E4EG8D-443H-AKeyless Entry System Transmitter

Test report FCC ID : E4EG8D-443H-A Our reference : 18F0063-02-1 Page: 2 of 13 Issued date: 99-07-16 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 Table of Contents Page 1 GENERAL INFORMATION3 1.1 Tested Methodology4 1.2 Test Facility4 2 PRODUCT DESCRIPTION5 3 TESTED SYSTEM DETAILS5 4 SYSTEM TEST CONFIGURATION6 4.1 Justification6 4.2 Test Procedure6 Figure 4.2 Configuration of Tested System7 5 RADIATED MEASUREMENT PHOTOS8 Figure 5.1 Radiated Measurement Photos8 5.1 Measurement Uncertainty9 6 RADIATED EMISSION DATA10 6.1 Field Strength Calculation11 7 TEST EQUIPMENT USED12 APPENDIX13 Test Data A1 - A3 Test report FCC ID : E4EG8D-443H-A Our reference : 18F0063-02-1 Page: 3 of 13 Issued date: 99-07-16 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 1 GENERAL INFORMATION APPLICANT: OMRON Corporation ADDRESS: 1-501, Yashirogaoka, Meito-ku, Nagoya-city Aichi, 465-0051 Japan Tel: +81-52-704-2525 Fax: +81-52-704-2769 REGULATION(S): FCC Part 15 Subpart C MODEL NUMBER: G8D-443H-A SERIAL NUMBER: - KIND OF EQUIPMENT: Keyless Entry System (Transmitter) TESTED DATE: July 7, 1999 RECEIPT DATE OF SAMPLE : June 26, 1999 REPORT FILE NUMBER: 18F0063-02-1 TEST SITE: A-PEX Yokowa NO.3 Open Test Site Test report FCC ID : E4EG8D-443H-A Our reference : 18F0063-02-1 Page: 4 of 13 Issued date: 99-07-16 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 1.1 Tested Methodology Radiated testing were performed according to the procedures in FCC/ANSI C63.4(1992). Radiated testing was performed at a distance of 3 meters from the antenna to EUT . 1.2 Test Facility The open area site measurement facility used to collect the radiated data is located on 108, Yokowa-cho, Ise-shi, Mie-ken, 516-1106 Japan. This site has been fully described in a report dated Aug. 1, 1997 submitted to FCC office, and listed dated Sep. 16, 1997 (31040/SIT 1300F2) and accepted Feb. 19, 1998 (IC2973-3) by Industry Canada. Test report FCC ID : E4EG8D-443H-A Our reference : 18F0063-02-1 Page: 5 of 13 Issued date: 99-07-16 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 2 Product Description OMRON Corporation, Model G8D-443H-A (referred to as the EUT in this report) is a Keyless Entry System (Transmitter). The specification is as following : Operation Frequency: 4.19MHz Carrier Frequency : 307.9MHz Operation Voltage: DC 3V, 20mA (Battery) 3 Tested Equipment Details The FCC IDs for all equipment, plus description of all cables used in the tested system are: Model FCC ID Description Cable description Backshell Material (1) OMRONE4EG8D-443H-AKeyless Entry System - - M/N: G8D-443H-A (Transmitter) S/N: - (EUT) Test report FCC ID : E4EG8D-443H-A Our reference : 18F0063-02-1 Page: 6 of 13 Issued date: 99-07-16 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 4 SYSTEM TEST CONFIGURATION 4.1 Justification The measurement was performed with the system configuration shown in Figure 4.2. Running mode was taken for the EUT operation mode. 4.2 Test Procedure Tabletop Equipment Radiated Emissions EUT was placed on a platform of nominal size, 1m by 1.0m, raised 80cm above the conducting ground plane. Test was made with the antenna positioned in both the horizontal and vertical planes of polarization. The measurement antenna was varied in height above the conducting ground plane to obtain the maximum signal strength. Test report FCC ID : E4EG8D-443H-A Our reference : 18F0063-02-1 Page: 7 of 13 Issued date: 99-07-16 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 Figure 4.2 Configuration of Tested System Front View (1) Top View (1) Test report FCC ID : E4EG8D-443H-A Our reference : 18F0063-02-1 Page: 9 of 13 Issued date: 99-07-16 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 5.1 Measurement Uncertainty Radiated Emission Test The measurement uncertainty (with a 95% confidence level) for this test was +3.3dB. The data listed in this test report may exceed the test limit because it does not have enough margin (more that 3.3dB). Test report FCC ID : E4EG8D-443H-A Our reference : 18F0063-02-1 Page: 10 of 13 Issued date: 99-07-16 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 6 RADIATED EMISSION DATA The initial step in collecting radiated data was a spectrum analyzer peak scan of the measurement range (30MHz-3100MHz). The final data was reported in the worst-case emissions. The minimum margin to the limit is as follows : * 30MHz - 1000MHz : QP Detect *1000MHz - 3100MHz : PK Detect ReceiverCorrectionField FrequencyReadingFactorStrengthLimitMargin (GHz)(dBuV)(dBuV)(dBuV/m)(dBuV/m)(dBuV) 615.7347.9 4.352.2 55.1 2.9 The Fundamental Frequency of this equipment is 307.9MHz. The peak of output level of fundamental frequency was confirmed at the 307.9MHz by perfarming the meaurement. It was corroborated that equipment was within of the tolerance which is prescribed in the FCC requlation Part 15 Subpart C sec. 15.231 (c). Since the fundamental frequency is 307.9MHz, the upper limit could be 308.6 MHz and lower limit could be 307.2MHz. The measurement result was 308.1MHz when the limit was 308.6MHz and also another measurement result was 307.6 MHz when the limit was 307.2MHz. Any spurious emissions did not detect except fundamental frequency’s spurious. Test report FCC ID : E4EG8D-443H-A Our reference : 1…
