E9601110Motorola Scriptor Jazz 200

Thank you for choosing the Motorola Scriptor® Jazz 200 . This Synthesized 2-Line alphanumeric FLEX TM pager has been developed using Motorola’s trademarked FLEX technology. The result? A technologically advanced yet user-friendly pager that will give you years ofreliable service.The Pager is a dynamic communication tool used by over 150 million people around the world. It is the smallest , lightest communication tool available. With its fixed monthly subscription and low battery usage , the pager is the most economical communication tool available. Over the years, paging utility hasincreased from receiving numbers to text messages & more. To ensure a full understanding of how the Scriptor® Jazz 200 works, please read this User’s Guide carefully. PAGERS ,QGH[ * : Indicates Operator Dependent You are here Get StartFeatures. .............. 1 Buttons, Backlight. .............. 2 FunctionsTurn ON, Turn OFF. .............. 3 Function Menu .............. 4 Alerts. .............. 5 Melody alert. .............. 6 Time/Date, Alarm. .............. 7 Msg read mode. .............. 8 Manual area, Battery level. ..............9 Screen contrast, Pager control. ............ 10 MessagesPersonal folder. ............ 11 Receiving messages. ............12 Personal folder function menu. ............. 13 Missed message * , Mail. .... 14 Mail (contd.) ............ 15 Mail folder function menu. ............16 Notebook. ............17 Notebook folder function menu. MaintenanceBattery info...18 Install/replace battery, Pager care...19 Repair/Maint, Symbols ............20 *HWWLQJ6WDUWHG Pager FeaturesThe Motorola Scriptor® Jazz 200 offers a wide range of useful features.• 2-Line, 18 English character screen or 1-Line, 14 English character screen, depending on paging operators • up to 30 personal messages• up to 15 mail messages (5 history/slot)•2 alarms• 5 user selectable pleasing alerts, 2 user programmable advanced melodies• Vibrator alert and vibracall• 3 speed scrolling of message• Message security by storing in Notebook• GPS Flex time, if applicable • Real time clock• Backlight display for ease of reading in dark. (Symbols and characters that are blinking on the pager display screen are shown in grey (e.g. ) in this User’s Guide.) Function ButtonsBacklightPress and hold * for 2 seconds to turn on your pager’s backlight. Press * for 2 seconds to turn off the backlight manually. Function Read/OnSelect Button 1. 2. 3. 1. 3. 2. 1. 2. 3. ButtonButton 1. 2. 3. )XQFWLRQ'HWDLOV Pager ON• Press and hold ( for 2 second to turn on your pager. The status screen is dis- played.  * indicates ‘Area Index’ (1 to 10) applicable when more than one areas are programmed. The pager returns to the standby screen after the time out period, & is displayed at the top left hand corner. Pager OFF• Press * to go to Function Menu screen. • Press ) to select TURN OFF function. • The “TURN OFF ?” is displayed in the function screen.• Press * again to confirm turning your pager off. )XQFWLRQ0HQX •Press * to enter the Function Menu screen from the status screen. • Press ) to move to the next Function Menu icon. •Press * to enter the current selected function sub-menu (function-setting mode). Alert Mode• Press ) to advance the different alert modes; from silent to sleep, vibra-call, chirp, and pleasing alert 1 to 5, A, B. • Press * to confirm your selection. The alert status is updated in the status screen as below. $ Audio : pleasing alert and chirp. # Silent : vibration. & Sleep : pager receives message but no alert. % Vibra-call : vibration follows by audio alert. Compose Melody AlertYou can program 2 melody (“A”,”B”) of your own as one of the alert tone.* :to advance melody “A” to “B”; melody note (ABCDEFG, abcdefg,’_’). ) :to advance cursor position. ( :to return to Alert Function screen. •Press * to enter the user-compose screen when the cursor is on “P” in Alert Function screen. • After completing the programming of the melody, press ( to return to Alert Function screen, confirm the melody for “A” or for “B”. Press * to confirm the setting. Time and D ate • Press * to choose the day of month. • Press ) to highlight the month field then press * to choose the value. • Repeat the steps to choose the value of year, hour, minute and AM/PM fields.• Press ( to update your setting and return to the status screen.  Time-date setting is disabled if “GPS” time update” is turned on. Alarm• Press * to select Alarm “1” OR “2”. • Press ) to move to the alarm icon field. • Press * to switch from H (Alarm OFF) to M (Alarm ON). • Press ) to move to the time field. • When alarm is turned ON, press * to change the fields (hour, minute) so that your pager alerts. • Press ( to update your setting. Message Read Mode• b “Page by page read mode” appears in the screen, press * to select G “Horizontal text scrolling”. • Press ) to highlight the speed field. • Press * to change the scroll speed, “MEDIUM”, “SLOW” OR “FAST”. • Press ( to confirm your setting. Printed In Singapore 09/99 1 2 3 4 5 6 7 8 ScrpJz200 (NP3) 7J89b (Sep99).fm Page 1 Tuesday, November 2, 1999 3:51 PM Manual Area Selection(provided more than one areas are programmed)• When you enter this mode, “Area 1” (an area name, if programmed) is displayed.• Press ) to move to the next area. • Press ( to select the area you wish to receive messages, e.g. Taipei which has an area index “3”. Battery Level• When the cursor is on the Battery icon in the Function menu screen, the battery level indicator is displayed. • If a bar is left, this indicates a low battery condition. Screen Contrast• Press ) to change the level of contrast of your paper screen. • Press * to confirm and to return to status screen. Pager Control• “UNREAD REMINDER” appears, press * to switch ON. • Press ) to more to the next control. • Press * to enter the selected control setting screen. (i) “UNREAD REMINDER” - ON : unread message reminder, alerts at 2-minute interval . (ii) “LOW CELL REMINDER” - ON : low battery condition, hourly…

Text truncated - open the document above for the full version.

1-14January 29, 19996802907J13 GENERALProduct Families 15D/30C Decoder The microcomputer controls the receiver circuits, powering them up and down at the proper time intervals, decodes the binary information received, stores the received message in external RAM and generates the alert tones. It also processes user inputs from the keypad and generates the display screen. The linear support module provides boosted dc voltage to all decoder circuits, monitors battery conditions and drives the lamp, speaker, and vibrator motor. Figure 1-2. Pager Functional Block Diagram Antenna Cascode RF Amp SAW Filter 1st Mixer Nova PLL 21.4MHz Crystal Filter 455kHz Ceramic Filter TOSHIBA 31149 4-Level FSK Quad Detector FSK Comparator 2nd Mixer 2nd LO B+ Reg. B+ Reg1.5V 76.8kHz Decoder 38.4kHz 1.5V 2.7V DC-DC Convertor EEPROM 1k bit BuzzerVibratorLamp HITACHI H8/3837 60k byte ROM 2k byte SRAM LCD Module sw2sw1 IF IC 2MHz Ref Osc AGC x N 2 RSSI BS/ Charge Pump sw3 2 3 VCO1 2.2V data 2M CGROM 32k byte SRAM Ideo only CHECK THIS

APPLICANT: MOTOROLA, INC.FCC ID: E9601110 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the product when in production. It will be placed on the product as shown in the external photographs. Other information may also be included on this label. FCC ID: E9601110 This device complies with part 15 of the FCC Rule s . Ope ration is s ubje ct to the conditio n tha t t his de vice doe s not ca us e harmful interference.

MOTOROLA PPG, Compliance Laboratory Paging Products Group 1500 Gateway Blvd., Boynton Beach, Florida 33426 (561) 739-2179 FAX: (561) 739-2131 TEST REPORT Laboratory IDSubmitter ID MOTOROLA PPG, Compliance Laboratory Motorola Inc. 1500 Gateway Boulevard 1500 Gateway Boulevard Boynton Beach, FL 33426-8292 Boynton Beach, FL 33426 PH (561)-739-2179 FAX (561)-739-2131 Report Issue Date: January 25, 2001 Test Report Number: 00001A Sample S/N: 30CKAG2229 Model Designation: VHF Scriptor Jazz 200 Sample Receipt Date: January 23, 2001Product Description: Paging Receiver Date: January 25, 2001 Description of non-standard test method or practice: N/A Estimated Measurement Uncertainty: +/- 3.2 dB for 95% confidence Special limitations of use: N/A Traceability: reference standards of measurement have been calibrated by a competent laboratory using standards traceable to the NIST. According to the tests performed at MOTOROLA PPG, Compliance Laboratory, the above-mentioned unit is in compliance with the electromagnetic compatibility requirements indicated on page (3) of the test report. The test results contained herein relate only to the model(s) identified above. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Project Manager, I hereby declare that the equipment tested as specified above conforms to the requirements indicated on page (3) of the test report. Signature: John FreemanName: _John Freeman__________ Title: Compliance Program ManagerDate : __________________ Reviewed by : Approved Signatory: _Edwin MendivilDate: __Jan. 30, 2001______ This report may only be reproduced in full with written permission from at MOTOROLA PPG, Compliance Laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY NVLAP OR ANY AGENCY OF THE U.S. GOVERNMENT MOTOROLA PPG, Compliance Laboratory Paging Products Group 1500 Gateway Blvd., Boynton Beach, Florida 33426 (561) 739-2179 FAX: (561) 739-2131 Lab Code: 200318-0 Test Report Number 00001A Page 1 of 12 D I R E C T O R Y - EMISSIONS A)DocumentationPage(s) Test report1 - 10 Directory2 Test Regulations3 General Requirements10 Test-setups (Photos)11 - 12 B)Test data Conducted Emissions10/150 kHz - 30 MHz5,9 Radiated emissions10 kHz - 30 MHz5, 9 Radiated emissions30 MHz - 1000 MHz6, 9 Radiated emissions1 GHz - 5 GHz6, 9 Interference power30 MHz - 300 MHz6, 9 Equivalent radiated emissions1 GHz - 18 GHz7, 9 C) Appendix A Test Equipment Calibration InformationA2 Test Data Sheets A3 - A4 D)Appendix B System Under Test DescriptionB2 - B4 E)Appendix C Measurement ProtocolC1 - C2 MOTOROLA PPG, Compliance Laboratory Paging Products Group 1500 Gateway Blvd., Boynton Beach, Florida 33426 (561) 739-2179 FAX: (561) 739-2131 Test Report Number 00001A Page 2 of 12 EMISSIONS TEST REGULATIONS : The emissions tests were performed according to the following regulations: - EN 55022 : 1994 / A1:1995 - Class A - Class B ! - FCC Part 15 - Class A ! - Class B ! - Certification - Notification - Verification - Declaration of Conformity - FCC Part 24 - Transmitter Spurious Emissions - EIRP - Occupied Bandwidth - IEC 1000-4-3 - Radiated Immunity MOTOROLA PPG, Compliance Laboratory Paging Products Group 1500 Gateway Blvd., Boynton Beach, Florida 33426 (561) 739-2179 FAX: (561) 739-2131 Test Report Number 00001A Page 3 of 12 Environmental Conditions During Testing : LABOATS Temperature: 78 deg. F 75 deg. F Relative Humidity: 60 – 70% 60 - 70% Atmospheric Pressure: _________ Power Supply System:: __________ Volts __________ Hz _________ phase Internal Battery Operated @ 1.5 Volts Sign Explanations: - not applicable ! - applicable MOTOROLA PPG, Compliance Laboratory Paging Products Group 1500 Gateway Blvd., Boynton Beach, Florida 33426 (561) 739-2179 FAX: (561) 739-2131 Test Report Number 00001A Page 4 of 12 Emissions Test Conditions: CONDUCTED EMISSIONS (Interference Voltage) The Conducted Emissions (Interference Voltage) measurements were performed at the following test location: ! - Test not applicable EUT DC Powered - Boynton Open Area Test Site - Boynton Compliance Laboratory Test equipment used: Model Number ManufacturerDescription Serial Number - 8566B Hewlett PackardSpec. Analyzer3014A06961 - 85650AHewlett Packard Quasi-Pk Adaptor2521A00671 - 8593EMHewlett Packard EMC Analyzer3536A00118 Emissions Test Conditions: RADIATED EMISSIONS (Magnetic Field) The Radiated Emissions (Magnetic Field) measurements were performed at the following test location: ! - Test not applicable - Boynton Open Area Test Site - Boynton Compliance Laboratory at a test distance of: -3 meters - 10 meters Test equipment used: Model Number ManufacturerDescriptionSerial Number - B-100Compliance DesignBiconical Antenna385 - 8566B Hewlett PackardSpec. Analyzer3014A06961 - 85650AHewlett Packard Quasi-Pk Adaptor2521A00671 MOTOROLA PPG, Compliance Laboratory Paging Products Group 1500 Gateway Blvd., Boynton Beach, Florida 33426 (561) 739-2179 FAX: (561) 739-2131 - 85685AHewlett PackardRf Preselector2510A00192 - 8447DHewlett Packard Preamplifier2944A07577 Test Report Number 00001A Page 5 of1 2 Emissions Test Conditions: RADIATED EMISSIONS (Electric Field) The Radiated Emissions (Electric Field) measurements, in the frequency range of 30 MHz - 1000 MHz, were tested in the vertical and horizontal polarization at the following test location: - Test not applicable - Boynton Open Area Test Site ! - Boynton Compliance Laboratory (GTEM!) at a test distance of: ! -3 meters - 10 meters Test equipment used: Model Number ManufacturerDescriptionSerial Number ! - 5305EMCOGTEM Cell1135 - 3147EMCO Log Periodic Antenna9311-1124 - B-100Compliance DesignBiconical Antenna385 - SAS-200/571AH SYSTEMSDual Ridge Horn Ant.265 - 8566B Hewlett PackardSpec. Analyzer3014A06961 - 85650BHewlett Packard Quasi-Pk Adaptor2521A00671 - 85685AHewlett PackardRf Preselector2510A00192 - 8447DHewlett Packard Pream…

Text truncated - open the document above for the full version.

Test setup photo(s): Radiated emissions tests
