E4E6CYAIDV7000100RF-ID System

Our reference : 17F0050-02-1 FCC ID: E4E6CYAIDV7000100 Page: 2 of 17 Issued date: 98-07-23 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken, 516-1106 JAPANFacsimile:+81 596 39 0232 Table of Contents Page 1 GENERAL INFORMATION3 1.1 Tested Methodology4 1.2 Tested Facility4 2 PRODUCT DESCRIPTION5 3 TESTED SYSTEM DETAILS6 4 SYSTEM TEST CONFIGURATION7 4.1 Justification7 4.2 Test Procedure7 Figure 4.2 Configuration of Tested System8 5 RADIATED MEASUREMENT PHOTOS10 Figure 5.1 Radiated Measurement Photos (V700-HMC71)10 Figure 5.2 Radiated Measurement Photos (V700-HMC73)11 Figure 5.3 Radiated Measurement Photos (V700-HMD11)12 5.1 Measurement Uncertainty13 6 RADIATED EMISSION DATA14 6.1 Field Strength Calculation15 7 TEST EQUIPMENT16 APPENDIX17 Test Data A1 - A12 Our reference : 17F0050-02-1 FCC ID: E4E6CYAIDV7000100 Page: 3 of 17 Issued date: 98-07-23 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken, 516-1106 JAPANFacsimile:+81 596 39 0232 1 GENERAL INFORMATION APPLICANT: OMRON Corporation REGULATION(S): FCC Part 15 Subpart B/C MODEL NUMBER: V700-HMC71/V700-HMC73 : V700-HMD11 SERIAL NUMBER: 81 KIND OF EQUIPMENT: RF-ID System TESTED DATE: July 10, 1998 REPORT FILE NUMBER: 17F0050-02 TEST SITE: A-PEX Yokowa NO.2 Open Test Site Our reference : 17F0050-02-1 FCC ID: E4E6CYAIDV7000100 Page: 4 of 17 Issued date: 98-07-23 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken, 516-1106 JAPANFacsimile:+81 596 39 0232 1.1 Tested Methodology Radiated testing were performed according to the procedures in FCC/ANSI C63.4(1992). Radiated testing was performed at a distance of 3 meters from the antenna to EUT . 1.2 Test Facility The open area site measurement facility used to collect the radiated data is located on 108, Yokowa-cho, Ise-shi, Mie-ken, 516-1106 Japan. This site has been fully described in a report dated May. 27, 1997 submitted to FCC office, and accepted in a letter dated Aug. 18, 1997 (31040/SIT 1300F2). Our reference : 17F0050-02-1 FCC ID: E4E6CYAIDV7000100 Page: 5 of 17 Issued date: 98-07-23 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken, 516-1106 JAPANFacsimile:+81 596 39 0232 2 Product Description OMRON Corporation Model: V700-HMC71/V700-HMC73/ V700-HMD11 (referred to as the EUT in this report) is a Electromagnetic Inductive RF-ID System with a 125-kHz-band Carrier. The specification is as following : The clock used: 125 kHz (Carrier frequency) : 8 MHz (CPU clock) Input voltage: DC 5V , +10% (V700-HMC71/V700-HMC73) : DC 5V , +5% (V700-HMD11) Our reference : 17F0050-02-1 FCC ID: E4E6CYAIDV7000100 Page: 6 of 17 Issued date: 98-07-23 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken, 516-1106 JAPANFacsimile:+81 596 39 0232 3 Tested System Details The FCC IDs for all equipment, plus description of all cables used in the tested system are: Model FCC ID Description Cable description (1) OMRON-Read/write moduleFlat Cable/ Unshielded M/N: V700-HMC71 S/N: 81 (EUT) (2) OMRON-Read/write moduleFlat Cable/ Unshielded M/N: V700-HMC73 S/N: 81 (EUT) (3) OMRON-Read/write moduleSignal Cable/ Shielded M/N: V700-HMD11 S/N: 81 (EUT) (4) Hewlett Packard-Personal ComputerRS232C Cable/ Shielded M/N: HP 200LX S/N: S (5) OMRONCorp.-Power Supply FG Cable/ Shielded M/N: S82S-0705 AC PS Cable/ Unshielded S/N: 25670K (6) OMRONCorp.-AC Adapter 1DC PS Cable/ Unshielded M/N: V600-A20 S/N: 971291D (7) OMRONCorp.-Level ConverterDC PS Cable/ Unshielded M/N: - S/N: 1 (8) OMRONCorp.-ID Tag - M/N: D21P31 S/N: 30 (9) Hewlett Packard-AC Adapter 2DC Power Cable/ Unshielded M/N: HP F1011A S/N: TH734018067 Our reference : 17F0050-02-1 FCC ID: E4E6CYAIDV7000100 Page: 7 of 17 Issued date: 98-07-23 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken, 516-1106 JAPANFacsimile:+81 596 39 0232 4 SYSTEM TEST CONFIGURATION 4.1 Justification The measurement was performed with the system configuration shown in Figure 4.2. Running mode was taken for the EUT operation mode. 4.2 Test Procedure Tabletop Equipment Radiated Emissions EUT was placed on a platform of nominal size, 1m by 1.5m, raised 80cm above the conducting ground plane. Test was made with the antenna positioned in both the horizontal and vertical planes of polarization. The measurement antenna was varied in height above the conducting ground plane to obtain the maximum signal strength. Our reference : 17F0050-02-1 FCC ID: E4E6CYAIDV7000100 Page: 8 of 17 Issued date: 98-07-23 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken, 516-1106 JAPANFacsimile:+81 596 39 0232 Figure 4.2 Configuration of Tested System Front View 1.V700-HMC71, HMC73 (5) (4) (9) (7) FG AC PS Cable Unshielded 1.5m DC PS Cable Unshielded 1.0m RS232C Cable Shielded 1.5m FG Cable Unshielded 2.0m Flat Cable Unshielded 0.3m : Ferrite core AC 120V / 60Hz AC 120V / 60Hz DC PS Cable Shielded 2.0m (8) EUT: (1) or (2) 2 turn 2.V700-HMD11 (4) (9) DC PS Cable Unshielded 1.7m RS232C Cable Shielded 1.5m DC PS Cable Unshielded 2.0m Signal Cable Shielded 0.3m : Ferrite core (6) AC 120V / 60Hz (8) EUT: (3) AC 100V / 60Hz 2 turn * Cabling was taken into consideration and test data was taken under worse case conditions. Our reference : 17F0050-02-1 FCC ID: E4E6CYAIDV7000100 Page: 9 of 17 Issued date: 98-07-23 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken, 516-1106 JAPANFacsimile:+81 596 39 0232 Top View 1.V700-HMC71, HMC73 (5) (4) (9) (7) FG AC PS Cable Unshielded 1.5m DC PS Cable Unshielded 1.0m RS232C Cable Shielded 1.5m DC PS Cable Shielded 2.0m FG Cable Unshielded 2.0m Flat Cable Unshielded 0.3m : Ferrite core AC 120V / 60HzAC 120V / 60Hz (8) EUT: (1) or (2) 2.V700-HMD11 (4) D…

Text truncated - open the document above for the full version.
