EMJDMORFDIUOA-D2.4G Wireless Dongle

HP 2.4G Wireless Mouse USRE MANUAL User’s Quick Guide This guide will take you through all the functions of the mouse and explain how to configure them using the mouse. Introduction Congratulations on your purchase of the HP 2.4G Wireless Mouse. This mouse is the latest in a wide range of computer peripherals manufactured by HP and is designed to provide you with the highest level of comfort available while also allowing for maximum functionality. Contents of the Package:
HP 2.4G Wireless Mouse
HP 2.4G Dongle
Two AA Battery
User’s Quick Guide Safety Guidelines Physical discomfort and injury can be caused by the incorrect use of your mouse. Follow these guidelines to ensure such problems are avoided: Sit up straight in your chair, with your elbows by your side. Adjust the height of your chair so your arm bends at a 90-degree angle respective to your desk. Position your mouse in front you, to the side of your keyboard. Do not slouch or hunch over your workspace. It is important to keep your wrists, arms and shoulders relaxed. If necessary, use a wrist rest or a palm rest to alleviate extra stress placed on your joints when typing or using the mouse, especially for long periods of time. If you experience any feelings numbness, cramp, swelling or stiffness in your wrist, arms, neck or shoulders, consult your local doctor or nearest health institution immediately. Navigating HP 2.4G Wireless Mouse The simple and straightforward interface makes it easy for you to customize each function of your mouse. Different settings are indicated by the tabs on the top of the screen. Click on the links to enter each settings screen. Changing Button Settings You can configure each of the five mouse buttons through the button settings screen. The ' Select Button' list displays the list of buttons and their current function. The 'Select Task' list displays a list of actions you can take to configure the button highlighted in the 'Select Button' list. Move your mouse over the ' Select Button' list and click each item to view more information. Restore Defaults Each setting screen has a Restore Defaults button. Click to restore all settings to their original defaults. The Left and Right Click Buttons By default, the left mouse button is set to operate as a standard left click button. The right mouse button is set to operate as a standard right click button. HP 2.4G Wireless Mouse USRE MANUAL If you want to swap these two button functions, check the Swap Buttons checkbox. Click to save all changes. The Middle Mouse Button By default, the mouse wheel is set to operate as Middle Button when pressed. Select the function you wish to assign to the middle button by checking the radio buttons in the Select Task list. Click to save all changes. Move your mouse over and click any of the Select Task list options for more detailed information. Side Button 1 By default, the button is set to operate as Backward when pressed. Select the function you wish to assign to the button by checking the radio buttons in the Select Task list. Click to save all changes. Move your mouse over and click any of the Select Task list options for more detailed information. Side Button 2 By default, the button is set to operate as Forward when pressed. Select the function you wish to assign to the button by checking the radio buttons in the Select Task list. Click to save all changes. Move your mouse over and click any of the Select Task list options for more detailed information. Middle Mouse Button Select to assign the button to Middle Mouse Button by checking the radio buttons in the Select Task list. Click to save all changes. Move your mouse over and click any of the Select Task list options for more detailed information. 3D Flip Select to switch between running programs when you click the mouse wheel. An application list appears Windows XP: Windows Vista: Roll the mouse wheel to scroll up and down the list. Click any mouse button to switch to the selected application. Forward When you press the button, the page you visited before you pressed the Backward button is displayed in your browser. Click to save all changes. Backward When you press the button, the last page you visited in your browser is displayed. Click to save all changes. HP 2.4G Wireless Mouse USRE MANUAL Others Select to execute one of a set of other pre-defined functions when you press the button. A drop down menu will appear. Select an application from the following list: Click to save all changes. Change Wheel Settings You can configure the wheel settings in the wheel settings screen. The 'Scrolling Speed' section allows you to adjust the scroll speed when you scroll the wheel vertically. The ' Horizontal Scrolling' section allows you to adjust the scroll speed when you scroll the wheel horizontally (tilt left/right). Mouse Wheel Select the scrolling speed you want by clicking the Scrolling Speed options: Scroll: Click the radio button and use the up/down arrows to increase/decrease the speed. Scroll one screen per notch: Click the radio button to choose scroll down by screen when you move the mouse wheel. Click to save all changes. HP 2.4G Wireless Mouse USRE MANUAL Horizontal Scrolling Move the slider to the left/right to decrease/increase the horizontal scrolling speed. Click to save all changes. Double-Click Speed Move the slider to set the pointer movement speed. Move the point in the Test Area to test your new setting. Test Area Click to save all changes. HP 2.4G Wireless Mouse USRE MANUAL Page 5 of 9 Slow Motion Check to enable the slow motion function by pressing the Shift key. Click to save all changes. Pointer Wrap Check to enable the "go through" function. Click to save all changes. Show icon in the system tray Click to display the icon in the system tray when the Mouse Suite software is running. Click this icon to bring up the main screen HP 2.4G Wireless Mouse USRE MANUAL Page 6 of 9 Troubleshooting Question: My mouse is not working. What should I do? A…

Text truncated - open the document above for the full version.

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Date: January 11, 2011 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: EMJDMORFDIUOA-D Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) FOR THE FOLLOWING EQUIPMENT: PRODUCT NAME: 2.4G Wireless Dongle MODEL NO.: MORFDIUOA-D TRADE NAME: HP IS HEREWITH CONFIRMED AND FOUND TO COMPLY WITH THE REQUIREMENTS OF CFR 47 PART 15 REGULATION. THE RESULTS OF ELECTROMAGNETIC EMISSION EVALUATION ARE SHOWN IN THE REPORT NO.: FD991223D09 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND, (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THE FOLLOWING LOCAL MANUFACTURER/IMPORTER IS RESPONSIBLE FOR THIS DECLARATION： PRIMAX ELECTRONICS LTD. (COMPANY NAME) No. 669, Ruey Kuang Road, Neihu, Taipei, Taiwan, R.O.C. (COMPANY ADDRESS) TEL： +886-2-2798-9008 FAX：+886-2-8797-1565 C.T. Huang Director (NAME) (TITLE) Jan. 11, 2011 (SIGNATURE) (DATE)

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Power of Attorney Date: January 12, 2011 To whom it may concern: We, the undersigned PRIMAX ELECTRONICS LTD. hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan Branch on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, --------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Brand: HP, Model: MORFDIUOA-D

Page 2 Brand: HP, Model: MORFDIUOA-D Page 3

FCC ID: EMJDMORFDIUOA-D Report No.: RF991223D09 Operational Description The transmitter of the EUT (2.4G Wireless Dongle) is powered by 5Vdc from host equipment. The type of antenna is Printed Antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF991223D09 1 Report Format Version 4.0.0 FCC TEST REPORT REPORT NO.: RF991223D09 MODEL NO.: MORFDIUOA-D FCC ID: EMJDMORFDIUOA-D RECEIVED: Dec. 15, 2010 TESTED: Dec. 15 ~ 24, 2010 ISSUED: Jan. 10, 2011 APPLICANT: PRIMAX ELECTRONICS LTD. ADDRESS: No. 669, Ruey Kuang Road, Neihu, Taipei, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 30 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF991223D09 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD..............................................................................3 1. CERTIFICATION..........................................................................................4 2. SUMMARY OF TEST RESULTS..................................................................5 2.1 MEASUREMENT UNCERTAINTY...............................................................5 3. GENERAL INFORMATION..........................................................................6 3.1 GENERAL DESCRIPTION OF EUT............................................................6 3.2 DESCRIPTION OF TEST MODES..............................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.........................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...........................10 3.4 DESCRIPTION OF SUPPORT UNITS......................................................10 4. TEST TYPES AND RESULTS....................................................................11 4.1 CONDUCTED EMISSION MEASUREMENT............................................11 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT..........................11 4.1.2 TEST INSTRUMENTS..............................................................................11 4.1.3 TEST PROCEDURES...............................................................................12 4.1.4 DEVIATION FROM TEST STANDARD.....................................................12 4.1.5 TEST SETUP............................................................................................12 4.1.6 EUT OPERATING CONDITIONS..............................................................13 4.1.7 TEST RESULTS........................................................................................14 4.2 RADIATED EMISSION MEASUREMENT.................................................16 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................16 4.2.2 TEST INSTRUMENTS..............................................................................17 4.2.3 TEST PROCEDURES...............................................................................18 4.2.4 DEVIATION FROM TEST STANDARD.....................................................18 4.2.5 TEST SETUP............................................................................................19 4.2.6 EUT OPERATING CONDITIONS..............................................................19 4.2.7 TEST RESULTS........................................................................................20 4.3 BAND EDGES MEASUREMENT..............................................................25 4.3.1 LIMITS OF BAND EDGES MEASUREMENT............................................25 4.3.2 TEST INSTRUMENTS..............................................................................25 4.3.3 TEST PROCEDURE.................................................................................25 4.3.4 DEVIATION FROM TEST STANDARD.....................................................25 4.3.5 EUT OPERATING CONDITION................................................................25 4.3.6 TEST RESULTS........................................................................................25 5. PHOTOGRAPHS OF THE TEST CONFIGURATION.................................28 6. INFORMATION ON THE TESTING LABORATORIES...............................29 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB......................................................30 Report No.: RF991223D09 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release N/A Jan. 10, 2011 Report No.: RF991223D09 4 Report Format Version 4.0.0 1. CERTIFICATION PRODUCT: 2.4G Wireless Dongle BRAND NAME: HP MODEL NO.: MORFDIUOA-D APPLICANT: PRIMAX ELECTRONICS LTD. TESTED: Dec. 15 ~ 24, 2010 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 ANSI C63.10-2009 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Celia Chen / Senior Specialist ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No.: RF991223D09 5 Report Format Version 4.0.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD SECTION TEST TYPE AND LIMIT RESULT REMARK 15.207 Conducted Emission Test PASS Minimum passing margin is –16.85dB at 0.162MHz 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radi…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST
