EMJ202R70Wireless Mouse

Manufacturer : PRIMAX ELECTRONICS LTD. Product Name : SCROLL POINT 4D RF MOUSE Model Number : RO07 User Manual How to Setup Transmitter & Receiver Step1 : Press receiver Setup button (below Receiver Module). Receiver Module “Data LED” will Keep ON, Indicate Now is prepare to Change ID code & RF channel. Step2 : Press Transmitter channel Setup button (below RF mouse). Receiver scan RF signal (send from mouse) and get desire channel. After 5 minutes mouse will into “SLEEP MODE” for power consumption and Only wakeup from button. Note : 66 (15ms) mean. Each Data Package is 15ms and per second can send out about 66 Data Package. Federal Communications Commission (FCC) Statement This Equipment has been tested and found to comply with the limits for FCC, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. You care cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.

Block Diagram

From: Charles Wang [[email protected]] Sent: Friday, February 16, 2001 9:41 PM To: Mike Kuo Cc: 'Nicki Cheng'; Chien chifangs Subject: Re: PRIMAX ELECTRONICS LTD.,FCC ID:EMJ202R70, Assessment no:AN01T1209 Dear Mike, In response to your questions, please see below. 1. Attached here is the test report in word format. 2. I asked our engineer for how to activate EUT during the tests, he said that the right button of EUT was held by a material to let it transmit as normal work. We could see the fundamental frequency on SPA to check whether the EUT actived or not. Since this case is very urgent, would you plesae release the FCC ID ASAP. Best regards, Charles Mike Kuo ¼g¹D¡G > Dear Nicki : > > Question #1 : Page 8 and Page 9 of test report still can not be read. > Please provide MS word file for these two pages only. > > Question #2 : The question # 2 of my previous e-mail did not answer fully. > I need to know how the device was activated during the tests ? If no > movements have been detected by the RF mouse, will RF mouse transmit as well > ? > > Best Regards > > Mike Kuo / Compliance Certification Services > > -----Original Message----- > From: Nicki Cheng [mailto:[email protected]] > Sent: Wednesday, February 14, 2001 10:28 PM > To: Mike Kuo > Cc: CharlesWang; Chien chifangs > Subject: RE: PRIMAX ELECTRONICS LTD.,FCC ID:EMJ202R70, Assessment > no:AN01T1209 > > Dear Mike, > > In reply to several questions raised as below, please > see our answers as embedded: > > Question #1: Page 8 and Page 9 can be read. Please > provide these two pages with Microsoft Word format. > > A: The test report format was adjusted accordingly. > Please refer to the attachment here. Though it is still > in PDF file, you should have no problem in reading > page 8 and 9 this time. > > Question #2: How do you activate the device during > the final test ? In the page 5 of test report, you indicated > the EUT was checked and stay in working status under test. > In accordance to the description of user manual, EUT will be > in Sleep mode in 5 minutes. How the device was continuously > transmitting during the tests? > > A: Before testing, we requested the manufacturer to disable > the sleeping mode for us. So during the test, the EUT will not > go into sleeping mode anytime. The EUT kept function > continuously. > > Question #3: As indicated in your test report, there is no 15.207 > tests was performed. However, you did provide the test setup > photo for 15.207 configuration. Please explain. > > A: Sorry, it is a negligence of us. The test report was corrected > accordingly. Please refer to the attachment here. > > Question #4: User manual does not contain the information > required by Section 15.21 of FCC rules. Ple ase provide revised > user manual. > > A: Thanks for your reminding. The User's Manual was revised as > attached. Please check. > > Hopefully we have fulfilled all requirements now. Your further > comments will be appreciated. > > Thanks & best regards, > > Nicki Cheng/ C&C Lab > February 15, 2001 > > -----Original Message----- > From: certadm [mailto:[email protected]] > Sent: None > To: [email protected]; [email protected] > Cc: [email protected] > Subject: PRIMAX ELECTRONICS LTD.,FCC ID:EMJ202R70, Assessment > no:AN01T1209 > > Notice_content > ------------- > Question #1: Page 8 and Page 9 can be read. Please > provide these two pages with Microsoft Word format. > > Question #2: How do you activate the device during > the final test ? In the page 5 of test report, you indicated > the EUT was checked and stay in working status under test. > In accordance to the description of user manual, EUT will be > in Sleep mode in 5 minutes. How the device was continuouly > transmitting during the tests? > > Question #3: As indicated in your test report, there is no 15.207 > tests was performed. However, you did provide the test setup > photo for 15.207 configuration. Please explain. > > Question #4: User manual does not contain the information > required by Section 15.21 of FCC rules. Please provide revised > user manual. > > Best Regards > > Mike Kuo / TCB Certifier. > The items indicated above must be submitted before > processing can continue on the above referenced application. > Failure to provide the requested information within 60 days of > the original e-mail date may result in application dismissal > and forfeiture of the filing fee. Also, please note that partial > responses increase processing time and should not be > submitted. Any questions about the content of this > correspondence should be directed to the e-mail > address listed below the name of the sender.

C&C Laboratory Co. Ltd. REPORT NO: RF00002 FCC ID:EMJ202R70 DATE:12/11/2000 Job Number: 000929 Accredited Lab. of NEMKO, A2LA, BSMI, CNLA NEMKO Authorization #: ELA 124 Page 22 Listed Lab. of FCC, VCCI, MoC A2LA Certificate #: 824-01 This report shall not be reproduced except in full, without the written approval of C&C Rev. 00 EXTERNAL

FCC ID Label sample of RF Mouse

C&C Laboratory Co. Ltd. REPORT NO: RF00002 FCC ID:EMJ202R70 DATE:12/11/2000 Job Number: 000929 Accredited Lab. of NEMKO, A2LA, BSMI, CNLA NEMKO Authorization #: ELA 124 Page 19 Listed Lab. of FCC, VCCI, MoC A2LA Certificate #: 824-01 This report shall not be reproduced except in full, without the written approval of C&C Rev. 00 INTERNAL C&C Laboratory Co. Ltd. REPORT NO: RF00002 FCC ID:EMJ202R70 DATE:12/11/2000 Job Number: 000929 Accredited Lab. of NEMKO, A2LA, BSMI, CNLA NEMKO Authorization #: ELA 124 Page 20 Listed Lab. of FCC, VCCI, MoC A2LA Certificate #: 824-01 This report shall not be reproduced except in full, without the written approval of C&C Rev. 00 C&C Laboratory Co. Ltd. REPORT NO: RF00002 FCC ID:EMJ202R70 DATE:12/11/2000 Job Number: 000929 Accredited Lab. of NEMKO, A2LA, BSMI, CNLA NEMKO Authorization #: ELA 124 Page 21 Listed Lab. of FCC, VCCI, MoC A2LA Certificate #: 824-01 This report shall not be reproduced except in full, without the written approval of C&C Rev. 00

Description of components of RF Mouse

C&C Laboratory Co. Ltd. REPORT NO: RF00002 FCC ID:EMJ202R70 DATE:12/11/2000 Job Number: 000929 Accredited Lab. of NEMKO, A2LA, BSMI, CNLA NEMKO Authorization #: ELA 124 Page 1 Listed Lab. of FCC, VCCI, MoC A2LA Certificate #: 824-01 This report shall not be reproduced except in full, without the written approval of C&C Rev. 00 ELECTROMAGNETIC EMISSONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF FCC ID: EMJ202R70 RF WIRELESS MOUSE MODEL NO: RO07 REPORT NO: RF00002 DEC. 11, 2000 Prepared for PRIMAX ELECTRONICS LTD. No. 669, Ruen Kuang Road, Neihu Taipei, Taiwan R.O.C. Prepared by C&C LABORATORY CO., LTD. #B1, 1 st FL., UNIVERSAL CENTER, NO.183, SEC.1, TATUNG RD., HSI CHIN, TAIPEI HSIEN, TAIWAN, R.O.C. TEL: (03) 324-0332 FAX: (03) 324-5235 C&C Laboratory Co. Ltd. REPORT NO: RF00002 FCC ID:EMJ202R70 DATE:12/11/2000 Job Number: 000929 Accredited Lab. of NEMKO, A2LA, BSMI, CNLA NEMKO Authorization #: ELA 124 Page 2 Listed Lab. of FCC, VCCI, MoC A2LA Certificate #: 824-01 This report shall not be reproduced except in full, without the written approval of C&C Rev. 00 TABEL OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE..........................................................................................................3 2. DESCRIPTION OF EQUIPMENT UNDER MEASUREMENT (EUT)...........................................................4 3. ANTENNA CONNECTION...............................................................................................................................4 4. CHANNEL USAGE............................................................................................................................................5 5. THEORY OF OPERATION...............................................................................................................................5 6. EUT SETUP FOR MEASUREMENT PURPOSE.............................................................................................5 7. MEASUREMENT LOCATION.........................................................................................................................5 8. SUPPORT EQUIPMENT...................................................................................................................................5 9. MEASUREMENT CONFIGURATION(SIGNAL PATH ONLY).....................................................................6 10. MEASUREMENT PROCEDURES AND MEASUREMENT RESULTS.............................................................6 RADIATED EMISSIONS (GENERAL REQUIREMENTS)................................................................................6 AC LINE CONDUCTED EMISSIONS........................................................................................................10 THE EMISSION LEVEL IN OPERATING BAND...........................................................................13 11. RADIATED EMISSION MEASUREMENT SETUP PHOTO.........................................................................17 12. AC LINE CONDUCTED EMISSION MEASUREMENT SETUP PHOTO....................................................18 C&C Laboratory Co. Ltd. REPORT NO: RF00002 FCC ID:EMJ202R70 DATE:12/11/2000 Job Number: 000929 Accredited Lab. of NEMKO, A2LA, BSMI, CNLA NEMKO Authorization #: ELA 124 Page 3 Listed Lab. of FCC, VCCI, MoC A2LA Certificate #: 824-01 This report shall not be reproduced except in full, without the written approval of C&C Rev. 00 1. VERIFICATION OF COMPLIANCE COMPANY NAME : PRIMAX ELECTRONICS LTD. No. 669, Ruen Kuang Road,Neihu Taipei, Taiwan R.O.C. CONTACT PERSON : Raymond Liang TELPHONE NO : 02-22993279 ext 377 EUT DESCRIPTION : RF WIRELESS MOUSE MODEM NAME : RO07 DATE OF MEASUREMENT: Dec. 05, 2000 LIMITES APPLY TO: FCC PART 15 SECTION 15.227 TECHNICAL LIMITS MEASUREMENT RESULT Radiated Emission/ 15.205 & 15.209 PASS AC Line Conducted Emission/15.207 PASS Emission in operating band/15.227 PASS The above equipment was tested by C&C Laboratory Co. Ltd. for compliance with the requirements set forth in CFR 47 PART 15, SUBPART C. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requires. Charles Wang/ Technical Director C&C Laboratory Co. Ltd. C&C Laboratory Co. Ltd. REPORT NO: RF00002 FCC ID:EMJ202R70 DATE:12/11/2000 Job Number: 000929 Accredited Lab. of NEMKO, A2LA, BSMI, CNLA NEMKO Authorization #: ELA 124 Page 4 Listed Lab. of FCC, VCCI, MoC A2LA Certificate #: 824-01 This report shall not be reproduced except in full, without the written approval of C&C Rev. 00 2. DESCRIPTION OF EQUIPMENT UNDER MEASUREMENT (EUT) RO07 is a wireless mouse product which allow its users to connect it to the USB port of PC through its receiver unit and wireless controlled by host mouse unit (Transmitter) to form a typical application as a traditional mouse Transmitter Technical Data Actual Operating Frequency 26.985 MHz to 27.26 MHz Transmit Power 0.75dBm Modulation scheme FSK Power consumption Maximum -------------------------------------------------25mA Standby -------------------------------------------------0.80mA Sleep -------------------------------------------------0.02mA (wake-up by clicking mouse key only) Channel 6 channel with 4 bit security ID for mouse Antenna type Antenna match at 27 MHz, integrated inside housing Operation range 1.5m (minimum) DC voltage 3V(2*AAA Alkaline battery for mouse) Receiver Technical Data PC interface type From USB interface DC voltage From PC Antenna type Wired-loop antenna integrated inside housing Receiver power consumption 60 mA Receiver dynamic range 0 dBm ~ 90 dBm 3. ANTENNA CONNECTION The RF wireless mouse equipped with an integrated antenna fixed permanently in transmitting unit, user can’t changeable. C&C Laboratory Co. Ltd. REPORT NO: RF00002 FCC ID:EMJ202R70 DATE:12/11/2000 Job Number: 000929 Accredited Lab. of NEMKO, A2LA, BSMI, CNLA NEMKO Authorization #: ELA 124 Page 5 Listed Lab. of FCC, VCCI, MoC …
