ELVAT1FCar Alarm Transmitter

CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user’s authority to operate the equipment. 128-6122 4 of 4

From: Denise Teng Sent: Wednesday, November 07, 2001 10:00 AM To: Mike Kuo; Steve Cheng; Kerwin Corpuz Cc: CLIENT ADVOCATES Subject: RE: Nutek Corporation, FCC ID:ELVAT1F, AN01T1656 Hi Mike, Please see attachments for the peak readins and revised user manual (page 4). Thanks! regards, -----Original Message----- From: CERTADM Sent: Monday, November 05, 2001 7:37 PM To: '[email protected]' Subject: Nutek Corporation, FCC ID:ELVAT1F, AN01T1656 Notice_content ------------- Question #1: Only Average readings are submitted in page 15 of test report. Per 15.231 (b)(2) requirements, when average measurement are employed, the provisionsin 15.35 for averaging pused emissions and for limiting peak emissions apply. Please submit the peak readings for those data taken in page 15 of test report. Question #2: User manual does not contain the information required under 15.21 of FCC rules. Please provide revised user manual. Best Regards Mike Kuo / TCB Certifier The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

PROPOSED FCC ID LABEL AND LOCATION NUTEK CORPORATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: ELVAT1F FCC ID LABEL

Operational Description The car alarm transmitter is a low powered, hand held unit for remote controlling the car locks and other features. See the function descriptions in attached. The transmitter is powered by a 12 volt battery. It is designed to operated on a single fixed frequency at 434 MHz. See the attached block diagram and schematic. There are 3 buttons trigger the integrated circuit (IC1) which produces the digital control signals and will modulate the carrier signal. The carrier signal is generated by a LC circuit comprised of a 434 MHz and a npn transmitter (TR1). The transmitter is manually operated by the buttons pushed and will automatically deactivate instant after the button being released. This feature is incorporated by the IC1 internally. All tuning and verification are performed by the manufacture and there are no adjustments can be made by the user. No external ground is required or used with this transmitter.

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR 434 MHz CAR ALARM TRANSMITTER MODEL NAME: PRO-OE3B4 TRADE NAME: NUTEK FCC ID NO: ELVAT1F REPORT NO: 01T0978-1 ISSUE DATE: SEPTEMBER 28, 2001 Prepared for NUTEK CORPORATION 5F, NO. 3, ALLEY 6, LANE 45 PAO-HSING ROAD, HSIN TIEN, TAIPEI TAIWAN R. O. C. Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 01T0978-1 FCC ID: ELVAT1F DATE: SEPTEMBER 28, 2001 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO:CCSUP4020B 561F MONTEREY RD., MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE........................................................................................3 2. Product Description.....................................................................................................................4 3. Test Facility.................................................................................................................................4 4. Measurement Standards...............................................................................................................4 5. Test Methodology........................................................................................................................4 6. Measurement Equipment Used....................................................................................................4 7. POWERLINE RFI LIMIT...........................................................................................................5 8. RADIATED EMISSION LIMITS...............................................................................................5 9. SYSTEM TEST CONFIGURATION.........................................................................................6 10. Test Procedure...........................................................................................................................7 11. Equipment Modifications...........................................................................................................8 12. TEST RESULT..........................................................................................................................9 12.1 Maximum Modulation Percentage (M%)................................................................................9 12.2 The Emissions Bandwidth.......................................................................................................9 TEST DATA • Maximum Modulation Percentage Plot • Emission Bandwidth Plot • Radiated Emission Worksheet for Peak Measurement • Radiated Emission Worksheet for Average Measurement ATTACHMENT • EUT Photographs • Proposed FCC ID Label • Schematics & Block Diagram • User Manual REPORT NO: 01T0978-1 FCC ID: ELVAT1F DATE: SEPTEMBER 28, 2001 Page 3 of 25 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO:CCSUP4020B 561F MONTEREY RD., MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. VERIFICATION OF COMPLIANCE COMPANY NAME: NUTEK CORPORATION 5F, NO. 3, ALLEY 6, LANE 45, PAO-HSING ROAD HSIN TIEN, TAIPEI, TAIWAN R. O. C. CONTACT PERSON: RUBY HSIEH TELEPHONE NO.: 02-2918-9478 EUT DESCRIPTION: 434 MHz CAR ALARM TRANSMITTER MODEL NAME/NUMBER: PRO-OE3B4 TRADE NAME: NUTEK FCC ID: ELVAT1F DATE TESTED: SEPTEMBER 21, 2001 REPORT NUMBER: 01U0978-1 TYPE OF EQUIPMENT SECURITY EQUIPMENT (INTENTIONAL RADIATOR) EQUIPMENT TYPE 434 MHz CAR ALARM TRANSMITTER MEASUREMENT PROCEDURE ANSI C63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15 The above equipment was tested by Compliance Certification Services for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Warning : This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification will constitute fraud and shall nullify the document. Tested By: KERWIN CORPUZ ASSOCIATE EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES Approved & Released By: THU CHAN SENIOR EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES REPORT NO: 01T0978-1 FCC ID: ELVAT1F DATE: SEPTEMBER 28, 2001 Page 4 of 25 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO:CCSUP4020B 561F MONTEREY RD., MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. PRODUCT DESCRIPTION Fundamental Frequency 434 MHz Power Source 12V Alkaline Battery Model 27A Transmitting Time Periodic < 5 seconds Associated Receiver FCC ID: ELVAR5F 3. TEST FACILITY The 3/10/30 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facility was submitted to the Commission on Ma…

Text truncated - open the document above for the full version.

01T0978-1 010927C1 09/27/019:33 AM KERWIN CORPUZ NUTEK CORPORATION 434MHz CAR ALARM TX (M/N: PRO-OE3B4) EUT ONLY 15.231(b) TX 09/27/01 Freq.ReadingAFClossPre-ampLevelLimitMarginPolAzHeightMark (MHz)(dBuV)(dB)(dB)(dB)(dBuV/m)FCC_B(dB)(H/V)(Deg)(Meter)(P/Q/A) X AXIS: 433.8574.2716.613.1527.5666.47100.80-34.333mV135.001.70P 433.8586.5716.533.1527.5678.69100.80-22.113mH135.001.70P Y AXIS: 433.8581.9716.533.1527.5674.09100.80-26.713mH180.001.00P 433.8577.4016.613.1527.5669.60100.80-31.203mV270.001.30P Z AXIS: 433.8589.1716.613.1527.5681.37100.80-19.433mV270.001.30P 433.8582.8716.533.1527.5674.99100.80-25.813mH0.001.00P WORSE CASE FOR VERTICAL POLARIZATION IS Z AXIS OF EUT AND HORIZONTAL POLARIZATION IS X AXIS OF EUT. 867.6344.1722.074.8327.6343.4480.80-37.363mH90.001.00P 867.6345.7721.324.8327.6344.2980.80-36.513mV180.001.00P TO COMPLETED RADIATED EMISSION, NEED TO SCAN ABOVE 1GHz UP TO 10th HARMONIC Total data #: 8 V.2c Company: EUT Description: Test Configuration : Type of Test: Mode of Operation: FCC, VCCI, CISPR, CE, AUSTEL, NZ UL, CSA, TUV, BSMI, DHHS, NVLAP 561F MONTEREY ROAD, SAN JOSE, CA 95037-9001 PHONE: (408) 463-0885 FAX: (408) 463-0888 Project #: Report #: Date& Time: Test Engr: A-Site nmlkj A-Site nmlkj B-Site nmlkj B-Site nmlkj C-Site nmlkji C-Site nmlkji F-Site nmlkj F-Site nmlkj 6 Worst DataDescending

REPORT NO: 01T0978-1 FCC ID: ELVAT1F DATE: SEPTEMBER 28, 2001 Page 6 of 25 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO:CCSUP4020B 561F MONTEREY RD., MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 9. SYSTEM TEST CONFIGURATION Use a block of foam and combined it with EUT wrapping rubber band around it. This way it can test X.Y, and Z axis. To activate continuous transmission, place a small plastic block between rubber band and EUT push button. Radiated Open Site Test Set-up
