DMORS03CDUSWireless Headphone System

LieferumfangKopfhörer: HDR 130Akku: 2 x Typ AAA Ni-MH 1,2 VSender: TR 130 mit Audio-Anschlusskabel (fest angeschlossen)Steckernetzteil: NT-RS 100Adapter 3,5 mm/6,3 mmCinch-Adapter (nur 925 MHz-Version)GebrauchsanleitungSicherheitshinweise Achtung: Setzen Sie den Kopfhörer nicht auf, wenn Ihre Umgebung besondere Aufmerksam-keit erfordert (z.B. im Straßenverkehr, bei hand-werklichen Tätigkeiten). Achtung: Keine Batterien über den Kopfhörer la- den! Nur aufladbare Akkus verwenden! AkkusAlte Akkus nur leer über den Fachhandel oder Batteriecon-tainer entsorgen.Akkus vor der ersten Benutzun g mindestens 16 Stunden la- den. Anschließend entspricht die Zeit zum vollständigen Aufladen der Akkus ungefähr der vorherigen Benutzungs-dauer. Wird der Kopfhörer längere Zeit nicht benutzt, ent-fernen Sie bitte die Akkus.Technische DatenSiehe Verpackung oder unter www.sennheiser.com.ZubehörZweithörer: HDR 130ErsatzohrpolsterVerwenden Sie nur Original-Sennheiser Komponenten und Ersatzteile. Andernfalls könne n Schäden am Gerät auftreten und die Garantie erlischt.Weitere InformationenHalten Sie das Gerät stets trocken und setzen Sie es weder extrem niedrigen noch extrem hohen Temperaturen aus (ideal: 10 bis 35°C). Behandeln Sie das Gerät sorgfältig und stellen Sie es an einem sauberen, staubfreien Ort auf. Lacke und Möbelpolituren können die Füße des Senders angreifen und so Flecken auf Ihren Möbeln verursachen. Bewahren Sie den Kopfhörer nicht über längere Zeit mit gespreiztem Bü-gel auf, da die Bügelspannung nachlassen kann.2 Jahre GarantieLänderspezifische Zulassungsvorschriften sind zu beachten!Bedeutung der Anzeigen und Quittungstöne Delivery includesHeadphones: HDR 130Rechargeable battery: 2 x AAA size Ni-MH 1,2 VTransmitter: TR 130 with audio connecting cable (permanently connected)Mains unit: NT-RS 100Adapter 3,5 mm/6,3 mmRCA phono plug (925 MHz variant only)Instructions for useSafety notes Attention: Do not wear the headphones in situations which require special attention (e.g. intraffic or when performing skilled jobs).Attention: Do not charge standard batteries via the headphones. Only use rechargeable batteries. Rechargeable batteriesDispose of exhausted rechargeable batteries at specialcollection points or return them to your specialist dealer. Charge the batteries for at least 16 hours prior to first timeuse. Subsequent charging time is about the same time as the previous operating time. If you do not use the head-phones for extended periods of time, please remove thebatteries.SpecificationsSee packaging or visit our web site at www.sennheiser.com.AccessoriesAdditional headphones: HDR 130Replacement ear cushionsOnly use original Sennheiser components, otherwise the unit can be damaged and the warranty becomes null and void.Additional informationAlways keep the unit dry and do not expose it to extreme temperatures (ideally 10-35°C). Use the unit with care and set it up in a clean, dust-free environment. Varnish orfurniture polish may degrade the rubber feet of thetransmitter, which could stain your furniture. Do not storeyour headphones on a glass dummy head, chair armrest, orsimilar for long periods of time as this can widen theheadband and reduce the contact pressure of theheadphones.2-year warrantyPlease observe the respective country-specific regulations on frequency usage.Meanings of the LEDs and acoustic signals LieferumfangCasque d'écoute: HDR 130Batterie : 2 du type AAA Ni-MH 1,2 VÉmetteur : TR 130 avec câble de raccordement audio (fixe)Bloc d'alimentation : NT-RS 100Adaptateur: 3,5 mm/6,3 mmCinch-Adapter (uniquement pour la version 926 MHz)Notice d'emploiSicherheitshinweise Attention : Ne pas utiliser le casque dans des si- tuations demandant une attention spéciale, par exemple en automobile ou lors de travaux à ris-que.Attention : Ne pas essayer de recharger des piles standard. Utiliser uniquement des batteries. AkkusAlte Akkus nur leer über den Fachhandel oder Batteriecon-tainer entsorgen.Akkus vor der ersten Benutzung mindestens 16 Stunden la-den. Anschließend entspricht die Zeit zum vollständigen Aufladen der Akkus ungefähr der vorherigen Benutzungs-dauer. Wird der Kopfhörer längere Zeit nicht benutzt, ent-fernen Sie bitte die Akkus.Caractéristiques techniquesVoir sur l'emballage ou sur notre site web www.sennhei-ser.com.AccessoiresDeuxième écouteur : HDR 130 Coussinet d'oreillette de rechange N'utilisez que des composants Se nnheiser d'origine sous pei- ne d'endommager l'appareil et de perdre tout droit à la ga-rantie.Informations complémentairesVeillez à ce que l'appareil soit toujours sec et ne l'exposezpas à des températures extrêmes, qu'elles soient basses ouélevées (idéalement, entre 10 et 35 °C). Prenez soin del'appareil et posez-le à un endroit propre et exempt depoussière. Les peintures et cires de meubles peuvent altérerles pieds de l'émetteur et être à l'origine de taches sur vosmeubles. Ne stockez pas votre casque sur une tête factice,l'accoudoir d'une chaise, ou autre support semblable,pendant les longues périodes. Le bandeau pourrait s'entrouvé élargi et la pression de contact du casque réduite. 2 ans de garantieVeuillez observer le s dispositions légales sur l'usage de fré- quences dans votre pays.Bedeutung der Anzeigen und Quittungstöne Dotazione di consegnaCuffie: HDR 130Accumulatore: 2 x tipo AAA Ni-MH 1,2 VTrasmettitore: TR 130 con ca vo di collegamento audio (collegato in modo fisso)Alimentatore a spina: NT-RS 100Adattatore 3,5 mm/6,3 mmCinch-Adapter (solo per la versione da 926 MHz)Istruzioni per l'usoSicherheitshinweise Attenzione: Non indossate le cuffie se l'ambiente che vi circonda richiede particolare attenzione (ad es. in mezzo al traffico, durante attività ma-nuali).Attenzione: Non utilizzate batterie per la carica delle cuffie! AkkusAlte Akkus nur leer über den Fachhandel oder Batteriecon-tainer entsorgen.Akkus vor der ersten Benutzung mindestens 16 Stunden la-den. Anschließend entspricht die Zeit zum vollständigen Aufladen der Akkus ungefähr der vorher…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 September 17, 2004 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Company requests confidentiality for the following products: FCC ID Number Product Title/Model DMORS03CDUS RS130-9 / RS140-9 For the product stated above, we request that the following information be held confidential: 1. Circuit diagrams, BOM, and PCBs submitted as Equipment Authorization Electronic Filing attachment: "schematics”. 2. Block diagram submitted as Equipment Authorization Electronic Filing attachment: “blockdiagram”. 3. Operational description submitted as Equipment Authorization Electronic Filing attachment: “operational description” The above exhibits contain Company trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our mobile handset. This material is not customarily available to the general public and we request that it be withheld from public inspection. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Volker Bartsch Company: Sennheiser electronic Address: Am Labor 1 D-30900 Wedemark (Germany) Phone: 49-5130-600-465 Email: [email protected]

CETECOM ICT Services GmbH Radio Satellite Communication Untertürkheimer Straße 6-10 . D-66117 Saarbrücken Telefon: +49 (0)681 598-9100 Telefax: -9075 RSC14 issue test report consist of 49 Pages Page 1 (49) Recognized by the Federal Communications Commission and Industry Canada Anechoic chamber registration No.: 90462 (FCC) Anechoic chamber registration No.: 3463 (IC) TCB ID: DE0001 Accredited by the German Accreditation Council DAR–Registration Number TTI–P–G 081/94-D0 Independent ETSI compliance test house ETSI Accredited Bluetooth™ Test Facility (BQTF) Test report no.: 2-3759-01-02/04 FCC Part 15.249 RS130 / RS140 FCC-ID: DMORS03CDUS IC : 2099A-RS03CDCN CETECOM – ICT Services GmbH Untertürkheimerstr. 6-10 66117 Saarbrücken, Germany Telephone: + 49 (0) 681 / 598-0 Fax: + 49 (0) 681 /598-9075 BLUETOOTH is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM CETECOM ICT Services GmbH Test report no.:2-3759-01-02/04 Issue date: 2004-09-20 Page 2 (49) Table of contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.4 Application details 1.5 Test item 1.6 Test specifications 2 Technical test 2.1 Summary of test results 2.2 Test report CETECOM ICT Services GmbH Test report no.:2-3759-01-02/04 Issue date: 2004-09-20 Page 3 (49) 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. Test laboratory manager: 2004-10-01 RSC - 8411 Berg M. Date Section Name Signature Technical responsibility for area of testing: 2004-10-01 RSC - 8412 Hausknecht D. Date Section Name Signature CETECOM ICT Services GmbH Test report no.:2-3759-01-02/04 Issue date: 2004-09-20 Page 4 (49) 1.2 Testing laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Telephone : + 49 681 598 - 0 Telefax : + 49 681 598 - 9075 E-mail : [email protected] Internet : www.cetecom-ict.de Accredited testing laboratory Accredited by : Regulierungsbehörde für Telekommunikation und Post (RegTP) Listed by : Federal Communications Commission (FCC) Authority Identification/Registration No. RegTP TTI-P-G 081/94-D0 FCC 90462 1.3 Details of applicant Name : Sennheiser electronic GmbH & Co. KG Street : Am Labor 1 City : D-30900 Wedemark Country : Germany Telephone: +49 5130 600-0 Telex : +49 5130 600-300 E-mail : [email protected] Contact person: Name : Mr. Volker Bartsch Telephone : +49 5130 600-465 Telex : +49 5130 600-330 E-mail : [email protected] 1.4 Application details Date of receipt of application : 2004-09-02 Date of receipt of test item : 2004-09-20 Date of test : 2004-09-21 CETECOM ICT Services GmbH Test report no.:2-3759-01-02/04 Issue date: 2004-09-20 Page 5 (49) 1.5 Test item Type of equipment : Wireless Headphone Type designation : RS130 / RS140 Consists of: 1 x Transmitter TR130-8 or TR140-8 (different AF circuit) 1 x AC/DC Adapter SIL Model No.:VD990020D 1 x Receiver HDR130-8 or HDR140-8 Manufacturer : Sennheiser electronic GmbH & Co. KG Street : Am Labor 1 City : D-30900 Wedemark Country : Germany Serial number : - / - Additional information : Frequency : 926.1 – 927.5 MHz 180KF3E (= 2 x max deviation (75 kHz) + 2 x max AF (15 kHz ) Channel spacing : 700 kHz Number of channels : 3 Antenna : integral antenna ERP : 49.5 dBmV/m in 3m Power supply : Tx: 120V/9V AC/DC Adapter; Rx: 2x 1.2V rechargeable battery Temperature range : +5°C - +45°C Transmitter spurious : 78.5 μV/m in 3m Receiver spurious . 42.1 dBμ/m (Noise floor) in 3m IC-ID : 2099A-RS03CDCN DECLARATION OF COMPLIANCE: I declare that the testing was performed or supervised by me; that the test measurements were made in accordance with the above-mentioned Industry Canada standard(s); and that the equipment identified in this application has been subjected to all the applicable test conditions specified in the Industry Canada standards and all of the requirements of the standard have been met. Signature: _______________________________________________ Date: ___2004-09-20Michael Berg ; Test management NAME AND TITLE (Please print or type): 1.6 Test specifications: FCC Part 15 §15.249 CANADA RSS-210 TR130-9 and HDR130-9 represent the worst case configuration and was chosen for test. RS130 consist of Receiver HDR130-9 and Transmitter TR130-9 RS140 consist of Receiver HDR140-9 and Transmitter TR140-9 CETECOM ICT Services GmbH Test report no.:2-3759-01-02/04 Issue date: 2004-09-20 Page 6 (49) 2 Technical test 2.1 Summary of test results The radiated measurements are performed in vertical and horizontal plane in the frequency range from 9 kHz to 20 GHz in semi-anechoic chambers. The EUT is positioned on a non- conductive support with a height of 0.80 m above a conductive ground plane that covers the whole chamber. The receiving antennas are conform with specifications ANSI C63.2-1996 clause 15 and ANSI C63.4-2003 clause 4.1.5. These antennas can be moved over the height range between 1.0 m and 4.0 m in order to search for maximum field strength emitted from EUT. The measurement distances between EUT and receiving antennas are indicated in the test set-ups for the various frequency ranges. For each measurement, the EUT is rotated in all three axes until the maximum field strength is received. The wanted and unwanted emissions are received by spectrum analysers where the detector modes and resolution bandwidths over various frequency ranges are set according to requirement ANSI C63.4-2003 clause 4.2. Antennas are conform with ANSI C63.2-1996 item 15. 9 kHz - 30 MHz: Quasi Peak measurement, 100 Hz/ 9kHz Band…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Test report no.:2-3759-01-02/04 Issue date: 2004-09-20 Page 26 (49) Test setup TR140-9 CETECOM ICT Services GmbH Test report no.:2-3759-01-02/04 Issue date: 2004-09-20 Page 27 (49) Test setup TR140-9 CETECOM ICT Services GmbH Test report no.:2-3759-01-02/04 Issue date: 2004-09-20 Page 28 (49) Test setup HDR140-9 CETECOM ICT Services GmbH Test report no.:2-3759-01-02/04 Issue date: 2004-09-20 Page 29 (49) Test setup HDR140-9 CETECOM ICT Services GmbH Test report no.:2-3759-01-02/04 Issue date: 2004-09-20 Page 30 (49) Test setup RS140
