ELVATRKATransmitter

128-8841a 1 of 8 Your Alarm and or Remote Start unit has a configurable receiver that allows the transmitter to be programmed to operate the Lock Unlock functions with one transmitter button or with two transmitter buttons (separate Lock/ Unlock). In addition, the receiver also allows driver priority function. This driver priority function takes place when ever a particular transmitter is used to unlock the vehicle regardless of the selection of one button or two button operation. The following indicates the receiver programmable slots. 1 Lock/Unlock or Lock 2 Unlock if Programmed 3 Trunk Release & or Remote Start (Optional on some models) 4 Auxiliary Output 5 Auxiliary Output 6 Driver 1 Priority or Seperate Output 7 Driver 2 Priority or Separate Output Receiver channels 6 or 7 will accept the programming of transmitter channel 1 if used as the Lock/Unlock button, or Channel 2 when separate Lock Unlock buttons are programmed. In this way, whenever the transmit- ter is used to unlock the vehicle, channel 6 or 7, when programmed, will provide a pulsed ground output. This output can be connected to the driver priority function of the vehicle to reset preset user features. Please consult with your installation center technician to see if this feature is available in your vehicle. NOTE: A total of 4 transmitters may be programmed into any receiver channel. Force programming a transmitter, removing a transmitter, or reprioritizing a transmitter is covered later in this manual. Also, if you do not program a transmitter button into channel 2 which is the separate unlock/disarm channel, then whatever button is programmed into channel 1 will serve as both lock/arm & unlock/disarm. Note: The RED Button serves as a function button in combination with other buttons explained in your owners manual. This button may not be used to operate a receiver channel. NOTE: The Option Button is predetermined and programmed for access to Time Start, and Temperature Start & Check so it cannot be used for multiple button operation of any other feature. It will however operate for any single button programming. This transmitter is also capable of one button programming for certain model Model SS92 Programming Guide Rev a Modify FCC Statement 5/06/11 128-8841a 2 of 8 2 THIS PAGE LEFT BLANK INTENTIONALLY 128-8841a 3 of 8 Audiovox Alarms. If your alarm is one of these models, then when step 3 is completed on the following page, you can turn the ignition switch off and programming with the default button configurations for the first four chan- nels will be complete. TO ENTER THE PROGRAM MODE: 1. Turn the ignition switch to the “ON” position. 2. Within 10 seconds, Press and release the valet/program switch three times. (Siren emits 1 short chirp indicating channel 1 has been entered) 3. Within 10 Seconds, Press and hold the button of the first transmitter you wish to control the Lock&Arm feature of your security system until a long chirp is heard from the siren, and a beep from the LCD transceiver. (Repeat this for each transmitter you wish to operate the Lock/Arm feature). 4. Within 10 seconds, Press and release the valet program switch one time. (Siren emits 2 short chirps indicating channel 2 has been entered) 5. Within 10 Seconds, Press and hold any unused button(s) of the first transmitter you wish to control the Unlock/Disarm feature of your security system until a long chirp is heard from the siren. NOTE: This channel is used only if you desire separate control of the Lock/Unlock feature. If you wish to operate the Lock/Unlock features from a single button, move onto step 6 as whatever button is programmed into channel 1 will control both Lock & Arm/Unlock & Disarm. (Repeat this for each transmitter you wish to operate the Unlock/Disarm feature). 6. Within 10 seconds, Press and release the valet program switch one time. (Siren emits 3 short chirps indicating channel 3 has been entered) 7. Within 10 Seconds, Press and hold any unused button(s) of the first transmitter you wish to control Channel 3 output, (Trunk Release) until a long chirp is heard from the siren. (Repeat this for each transmitter you wish to operate the Channel 3 output (Trunk Release) 8. Within 10 seconds, Press and release the valet program switch one time. (Siren emits 4 short chirps indicating channel 4 has been entered) 9. Within 10 Seconds, Press and hold any unused button(s) of the first transmitter you wish to control Channel 4 output, (Auxiliary Output 1) until a long chirp is heard from the siren. (Repeat this for each transmitter you wish to operate the Channel 4 output) 10. Within 10 seconds, Press and release the valet program switch one 3 128-8841a 4 of 8 time. (Siren emits 5 short chirps indicating channel 5 has been entered) 11. Within 10 Seconds, Press and hold any unused button(s) of the first transmitter you wish to control Channel 5 output, (Auxiliary Output 2) until a long chirp is heard from the siren. (Repeat this for each transmitter you wish to operate the Channel 5 output) 12. Within 10 seconds, Press and release the valet program switch one time. (Siren emits 6 short chirps indicating channel 6 has been entered) 13. Within 10 Seconds, Press and hold the unlock button, (or any unused button(s)), of the first transmitter you wish to control Channel 6 output, (Driver Priority 1) until a long chirp is heard from the siren. (Repeat this for each transmitter you wish to operate the Channel 6 output, Driver Priority 1) 14. Within 10 seconds, Press and release the valet program switch one time. (Siren emits 7 short chirps indicating channel 7 has been entered) 15 .Within 10 Seconds, Press and hold the unlock button (or any unused button(s)) of the first transmitter you wish to control Channel 7 output, (Driver Priority 2) until a long chirp is heard from the siren. (Repeat this for each transmitter you wish to operate the Channel 7 output, Driver Priority 2) NOTE: Channels 6 and 7 can be used as a separate output to control a fun…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Apr. 26, 2011 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Nutek Corporation hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product: Transmitter, Model No.: SS92P, FCC ID: ELVATRKA We affirm that between SIEMIC and Nutek Corporation, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Charles Chen / President Nutek Corporation Tel: +886 2 2918 9478 Fax: +886 2 2917 9069 E-mail: [email protected]

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Apr. 26, 2011 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: ELVATRKA We hereby request confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Charles Chen / President Nutek Corporation Tel: +886 2 2918 9478 Fax: +886 2 2917 9069 E-mail: [email protected]

Report No.: 11A032103FR FCC ID：ELVATRKA Page 47 of 53 Interocean EMC Technology Corp. Test Report 12 Photographs of EUT Front View of EUT Rear View of EUT Report No.: 11A032103FR FCC ID：ELVATRKA Page 51 of 53 Interocean EMC Technology Corp. Test Report Front View of Battery Rear View of Battery Report No.: 11A032103FR FCC ID：ELVATRKA Page 52 of 53 Interocean EMC Technology Corp. Test Report Front View of Adapter Rear View of Adapter Report No.: 11A032103FR FCC ID：ELVATRKA Page 53 of 53 Interocean EMC Technology Corp. Test Report Spec. of Adapter

O P T I O N PART NO.SS92P 800-225-6074 FCC ID:ELVATRKA XX mobile.audiovox.com BODY MATERIAL : ABS+PC MT-11010 0.2 Eason YYS Victor FCC ID: ELVATRJB

Report No.: 11A032103FR FCC ID：ELVATRKA Page 48 of 53 Interocean EMC Technology Corp. Test Report Inner View of EUT Antenna Location Report No.: 11A032103FR FCC ID：ELVATRKA Page 49 of 53 Interocean EMC Technology Corp. Test Report Front View of Main Board -1 Front View of Main Board -2 Report No.: 11A032103FR FCC ID：ELVATRKA Page 50 of 53 Interocean EMC Technology Corp. Test Report Rear View of Main Board

FCC ID：ELVATRKA Report No.：11A032103FR Page 1 of 2 RF Exposure Evaluation E.U.T.： Transmitter Model Number： SS92P Report Issued： 2011/04/28 Project Engineer： Approved： Elli Chang Jerry Liu Applicant： Nutek Corporation Address： NO.167, LANE235, BAUCHIAU RD., XINDIAN DISTRICT , NEW TAIPEI CITY 231, TAIWAN Issued By： Interocean EMC Technology Corp. LAB Location： No. 5-2, Lin 1, Tin-Fu, Lin-Kou Dist., New Taipei City, Taiwan 244, R.O.C. FCC ID：ELVATRKA Report No.：11A032103FR Page 2 of 2 Portable Device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 (2)(a)(i) Frequency Range (MHz) Low Freq. High Freq. Center Frequency (MHz) 60/f SAR Limitation (mw) 909.5 919.024 914.743 66 Maximum measured transmitter power Output power To antenna (mW) Maximum Antenna gain (numeric) EIRP (mw) 50.9331 1 50.9331 Threshold at which no SAR required is 66 mw. Maximum Tx power is 50.9331mw EIRP. Conclusion: No SAR is required. SIMULTANEOUS TRANSMISSION EVALUATION N/A

Report No.: 11A032103FR FCC ID：ELVATRKA Page 1 of 53 Interocean EMC Technology Corp. Test Report CFR 47 FCC Part 15.247 TEST REPORT Product： Transmitter Trade Name： N/A Model Number： SS92P FCC ID： ELVATRKA Prepared for Nutek Corporation NO.167, Lane 235, Bauchiau Rd., Shindian City, Taipei County 23145, Taiwan TEL.： +886 2 2918 9478 FAX.： +886 2 2917 9069 Prepared by Interocean EMC Technology Corp. 244 No.5-2, Lin 1, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei County, Taiwan, R.O.C. TEL.: +886 2 2600 6861 FAX.: +886 2 2600 6859 Remark： The test report consists of 53 pages in total. It shall not be reproduced except in full, without the written approval of IETC. This document may be altered or revised by IETC only, and shall be noted in the revision section of the document. The test results in the report only to the tested sample. Report No.: 11A032103FR FCC ID：ELVATRKA Page 2 of 53 Interocean EMC Technology Corp. Test Report Table of Contents 1 General Information 5 1.1 Description of Equipment Under Test 5 1.2 Table for Carrier Frequencies 6 1.3 Test Facility 7 1.4 Test Equipment 8 1.5 Summary of Measurement 9 1.6 Justification 10 2 Test specifications 11 2.1 Test standard 11 2.2 Operation mode 11 3 20dB Bandwidth test 12 3.1 Limit 12 3.2 Configuration of Measurement 12 3.3 Test Procedure 12 3.4 Test Result 12 4 Carrier Frequency Separation test 15 4.1 Limit 15 4.2 Configuration of Measurement 15 4.3 Test Procedure 15 4.4 Test Result 15 5 Number of hopping frequencies test 17 5.1 Configuration of Measurement 17 5.2 Test Procedure 17 5.3 Test Result 17 6 Time of Occupancy (dwell time) test 19 6.1 Limit 19 6.2 Configuration of Measurement 19 6.3 Test Procedure 19 6.4 Test Result 19 7 Maximum Output Power test 21 7.1 Limit 21 7.2 Configuration of Measurement 21 7.3 Test Procedure 21 7.4 Test Result 21 8 RF Conducted spurious emission 25 8.1 Limit 25 8.2 Configuration of Measurement 25 8.3 Test Procedure 25 8.4 Test Result 25 Report No.: 11A032103FR FCC ID：ELVATRKA Page 3 of 53 Interocean EMC Technology Corp. Test Report 9 RF Radiated spurious emission test 31 9.1 Limit 31 9.2 Configuration of Measurement 31 9.3 Test Procedure 32 9.4 Test Result 32 10 AC Power Line Conducted Emission test 37 10.1 Limits 37 10.2 Configuration of Measurement 37 10.3 Test Procedures 37 10.4 Test Result 37 11 Photographs of Test 44 11.1 Power Line Conducted Emission Measurement 44 11.2 Radiated Emission Measurement 45 12 Photographs of EUT 47 Report No.: 11A032103FR FCC ID：ELVATRKA Page 4 of 53 Interocean EMC Technology Corp. Test Report Statement of Compliance Applicant: Nutek Corporation Manufacturer: Nutek Corporation Product: Transmitter Model No.: SS92P Tested Power Supply: 120Vac, 60Hz Date of Final Test: Apr. 13, 2011 Revision of Report: Rev. 00 Configuration of Measurements and Standards Used： FCC Rules and Regulations Part 15 Subpart C I HEREBY CERTIFY THAT: The data shown in this report were made in accordance with the procedures given in ANSI C63.4, and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Note: 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of IETC Report Issued: 2011/04/26 Project Engineer: Approved: Elli Chang Jerry Liu Report No.: 11A032103FR FCC ID：ELVATRKA Page 5 of 53 Interocean EMC Technology Corp. Test Report 1 General Information 1.1 Description of Equipment Under Test Product : Transmitter Model Number : SS92P Applicant : Nutek Corporation NO.167, Lane 235, Bauchiau Rd., Shindian City, Taipei County 23145, Taiwan Manufacturer : Nutek Corporation NO.167, Lane 235, Bauchiau Rd., Shindian City, Taipei County 23145, Taiwan Power Supply : AC/DC Adaptor Model No.: YL20W-050A-050 Input: 100-240Vac, 50/60Hz, 0.2A Output: 5Vdc, 0.5A Power Cable: Non-shielded, Un-detachable, 1.8m, without core Operating Frequency : 909.5MHz ~ 919.024MHz Channel Number : 25 channels Type of Modulation : FSK Antenna Description : This device uses Helix antenna. The antenna is integral to the device, thereby meeting the requirement of FCC 15.203. Date of Test : Mar. 21~Apr. 13, 2011 Additional Description : 1) The Model Number “SS92P” is representative selected in the test and included in this report. 2) For more detail specification about EUT, please refer to the user’s manual. Report No.: 11A032103FR FCC ID：ELVATRKA Page 6 of 53 Interocean EMC Technology Corp. Test Report 1.2 Table for Carrier Frequencies Channel Frequency (MHz) Channel Frequency (MHz) CH0 909.5000 CH13 915.1110 CH1 909.9570 CH14 915.4590 CH2 910.2860 CH15 915.8100 CH3 910.6380 CH16 916.1900 CH4 911.0000 CH17 916.5280 CH5 911.3600 CH18 916.8890 CH6 912.6270 CH19 917.2310 CH7 912.9800 CH20 917.5810 CH8 913.3620 CH21 917.9430 CH9 913.7140 CH22 918.3030 CH10 914.0650 CH23 918.6670 CH11 914.4000 CH24 919.0240 CH12 914.7430 Report No.: 11A032103FR FCC ID：ELVATRKA Page 7 of 53 Interocean EMC Technology Corp. Test Report 1.3 Test Facility Site Description : Conduction 2 OATS 2 RF Test Room Name of Firm : Interocean EMC Technology Corp. Company web : http://www.ietc.com.tw Site 1, 2, 3 Location : No.5-2, Lin 1, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei County, Taiwan, R.O.C. Site Filing : z Federal Communication Commissions – USA Registration No.: 96399 (OATS 1 & 2) Registration No.: 518958 (OATS 3) Designation No.: TW1020 z Voluntary Control Council for Interference by Information Technology Equipment (VCCI) – Japan Member No.: 1349 Registration No. (Conducted Room): C-1094 Registration No. (Conducted Room): T-1562 Registration No. (OATS 1): R-1040; G-274 Registration No. (OATS 2): R-1041 z Industry Canada (IC) OUR FILE: 46405-4437 Submission: 145171 Registration No. (OATS 1): Site# 4437A-1 Registration No. (OATS 2): Site# 4437A-2 Registration No. (OATS 3): Site# 4437A-3 Site Accreditation : z Bureau of Standards and Metrology and Inspection (BS…

Text truncated - open the document above for the full version.

Report No.: 11A032103FR FCC ID：ELVATRKA Page 44 of 53 Interocean EMC Technology Corp. Test Report 11 Photographs of Test 11.1 Power Line Conducted Emission Measurement Front View Rear View Report No.: 11A032103FR FCC ID：ELVATRKA Page 45 of 53 Interocean EMC Technology Corp. Test Report 11.2 Radiated Emission Measurement Front View (Frequency below 1GHz) Rear View (Frequency below 1GHz) Report No.: 11A032103FR FCC ID：ELVATRKA Page 46 of 53 Interocean EMC Technology Corp. Test Report Front View (Frequency above 1GHz) Rear View (Frequency above 1GHz)
