ELVNTNHTransmitter

AL-1860-EDPB Deluxe 2-way Alarm & Remote Start w/ BLADE Technology July 8, 2013 Operation Guide Temporary cover. Color cover is in a separate file. 1 Table Of Contents Controller & Transmitter Overview3 The 2-Way Controller 3 The 1-Way Transmitter 3 Controller & Transmitter Functions 3 Other Remote Start Features 7 Low Battery/Low Temp Automatic Starting 7 Turbo Timer Feature 8 Pit-Stop Feature 8 Manual Transmission Starting 8 Security System Features 8 Last Door Arming 8 Automatic Rearming 9 Pre-Warn Detection 9 When The System Triggers 9 Using The Valet Switch 10 Emergency Override 10 Valet Mode 10 SecureCode 10 The Status Light 11 Multi-Car Operation 12 Selecting CAR #1 or CAR #2 12 Controller Options12 LCD Screen Icons 12 In-Range Indicator 12 Setting The Clock 12 Changing remote start melodies 13 Power Save Mode 13 Selecting Melody & Vibrate modes13 Parking Timer & Remote Start Timer 13 Button Lock 13 Anti-Carjacking Protection 14 Programming Controllers/Transmitters 15 Programming Features 15 User Programmable Features 16 Installer Programmable Features 19 Programmable Features Matrix 23 2 ThE 2-WAy COnTROLLER Controller & Transmitter Overview Controller part number: 159-03 (w/ 2 CR2032 batteries) Call your dealer or visit www.caralarm.com to order replacement transmitters. Transmitter part number: 1411-03E (w/ 2 CR2016 batteries) Call your dealer or visit www.caralarm.com to order replacement transmitters. Transmitter battery replacement: Remove the small screw from the lower back case, and separate the transmitter halves Replace the battery with the same type and reassemble the transmitter case ThE 1-WAy TRAnSmiTTER LOCK / ARm: Press and release the “LOCK” button • THE SIREN WILL CHIRP & THE PARKING LIGHTS WILL FLASH ONCE • UPON RECEIVING CONFIRMATION FROM YOUR SYS- TEM, THE CONTROLLER WILL SHOW THE LOCK/ARM ICON AND BEEP ONCE nOTE: PRESSinG LOCK TWiCE in 5 SECOnDS STARTS ThE PARKinG TimER. ThE CLOCK WiLL ChAnGE TO 0:00 AnD START COunTinG in minuTES & hOuRS. Controller & Transmitter Functions Controller battery replacement: Slide the back cover (do not pry up) off the back of the case in the direction of the arrow Release the small black battery clips and pull up on the battery from the inside edge (closest to the other battery) Sometimes a small tool or the edge of the back cover is helpful in gently prying up the batteries Insert the new batteries, making sure to insert the edge beneath the “+” terminal fi rst. Slide the back cover back onto the case “lock” button “start” button “unlock” button “trunk” button “start” button “unlock” button “trunk” button programming button “lock” button 3 Controller & Transmitter Functions (cont’d) unLOCK / DiSARm: Press and rele…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012

Report No.：14A072111R-FR FCC ID： ELVNTNH Page 24 of 28 Interocean EMC Technology Corp. Test Report 7 Photographs of EUT Front View of EUT Rear View of EUT Report No.：14A072111R-FR FCC ID： ELVNTNH Page 25 of 28 Interocean EMC Technology Corp. Test Report FCC ID

START HOLDHOLD x2 BODY MATERIAL : ABS MT-11010 0.2 Eason YYSVictor A ± B C ± ± Battery: CR2016 x 2 FCC ID ： ELVNTNH Omega Part #1411 www.caralarm.com

Report No.：14A072111R-FR FCC ID： ELVNTNH Page 26 of 28 Interocean EMC Technology Corp. Test Report Inner View of EUT Antenna Location Report No.：14A072111R-FR FCC ID： ELVNTNH Page 27 of 28 Interocean EMC Technology Corp. Test Report Front View of Main Board Rear View of Main Board Report No.：14A072111R-FR FCC ID： ELVNTNH Page 28 of 28 Interocean EMC Technology Corp. Test Report Front View of Battery Rear View of Battery

Report No.：14A072111R-FR FCC ID： ELVNTNH Page 1 of 28 Interocean EMC Technology Corp. Test Report CFR 47 FCC Part 15.231 TEST REPORT Product： Transmitter Trade Name： N/A Model Number： #1411 FCC ID： ELVNTNH Prepared for Nutek Corporation NO. 167, Lane 235, Bauchiau Rd., Xindian District, New Taipei City 23145, Taiwan TEL.： +886 2 2918 9478 FAX.： +886 2 2917 9069 Prepared by Interocean EMC Technology Corp. No. 5-2, Lin 1, Tin-Fu, Lin-Kou Dist., New Taipei City, Taiwan 244, R.O.C. TEL.: +886 2 2600 6861 FAX.: +886 2 2600 6859 Remark: The test report consists of 28 pages in total. It shall not be reproduced except in full, without the written approval of IETC. This document may be altered or revised by IETC only, and shall be noted in the revision section of the document. The test result in the report is only subjected to the test sample. Report No.：14A072111R-FR FCC ID： ELVNTNH Page 2 of 28 Interocean EMC Technology Corp. Test Report Statement of Compliance Applicant: Nutek Corporation Manufacturer: Nutek Corporation Product: Transmitter Model No.: #1411 Tested Power Supply: 6Vdc Battery Date of Final Test: Jul. 22, 2014 Configuration of Measurements and Standards Used： FCC Rules and Regulations Part 15 Subpart C 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of IETC. Report Issued: 2014/07/31 Project Engineer: Approved: Elli Chang Jerry Liu Report No.：14A072111R-FR FCC ID： ELVNTNH Page 3 of 28 Interocean EMC Technology Corp. Test Report Table of Contents 1 Summary of Measurement 4 2 General Information 5 2.1 Description of Equipment Under Test 5 2.2 Details of Tested Peripheral Equipment 6 2.3 Test Facility 7 3 Test Specifications 8 3.1 Test Standard 8 3.2 Operation Mode 8 3.3 Test Step of EUT 8 3.4 Test Equipment 9 4 Radiated Emission Test 10 4.1 Limits 10 4.2 Calculation of Average Factor 11 4.3 Configuration of Measurement 16 4.4 Test Procedure 16 4.5 Test Result 16 5 Emission Bandwidth 20 5.1 Limits 20 5.2 Test Result 20 6 Photographs of Test 22 6.1 Radiated Emission Measurement 22 7 Photographs of EUT 24 Report No.：14A072111R-FR FCC ID： ELVNTNH Page 4 of 28 Interocean EMC Technology Corp. Test Report 1 Summary of Measurement Report Clause Test Parameter Reference Document CFR47 Part15 Results 4 Timing requirement §15.231(a) Pass 4 Radiated Emission §15.231(b), 15.209 Pass 5 Emission Bandwidth §15.231(c) Pass Report No.：14A072111R-FR FCC ID： ELVNTNH Page 5 of 28 Interocean EMC Technology Corp. Test Report 2 General Information 2.1 Description of Equipment Under Test Product : Transmitter Model Number : #1411 Applicant : Nutek Corporation NO. 167, Lane 235, Bauchiau Rd., Xindian District, New Taipei City 23145, Taiwan Manufacturer : Nutek Corporation NO. 167, Lane 235, Bauchiau Rd., Xindian District, New Taipei City 23145, Taiwan Power Supply : 6Vdc Battery Operating Frequency : 433.92MHz Type of Modulation : ASK Antenna Description : This device uses PCB Printed antenna. The antenna is integral to the device, thereby meeting the requirement of FCC 15.203. Date of Test : Jul. 01 ~ 22, 2014 Additional Description : 1) The Model Number “#1411” is representative selected in the test and included in this report. 2) For more detail specification about EUT, please refer to the user’s manual. Report No.：14A072111R-FR FCC ID： ELVNTNH Page 6 of 28 Interocean EMC Technology Corp. Test Report 2.2 Details of Tested Peripheral Equipment N/A Report No.：14A072111R-FR FCC ID： ELVNTNH Page 7 of 28 Interocean EMC Technology Corp. Test Report 2.3 Test Facility Site Description : OATS 1 Name of Firm : Interocean EMC Technology Corp. Company web : http://www.ietc.com.tw Location : No. 5-2, Lin 1, Tin-Fu, Lin-Kou Dist., New Taipei City, Taiwan 244, R.O.C. Site Filing : Federal Communication Commissions – USA Registration No.: 96399 (OATS 1, 2, 3 & Chamber 3) Designation No.: TW1020 Industry Canada (IC) OUR FILE: 46405-4437 Registration No. (OATS 1): Site# 4437A-1 Registration No. (OATS 3): Site# 4437A-3 Registration No. (Chamber 3): Site# 4437A-5 Registration No. (OATS 5): Site# 4437A-6 Voluntary Control Council for Interference by Information Technology Equipment (VCCI) – Japan Member No.: 1349 Registration No. (Conducted Room): C-1094 Registration No. (Conducted Room): T-1562 Registration No. (OATS 1): R-1040; G-274 Registration No. (OATS 2): R-1041 Site Accreditation : Bureau of Standards and Metrology and Inspection (BSMI) – Taiwan, R.O.C. Accreditation No.: SL2-IN-E-0026 for CNS13438 / CISPR 22 SL2-IN-E-0026 for CNS14757-2 / IEC 62040-2 SL2-R1-E-0026 for CNS13439 / CISPR 13 SL2-R2-E-0026 for CNS13439 / CISPR 13 SL2-A1-E-0026 for CNS13783-1 / CISPR 14-1 SL2-L1-E-0026 for CNS 14115 / CISPR 15 Taiwan Accreditation Foundation (TAF) Accreditation No.: 1113 Vehicle Safety Certification Center (VSCC) Approval No.: TW16-11-0 TüV NORD Certificate No: TNTW0801R-04 Nemko Authorisation No: AeLA 011 Authorisation No: ELA 181 Report No.：14A072111R-FR FCC ID： ELVNTNH Page 8 of 28 Interocean EMC Technology Corp. Test Report 3 Test Specifications 3.1 Test Standard The EUT was performed according to FCC Part 15 Subpart C Section 15.231 procedure and setup followed by ANSI C63.4, 2003 requirements. 3.2 Operation Mode By preliminary testing and verifying three axis (X, Y and Z) position of EUT transmitted status, it was found that “X axis” position was the worst, then the final test was executed the worst condition and test data were recorded in this report The EUT was operated in continuous transmission mode during all of the tests. X axis mode Y axis mode Z axis mode 3.3 Test Step of EUT 3.3.1 Setup the fixture to EUT for power supplying. 3.3.2 Turn on the power of all equipment. 3.3.3 Let the EUT continuous transmission. Executed the test. Report No.：14A072111R-FR FCC ID： ELVNTNH Page 9 of 28 Interocean EMC Technology Corp. Test Report 3.4 Test Equipment Instrument Manufacturer Model Serial No.…

Text truncated - open the document above for the full version.

Report No.：14A072111R-FR FCC ID： ELVNTNH Page 22 of 28 Interocean EMC Technology Corp. Test Report 6 Photographs of Test 6.1 Radiated Emission Measurement Front View (Frequency below 1GHz) Rear View (Frequency below 1GHz) Report No.：14A072111R-FR FCC ID： ELVNTNH Page 23 of 28 Interocean EMC Technology Corp. Test Report Front View (Frequency above 1GHz) Rear View (Frequency above 1GHz)
