DZO-OSREFRMG13PiQ RF Controller

production documentation iQ RF Controller User Manual Status: Draft Date 02/18/2020 1. Introduction: iQ RF Controller board is designed for Osram internal use only. To explain further, this RF controller board can be integrated into any Osram end products such as LED Lamp, Power Supply for LED, Electronic Ballast or Luminaires. However, this RF Controller board is NOT meant to be sold to third parties. Specification of this RF Controller board is presented in Table1. Table 1: RF Module specification Parameter Description Description iQ RF Controller PHY and MAC layers transceiver 2.4GHz IEEE 802.15.4-2003 Agency Approvals FCC, IC FCC # DZO-OSREFRMG13P IC# 23566-OSREFRMG13P HVIN# OSREFRMG13P 2. Warning Changes or modifications not expressly approved by R&D Director of Osram could void the user’s authority to operate this equipment. This is due to FCC or IC requirements. 3. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: − Reorient or relocate the receiving antenna. − Increase the separation between the equipment and receiver. − Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. − Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. production documentation iQ RF Controller User Manual Status: Draft Date 02/18/2020 4. Industry Canada Statement This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. WARNING! This module is to be installed only in OSRAM end products by their personnel, and shall not be offered to 3rd party OEM integrators or the general public. This RF Module has been certified for integration into products without further testing or certification. However, OSRAM is still responsible for testing their end-product for any additional compliance requirements required with this module installed (such as digital device emissions, PC peripheral requirements, etc.). 5. End Product Labeling Requirements The following statement shall be placed in the manual of the end product as this RF Controller board is considered extremely small (~8 x 10cm). “This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.” « Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement « . The final end product must be labeled in a visible area with the following: “Contains Transmitter Module FCC ID: DZO-OSREFRMG13P (IC: 23566-OSREFRMG13P)” OR “Contains FCC ID: DZO-OSREFRMG13P (IC: 23566-OSREFRMG13P)” or similar wording.” production documentation iQ RF Controller User Manual Status: Draft Date 02/18/2020 6. End Product User Manual Requirements • The user manual for the end product must include the following information in a prominent location: “To comply with FCC and Industry Canada RF radiation exposure limits for general population/uncontrolled exposure, the antenna(s) used for this transmitter must be installed such that a minimum separation d…

Text truncated - open the document above for the full version.

Top Side - Internal Bottom Side - Internal

Top Side - Internal Bottom Side - Internal

FCC ID: XYZ123 DZO- OSREFRMG13P Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at the antenna terminal: 11.37(dBm) Maximum peak output power at the antenna terminal: 13.70881766(mW) Antenna gain(typical):0.63(dBi) Maximum antenna gain:1.156112242(numeric) Prediction distance: 20(cm) Prediction frequency:2450(MHz) MPE limit for uncontrolled exposure at prediction frequency:1(mW/cm^2) Power density at prediction frequency:0.003153(mW/cm^2) Therefore device complies with FCC RF radiation exposure limits for general population in mobile exposure category (distance > 20cm) 2 4R PG S π =

FCC ID: XYZ123 DZO- OSREFRMG13P Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at the antenna terminal: 11.67(dBm) Maximum peak output power at the antenna terminal: 14.68926278(mW) Antenna gain(typical):0.63(dBi) Maximum antenna gain:1.156112242(numeric) Prediction distance: 20(cm) Prediction frequency:2450(MHz) MPE limit for uncontrolled exposure at prediction frequency:1(mW/cm^2) Power density at prediction frequency:0.003379(mW/cm^2) Therefore device complies with FCC RF radiation exposure limits for general population in mobile exposure category (distance > 20cm) 2 4R PG S π =

Bureau Veritas Consumer Products Services Inc.is accredited by the American Association for Laboratory Accreditation for the specific scope of accreditation under Certificate Number 1627-01. This report may contain data which is not covered by the A2LA accreditation. ____________________________________________________________ Bureau Veritas Consumer Products Services Inc. One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 1 of 35 Test Report Bureau Veritas Consumer Products Services Inc. Report No EU0026- 1 Client OSRAM SYLVANIA INC. Address 200 Ballardvale Street Wilmington, MA 01887 Phone 978-750-3865 Items tested iQ RF Controller FCC ID IC DZO-OSREFRMG13P 23566-OSREFRMG13P FRN 0021513163 Equipment Type Digital Transmission System Equipment Code Emission Designator DTS 2M26G1D FCC/IC Rule Parts CFR Title 47 FCC Part 15.247, RSS-247 Issue 2 Test Dates January 20 – 29, 2020 Results As detailed within this report Prepared by Landu Nsalambi – EMC Engineer Authorized by Anna Vancheva – EMC Wireless Engineer Issue Date 1/29/2020 Conditions of Issue This Test Report is issued subject to the conditions stated in the ‘Conditions of Testing’ section on page 31 of this report. Test Report for OSRAM SYLVANIA INC.  Report No. EU0026-1 January 29, 2020 ______________________________________________________________________ ____________________________________________________________ Bureau Veritas Consumer Products Services Inc. One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 2 of 35 Contents Contents .................................................................................................................................... 2 Summary ................................................................................................................................... 3 Test Methodology ...................................................................................................................... 4 Product Tested - Configuration Documentation ........................................................................ 5 Statement of Conformity ............................................................................................................ 6 Modifications Required for Compliance ..................................................................................... 6 Test Results .............................................................................................................................. 7 DTS (6dB) Bandwidth ............................................................................................................ 7 99% Occupied Bandwidth ...................................................................................................... 9 Peak Output Power .............................................................................................................. 11 Peak Power Spectral Density .............................................................................................. 13 Conducted Bandedges ........................................................................................................ 15 Conducted Spurious Emissions ......................................................................................... 117 Radiated Bandedges ........................................................................................................... 20 Radiated Spurious Emissions .............................................................................................. 21 AC Line Conducted Emissions ................................................................................................ 29 Measurement Uncertainty ....................................................................................................... 32 Conditions of Testing ............................................................................................................... 33 Test Report for OSRAM SYLVANIA INC.  Report No. EU0026-1 January 29, 2020 ______________________________________________________________________ _____________________________________________________________ Bureau Veritas Consumer Products Services Inc. One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 3 of 35 Summary This test report supports an application for certification of a transmitter operating pursuant to CFR Title 47 FCC Part 15.247, ISED Canada RSS-247 Issue 2. The EUT is iQ RF Controller (Model: OSREFRMG13P). This is a radio that can support dual protocols i.e., Zigbee and Bluetooth Low Energy (BLE). Zigbee operates in the 2405 – 2480MHz frequency. BLE radio operates in the 2402 – 2480MHz frequency range with DTS equipment code. Client declares that time division multiplexing is used between the Zigbee and BLE functions of the device. Therefore there’s no simultaneous transmission capability between Zigbee and BLE. This module is to be used within OSRAM products i.e., not authorized to be sold to third parties. The approved module will be used in several lighting products of OSRAM. Antenna: Internal PCB trace antenna with max 0.63dBi gain. We found that the product met the above requirements without modification. Test samples were received in good condition. Test Report for OSRAM SYLVANIA INC.  Report No. EU0026-1 January 29, 2020 ______________________________________________________________________ _____________________________________________________________ Bureau Veritas Consumer Products Services Inc. One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 4 of 35 Test Methodology All testing was performed according to the following rules/procedures/documents: CFR Title 47 FCC Part 15.247, ISED Canada RSS-247 Issue 2, ISED Canada RSS-Gen Issue 5, FCC KDB 558074 D01 15.247 Measurement Guidance v05r02 and ANSI C63.10-2013. Radiated emissions were measured by rotating the device around thr…

Text truncated - open the document above for the full version.

Bureau Veritas Consumer Products Services Inc.is accredited by the American Association for Laboratory Accreditation for the specific scope of accreditation under Certificate Number 1627-01. This report may contain data which is not covered by the A2LA accreditation. ____________________________________________________________ Bureau Veritas Consumer Products Services Inc. One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 1 of 34 Test Report Bureau Veritas Consumer Products Services Inc. Report No EU0026-2 Client OSRAM SYLVANIA INC. Address 200 Ballardvale Street Wilmington, MA 01887 Phone 978-750-3865 Items tested iQ RF Controller FCC ID IC DZO-OSREFRMG13P 23566-OSREFRMG13P FRN 0021513163 Equipment Type Digital Transmission System Equipment Code Emission Designator DTS 1M04F1D FCC/IC Rule Parts CFR Title 47 FCC Part 15.247, RSS-247 Issue 2 Test Dates January 20 – 29, 2020 Results As detailed within this report Prepared by Landu Nsalambi – EMC Engineer Authorized by Anna Vancheva – EMC Wireless Engineer Issue Date 1/29/2020 Conditions of Issue This Test Report is issued subject to the conditions stated in the ‘Conditions of Testing’ section on page 31 of this report. Test Report for OSRAM SYLVANIA INC.  Report No. EU0026-2 January 29, 2020 ______________________________________________________________________ ____________________________________________________________ Bureau Veritas Consumer Products Services Inc. One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 2 of 34 Contents Contents .................................................................................................................................. 2 Summary ................................................................................................................................. 3 Test Methodology .................................................................................................................... 4 Product Tested - Configuration Documentation ....................................................................... 5 Statement of Conformity .......................................................................................................... 6 Modifications Required for Compliance ................................................................................... 6 Test Results ............................................................................................................................ 7 DTS (6dB) Bandwidth .......................................................................................................... 7 99% Occupied Bandwidth .................................................................................................... 9 Peak Output Power ............................................................................................................ 11 Peak Power Spectral Density ............................................................................................. 13 Conducted Bandedges....................................................................................................... 15 Conducted Spurious Emissions ......................................................................................... 17 Radiated Bandedges ......................................................................................................... 20 Radiated Spurious Emissions ............................................................................................ 21 AC Line Conducted Emissions .............................................................................................. 29 Measurement Uncertainty...................................................................................................... 32 Conditions of Testing ............................................................................................................. 33 Test Report for OSRAM SYLVANIA INC.  Report No. EU0026-2 January29, 2020 ______________________________________________________________________ _____________________________________________________________ Bureau Veritas Consumer Products Services Inc. One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 3 of 34 Summary This test report supports an application for certification of a transmitter operating pursuant to CFR Title 47 FCC Part 15.247, ISED Canada RSS-247 Issue 2. The EUT is iQ RF Controller (Model: OSREFRMG13P). This is a radio that can support dual protocols i.e., Zigbee and Bluetooth Low Energy (BLE). Zigbee operates in the 2405 – 2480MHz frequency. BLE radio operates in the 2402 – 2480MHz frequency range with DTS equipment code. Client declares that time division multiplexing is used between the Zigbee and BLE functions of the device. Therefore there’s no simultaneous transmission capability between Zigbee and BLE. Antenna: Internal PCB trace antenna with max 0.63dBi gain. We found that the product met the above requirements without modification. Test samples were received in good condition. Test Report for OSRAM SYLVANIA INC.  Report No. EU0026-2 January29, 2020 ______________________________________________________________________ _____________________________________________________________ Bureau Veritas Consumer Products Services Inc. One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 4 of 34 Test Methodology All testing was performed according to the following rules/procedures/documents: CFR Title 47 FCC Part 15.247, ISED Canada RSS-247 Issue 2, ISED Canada RSS-Gen Issue 5, FCC KDB 558074 D01 15.247 Measurement Guidance v05r02 and ANSI C63.10-2013. Radiated emissions were measured by rotating the device around three orthogonal planes, as well as varying the test antenna’s height and polarity. Worst case results are presented in this report. AC line conducted emissions testing was performed with a 50Ω/50μH LISN. EUT …

Text truncated - open the document above for the full version.

FCC ID: DZO-OSREFRMG13P IC: 23566-OSREFRMG13P 30MHz-1GHz 1-6GHz FCC ID: DZO-OSREFRMG13P IC: 23566-OSREFRMG13P 6-18GHz 18-25GHz FCC ID: DZO-OSREFRMG13P IC: 23566-OSREFRMG13P AC Line Conducted FCC ID: DZO-OSREFRMG13P IC: 23566-OSREFRMG13P Antenna Port
