DMOSK5012Wireless Microphone

SK 5012 GEBRAUCHSANLEITUNGINSTRUCTION MANUALNOTICE D ́EMPLOIISTRUZIONI PER L ́USOINSTRUCCIONES PARA EL USOGEBRUIKSAANWIJZINGBRUKSANVISNING SK5012.book Seite 1 Montag, 23. Juli 2001 3:43 15 SK5012.book Seite 2 Montag, 23. Juli 2001 3:43 15 SK 5012 - 3 English Delivery includes- SK 5012- Antenna- 2 Batteries- Attachment clip- Screwdriver SK5012.book Seite 3 Montag, 23. Juli 2001 3:43 15 SK 5012 - 4 English Operating Elements1 Mikrofone input2 LED for operation, battery status and peak indication 3 Antenna socket4 Sensitivity switch5 Channel selector switch6 Frequency/channel data plate 7 Type plate (in battery compartment) 8 ON/OFF switch 1 2 3 4 5 6 7 8 SK5012.book Seite 4 Montag, 23. Juli 2001 3:43 15 SK 5012 - 5 English SK 5012 Mikroport bodypack transmitterThank you for choosing Sennheiser! We have designed this product to give you reliable operation over many years. Over half a century of accumulated expertise in the design and manufacture of high-quality of electro-acoustic equipment have made Sennheiser a world-leading company in this field.Due to its extremely flat design and small dimensions, the SK 5012 is espe-cially suitable for applications where a very unobtrusive transmitter is being required. SK5012.book Seite 5 Montag, 23. Juli 2001 3:43 15 SK 5012 - 6 English Features• Extremely small metal diecast casing• Special protection against the ingress of moisture• 6-step sensitivity switch for optimum adaption to different microphone input voltages • Supplies connected condenser microphones• State-of-the-art PLL technology, 16 switchable channels• HiDyn plus TM noise reduction system • Signal-to-noise-ratio > 110 dB (A) • Voltage converter ensures constant output power until the batteries are completely discharged • LED operation indicator: LED lights up dimly • LED “ low-battery “ indicator: LED blinks periodically • LED peak indicator: LED flashes brightly • Reliable, easy-to-use clip attachement SK5012.book Seite 6 Montag, 23. Juli 2001 3:43 15 SK 5012 - 7 English Inserting batteriesOpen the transmitter by pushing down and pulling the two catches at the sides.Insert the two batteries into the battery compartment.When closing the transmitter, make sure that the two catches at the sides lock into place.The transmitter can also be powered by rechargeable batteries. SK5012.book Seite 7 Montag, 23. Juli 2001 3:43 15 SK 5012 - 8 English Important noteFor maximum operating time, we recommend using AAA size alkaline manganese batteries (IEC LR 03). Turning the transmitter onSet the ON/OFF switch to ON. The red LED lights up dimly. This LED also serves as a peak indicator (LED flashes brightly) and “ low battery “ indicator (LED blinks periodi-cally)
SK5012.book Seite 8 Montag, 23. Juli 2001 3:43 15 SK 5012 - 9 English Indicating “ low-battery “ status The transmitter has an inte-grated voltage converter which ensures constant operating conditions until the batteries are completely discharged. When the remaining operation time is approx. 30 minutes, the LED starts blinking periodi-cally.. As the batteries discharge, the blinking of the LED accelera-tes. NoteIf the transmitter is powered by rechargeable batteries, the LED only starts blinking shortly before the batteries are com-pletely discharged.
SK5012.book Seite 9 Montag, 23. Juli 2001 3:43 15 SK 5012 - 10 English Connecting microphonesThe transmitter has been designed for use with “ lavalier “ clip-on microphones which are fitted with a special Lemo plug. The supply voltage for powering these micro-phones is available at the transmit-ter ’ s microphone input. Connect the microphone ’ s Lemo plug to the socket at the top of the transmitter and lock the connection by screwing down the coupling ring. SK5012.book Seite 10 Montag, 23. Juli 2001 3:43 15 SK 5012 - 11 English Selecting a channelSet the channel selector switch to the desired position. The assign-ment of a switch position /channel to a frequency is listed on the fre-quency/channel data plate (see inside battery compartment cover) . SK5012.book Seite 11 Montag, 23. Juli 2001 3:43 15 SK 5012 - 12 English Attachment of the bodypack transmitterDue to its small dimensions and extrememly flat design, the transmit-ter can easily be attached to your clothing (e.g. pocket, waistband, belt) by means of the supplied clip. To avoid kinking the antenna, the clip can be withdrawn from its fixing points and attached the other way round.Make sure not to kink the antenna. SK5012.book Seite 12 Montag, 23. Juli 2001 3:43 15 SK 5012 - 13 English Adjusting the sensitivityUse the 6-step sensitivity switch to adapt the gain of the micro-phone input to the expected sound levels. In practice, the following set-tings have proved their worth for adjusting the sensitivity:Position 1 = high-frequency, loud audio material with many plosives Position 2,3 = loud voices, vocals, theater applications (close-miking) Position 3,4,5 = normal voices, talkshows, Position 6 = soft voices SK5012.book Seite 13 Montag, 23. Juli 2001 3:43 15 SK 5012 - 14 English To provide for an accurate sensi-tivity setting, use the deviation indicator of your receiver (e.g. EM 1046). As an aid to orientation, the transmitter ’ s LED peak indica- tor lights up brightly. The sensi-tivity is set correctly, when the LED peak indicator lights up brightly only during peak levels. When adjusting the sensitivity, hold or attach the microphone exactly where it will be positio-ned during use.HiDyn plus TM This transmitter is equiped with HiDyn plus TM , the Sennheiser noise reduc- tion system that reduces RF interference. Together with a receiver which is also equipped with HiDyn plus TM (e.g. EM 1046), an RF link of excellent operational reliability and high transmission quality can be set up. SK5012.book Seite 14 Montag, 23. Juli 2001 3:43 15 SK 5012 - 15 English AccessoriesOnly use original Sennheiser accessories and spare parts. AttentionComponents from other manufacturers may cause damage to the unit and will invalidate the warrant…

Text truncated - open the document above for the full version.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TRP/Cetecom bvba July 28, 2001 FCC Laboratory 7435 Oakland Mills Rd Dayton, MD 21036 Re: FCC ID:DMO-SK5012, EA101844 FCC Exami ner, During the application filing process for FCCID:DMOSK5012, EA101843, the internet connection failed. As a result I was unable to complete the filing and submission of the fee payment form. I have requested that FCCID:DMOSK5012, EA101843, be dismissed or otherwise deleted. I have refiled the equipment under the above FCCID with a hyphen in the identifier which allowed the completion of the filing and fee payment process. After dismissal or deletion of the application under EA101843, please correct the FCC ID listed on the Form 731 to read FCCID:DMOSK5012. This will correct the FCCID on the Form 731 to correspond with the FCC ID label submitted in this application. Sincerely, Phillip Inglis Cons ulta nt 14085 Howard Rd Dayton, MD 21036

Authorisation (Power of attorney) We, Sennheiser electronic GmbH & Co. KG Am Labor 1, 30900 Wedemark Germany authorise CETECOM ICT Services GmbH Untertürkheimer Strasse 6 - 10 D-66117 Saarbrücken Germany to act as our agent and to process and sign on our behalf for all approval activities in all countries. This authorisation is applicable for the product: SK 5012 Wedemark, 2001-07-28. _____________________ (Place, date)(signature) Klaus Willemsen (Name in blockletters & companystamp)

July 26 , 2001 CONFIDENTIALITY REQUEST Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re:Sennheiser Electronic Corp. FCC ID: DMOSK5012 Gentlemen: Sennheiser Electronic Corp., herein submits an Application for Equipment Authorization to be followed by submission of a fee for $1130.00 along with Form 159 for certification of a wireless microphone transmitter under FCC Rules Part 74 as required by the FCC Rules. Sennheiser requests, pursuant to 47CFR 0.459, post grant confidentiality for portions of the material contained in this application such that the identified material will be withheld from public inspection following the grant of this authorization. This material, as indicated by request for confidentiality of the item during the electronic submission process and further identified below, includes: 1. Circuit diagrams submitted as Equipment Authorization Electronic Filing attachment: "schematics". Specifically, this exhibit contains information relating to circuit function and complexity that could be of benefit to competitors. The material contains trade secrets and confidential information that Sennheiser does not customarily release to the public and which is otherwise not generally available to the public. Please contact the undersigned by phone at 410-531-3439, by fax at 410-531-0807, by email at [email protected], or by correspondence at the address below if there are any further questions or additional information needed concerning this filing. Regards, (signed) Phillip Inglis, TRP/Cetecom b.v.b.a. 14085 Howard Rd. Dayton, MD. 21036

TRP/Cetecom bvba September 24, 2001 Federal Communications Commission 7435 Oakland Mills Rd Columbia, MD 21036 Re: FCC confirmation number, EA101844, and correspondence number 20699 Gentlemen: Following are clarifications of the measurement procedures used by Cetecom ICT Services for showing compliance with the technical parameters specified in Section 74.861 for Low Power Auxiliary Stations. The parameters measured to show compliance with the technical specifications in Section 74.861 are the following: 1) power output, 2) frequency stability with voltage and temperature, 3) audio modulation circuitry, 4) occupied bandwidth, and 5) spurious emissions. 1. Power output: The equipment uses a small vertical whip antenna and ERP measurements were made using a substitution technique. A reference level from the EUT was established on a spectrum analyzer. A signal generator attached to a dipole cut to the frequency being measured was substituted for the EUT. The signal generator power level was adjusted to match the reference level on the spectrum analyzer and the power level setting of the generator was recorded as the ERP power level at the frequency being measured in dBm. The power level in dBm was then converted to ERP power level in milliwatts. Maximum ERP power level is 17.38 mW and complies with 74.861(d)(1) and 74.861(e)(1)(ii) as appropriate. 2. Frequency stability with voltage and temperature: Frequency variation with temperature was run using a temperature chamber in 10-degree Centigrade steps. At each temperature step the EUT was allowed to “soak” a sufficient amount of time to allow the EUT frequency determining components to stabilize at each temperature level and the frequency measurement was then made. Frequency variation with voltage level was conducted using a variable DC voltage source to replace the conventional batteries. Nominal voltage from a set of new batteries is 3.0 V. The manufacture specifies the operating voltage range to be from 1.89 V (63% of nominal) to the full battery voltage. A set of frequency measurements made over the range of power supply voltages from 1.89 V to 3 V were made and are presented in the report. Measured frequency stability easily meets the tolerance requirement of 0.005% for both temperature and voltage variation of 74.681(e)(5). 3. Audio modulation circuitry: The audio frequency response over a frequency range from 10 to 21kHz is shown for 4 RF frequencies across the band with a range of audio input voltages from 10 millivolts to 3 volts incremented in 5 dB steps. The response curve shows that essentially full limiting occurs with an audio input level of approximately 100 millivolts. All measurements were done under computer control with the measurement data taken at the input to the EUT modulator. 14085 Howard Rd Dayton, MD 21036 September 24, 2001 Page 2 4. Occupied bandwidth: Occupied bandwidth measurements were made in accordance with the requirements for transmitters for use in the broadcast radio services, Section 2.1049(e)(3). Tone used was 15 kHz at an 85% modulation level. The audio signal was input through the microphone and the radiated signal was displayed on the spectrum analyzer. Four occupied bandwidth plots at frequencies across the band of operation show the requirements for +/- 75 kHz maximum deviation, the 200 kHz operating bandwidth and that emissions requirements within the band of frequencies of 250% of the authorized bandwidth centered on the operating frequency are met. For emissions within 100 kHz to 200 kHz of the operating frequency, the levels are attenuated at least –60 dB thus meeting the 25-dB requirement. At frequencies between 200 kHz and 250 kHz removed from the operating frequency, emissions are attenuated to a level of –68 dB below the operating frequency. All close in emissions are attenuated to the measurement system noise floor, -70 dB or better below the operating frequency carrier level, at frequencies greater than 250 kHz removed from the operating frequency. In this region of spectrum attenuation below 43 + 10 log 10 (mean power in watts) = 43 –12 or 31 dB which is easily met. 5. Spurious emissions: To show compliance with the spurious limit spectrum scans from 30 MHz to 12 GHz are presented. These scans show that all emissions outside the band +/- 250 kHz of the operating frequency are attenuated more that –60 dB based on radiated levels relative to the level of the operating frequency. The spectrum analyzer computes and displays all levels in terms of dBuV/m. Sincerely, Phillip Inglis Consultant

CETECOM ICT Services GmbH Test report no.: 2_2575-A/01Issue Date: 25.06.2001Page 34 (42) Photographs of the equipment SK 5012 Photograph no.: 2 CETECOM ICT Services GmbH Test report no.: 2_2575-A/01Issue Date: 25.06.2001Page 35 (42) Photographs of the equipment SK 5012 Photograph no.: 3 CETECOM ICT Services GmbH Test report no.: 2_2575-A/01Issue Date: 25.06.2001Page 36 (42) Photographs of the equipment SK 5012 Photograph no.: 4

The above label is located in the battery compartment and is clearly visible when the cover is removed . The FCC ID will be as follows below and will replace the FCC ID: XXXXXX in the above label. FCC ID:DMOSK5012

CETECOM ICT Services GmbH Test report no.: 2_2575-A/01Issue Date: 25.06.2001Page 42 (42) Photographs of the equipment SK 5012 Photograph no.: 10

CETECOM ICT Services GmbH Test report no.: 2_2575-A/01Issue Date: 25.06.2001Page 37 (42) Photographs of the equipment SK 5012 Photograph no.: 5 CETECOM ICT Services GmbH Test report no.: 2_2575-A/01Issue Date: 25.06.2001Page 38 (42) Photographs of the equipment SK 5012 Photograph no.: 6 CETECOM ICT Services GmbH Test report no.: 2_2575-A/01Issue Date: 25.06.2001Page 39 (42) Photographs of the equipment SK 5012 Photograph no.: 7 CETECOM ICT Services GmbH Test report no.: 2_2575-A/01Issue Date: 25.06.2001Page 40 (42) Photographs of the equipment SK 5012 Photograph no.: 8 CETECOM ICT Services GmbH Test report no.: 2_2575-A/01Issue Date: 25.06.2001Page 41 (42) Photographs of the equipment SK 5012 Photograph no.: 9

Operational Description. The Sennheiser Wireless Microphone is a belt clip worn device for transmitting voice to a separate studio. The system uses a PLL/VCO for generating the output carrier frequency with frequency determined from an EEPROM with stored frequency data. Audio modulation from the input microphone is coupled to an amplifier, compander, and limiter system before coupling to the FM modulator.
