DMOH1EURH

Sennheiser Electronic Corp

Click to zoom

Application Details

Equipment Class: TNF - Licensed Non-Broadcast Transmitter Held to Face
Date of Grant: Feb 08, 2000
Application Purpose: Original Equipment
Date of Application: Sep 28, 1999
Frequency Range: 944.00000000 - 952.00000000
Company: Sennheiser Electronic Corp
Country: United States

Documents & Files

Select a file to view

Operational Description

Schematics

↗

Test Report

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Test Report

Occupied Bandwidth Equipment under Test:SKM500 / SKM300 / SKM100 Ambient Temperature:23°C Relative Humidity:62% Frequency:756.000 MHz Modulation:85% by a 15 kHz input signal FCC ID: DMOH1EURH 3 Occupied Bandwidth Equipment under Test:SKM500 / SKM300 / SKM100 Ambient Temperature:23°C Relative Humidity:62% Frequency:870.000 MHz Modulation:85% by a 15 kHz input signal FCC ID: DMOH1EURH 4 5) Converting pages 10 to 14 of the Test Report to electronic format may have rendered the traces of the audio analyzer screen unrecognizable. The audio analyzer screen representations reproduced on the next five pages plot the audio modulation circuit behavior per §2.1047(a) and (b). The panel to the left of the screen displays the generator settings of the audio analyzer. Frequency and amplitude responses between audio input and the modulated stage clearly show the performance of the modulation limiter and low pass filter employed in the transmitter design to prevent any reasonable possibility of overmodulation. Please substitute the following 5 pages for pages 10 through 14 of the original Test Report. FCC ID: DMOH1EURH 5

Test Report

Characteristics of the Audio Modulation Circuitry Equipment under Test:SKM500 / SKM300 / SKM100 Ambient Temperature:23°C Relative Humidity:62% Frequency:518.100 MHz FCC ID: DMOH1EURH 6 Characteristics of the Audio Modulation Circuitry Equipment under Test:SKM500 / SKM300 / SKM100 Ambient Temperature:23°C Relative Humidity:62% Frequency:646.000 MHz FCC ID: DMOH1EURH 7 Characteristics of the Audio Modulation Circuitry Equipment under Test:SKM500 / SKM300 / SKM100 Ambient Temperature:23°C Relative Humidity:62% Frequency:756.000 MHz FCC ID: DMOH1EURH 8 Characteristics of the Audio Modulation Circuitry Equipment under Test:SKM500 / SKM300 / SKM100 Ambient Temperature:23°C Relative Humidity:62% Frequency:806.000 MHz FCC ID: DMOH1EURH 9 Characteristics of the Audio Modulation Circuitry Equipment under Test:SKM500 / SKM300 / SKM100 Ambient Temperature:23°C Relative Humidity:62% Frequency:870.000 MHz FCC ID: DMOH1EURH 10
