Sennheiser electronic GmbH & Co. KG Am Labor 1, 30900 Wedemark, Germany www.sennheiser.com Printed in Germany, Publ. 06/22, 587466/A02 Evolution Wireless Digital Technische Daten & Herstellererklärungen Specifications & Manufacturer declarations Caractéristiques techniques & Déclarations du fabricant Dati tecnici & Dichiarazioni del costruttore Especificaciones técnicas & Declaraciones del fabricante Dados técnicos & Declarações do fabricante Technische specificaties & Verklaringen van de fabrikant Dane techniczne & Deklaracje producenta Tekniska data & Tillverkarintyg Tekniske data & Producenterklæringer Tekniset tiedot & Valmistajan vakuutukset Τεχνικά χαρακτηριστικά & Δηλώσεις κατασκευαστή Teknik Bilgiler & Üretici Beyanları Технические характеристики & Заявления изготовителя 技术参数 & 制造商声明 產品規格 & 廠商聲明 技術仕様 & 製造者宣言 기술 데이터 & 제조사 선언 EW-DX EM 2 EW-DX SK EW-DX SKM EW-D Power Supply (Model: S012DXM1200100) SPECIFICATIONS System Audio link frequency ranges Q1-9 R1-9 S1-10 S2-10 S4-10 U1/5 V3-4 V5-7 X1-6 X9-18 Y1-3 470.2 - 550 MHz 520 - 607.8 MHz 606.2 - 693.8 MHz 614.2 - 693.8 MHz 630 - 693.8 MHz 823.2 - 831.8 MHz & 863.2 - 864.8 MHz 925.2 - 937.3 MHz 941.7 - 951.8 MHz & 953.05 - 956.05 MHz & 956.65 - 959.65 MHz 1350.2 - 1398.8 MHz 1435.2 - 1524.8 MHz 1785.2 - 1799.8 MHz Bluetooth® Low Energy (BLE) frequency range 2402 - 2480 MHz Audio frequency response 20 Hz - 20 kHz (-3 dB) Audio THD≤ -60 dB for 1 kHz @ -3 dBfs input level Dynamic range134 dB System latency1.9 ms Operating temperature-10 °C - +50 °C (14 °F - 122 °F) Relative humidity5 - 95 % (non-condensing) EW-DX EM 2 (Rack Receiver) Input voltage11 - 13 V ⎓ or PoE IEEE 802.3af Class 0 (CAT5e or higher) Input current≤ 1 A Transmit power (ra- diated) BLE: max. 10 mW EIRP Audio output power18 dBu max. Headphone output2x 70 mW @ 32 Ω EthernetRJ-45 socket, IEEE802.3 100Base-TX (half+full duplex) 10Base-T (half+full duplex) (CAT5e or higher) Dimensions212 x 44 x 206 mm Weightapprox. 1000 g (without anten- nas and power supply) EW-DX SKM (Handheld Transmitter) Input voltage2.0 - 4.35 V Input current< 300 mA Power supply2 AA batteries 1.5 V (alkali man- ganese) or BA 70 rechargeable battery pack Occupied bandwidth200 kHz Transmit power (radiated) Audio link: 10 mW ERP (Range Y1-3: 12 mW ERP) LD mode: 10 mW ERP BLE: max. 10 mW EIRP Dimensions (ø x l)50 x 268 mm (incl. MMD 835 microphone module) 40 x 200 mm (without micro- phone module) Weight (without bat- teries) approx. 304 g (incl. MMD 835 microphone module) approx. 195 g (without micro- phone module) EW-DX SK (Bodypack Transmitter) Input voltage2.0 - 4.35 V Input current< 300 mA Power supply2 AA batteries 1.5 V (alkali man- ganese) or BA 70 rechargeable battery pack Occupied bandwidth200 kHz Transmit power (radiated) Audio link: 10 mW ERP (Range Y1-3: 12 mW ERP) LD mode: 10 mW ERP BLE: max. 10 mW EIRP Dimensions63.5 x 85 x 20 mm (without antenna) Weight (without bat- teries) approx. 115 - 120 g (depending on socket type and antenna length) EW-D Power Supply (Model: S012DXM1200100) Input voltage100 - 240 V ~ Input frequency50 - 60 Hz Input current350 mA rms Output voltage12 V ⎓ Output current1000 mA Stand-by power consumption ≤ 100 mW @ 230 V ~ ≤ 100 mW @ 115 V ~ Operating temperature-10 °C to +55 °C (14 °F to 131 °F) Storage temperature-20 °C to +70 °C (-4 °F to 158 °F) Relative humidity5 to 95 %, non-condensing LICENSES The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Sennheiser electronic GmbH & Co.KG is under license. Other trademarks and tra- de names are those of their respective owners. DE Rahmenbedingungen und Einschränkungen für die Nutzung von Frequenzen In Ihrem Land gelten möglicherweise gesonderte Rahmenbedingungen und Einschränkungen für die Nutzung von Frequenzen. Informieren Sie sich vor der Inbetriebnahme des Produktes unter fol- gender Adresse: www.sennheiser.com/sifa Bestimmungsgemäßer Gebrauch Das Produkt darf gewerblich verwendet werden. Als nicht bestimmungsgemäßer Gebrauch gilt, wenn Sie das Produkt anders benutzen, als in der zugehörigen Bedienungsanleitung be- schrieben. Sennheiser übernimmt keine Haftung bei Missbrauch oder nicht ord- nungsgemäßem Gebrauch des Produkts sowie der Zusatzgeräte/Zu- behörteile. Vor Inbetriebnahme sind die jeweiligen länderspezifischen Vorschrif- ten zu beachten! Sennheiser haftet nicht für Schäden aus Verbindungsabbrüchen durch leere oder überalterte Akkus/Batterien oder Überschreiten des Sen- debereichs. Herstellererklärungen Garantie Sennheiser electronic GmbH & Co. KG übernimmt für diese Produkte eine Garantie von 24 Monaten. Die aktuell geltenden Garantiebedingungen können Sie über das In- ternet www.sennheiser.com oder Ihren Sennheiser-Partner beziehen. In Übereinstimmung mit den folgenden Anforde- rungen WEEE-Richtlinie (2012/19/EU) Batterierichtlinie (2006/66/EG & 2013/56/EU) Hinweise zur Entsorgung Das Symbol der durchgestrichenen Mülltonne auf dem Produkt, Batte- rie/Akku (falls zutreffend) und/oder der Verpackung weist Sie darauf hin, dass diese Produkte nicht über den normalen Hausmüll entsorgt werden dürfen, sondern am Ende ihrer Lebensdauer getrennt entsorgt werden müssen. Für die Verpackung beachten Sie die Abfalltrennung in Ihrem Land. Nicht sachgerechte Entsorgung von Verpackungsmate- rialien kann Ihre Gesundheit und die Umwelt schädigen. Die getrennte Sammlung von Elektro- und Elektronik-Altgeräten, Bat- terien/Akkus (falls zutreffend) und Verpackungen dient dazu, die Wie- derverwendung und das Recycling zu fördern und negative Auswirkun- gen auf Ihre Gesundheit und die Umwelt zu verhindern, z. B. durch potenziell gefährliche Stoffe, die in diesen Produkten enthalten sind. Führen Sie Elektro- und Elektronikgeräte und Batterien/Akkus am Ende ihrer Lebensdauer dem Recycling zu, um enthaltene Wertstoffe nutzbar zu machen und eine Vermüllung der Umwelt zu vermeiden. Wenn Batterien/Akkus zerstörungsfrei entnommen werden können, haben Sie die Pflicht, diese g…
Text truncated - open the document above for the full version.
Sennheiser electronic GmbH & Co. KG Am Labor 1, 30900 Wedemark, Germany www.sennheiser.com Printed in Germany Publ. 04/22, 587467/A01 Quick Guide Kurzanleitung Guide rapide Guida rapida Guía de inicio rápido Guia rápido Beknopte handleiding Krótka instrukcja obsługi Snabbguide Kort vejledning Pikaohje Γρήγορος οδηγός Kısa Kılavuz Краткая инструкция 快速指南 クイックガイド 퀵 가이드 Evolution Wireless Digital EW-DX EM 2 EW-DX SK EW-DX SKM EW-D Smart Assist Sennheiser Documentation App or online at www.sennheiser.com/download EW-DX Instruction Manual EW-DX EM 2 Remote controlIn the box Antennas Audio Out Power supply Battery Identify/Battery checkEW-DX SK | EW-DX SK 3-PIN EW-DX SKM-S | EW-DX SKM On/Off MUTESYNC KORCNUSUKAU EU 6.3 mmXLR-3 ≥ 0,5 m ≥ 1 m * * *optional accessories: ADP UHF (470 - 1075 MHz) AD 1800 (1400 - 2400 MHz) Wireless Systems Manager (WSM) www.sennheiser.com/wsm Sennheiser Control Cockpit (SCC) www.sennheiser.com/control-cockpit-software 2 AA batteriesBA 70 rechargeable battery 2 AA batteriesBA 70 rechargeable battery OROR SKSKM(-S) 23 1 1234 OR OR Antenna inputsAudio outputs Power supply PoE / Network control (WSM / SCC) SYNC SETUP DOWN ESC Display ON/OFFLED ch. 2Headphone volume control LED ch. 1 Channel 2 Channel 1 Headphone output DATA LED SYNC MUTE ON/OFF ESC DOWN SET UP LINK LED DATA LED SYNC ON/OFF LINK LED UP SET ESC DOWN MUTE (EW-DX SKM-S) Display Display Off -> OnEM SKM(-S) SK EM/SK/SKM(-S) shorton On -> Off EM/SK/SKM(-S) longoff Rack mount angles Power supply Power supply adapters * * EW-DX SK 3-PIN EW-DX SK 3.5 mm jack 3 pin socket EW-D Smart Assist App Display & MenuLEDs Mute Key Lock Sync Auto Setup MUTESYNC MUTESYNC MUTESYNC MUTESYNC EM 2 - - Link ok audio active - - No link Device switched off - No link - - Link ok audio muted or no capsule on SKM - - Link ok audio clip - - Link ok Low transmitter battery LINK LED (SK/SKM) LED Ch.1/2 (EM 2) Firmware update in progress Bluetooth active to - sync with transmitter - connect with app DATA LED (SK/SKM) LED Ch.1/2 (EM 2) Instruction Manual Instruction Manual SKM(-S) DATA LINK DATA LINK SK Radio frequency level and link quality (Channel 1) Radio frequency level and link quality (Channel 2) Transmitter audio level (Channel 1) Transmitter battery (Ch.1/Ch.2) Transmitter audio level (Channel 2) System Home Screen Frequency (Channel 1) Frequency (Channel 2) Link name (Channel 1) Link name (Channel 2) Radio frequency level and link quality Transmitter audio level Transmitter battery Audio settings Channel 1 Home ScreenChannel 2 Home Screen Frequency Link name Radio frequency level and link quality Transmitter audio level Transmitter battery Audio settings Frequency Link name short press select channel & set parameters short press short press SKM(-S)SK 3 21 OR Instruction manual | Bedienungsanleitung | Notice d'emploi | Istruzioni per l'uso | Instrucciones de manejo | Manual de instruções | Gebruiksaanwijzing | Instrukcja obsługi | Bruksanvisning | Betjenings vejledning | Käyttöohje | Οδηγίες λειτουργίας | Kullanım kılavuzu | Инструкция по эксплуатации | 使用说明书 | 取扱説明書 | 사용�설명서 | Sennheiser Documentation App EW-D Smart Assist SKM-SSK Mute Lock Instruction Manual Auto Lock Instruction Manual SKM | SKM-S 10 s
Document Version 1.1 2020-10-30 LONG-TERM CONFIDENTIALITY REQUEST for Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 TO WHOM IT M AY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request Long-Term Confidentiality for the following product: For the product stated above, we request Long-Term Confidentiality for exhibits which contain Block Diagram, Operational Description, Parts List/Tune Up Info, Schematics, SDR Software/Security Info. The above exhibits contain ou r trade secrets and proprietary information that could be of benefit to o ur competitors. This information will not be publicly available. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Company Name: Phone: Company Address: Fax: E-mail: Contact Name: Signature: Signature Date: Check your GC here. Click Grantee Search. FCC I D: Grantee Code Equipment Product Code
Document Version 1.1 2020-10-30 SHORT-TERM CONFIDENTIALITY REQUEST for Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request Short-Term Confidentiality for the following product: For the product stated above, we request Short-Term Confidentiality for exhibits which contain External Photos, Internal Photos, Test Setup Photos, User Manual. We request Short-Term Confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device which is planned for: We are aware that the Short-Term Confidentiality must be released when the product is marketed. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Company Name: Phone: Company Address: Fax: E-mail: Contact Name: Signature: Signature Date: Check your GC here. Click Grantee Search. FCC ID: Grantee Code Equipment Product Code
Annex A No.1-2867/21-01-16_Annex_A External photos of the Device Under Test This document is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorized: Hans-Joachim Wolsdorfer Lab Manager Radio Communications CTC advanced GmbHUntertuerkheimer Str. 6-10 66117 Saarbruecken / Germany Phone: +49 681 5 98 - 0 Fax: +49 681 5 98 - 9075 web: ctcadvanced.com e-mail: [email protected] Photos Annex A Photo 1 Photo 2 2022-09-07Document 1-2867/21-01-16_Annex_A2/6 Photo 3 Photo 4 2022-09-07Document 1-2867/21-01-16_Annex_A3/6 Photo 5 Photo 6 2022-09-07Document 1-2867/21-01-16_Annex_A4/6 Photo 7 Photo 8 2022-09-07Document 1-2867/21-01-16_Annex_A5/6 Photo 9 - END OF DOCUMENT - 2022-09-07Document 1-2867/21-01-16_Annex_A6/6
Annex B No.1-2868/21-01-16_Annex_B Internal photos of the Device Under Test This document is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorized: Hans-Joachim Wolsdorfer Lab Manager Radio Communications CTC advanced GmbHUntertuerkheimer Str. 6-10 66117 Saarbruecken / Germany Phone: +49 681 5 98 - 0 Fax: +49 681 5 98 - 9075 web: ctcadvanced.com e-mail: [email protected] Photos Annex B Photo 1 Photo 2 2022-09-07Document 1-2868/21-01-16_Annex_B2/6 Photo 3 Photo 4 2022-09-07Document 1-2868/21-01-16_Annex_B3/6 Photo 5 Photo 6 2022-09-07Document 1-2868/21-01-16_Annex_B4/6 Photo 7 Photo 8 2022-09-07Document 1-2868/21-01-16_Annex_B5/6 Photo 9 - END OF DOCUMENT - 2022-09-07Document 1-2868/21-01-16_Annex_B6/6
