DYY22102210 HF Radio System

RADIO COMMUNICATIONS Getting Started Guide Envoy™ Transceiver No part of this manual may be reproduced, transcribed, translated into any language or transmitted in any form whatsoever without the prior written consent of Codan Limited. © Copyright 2012–2013 Codan Limited. Codan part number 15-04177-EN Issue 3, June 2013. CODAN™, Envoy™, Easitalk™, and CALM™ are trademarks of Codan Limited. Other brand, product, and company names mentioned in this document are trademarks or registered trademarks of their respective holders. The English version takes precedence over any translated versions. TABLE OF CONTENTS ENVOY™ TRANSCEIVER GETTING STARTED GUIDEi Table of contents Section 1Introduction Overview of this guide . . . . . . . . . . . . . . . . . . . . 1 The 2220 Handset . . . . . . . . . . . . . . . . . . . . . . 3 The 2221 Handset . . . . . . . . . . . . . . . . . . . . . . 5 The 2230 Desk Console . . . . . . . . . . . . . . . . . . . 7 Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Accessing the CD . . . . . . . . . . . . . . . . . . . . . . . 11 Standards and icons . . . . . . . . . . . . . . . . . . . . . . 12 Section 2Using the wizard Overview of the wizard . . . . . . . . . . . . . . . . . . . . 14 Using the wizard . . . . . . . . . . . . . . . . . . . . . . . 16 Selecting a language . . . . . . . . . . . . . . . . . . . 17 Setting the time and date . . . . . . . . . . . . . . . . . 17 Setting the location of the desk console . . . . . . . . . 18 Adding a channel . . . . . . . . . . . . . . . . . . . . . 19 Entering a self address . . . . . . . . . . . . . . . . . . 21 Adding a contact . . . . . . . . . . . . . . . . . . . . . 22 Selecting an antenna . . . . . . . . . . . . . . . . . . . 29 Selecting a peripheral device . . . . . . . . . . . . . . . 30 Section 3Navigating the menu structure The basic menu structure . . . . . . . . . . . . . . . . . . . 32 Navigating the menu structure . . . . . . . . . . . . . . . . 34 Overview of basic and advanced views . . . . . . . . . . . 36 Basic view . . . . . . . . . . . . . . . . . . . . . . . . 36 TABLE OF CONTENTS iiENVOY™ TRANSCEIVER GETTING STARTED GUIDE Advanced view . . . . . . . . . . . . . . . . . . . . . 36 Switching between basic and advanced views . . . . . . 37 Finding a word or value . . . . . . . . . . . . . . . . . . . 38 Selecting an icon . . . . . . . . . . . . . . . . . . . . . . . 41 Selecting a function from the menu bar . . . . . . . . . . . 42 Entering text in a field . . . . . . . . . . . . . . . . . . . . 44 Entering special characters . . . . . . . . . . . . . . . 46 Entering text in the 2221 Handset . . . . . . . . . . . . 47 Selecting a value from a list . . . . . . . . . . . . . . . . . 49 Selecting/deselecting a check box . . . . . . . . . . . . . . 50 Moving a slider . . . . . . . . . . . . . . . . . . . . . . . . 51 Changing the order of items in a list . . . . . . . . . . . . . 52 Saving your changes . . . . . . . . . . . . . . . . . . . . . 53 Section 4Structure of information Structure of user information . . . . . . . . . . . . . . . . . 56 Structure of contact and call information . . . . . . . . . . 58 Section 5Operating the transceiver Switching the transceiver on and off . . . . . . . . . . . . . 60 Switching on the transceiver . . . . . . . . . . . . . . . 60 Switching off the transceiver . . . . . . . . . . . . . . . 60 The channel screen . . . . . . . . . . . . . . . . . . . . . 61 Selecting a channel . . . . . . . . . . . . . . . . . . . . 63 Scanning channels . . . . . . . . . . . . . . . . . . . . . . 65 Switching scanning on or off . . . . . . . . . . . . . . . 65 Pausing scanning . . . . . . . . . . . . . . . . . . . . . 66 Muting the transceiver . . . . . . . . . . . . . . . . . . . . 67 Switching mute on or off . . . . . . . . . . . . . . . . . 67 Selecting the mute type . . . . . . . . . . . . . . . . . . 67 Using the microphone . . . . . . . . . . . . . . . . . . . . 68 Setting the basics . . . . . . . . . . . . . . . . . . . . . . . 69 Setting the date and time . . . . . . . . . . . . . . . . . 69 Setting the brightness of the display . . . . . . . . . . . 70 Calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 Making a Selective call . . . . . . . . . . . . . . . . . . 71 Making a Message call . . . . . . . . . . . . . . . . . . 73 Making a call to a contact . . . . . . . . . . . . . . . . 76 Making a call from the Call History . . . . . . . . . . . 77 TABLE OF CONTENTS ENVOY™ TRANSCEIVER GETTING STARTED GUIDEiii Making a call from the Emergency key . . . . . . . . . 78 Using GPS . . . . . . . . . . . . . . . . . . . . . . . . . . 79 Viewing GPS information . . . . . . . . . . . . . . . . 79 Using encryption . . . . . . . . . . . . . . . . . . . . . . . 81 Switching the encryptor on or off . . . . . . . . . . . . . 81 Selecting a secure key . . . . . . . . . . . . . . . . . . 84 Adding a secure key . . . . . . . . . . . . . . . . . . . 85 Selecting the data rate . . . . . . . . . . . . . . . . . . . 86 Using a crosspatch . . . . . . . . . . . . . . . . . . . . . . 88 Overview of the 3031 Crosspatch . . . . . . . . . . . . 88 Changing the operating mode of the crosspatch . . . . . 90 Upgrading the transceiver via a USB stick . . . . . . . . . . 91 Section 6Contacts Adding a contact . . . . . . . . . . . . . . . . . . . . . . . 94 Adding a simple call . . . . . . . . . . . . . . . . . . . 96 Adding a Message call . . . . . . . . . . . . . . . . . . 97 Adding a Phone call . . . . . . . . . . . . . . . . . . . . 98 Adding a Get Status call . . . . . . . . . . . . . . . . . 99 Adding an RFDS Emergency call . . . . . . . . . . . 100 Completing the contact . . . . . . . . . . . . . . . . . 101 Adding a contact from the Call Log, Call History, or Last Heard Log . . . . . . . . . . . . . . . . . . . . . . . 102 Section 7Specifications Appendix AInstalling the transceiver Overview of mobile stations . . . . . . . . . . . . . . . . 108 Cables in a mobile station . . . .…

Text truncated - open the document above for the full version.

RADIO COMMUNICATIONS Reference Manual Envoy™ Transceiver No part of this manual may be reproduced, transcribed, translated into any language or transmitted in any form whatsoever without the prior written consent of Codan Limited. © Copyright 2012–2013 Codan Limited. Codan part number 15-04176-EN Issue 3, June 2013. CODAN™, Envoy™, Easitalk™, and CALM™ are trademarks of Codan Limited. Other brand, product, and company names mentioned in this document are trademarks or registered trademarks of their respective holders. The English version takes precedence over any translated versions. TABLE OF CONTENTS ENVOY™ TRANSCEIVER REFERENCE MANUALi Table of contents Section 1Introduction Standards and icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Section 2Using the wizard Overview of the wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Using the wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Selecting a language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 Setting the time and date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 Setting the location of the desk console . . . . . . . . . . . . . . . . . . . . . 10 Adding a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Entering a self address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Adding a contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Selecting an antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Selecting a peripheral device . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Section 3The Envoy™ Transceiver Overview of the Envoy™ Transceiver . . . . . . . . . . . . . . . . . . . . . . . 20 The 2220 Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 The 2221 Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 TABLE OF CONTENTS iiENVOY™ TRANSCEIVER REFERENCE MANUAL The 2230 Desk Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 The 2210 RFU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Section 4Navigating the menu structure Menu structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Navigating the menu structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Overview of basic and advanced views . . . . . . . . . . . . . . . . . . . . . . . 31 Basic view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Advanced view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Switching between basic and advanced views . . . . . . . . . . . . . . . . . . 32 Overview of user and admin levels . . . . . . . . . . . . . . . . . . . . . . . . . 33 User level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Admin level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Logging in to admin level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Logging out of admin level . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Finding a word or value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Selecting an icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Selecting a function from the menu bar . . . . . . . . . . . . . . . . . . . . . . . 39 Entering text in a field . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Entering special characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Entering text in the 2221 Handset . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Selecting a value from a list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 Selecting/deselecting a check box . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Moving a slider . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 Changing the order of items in a list . . . . . . . . . . . . . . . . . . . . . . . . . 47 Saving your changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Section 5Structure of information Structure of user information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Structure of contact and call information . . . . . . . . . . . . . . . . . . . . . . 51 Section 6Operating the transceiver Switching the transceiver on and off . . . . . . . . . . . . . . . . . . . . . . . . . 54 Switching on the transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Switching off the transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 The channel screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Selecting information to be shown in a status area . . . . . . . . . . . . . . . . 57 Selecting a theme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Scanning channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Switching scanning on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Pausing scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 Muting the transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 Switching mute on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 TABLE OF CONTENTS ENVOY™ TRANSCEIVER REFERENCE MANUALiii Selecting the mute type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64 Using the microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Manually tuning the antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 Selecting a language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67 Setting the date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 Setting the brightness of the d…

Text truncated - open the document above for the full version.

ENVOY™ TRANSCEIVER REFERENCE MANUAL245 17 Keys and macros This section contains the following topics: •Overview of the keypad and macros on page 246 •Keypad on page 247 •Macros on page 249 •Entries for a macro on page 250 •Working with macros on page 252 KEYS AND MACROS OVERVIEW OF THE KEYPAD AND MACROS 246ENVOY™ TRANSCEIVER REFERENCE MANUAL Overview of the keypad and macros Each control point for the Envoy™ Transceiver has a set of keys that are used to set up and operate the transceiver. The 2220 Handset and 2230 Desk Console have the Power and Emergency keys, and a full set of navigation and alphanumeric keys. The 2230 also has three dedicated function keys. The 2221 Handset has the Power and Emergency keys, and the navigation keys. These are used for operation in conjunction with extra menu options in the user interface. Figure 48:Power and Emergency keys Figure 49:Navigation keys Figure 50:Alphanumeric keys Figure 51:Function keys (desk console only) Each key may have more than one function. This function depends on your current location in the user interface of the control point, the length of time that you press it, and whether or not you press it in conjunction with another key. Some keys have a specific function (macro) assigned to them. This function is written in blue text on the key. A key with a macro assigned to it is called a hot key. The dedicated function keys on the desk console may be used at any location within the user interface. You can press a key briefly to perform the direct function, or you can hold a key for two seconds. Related links: Keypad on page 247 Macros on page 249 CALL SCAN OK 1 TUNE FUNC MODE FREE Rx SEC VS VIEW EASI TALK ABC DEF GHI JKL MNO PQRS TUV WXYZ 2 3 4 5 6 7 8 9 0 F1F2F3 KEYS AND MACROS KEYPAD ENVOY™ TRANSCEIVER REFERENCE MANUAL247 Keypad Standard macros are programmed in the transceiver in the factory. You can also create a macro and assign it to a hot key. Table 9:Keys and their function KeyFunction Switches on the transceiver. Switches off the transceiver (hold for 2 sec). Performs a hot-key sequence with another key (hold + key): • + 0 jumps to the Brightness screen • + 2 toggles advanced view • + 3 jumps to the Select Language screen (admin level) • + SEC performs secure erase Starts a chain call of all calls for the selected emergency contact (hold for 2 sec). PTTPress-to-talk. Cancels out of editing and calls before they are connected. Performs the function shown directly above the key in the menu bar of the screen. Scrolls left in a list of values. Moves the cursor/highlight to the left. Reduces the volume when the indicator is shown in the menu bar of the screen. Scrolls right in a list of values. Moves the cursor/highlight to the right. Increases the volume when the indicator is shown in the menu bar of the screen. Scrolls up in a list of entries. Moves the highlight up a row. Scrolls down in a list of entries. Moves the highlight down a row. OKEnters the submenu or list of entries represented by the selected icon. Toggles the selection of a check box. Enters the virtual keypad in the user interface of a 2221 Handset. CALLStarts the calling process by jumping to the call screen (default behaviour). Jumps to Contacts/Call History/Emergency Contacts/Last Heard Log (hold for 2 sec). KEYS AND MACROS KEYPAD 248ENVOY™ TRANSCEIVER REFERENCE MANUAL Related links: Macros on page 249 Free tune on page 265 Selecting the mute type on page 64 SCAN Toggles scanning on and off. Ends a call. Deletes the character to the left of the cursor. Deletes all characters (hold for 2 sec). 1 TUNEEnters 1 in character-entry mode. Tunes the antenna. 2 FUNCEnters 2, a, b, c, A, B, C in character-entry mode. Access the clarifier for the currently selected channel. 3 MODEEnters 3, d, e, f, D, E, F in character-entry mode. Selects the next allowed mode for the current channel. 4 FREE RxEnters 4, g, h, i, G, H, I in character-entry mode. Accesses the free-tune receive function. 5Enters 5, j, k, l, J, K, L in character-entry mode. Toggles the operating mode of a crosspatch, if connected. Shows the firmware version of a crosspatch, if connected (hold for 2 sec). 6Enters 6, m, n, o, M, N, O in character-entry mode. 7 V/SEnters 7, p, q, r, s, P, Q, R, S in character-entry mode. Toggles the type of mute selected. 8 SECEnters 8, t, u, v, T, U, V in character-entry mode. Toggles secure mode on and off. Enables you to enter a PIN for a secure session, or access secure information (hold for 2 sec). 9Enters 9, w, x, y, W, X, Y in character-entry mode. 0 VIEWEnters 0 or a space in character-entry mode. Toggles between the channel screen and Contacts/Call History. EASITALKEnters a special character (repeated press, or hold for 2 sec). Toggles Easitalk™ on or off. Toggles character-entry mode. Enables you to select the input language (hold for 2 sec). Table 9:Keys and their function (cont.) KeyFunction KEYS AND MACROS MACROS ENVOY™ TRANSCEIVER REFERENCE MANUAL249 Macros If you want to automate some of the tasks you perform with the transceiver you can create hot keys on the handset and desk console to perform the tasks for you. Each task is stored in a macro as a series of steps, and the macro is assigned to a hot key. Performing the tasks is then as simple as pressing or holding the hot key. The transceiver is supplied with a set of standard hot keys. These functions are labelled on the corresponding hot key in BLUE text. The descriptions of these standard hot keys are included in Table 9. The hot keys to which these macros are assigned cannot be moved at user level. The user can create hot keys when in advanced view. A macro can be assigned to the alphanumeric or keys. When the user interface is in character-entry mode, macros assigned to an alphanumeric key cannot be used, as the key is used to enter characters. If you want to be able to use a macro at any time, you should assign the macro to the key. Related links: Keypad on page 247 Advanced view on page 31 Switching betwe…

Text truncated - open the document above for the full version.

Extended Frequency Justification DATE 28 th May 2013 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: DYY2210 Product Name: 2210 HF Radio System Extended Frequency Justification Codan Limited requests that the FCC certify the entire 1.6 MHz to 30 MHz spectrum to include the Part 90 extended frequencies. This would be done to facilitate the requirements of agencies covered by under NTIA spectrum usage, who must purchase equipment from private industry manufacturers governed by the FCC rules. This conflict in spectrum allocation reduces the options available to these agencies for commercial off-the-shelf equipment. However, it is understood that to maintain compliance with the Part 90 rules, the 2210 HF Radio System only be programmed for the frequencies listed as allowable in the FCC Table of Frequency Allocations, 47 CFR § 2.106. Codan Limited acknowledges that the FCC Part 90 rules are violated if the 2110 HF Radio System transmits on unauthorised frequencies. To this end, the 2210 HF radio system is factory locked to transmit only on frequencies licensed to the user. The equipment can only be purchased through an authorised dealer who programs the channel frequencies to ensure this restriction is enforced. It is the user’s responsibility to obtain the appropriate licenses for use. The user is excluded from selecting unlicensed transmit frequencies. The user is made aware of these restrictions in the “Compliance” section of the supplied handbooks. Dated this 28th Day of May 20 13 By: Bruce Johnson Signature Printed Title: RF design Engineer On behalf of : Codan Limited Telephone: +618 8305 0311

DATE 12th April 2013 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: DYY2210 Product Name: 2210 HF Radio System Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operational Description  Parts List These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 12th Day of April 20 13 By: Bruce Johnson Signature Printed Title: RF design Engineer On behalf of : Codan Limited Telephone: +618 8305 0311

MATERIAL FINISH H G C D E F DIMENSIONS IN mm A B 12345 DO NOT SCALE 678 DRAWING/DOC NO. DATE TITLE 9101112 2 2 2:1 0.2 x 45
$R0.2 max SCALE 2013 DRN GS 29-02-2012 CHKD NJA16-04-2012 APPD NJA26-11-2012 A2 ESCUTCHEON, RF UNIT 2210 TOLERANCES UNLESS OTHERWISE SPECIFIED LINEAR
#0.2 ANGULAR
#0.5
$ ISS 06-02806 SHT. FLATNESS
#0.2 ROUGHNESS1.6 μmRa 5a OF ISSUE 2 REFER SH 1 ISSUE 3 REFER SH 1 ISSUE 4 REFER SH 1 ISSUE 5 REFER SH 1 6 H E F G C D A B 12345 MATERIAL FINISH DIMENSIONS IN mm DRAWING/DOC NO. DATE TITLE 5 5 DO NOT SCALE 789101112 1:1 CONFIDENTIAL The information contained herein is proprietary to Codan Limited, and is to be used by the recipient solely for the purpose for which it is supplied. Codan does not permit the recipient to copy, adapt, publish or disclose the information to third parties except as otherwise agreed with Codan in writing. CODAN LIMITED, ACN 007 590 605: C CODAN 0.2 x 45°R0.2 max SCALE 2012 DRN GS 07-06-2011 CHKD NJA 18-09-2012 APPD A1 RF UNIT FINAL ASSEMBLY 2210 TOLERANCES UNLESS OTHERWISE SPECIFIED LINEAR±0.2 ANGULAR±0.5° ISS 08-07175 SHT. FLATNESS±0.2 ROUGHNESS1.6 μmRa 1 OF QTYCPNDESCRIPTIONITEM 106-02811LABEL, COUNTRY OF MANUFACTURE1 260-90410-001JUMPER, 2 WAY OPEN TOP2 1enter CPNSCREEN RF/IF, SYN PCB3 106-02806ESCUTCHEON, RF UNIT5 106-02068LABEL, SERIAL/BARCODE7 208-07235COVER & GASKET ASSEMBLY9 1431-03010-582SCREW, M3X10 "TAPTITE 2: PAN POZI19 REFER NOTES, SH 1 STEP 8 ASSEMBLY OF ESCUTCHEON, & ASSEMBLY OF COVER & GASKET TO LOWER SIDE OF RF UNIT ASSEMBLY ALIGN & FIT LABEL TO REAR SIDE OF ESCUTCHEON CHASSIS UPPER SIDE STEP 9 ASSEMBLY OF COVER & GASKET TO LOWER SIDE OF RF UNIT ASSEMBLY CHASSIS LOWER SIDE 7 1 5 1 19 7 9 1 9 1 19 7

Safe Working Distance Page 1 of 6 Revision History Issue Comment Signed 1 First release NJA 9/2/2009 2 Expand average power and J2B justification, add extrapolation to 1.8metres BHJ 31/5/2013 Safe working distance measurements, with 9350 mobile and fixed antenna installations Equipment available : Electric field sensor ( Isotropic ) NATA traceable calibrated Holaday HI-4422 Probe HI-4416 Readout Safe-working standards (occupational) FCC 2.1091 : 1MHz – 3MHz : E = 614 V/m, 3MHz – 30MHz : E = (1842/f) V/m, ICNIRP 1998 : 1MHz – 10MHz : E = (600/f) V/m, 10MHz – 30MHz : E = 60V/m, Measurements for Mobile 9350 whip antenna installation: 1. The radiated V/m was measured at a distance of 1.5m from the antenna at a power level of 40 Watts CW to simulate continuous speech from the SSB Transceiver. (a) This gives us a safety factor of 2 as the normally accepted average heating power of voice is about 10-20% of the peak power. (This is measured using a thermal Wattmeter at the transceiver output, and is broadly in agreement with the typical crest factor (peak-to-average ratio) of normal speech, being 12dB, with about 3dB signal processing compression. Average speech power in this case is of the order of 1/8 peak power, or about 15W). (b) Regarding J2B (FSK) emissions, this type of emission is used for selective calling systems, and consists of a single nominal 11 second burst of RF transmission at 75W CW, initiated by the caller. Once the call is confirmed, the caller can commence normal speech communication. The averaged power over 6 minutes due only to the J2B emission is therefore about 2.5W. 2. The field strength was measured in a 180 degree arc around the antenna and no significant change in reading was noted (<10%). This was tested at several frequencies with the same results. Safe Working Distance Page 2 of 6 3. The measurements in the car where made at the point of highest reading assuming a person was in that position. This was directly in line with the antenna and the middle of the rear window. Measurements for Fixed (Base ) antenna installation: 1. This was carried out on a “Semi Delta “ fixed broadband antenna mounted above a metal roof. 2. This was measured at the feed end of the antenna at a distance of 1m with a power of 40 Watts CW. Safe Working Distance Page 3 of 6 Results Mobile 9350 whip antenna installation Freq (MHz) FCC Occ V/m Limit FCC Public V/m Limit V/m @ 1.5m Measured V/m in car Measured 2 614 412 230 16 3 614 274 168 4 460 206 124 12 5 368 165 114 6 307 137 104 8 230 103 68 14 10 184 82 60 12 153 69 48 14 132 59 42 24 16 115 51 34 18 102 46 28 20 92 41 22 14 22 83 37 24 24 76 34 22 26 71 32 20 4 28 65 29 14 30 61 27 14 FCC RF Exposure ( Mobile) 0 50 100 150 200 250 300 0102030 Freq MHz V/m FCC Occ V/m FCC Public V/m V/m @ 1.5m measured V/m in car measured Safe Working Distance Page 4 of 6 Outside Vehicle @ 1.5m Inside Vehicle at highest reading point Results Fixed antenna installation Freq ( MHz ) FCC Occ V/m Limit FCC Public V/m Limit V/m Fixed ant @ 1m Measured 2 614 412 18 3 614 274 4 460 206 28 5 368 165 6 307 137 30 8 230 103 26 10 184 82 26 12 153 69 14 132 59 18 16 115 51 18 102 46 28 20 92 41 22 83 37 28 24 76 34 26 71 32 14 28 65 29 30 61 27 10 Safe Working Distance Page 5 of 6 FCC RF Exposure (Fixed) 0 20 40 60 80 100 120 140 160 180 200 0102030 Freq MHz V/m FCC Occ V/m FCC Public V/m V/m Fixed ant @ 1m measured Photo of Semi-Delta fixed antenna ( Feed end ) Safe Working Distance Page 6 of 6 Conclusions 1. The requirements of FCC 2.1091 (occupational) are easily met at a distance of 1.5 metres from a typical Mobile antenna installation for all frequencies and possible average power levels from a 125wPEP Power Amplifier. 2. The requirements of FCC 2.1091 (occupational) are easily met at a distance of 2 metres from a typical Fixed antenna installation for all frequencies and possible average power levels from a 125w PEP Power Amplifier.. 3. Average exposure levels are significantly less with typical usage of transceiver systems using 125w PEP . 4. From the measurements the requirements for FCC 2.1091 (General Population / Uncontrolled Exposure) are also met at the distances we recommend. 5. The following table shows measured field strengths extrapolated to 1.8 metres to demonstrate compliance with RSS-102 (Controlled Use). Freq (MHz) RSS-102 controlled use V/m Limit V/m @ 1.5m Measured V/m @ 1.8m Calculated V/m in car Measured 2 300 230 192 16 3 200 168 140 4 150 124 103 12 5 120 114 95 6 100 104 87 8 75 68 57 14 10 60 60 50 12 60 48 40 14 60 42 35 24 16 60 34 28 18 60 28 23 20 60 22 18 14 22 60 24 20 24 60 22 18 26 60 20 17 4 28 60 14 12 30 60 14 12 Neil Abraham Engineering Design Manager 9 th Feb 2009

www.nemko.com Nemko Canada Inc., a testing laboratory, is accredited by the Standards Council of Canada. The tests included in this report are within the scope of this accreditation FCC 90 and RSS-125.docx; Date: May 2013 SCC Accredited LAB LAB Accrédité CCN TM ONE WORLDOURAPPROVAL Test report 231990-1TRFWL Date of issue: May 29, 2013 Applicant: Codan Limited Product: HF Radio System Model: 2210 FCC ID: IC Registration number: DYY2210 1029A-1 Specifications:  FCC 47 CFR Part 90 Private Land Mobile Radio Services  RSS-125, Issue 2 Land Mobile and Fixed Radio Transmitters and Receivers, 1.705 to 50.0 MHz, Primarily Amplitude Modulated Report reference ID: 231990-1TRFWL Page 2 of 31 Test location Nemko Canada Inc. 303 River Road Ottawa, ON, K1V 1H2 Canada Test site FCC ID: 176392 and IC ID: 2040A-4 (3 m semi anechoic chamber) Telephone +1 613 737 9680 Facsimile +1 613 737 9691 Toll free +1 800 563 6336 Website www.nemko.com Tested by Kevin Rose, Wireless/EMC Specialist Reviewed by May 29, 2013 Andrey Adelberg, Senior Wireless/EMC Specialist Date Limits of responsibility Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. All results contain in this report are within Nemko Canada’s ISO/IEC 17025 accreditation. Copyright notification Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. © Nemko Canada Inc. Report reference ID: 231990-1TRFWL Page 3 of 31 Table of Contents Section 1 Report summary ................................................................................................................................................................................. 4 1.1 Applicant ................................................................................................................................................................................................................................ 4 1.2 Manufacturer ........................................................................................................................................................................................................................ 4 1.3 Test specifications ................................................................................................................................................................................................................. 4 1.4 Statement of compliance ................................................................................................................................…
