Page 1 CONSTRUCTION PHOTOS OF EUT

FCC ID: EMJDMORFBVUO FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

Page 2 Page 3

FCC ID: EMJDMORFBVUO Report No.: RF960823A06 Operational Description The transmitter of the EUT (Laser 2.4G 2-Way Wireless Travel Mice) is powered by 5Vdc host equipment. The type of antenna is Printed antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF960823A06 1 Report Format Version 2.0.6 FCC TEST REPORT REPORT NO.: RF960823A06 MODEL NO.: MS01-D, MORFBVUO1 RECEIVED: Aug. 23, 2007 TESTED: Sep. 3 ~ 14, 2007 ISSUED: Sep. 17, 2007 APPLICANT: PRIMAX ELECTRONICS LTD. ADDRESS: No. 669, Ruey Kuang Road, Neihu, Taipei, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. This test report consists of 32 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF960823A06 2 Report Format Version 2.0.6 Table of Contents 1. CERTIFICATION..........................................................................................3 2. SUMMARY OF TEST RESULTS..................................................................4 2.1 MEASUREMENT UNCERTAINTY...............................................................4 3. GENERAL INFORMATION..........................................................................5 3.1 GENERAL DESCRIPTION OF EUT............................................................5 3.2 DESCRIPTION OF TEST MODES..............................................................6 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.........................................6 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............7 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................8 3.4 DESCRIPTION OF SUPPORT UNITS........................................................8 4. TEST TYPES AND RESULTS......................................................................9 4.1 CONDUCTED EMISSION MEASUREMENT..............................................9 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT............................9 4.1.2 TEST INSTRUMENTS................................................................................9 4.1.3 TEST PROCEDURES...............................................................................10 4.1.4 DEVIATION FROM TEST STANDARD.....................................................10 4.1.5 TEST SETUP ...........................................................................................10 4.1.6 EUT OPERATING CONDITIONS..............................................................11 4.1.7 TEST RESULTS........................................................................................12 4.2 RADIATED EMISSION MEASUREMENT.................................................18 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................18 4.2.2 TEST INSTRUMENTS..............................................................................19 4.2.3 TEST PROCEDURES...............................................................................20 4.2.4 DEVIATION FROM TEST STANDARD.....................................................20 4.2.5 TEST SETUP ...........................................................................................21 4.2.6 EUT OPERATING CONDITIONS..............................................................21 4.2.7 TEST RESULTS........................................................................................22 4.3 BAND EDGES MEASUREMENT..............................................................27 4.3.1 LIMITS OF BAND EDGES MEASUREMENT............................................27 4.3.2 TEST INSTRUMENTS..............................................................................27 4.3.3 TEST PROCEDURE.................................................................................27 4.3.4 DEVIATION FROM TEST STANDARD.....................................................27 4.3.5 EUT OPERATING CONDITION................................................................27 4.3.6 TEST RESULTS........................................................................................27 5. PHOTOGRAPHS OF THE TEST CONFIGURATION.................................30 6. INFORMATION ON THE TESTING LABORATORIES...............................31 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB......................................................32 Report No.: RF960823A06 3 Report Format Version 2.0.6 1. CERTIFICATION PRODUCT: Laser 2.4G 2-Way Wireless Travel Mice MODEL NO.: MS01-D BRAND NAME: ICON7 MORFBVUO1 BRAND NAME: PRIMAX APPLICANT: PRIMAX ELECTRONICS LTD. TESTED: Sep. 3 ~ 14, 2007 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249), ANSI C63.4-2003 The above equipment (model no.: MS01-D) has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Sep. 17, 2007 ( Celia Chen / Specialist ) TECHNICAL ACCEPTANCE : , DATE: Sep. 17, 2007 Responsible for RF ( Jamison Chan / Senior Engineer ) APPROVED BY : , DATE: Sep. 17, 2007 ( Ken Liu / Deputy Manager ) Report No.: RF960823A06 4 Report Format Version 2.0.6 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD PARAGRAPH TEST TYPE RESULT REMARK 15.207 Conducted Emission Test PASS Minimum passing margin is –10.28dB at 0.150MHz 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 12.209 PASS Minimum passing margin is –7.93dB at 2483.500MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following mea…
