Emergency Dialer UL Certified MODEL: GM-100 FCC Approved P/N. 101A365-001 Emergency Dialer USER'S INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool. 2. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. 3. Do not use the telephone to report a gas leak in the vicinity of the leak. 4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special disposal instructions. 5. Plug the adaptor to the socket-outlet that near the equipment and shall be easily accessible. 6. WHEN PROGRAMMING EMERGENCY NUMBERS AND (OR) MAKING TEST CALLS TO EMERGENCY NUMBERS: 1) Remain on the line and briefly explain to the dispatcher the reason for the call. 2) Perform such activities in the off-peak hours, such as early morning or late evenings. 7. Caution – To ensure proper operation, this equipment must be installed according to the enclosed installation instructions. To verify that the equipment is operating properly and can successfully report an alarm, this equipment must be tested immediately after installation, and periodically thereafter, according to the enclosed test instructions. 8. Caution – Verification of Line Seizure capability should be made imme diately after installation, and periodically thereafter, in order to ensure that this equipment can initiate a call even when other equipment (telephone, answering system, computer modem, etc.) connected to the same line is in use. SAVE THESE INSTRUCTIONS Attention This product is not an alarm system providing facilities to summon assistance, for use by persons who can be considered to be living at risk. This product is not intended to for use in health care signaling equipment or directly connect to central-station (Police, Medical, Fire). Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. In some cases, the company’s inside wiring associated with a single line individual service may be extended by means of a certified connector assembly (telephone extension cord). The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations. Repairs to certified equipment should be made by an authorized maintenance facility designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment. Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas. ‘’The Ringer Equivalence Number is an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed five.’’ CONTENT Introduction.........................................................................................................................4 Overview....................................................................................................................... 4 Installation.......................................................................................................................... 6 Emergency Dialer........................................................................................................ 6 Remote Control........................................................................................................... 7 Programming................................................................................................................... .8 Local Programming.................................................................................................... 8 Add Remote Controls / Sensors............................................................................... 9 Erase All Remote Controls / Sensors........................................................................ 9 Record Voice Message............................................................................................ 10 Remote Operation Range Test............................................................................... 10 Programming Emergency Phone Number.......................................................... 11 Operation....................................................................................................................... . 19 Panic Call................................................................................................................... 19 Speed-Dial (Non-Panic Call)................................................................................... 19 System Failure................................................................................................................. 20 Monitoring Station DTMF Control................................................................................. 21 INTRODUCTION Overview Congratulations on your purchase of the Emergency Dialer Model GM-100. The GM-100 is an advanced emergency dialer which is connected to a phone line for assistance to monitoring station during emergency thru 2-way voice conversation with Contact ID compatibil…

Text truncated - open the document above for the full version.

Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 To Whom It May Concern: Please be advised that Nutek Corporation authorizes Interocean EMC Technology Corp to act on our behalf, until otherwise notified, for applications submitted to American Telecommunications Certification Body, Inc. (ATCB) We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C.862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Charles Chen / President Nutek Corporation Tel: +886 2 2918 9478 Fax: +886 2 2917 9069 E-mail: [email protected]

Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 RE: Certification Application Data: Dec. 24, 2009 FCC ID: ELVUTII Confidentiality Request Pursuant to Section 0.459 of the Commission’s Rule, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: • Block Diagram • Schematics • Operational Description The above materials contain trade secrets and proprietary information not customarily released to the prublic. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. Thank you for your attention in this matter. Charles Chen / President Nutek Corporation Tel: +886 2 2918 9478 Fax: +886 2 2917 9069 E-mail: [email protected]

Report No.：9A121601FR FCC ID： ELVUTII Page 22 of 25 Interocean EMC Technology Corp. Test Report 7 Photographs of EUT Front View of EUT Rear View of EUT

B O D Y M A T E R I A L : A B S M T - 1 1 0 1 0 0 . 2 C ± B ± A ±

Report No.：9A121601FR FCC ID： ELVUTII Page 23 of 25 Interocean EMC Technology Corp. Test Report Inner View of EUT Antenna Location Report No.：9A121601FR FCC ID： ELVUTII Page 24 of 25 Interocean EMC Technology Corp. Test Report Component View of PCB Board Solder View of PCB Board-1 Report No.：9A121601FR FCC ID： ELVUTII Page 25 of 25 Interocean EMC Technology Corp. Test Report Solder View of PCB Board-2

Report No.：9A121601FR FCC ID： ELVUTII Page 1 of 25 Interocean EMC Technology Corp. Test Report CFR 47 FCC Part 15.231 TEST REPORT Product： Transmitter Trade Name： N/A Model Number： GM-TX 001 FCC ID： ELVUTII Prepared for Nutek Corporation NO.167, Lane 235, Bauchiau Rd., Shindian City, Taipei County 23145, Taiwan TEL.： +886 2 2918 9478 FAX.： +886 2 2917 9069 Prepared by Interocean EMC Technology Corp. 244 No.5-2, Lin 1, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei County, Taiwan, R.O.C. TEL.: +886 2 2600 6861 FAX.: +886 2 2600 6859 Remark: The test report consists of 25 pages in total. It shall not be reproduced except in full, without the written approval of IETC. This document may be altered or revised by IETC only, and shall be noted in the revision section of the document. The test results in the report only to the tested sample. Report No.：9A121601FR FCC ID： ELVUTII Page 3 of 25 Interocean EMC Technology Corp. Test Report Table of Contents 1 Summary of Measurement 4 2 General Information 5 2.1 Description of Equipment Under Test 5 2.2 Details of tested peripheral equipment 6 2.3 Test Facility 7 3 Test specifications 8 3.1 Test standard 8 3.2 Operation mode 8 3.3 Test Equipment 9 4 Radiated emission test 10 4.1 Limits 10 4.2 Calculation of Average Factor 11 4.3 Configuration of Measurement 16 4.4 Test Procedure 16 4.5 Test Result 16 5 Emission bandwidth 19 5.1 Limits 19 5.2 Test Result 19 6 Photographs of Test 21 6.1 Radiated Emission Measurement 21 7 Photographs of EUT 22 Report No.：9A121601FR FCC ID： ELVUTII Page 4 of 25 Interocean EMC Technology Corp. Test Report 1 Summary of Measurement Report Clause Test Parameter Reference Document CFR47 Part15 Results 4 Radiated Emission §15.231(b), 15.209 Pass 5 Emission bandwidth §15.231(c) Pass Report No.：9A121601FR FCC ID： ELVUTII Page 5 of 25 Interocean EMC Technology Corp. Test Report 2 General Information 2.1 Description of Equipment Under Test Product : Transmitter Model Number : GM-TX 001 Applicant : Nutek Corporation NO.167, Lane 235, Bauchiau Rd., Shindian City, Taipei County 23145, Taiwan Manufacturer : Nutek Corporation NO. 167, Lane 235, Bauchiau Rd., Shindian City, Taipei County 23145, Taiwan Power Supply : 3Vdc Battery Operating Frequency : 433.92MHz Channel Number : 1 channel Type of Modulation : ASK Antenna description : This device uses PCB antenna. The antenna is integral to the device, thereby meeting the requirement of FCC 15.203. Date of Receipt Sample : Dec. 16, 2009 Date of Test : Dec. 16 ~ 23, 2009 Additional Description : 1) The Model Number “GM-TX 001” is representative selected in the test and included in this report. 2) For more detail specification about EUT, please refer to the user’s manual. Report No.：9A121601FR FCC ID： ELVUTII Page 6 of 25 Interocean EMC Technology Corp. Test Report 2.2 Details of tested peripheral equipment N/A Report No.：9A121601FR FCC ID： ELVUTII Page 7 of 25 Interocean EMC Technology Corp. Test Report 2.3 Test Facility Site Description : OATS 2 Name of Firm : Interocean EMC Technology Corp. Company web : http://www.ietc.com.tw Site 1, 2 Location : No.5-2, Lin 1, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei County, Taiwan, R.O.C. Site 3, 4 Location : No. 12, Ruei-Shu Valley, Ruei-Ping Tsun, Lin-Kou Hsiang, Taipei County, Taiwan, R.O.C. Site Filing : z Federal Communication Commissions – USA Registration No.: 96399 (OATS 1 & 2) Registration No.: 518958 (OATS 3 & 4) Designation No.: TW1020 z Voluntary Control Council for Interference by Information Technology Equipment (VCCI) – Japan Member No.: 1349 Registration No. (Conducted Room): C-1094 Registration No. (Conducted Room): T-1562 Registration No. (OATS 1): R-1040 Registration No. (OATS 2): R-1041 z Industry Canada (IC) OUR FILE: 46405-4437 Submission: 130946 Registration No. (OATS 1): 4437A-1 Registration No. (OATS 2): 4437A-2 Registration No. (OATS 3): 4437A-3 Registration No. (OATS 4): 4437A-4 z Japan Electrical Safety & Environment Technology Laboratories (JET) Registration No.: 04S03-01 Site Accreditation : z Bureau of Standards and Metrology and Inspection (BSMI) – Taiwan, R.O.C. Accreditation No.: SL2-IN-E-0026 for CNS 13438 / CISPR 22 SL2-R1-E-0026 for CNS 13439 / CISPR 13 SL2-R2-E-0026 for CNS 13439 / CISPR 13 SL2-A1-E-0026 for CNS 13783-1 / CISPR 14-1 SL2-L1-E-0026 for CNS 14115 / CISPR 15 z Taiwan Accreditation Foundation (TAF) Accreditation No.: 1113 z TüV NORD Certificate No: TNTW0801R-02 Report No.：9A121601FR FCC ID： ELVUTII Page 8 of 25 Interocean EMC Technology Corp. Test Report 3 Test specifications 3.1 Test standard The EUT was performed according to FCC Part 15 Subpart C Section 15.231 procedure and setup followed by ANSI C63.4, 2003 requirements. 3.2 Operation mode By preliminary testing and verifying three axis (X, Y and Z) position of EUT transmitted status, it was found that “X axis” position was the worst, then the final test was executed the worst condition and test data were recorded in this report The EUT was operated in continuous transmission mode during all of the tests. X axis mode Y axis mode Z axis mode Report No.：9A121601FR FCC ID： ELVUTII Page 9 of 25 Interocean EMC Technology Corp. Test Report 3.3 Test Equipment Instrument ManufacturerModel Serial No. Next Cal. Date Spectrum Analyzer R&S FSP30 100002 2010/12/08 Spectrum Analyzer R&S FSP40 100478 2010/04/15 Preamplifier Agilent 8449B 3008A01434 2010/04/01 Horn Antenna COM-POWER AH-118 10081 2010/05/12 Horn Antenna Schwarzbeck BBHA 9120 9120D-583 2011/02/09 Horn Antenna Schwarzbeck BBHA 9170 213 2010/06/08 Wide Bandwidth Sensor Anritsu MA2491A 728133 2010/10/15 Power Meter Anritsu ML2495A 736010 2010/10/15 Temp & Humidity chamber GIAN FORCE GTH-150-40-2P-U MAA0305-012 2011/05/07 Note: The above equipments are within the valid calibration period. Report No.：9A121601FR FCC ID： ELVUTII Page 10 of 25 Interocean EMC Technology Corp. Test Report 4 Radiated emission test 4.1 Limits According to FCC 15.231(b) requirement: In addition to the provisions of §15.205, the field strength o…

Text truncated - open the document above for the full version.

Report No.：9A121601FR FCC ID： ELVUTII Page 21 of 25 Interocean EMC Technology Corp. Test Report 6 Photographs of Test 6.1 Radiated Emission Measurement Front View Rear View
