128-8857 1 of 20 The selectable features can be set manually as explained below, or with the RF feature programmer.To set features using the RF programmer, follow the instructions packaged with the programmer.Factory default settings are indicated by bold text.Note: The manual override method can be selected to either operate from the valet switch or operate as custom code. Note: Keyless Entry Models with no horn output will Flash the Parking Lights instead of chirp where chirp is indicated. Also, No data will be indicated if a feature is not available for a particular model. The unit will enter the feature but no se lection will be available. RF Programmable Feature Bank 1 Is For Transmitter Programming. See the Transmitter Programming Guide.RF Programmable Features Bank 2 Is Alarm Selectable Features:Feature Selection 1 Chirp 2 Chirps 3 Chirps 4 Chirps 5 Chirps 6 Chirps 1st DoorL/UL 1 Sec. 3.5 Sec. 1 Sec L, Dbl. U/L Dbl L, 1 Sec UL Dbl L, Dbl UL 1 S l/350mS ul 2nd Accy Lock Not Available 3rd Accy . UL Not Available 4th Headlights Not Available 5th Passive Locks Not Available 6th Pass/Act Arm Not Available 7th Siren/Horn Not Available 8th Horn Chirp Not Available 9th O/R Method Not Available 10th 2 S tep U/L Not Available 1 1th Chp Del Tx Not Available 12th V olt age/Hd W ire Not Available 13th Trigger Circuits Not Available 14th Lock/Unlock Poll Not Available 15th Aux Ch 5 Sel Not Available 16th Aux Ch 6 Sel Not Available 17th Aux Ch 7 Sel Not Available 18th Trigger Delay Not Available When using the RF programmer, enter the program mode as follows:Turn the ignition on.Press and release the valet switch 3 times.Turn the ignition off then on.Press and hold the valet switch for 5 seconds.Siren and or lights chirp/flash 2 times indicating access to RF feature program mode. Model PRO-9056TW Installation Manual 128-8857 2 of 20 To program these selectable features; ActionSystem Response Turn ignition onNo response Press and release the valet switch 3 times1 Chirp - LED 1 flash Within 3 seconds, turn ignition Off Then OnShort chirp, then long chirp This Action Accesses Feature Bank 2 Alarm Selectable Features FirstPress and release the valet switch 1 time1 chirp = 1 second door lock & unlock Press transmitter Lock button to change2 chirps = 3.5 second door lock & Unlock Press transmitter Lock button to change3 chirps = 1 sec. lock, dbl 1 sec. unlock Press transmitter Lock button to change4 chirps = dbl 1 sec lock, 1 sec unlock Press transmitter Lock button to change5 chirps = dbl 1 sec lock, dbl 1 sec unlock Press transmitter Lock button to change6 chirps = 350mS unlock. 1 sec lock or SecondPress and release the valet switchNon Functional On This Unit or ThirdPress and release the valet switchNon Functional On This Unit or FourthPress and release the valet switchNon Functional On This Unit or FifthPress and release the valet switchNon Functional On This Unit or SixthPress and release the valet switchNon Functional On This Unit or SeventhPress and release the valet switchNon Functional On This Unit or EighthPress and release the valet switchNon Functional On This Unit or NinthPress and release the valet switchNon Functional On This Unit or TenthPress and release the valet switchNon Functional On This Unit or EleventhPress and release the valet switchNon Functional On This Unit or TwelfthPress and release the valet switchNon Functional On This Unit or ThirteenthPress and release the valet switchNon Functional On This Unit or FourteenthPress and release the valet switchNon Functional On This Unit or FifteenthPress and release the valet switchNon Functional On This Unit or SixteenthPress and release the valet switchNon Functional On This Unit or SeventeenthPress and release the valet switchNon Functional On This Unit or EighteenthPress and release the valet switchNon Functional On This Unit or Press and release the valet switch or turn the ignition off to:Exit Programming Mode or Turn ignition switch off then on to advance to feature Bank 3: 128-8857 3 of 20 To exit program mode, turn ignition off, or press and release valet switch.RF Programmable Features Bank 3 Is Remote Start Selectable Features:Feature Selection 1 Chirp 2 Chirps 3 Chirps 4 Chirps 5 Chirps 6 Chirps 1st Defrost Output NA 2nd RF Start Chirp NA 3rd Run Time 5 Mins 10 Mins 15 Mins 20 Mins 45 Mins 60 Mins 4th Parking Lights On Steady Flashing 5th Input Check Voltage Tach DBI T ach Hybrid 6th Voltage Level >0.5V B4 Start < 0.5V B4 Start 7th Ign. 2 Select Off During Crank On During Crank Same As Accy. 8th Ign. 3 Select NA 9th Diagnostics Off On 10th Crank Time 0.8 Sec 1.0 Sec 1.5 Sec 2.0 Sec 11th Gas/Diesel Gas Diesel 10 Diesel 15 Diesel 20 12th Transponder O/P While R/S On During Start Until Ign. Off 13th Temp Start Not Available 14th Crank Averaging Averaging Preset Time Note: When averaging, the engine must be started 4 times with the key to be effective. 15th R/S Shock NA 16th Turbo Select NA 17th Black/Blue (Aux O/P) Single Pulse As Feat #1 Bank 2 18th One or Two Press Start Two Press One Press Note: When feature #5 is set for Voltage or Hybrid, the unit must also have feature #14 set for Preset Time or the unit will flash th e Pk. Lts. 7 times and not start. Note: When setting feature #17 to operate as feature #1 Bank 1, the transmitter will also control this output only while running und er R/S command. So in other words, if this output is used to unlock the doors with the transmitter, the doors will unlock on startup. To relock the d oors, use the After Start Black Green wire of the 4 pin connector. When using the RF programmer, enter the program mode as follows:Turn the ignition onPress and release valet switch 3 timesturn ignition off then onPress and hold valet switch for 5 secondsSiren chirps 2 times indicating access to RF feature program mode.To exit program mode, turn ignition off, or press and release valet switch. 128-8857 4 of 20 ActionSystem Response Turn ignition onNo response Press and release the valet switch 3…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Sep. 08, 2010 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Nutek Corporation hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product: IVU, Model No.: TRX24FSK, FCC ID: ELVATRJD We affirm that between SIEMIC and Nutek Corporation, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Charles Chen / President Nutek Corporation Tel: +886 2 2918 9478 Fax: +886 2 2917 9069 E-mail: [email protected]

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Sep. 08, 2010 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: ELVATRJD We hereby request confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Charles Chen / President Nutek Corporation Tel: +886 2 2918 9478 Fax: +886 2 2917 9069 E-mail: [email protected]

Report No.：10A082503FR FCC ID： ELVATRJD Page 22 of 24 Interocean EMC Technology Corp. Test Report 7 Photographs of EUT Front View of EUT Rear View of EUT

FCC ID:ELVATRJD P/N:TRX24FSK mobile.audiovox.com DANIEL MT-11020 MTF02010*1 0.2 B ± A ± C ± NTABA0B0*1/NTABA0C0*1 YYS VICTOR BODY MATERIAL : CLEAR PC + UV BLACK(CLEAR PC)

Report No.：10A082503FR FCC ID： ELVATRJD Page 23 of 24 Interocean EMC Technology Corp. Test Report Inner View of EUT Antenna Location Report No.：10A082503FR FCC ID： ELVATRJD Page 24 of 24 Interocean EMC Technology Corp. Test Report Component View of PCB Board Solder View of PCB Board

Report No.：10A082503FR FCC ID： ELVATRJD Page 1 of 24 Interocean EMC Technology Corp. Test Report CFR 47 FCC Part 15.231 TEST REPORT Product： IVU Trade Name： N/A Model Number： TRX24FSK FCC ID： ELVATRJD Prepared for Nutek Corporation NO.167, Lane 235, Bauchiau Rd., Shindian City, Taipei County 23145, Taiwan TEL.： +886 2 2918 9478 FAX.： +886 2 2917 9069 Prepared by Interocean EMC Technology Corp. 244 No.5-2, Lin 1, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei County, Taiwan, R.O.C. TEL.: +886 2 2600 6861 FAX.: +886 2 2600 6859 Remark: The test report consists of 24 pages in total. It shall not be reproduced except in full, without the written approval of IETC. This document may be altered or revised by IETC only, and shall be noted in the revision section of the document. The test results in the report only to the tested sample. Report No.：10A082503FR FCC ID： ELVATRJD Page 2 of 24 Interocean EMC Technology Corp. Test Report Statement of Compliance Applicant: Nutek Corporation Manufacturer: Nutek Corporation Product: IVU Model No.: TRX24FSK Tested Power Supply: 12Vdc Battery Date of Final Test: Sep. 07, 2010 Configuration of Measurements and Standards Used： FCC Rules and Regulations Part 15 Subpart C 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of IETC. Report Issued: 2010/09/10 Project Engineer: Approved: Adam Cheng Jerry Liu Report No.：10A082503FR FCC ID： ELVATRJD Page 3 of 24 Interocean EMC Technology Corp. Test Report Table of Contents 1 Summary of Measurement 4 2 General Information 5 2.1 Description of Equipment Under Test 5 2.2 Details of tested peripheral equipment 6 2.3 Test Facility 7 3 Test specifications 8 3.1 Test standard 8 3.2 Operation mode 8 3.3 Test Equipment 9 4 Radiated emission test 10 4.1 Limits 10 4.2 Calculation of Average Factor 11 4.3 Configuration of Measurement 15 4.4 Test Procedure 15 4.5 Test Result 15 5 Emission bandwidth 18 5.1 Limits 18 5.2 Test Result 18 6 Photographs of Test 20 6.1 Radiated Emission Measurement (below 1GHz) 20 6.2 Radiated Emission Measurement (above 1GHz) 21 7 Photographs of EUT 22 Report No.：10A082503FR FCC ID： ELVATRJD Page 4 of 24 Interocean EMC Technology Corp. Test Report 1 Summary of Measurement Report Clause Test Parameter Reference Document CFR47 Part15 Results 4 Radiated Emission §15.231(b), 15.209 Pass 5 Emission bandwidth §15.231(c) Pass Report No.：10A082503FR FCC ID： ELVATRJD Page 5 of 24 Interocean EMC Technology Corp. Test Report 2 General Information 2.1 Description of Equipment Under Test Product : IVU Model Number : TRX24FSK Applicant : Nutek Corporation NO. 167, Lane 235, Bauchiau Rd., Shindian City, Taipei County 23145, Taiwan Manufacturer : Nutek Corporation NO. 167, Lane 235, Bauchiau Rd., Shindian City, Taipei County 23145, Taiwan Power Supply : 12Vdc Battery Operating Frequency : 433.92MHz Channel Number : 1 channel Type of Modulation : FSK Antenna description : This device uses Spring antenna. The antenna is integral to the device, thereby meeting the requirement of FCC 15.203. Date of Receipt Sample : Aug. 30, 2010 Date of Test : Aug. 30 ~ Sep. 07, 2010 Additional Description : 1) The Model Number “TRX24FSK” is representative selected in the test and included in this report. 2) For more detail specification about EUT, please refer to the user’s manual. Report No.：10A082503FR FCC ID： ELVATRJD Page 6 of 24 Interocean EMC Technology Corp. Test Report 2.2 Details of tested peripheral equipment N/A Report No.：10A082503FR FCC ID： ELVATRJD Page 7 of 24 Interocean EMC Technology Corp. Test Report 2.3 Test Facility Site Description : OATS 2 Name of Firm : Interocean EMC Technology Corp. Company web : http://www.ietc.com.tw Site 1, 2 Location : No.5-2, Lin 1, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei County, Taiwan, R.O.C. Site 3, 4 Location : No. 12, Ruei-Shu Valley, Ruei-Ping Tsun, Lin-Kou Hsiang, Taipei County, Taiwan, R.O.C. Site Filing : z Federal Communication Commissions – USA Registration No.: 96399 (OATS 1 & 2) Registration No.: 518958 (OATS 3 & 4) Designation No.: TW1020 z Voluntary Control Council for Interference by Information Technology Equipment (VCCI) – Japan Member No.: 1349 Registration No. (Conducted Room): C-1094 Registration No. (Conducted Room): T-1562 Registration No. (OATS 1): R-1040 Registration No. (OATS 2): R-1041 z Industry Canada (IC) OUR FILE: 46405-4437 Submission: 130946 Registration No. (OATS 1): 4437A-1 Registration No. (OATS 2): 4437A-2 Registration No. (OATS 3): 4437A-3 Registration No. (OATS 4): 4437A-4 Site Accreditation : z Bureau of Standards and Metrology and Inspection (BSMI) – Taiwan, R.O.C. Accreditation No.: SL2-IN-E-0026 for CNS13438 / CISPR22 SL2-R1-E-0026 for CNS13439 / CISPR13 SL2-R2-E-0026 for CNS13439 / CISPR13 SL2-A1-E-0026 for CNS13783-1 / CISPR14-1 SL2-L1-E-0026 for CNS 14115 / CISPR 15 z Taiwan Accreditation Foundation (TAF) Accrditation No.: 1113 z TüV NORD Certificate No: TNTW0801R-02 Report No.：10A082503FR FCC ID： ELVATRJD Page 8 of 24 Interocean EMC Technology Corp. Test Report 3 Test specifications 3.1 Test standard The EUT was performed according to FCC Part 15 Subpart C Section 15.231 procedure and setup followed by ANSI C63.4, 2003 requirements. 3.2 Operation mode By preliminary testing and verifying three axis (X, Y and Z) position of EUT transmitted status, it was found that “X axis” position was the worst, then the final test was executed the worst condition and test data were recorded in this report The EUT was operated in continuous transmission mode during all of the tests. X axis mode Y axis mode Z axis mode Report No.：10A082503FR FCC ID： ELVATRJD Page 9 of 24 Interocean EMC Technology Corp. Test Report 3.3 Test Equipment Instrument ManufacturerModel Serial No. Next Cal. Date Spectrum Analyzer R&S FSP30 100002 2010/12/08 Spectrum Analyzer R&S FSP40 100478 2011/04/20 Preamplifier Agilent 8449B 3008A01434 2011/04/20 Preamplifier SCHAFFNER CA30100 2 2010/11/03 H…

Text truncated - open the document above for the full version.

Report No.：10A082503FR FCC ID： ELVATRJD Page 20 of 24 Interocean EMC Technology Corp. Test Report 6 Photographs of Test 6.1 Radiated Emission Measurement (below 1GHz) Front View Rear View Report No.：10A082503FR FCC ID： ELVATRJD Page 21 of 24 Interocean EMC Technology Corp. Test Report 6.2 Radiated Emission Measurement (above 1GHz) Front View Rear View
