USER MANUAL TRANSMITTER CODE LEARNING The system has a four-transmitter memory capacity. Entering a fifth transmitter will eliminate the first one entered. To replace lost transmitters, enter new transmitters twice to eliminate all old codes. To enter a transmitter into memory: 1.Enter vehicle and close door. Be sure interior lights are off. 2. Put system into Valet mode, 3. Within 5 seconds after entering Valet , turn ignition key to ACCY, OFF, ACCY, OFF, ACCY Leave in the ACCY position. You should hear one long siren chirp that indicates the system is in the transmitter code-learning mode. 4. Press the LOCK button of the new transmitter. The system will learn all channels of the new transmitter. You should hear one long siren chirp that indicates the system learned the code. 5. Turn the ignition key OFF to exit the routine. Two long siren chirps will signal successful exit. Remove the system from Valet mode using Transmitter, Valet switch, or Pulse code.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 Nov. 12, 2012 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Nutek Corporation hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product: Transmitter, Model No.: KTLA FCC ID: ELVNTLC We affirm that between SIEMIC and Nutek Corporation , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: Charles Chen / President Contact information / address: Tel: +886 2 2918 9478 Fax: +886 2 2917 9069 E-mail: [email protected]

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Nov. 12, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: ELVNTLC We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Charles Chen / President Contact information / address: Tel: +886 2 2918 9478 Fax: +886 2 2917 9069 E-mail: [email protected]

Power of Attorney Date: 2012/11/12 To whom it may concern Dear Sir / Madam, I hereby have entrusted the following person to be a proxy regarding application for FCC Certification. I am therefore responsible for the contents of the application. Project Information Product : Transmitter Model No. : KTLA FCC ID : ELVNTLC Company Name : Interocean EMC Technology Corp. Company Address : No., 5-2, Lin 1, Tin-Fu, Lin-Kou Dist., New Taipei City, Taiwan 244, R.O.C. Name : Jerry Liu Job Title : Manager Applicant’s Company Name : Nutek Corporation Company Address : No.167, Lane 235, Bauchiau Rd., Xindian District, New Taipei City 23145, Taiwan Signature : Name : Charles Chen Job Title : President E-mail : [email protected]

Report No.：12A091308R-FR FCC ID： ELVNTLC Page 23 of 27 Interocean EMC Technology Corp. Test Report 7 Photographs of EUT Front View of EUT Rear View of EUT Report No.：12A091308R-FR FCC ID： ELVNTLC Page 24 of 27 Interocean EMC Technology Corp. Test Report FCC ID Location

Report No.：12A091308R-FR FCC ID： ELVNTLC Page 25 of 27 Interocean EMC Technology Corp. Test Report Inner View of EUT Antenna Location Report No.：12A091308R-FR FCC ID： ELVNTLC Page 26 of 27 Interocean EMC Technology Corp. Test Report Component View of Main Board Solder View of Main Board Report No.：12A091308R-FR FCC ID： ELVNTLC Page 27 of 27 Interocean EMC Technology Corp. Test Report Front View of Battery Rear View of Battery

Report No.：12A091308R-FR FCC ID： ELVNTLC Page 1 of 27 Interocean EMC Technology Corp. Test Report CFR 47 FCC Part 15.231 TEST REPORT Product： Transmitter Trade Name： N/A Model Number： KTLA FCC ID： ELVNTLC Prepared for Nutek Corporation NO.167, Lane 235, Bauchiau Rd., Shindian City, Taipei County 23145, Taiwan TEL.： +886 2 2918 9478 FAX.： +886 2 2917 9069 Prepared by Interocean EMC Technology Corp. No. 5-2, Lin 1, Tin-Fu, Lin-Kou Dist., New Taipei City, Taiwan 244, R.O.C. TEL.: +886 2 2600 6861 FAX.: +886 2 2600 6859 Remark: The test report consists of 27 pages in total. It shall not be reproduced except in full, without the written approval of IETC. This document may be altered or revised by IETC only, and shall be noted in the revision section of the document. The test result in the report is only subjected to the test sample. Report No.：12A091308R-FR FCC ID： ELVNTLC Page 2 of 27 Interocean EMC Technology Corp. Test Report Statement of Compliance Applicant: Nutek Corporation Manufacturer: Nutek Corporation Product: Transmitter Model No.: KTLA Tested Power Supply: 3Vdc Battery Date of Final Test: Sep. 20, 2012 Configuration of Measurements and Standards Used： FCC Rules and Regulations Part 15 Subpart C 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of IETC. Report Issued: 2012/11/23 Project Engineer: Approved: Elli Chang Jerry Liu Report No.：12A091308R-FR FCC ID： ELVNTLC Page 3 of 27 Interocean EMC Technology Corp. Test Report Table of Contents 1 Summary of Measurement 4 2 General Information 5 2.1 Description of Equipment Under Test 5 2.2 Details of tested peripheral equipment 6 2.3 Test Facility 7 3 Test specifications 8 3.1 Test standard 8 3.2 Operation mode 8 3.3 Test Equipment 9 4 Radiated emission test 10 4.1 Limits 10 4.2 Calculation of Average Factor 11 4.3 Configuration of Measurement 15 4.3 Configuration of Measurement 16 4.4 Test Procedure 16 4.5 Test Result 16 5 Emission bandwidth 19 5.1 Limits 19 5.2 Test Result 19 6 Photographs of Test 21 6.1 Radiated Emission Measurement 21 7 Photographs of EUT 23 Report No.：12A091308R-FR FCC ID： ELVNTLC Page 4 of 27 Interocean EMC Technology Corp. Test Report 1 Summary of Measurement Report Clause Test Parameter Reference Document CFR47 Part15 Results 4 Radiated Emission §15.231(b), 15.209 Pass 5 Emission bandwidth §15.231(c) Pass Report No.：12A091308R-FR FCC ID： ELVNTLC Page 5 of 27 Interocean EMC Technology Corp. Test Report 2 General Information 2.1 Description of Equipment Under Test Product : Transmitter Model Number : KTLA Applicant : Nutek Corporation NO. 167, Lane 235, Bauchiau Rd., Shindian City, Taipei County 23145, Taiwan Manufacturer : Nutek Corporation NO. 167, Lane 235, Bauchiau Rd., Shindian City, Taipei County 23145, Taiwan Power Supply : 3Vdc Battery Operating Frequency : 433.92MHz Channel Number : 1 channel Type of Modulation : ASK Antenna description : This device uses PCB antenna. The antenna is integral to the device, thereby meeting the requirement of FCC 15.203. Date of Test : Sep. 18 ~ 20, 2012 Additional Description : 1) The Model Number “KTLA” is representative selected in the test and included in this report. 2) For more detail specification about EUT, please refer to the user’s manual. Report No.：12A091308R-FR FCC ID： ELVNTLC Page 6 of 27 Interocean EMC Technology Corp. Test Report 2.2 Details of tested peripheral equipment N/A Report No.：12A091308R-FR FCC ID： ELVNTLC Page 7 of 27 Interocean EMC Technology Corp. Test Report 2.3 Test Facility Site Description : OATS 2 Name of Firm : Interocean EMC Technology Corp. Company web : http://www.ietc.com.tw Site 1, 2, 3 Location : No. 5-2, Lin 1, Tin-Fu, Lin-Kou Dist., New Taipei City, Taiwan 244, R.O.C. Site Filing : z Federal Communication Commissions – USA Registration No.: 96399 (OATS 1 & 2) Registration No.: 518958 (OATS 3) Designation No.: TW1020 z Voluntary Control Council for Interference by Information Technology Equipment (VCCI) – Japan Member No.: 1349 Registration No. (Conducted Room): C-1094 Registration No. (Conducted Room): T-1562 Registration No. (OATS 1): R-1040; G-274 Registration No. (OATS 2): R-1041 z Industry Canada (IC) OUR FILE: 46405-4437 Submission: 145171 Registration No. (OATS 1): Site# 4437A-1 Registration No. (OATS 2): Site# 4437A-2 Registration No. (OATS 3): Site# 4437A-3 Site Accreditation : z Bureau of Standards and Metrology and Inspection (BSMI) – Taiwan, R.O.C. Accreditation No.: SL2-IN-E-0026 for CNS13438 / CISPR22 SL2-R1-E-0026 for CNS13439 / CISPR13 SL2-R2-E-0026 for CNS13439 / CISPR13 SL2-A1-E-0026 for CNS13783-1 / CISPR14-1 SL2-L1-E-0026 for CNS 14115 / CISPR 15 z Taiwan Accreditation Foundation (TAF) Accreditation No.: 1113 z TüV NORD Certificate No: TNTW0801R-04 Report No.：12A091308R-FR FCC ID： ELVNTLC Page 8 of 27 Interocean EMC Technology Corp. Test Report 3 Test specifications 3.1 Test standard The EUT was performed according to FCC Part 15 Subpart C Section 15.231 procedure and setup followed by ANSI C63.4, 2003 requirements. 3.2 Operation mode By preliminary testing and verifying three axis (X, Y and Z) position of EUT transmitted status, it was found that “X axis” position was the worst, then the final test was executed the worst condition and test data were recorded in this report The EUT was operated in continuous transmission mode during all of the tests. X axis mode Y axis mode Z axis mode Report No.：12A091308R-FR FCC ID： ELVNTLC Page 9 of 27 Interocean EMC Technology Corp. Test Report 3.3 Test Equipment Instrument ManufacturerModel Serial No. Next Cal. Date Spectrum Analyzer R&S FSP40 100478 2013/05/29 Preamplifier Agilent 8449B 3008A01434 2013/05/02 Preamplifier Agilent 83050A 3950A00225 2013/08/28 Horn Antenna COM-POWER AH-118 10081 2013/05/29 Horn Antenna Schwarzbeck BBHA 9120 9120D-583 2013/05/01 Horn Antenna Schwarzbeck BBHA 9170 213 2013/07/24 Cable HARBOUR 27478LL142 CBL22 2012/09/28 EMI Test Receive…
