Power density: 0.009 mW/cm 2 This prediction demonstrates the following: The power density levels at a distance of 20 cm are below the maximum levels allowed by regulations. Andreas Luckenbill Cetecom ICT Services GmbH

2015-01-23 Page 1 of 61 TEST REPORT Test report no.: 1-5753/12-01-14-A Testing laboratory Applicant CETECOM ICT Services GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken / Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: http://www.cetecom.com e-mail: [email protected] Accredited Testing Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2005) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-00 Area of Testing: Radio Communications & EMC (RCE) Sennheiser electronic GmbH & Co. KG Am Labor 1 30900 Wedemark / GERMANY Phone: +49 5130 600-0 Fax: +49 5130 600-574 Contact: Marco Happ e-mail: [email protected] Phone: +49 5130 600-2621 Manufacturer Sennheiser electronic GmbH & Co. KG Am Labor 1 30900 Wedemark / GERMANY Test standard/s 47 CFR Part 15 Title 47 of the Code of Federal Regulations; Chapter I; Part 15 - Radio frequency devices RSS - 210 Issue 8 Spectrum Management and Telecommunications Radio Standards Specification - Licence-exempt Radio Apparatus (All Frequency Bands): Category I Equipment For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: Wireless Microphone Stationary Device Model name: EM D1 FCC ID: DMOEM2G4WE IC: 2099A-EM2G4WE Frequency: DTS band 2400 MHz to 2483.5 MHz Technology tested: Modulated carrier Antenna: External rod. antennas Power supply: 12.0 V DC by external AC/DC adapter Temperature range: -10°C to +55°C This test report is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report authorised: Test performed: Stefan Bös Andreas Luckenbill Radio Communications & EMC Radio Communications & EMC Test report no.: 1-5753/12-01-14-A 2015-01-23 Page 2 of 61 1 Table of contents 1 Table of contents ............................................................................................................................................ 2 2 General information ....................................................................................................................................... 3 2.1 Notes and disclaimer .......................................................................................................................... 3 2.2 Application details ............................................................................................................................... 3 3 Test standard/s ............................................................................................................................................... 3 3.1 Measurement guidance ....................................................................................................................... 3 4 Test environment ............................................................................................................................................ 4 5 Test item .......................................................................................................................................................... 4 5.1 Additional information ........................................................................................................................ 4 6 Test laboratories sub-contracted ................................................................................................................. 4 7 Description of the test setup ......................................................................................................................... 5 7.1 Radiated measurements chamber F .................................................................................................. 5 7.2 Radiated measurements chamber C ................................................................................................. 6 7.3 Radiated measurements 12.75 GHz to 26 GHz ................................................................................. 7 7.4 AC conducted ...................................................................................................................................... 8 7.5 Conducted measurements ................................................................................................................. 8 8 Summary of measurement results ............................................................................................................... 9 9 Additional comments ................................................................................................................................... 10 10 Measurement results ............................................................................................................................ 11 10.1 Antenna gain .................................................................................................................................. 11 10.2 Maximum output power ................................................................................................................. 12 10.3 Power spectral density .................................................................................................................. 13 10.4 Spectrum bandwidth – 6 dB .......................................................................................................... 16 10.5 Occupied bandwidth – 99% emission bandwidth....................................................................... 17 10.6 Spurious emissions near the band edges ................................................................................... 20 10.7 Band edge compliance radiated ................................................................................................... 22 10.8 TX spurious emissions conducted ......................................................................…

Text truncated - open the document above for the full version.

Test report no.: 1-5753/12-01-01_AnnexD 2014-07-03 Page 1 of 7 Annex D This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorised: Marco Bertolino Testing Manager Test report no.: 1-5753/12-01-01_AnnexD 2014-07-03 Page 2 of 7 EUT Test se tu p p h otos Photo 1: Photo 2: Test report no.: 1-5753/12-01-01_AnnexD 2014-07-03 Page 3 of 7 Photo 3: Photo 4: Test report no.: 1-5753/12-01-01_AnnexD 2014-07-03 Page 4 of 7 Photo 5: Photo 6: Test report no.: 1-5753/12-01-01_AnnexD 2014-07-03 Page 5 of 7 Photo 7: Photo 8: Test report no.: 1-5753/12-01-01_AnnexD 2014-07-03 Page 6 of 7 Photo 9: Photo 10: Test report no.: 1-5753/12-01-01_AnnexD 2014-07-03 Page 7 of 7 Docu men t his to r y Version Applied changes Date of release Initial release 2014-07-03
