EMJDMORFE4UL2-DRocketfish 2.4G Wireless Dongle

2.4 GHz Wireless Combo RF-RCMBO2 User Guide RF-RCMBO2_10-1280_MAN_V1_English.fm Page 1 Wednesday, December 15, 2010 9:02 AM 2 2.4 GHz Wireless Combo Contents Important safety instructions ..................................... 3 Introduction ...................................................................... 4 Features............................................................................... 4 Package contents .................................................. 5 System requirements ........................................... 5 Keyboard top.......................................................... 5 Keyboard status LED............................................. 7 Keyboard bottom .................................................. 7 Mouse top ................................................................ 8 Mouse status LED .................................................. 8 Mouse bottom ........................................................ 9 Setting up the keyboard and mouse......................10 Installing keyboard batteries...........................10 Installing the mouse batteries ........................11 Setting up the keyboard and mouse............13 RF-RCMBO2_10-1280_MAN_V1_English.fm Page 2 Wednesday, December 15, 2010 8:59 AM 3 RF-RCMBO2 Using the combo driver .............................................. 14 Installing the combo driver ............................. 14 Configuring the mouse ..................................... 14 Uninstalling the combo driver........................ 19 Maintaining ..................................................................... 20 Troubleshooting............................................................ 20 Specifications.................................................................. 21 Legal notices ................................................................... 22 One-year limited warranty ......................................... 25 Important safety instructions 1Read these instructions. 2Keep these instructions. 3Heed all warnings. 4Follow all instructions. 5Do not use this apparatus near water. 6Clean only with dry cloth. 7Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 8Only use attachments/accessories specified by the manufacturer. 9To reduce the risk of fire or electric shock, do not expose this device to rain, moisture, dripping, or splashing, and no objects filled with liquids, such as vases, shall be placed on it. 10Batteries should not be exposed to excessive heat such as sunshine, fire, or the like. Caution: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. RF-RCMBO2_10-1280_MAN_V1_English.fm Page 3 Wednesday, December 15, 2010 8:59 AM 4 Introduction Congratulations on your purchase of a Rocketfish 2.4 GHz Wireless Combo. This guide explains how to correctly operate and get the best performance from your wireless keyboard and mouse. Read this user guide carefully before using your product, then keep it next to your computer for quick reference. Features •Keyboard •104-key design • Eighteen hotkeys • One connect button • Power switch •Soft palm rest • Laser mouse • Tilt/ scroll wheel • Three mouse buttons • Two hotkey buttons • One pairing button • Power switch •Power saving mode •Working range up to 10 meters (line-of-sight) • Dual color status LED indicator If any item is missing or damaged, contact Rocketfish at 1-800-620-2790. RF-RCMBO2_10-1280_MAN_V1_English.fm Page 4 Wednesday, December 15, 2010 8:59 AM 5 RF-RCMBO2 Package contents Before you start using your keyboard and mouse the first time, verify that your package contains the following: •Keyboard •Laser Mouse • 2.4 GHz receiver • Installation CD • Batteries for the keyboard and mouse •Quick setup guide System requirements • Computer with a USB port • Microsoft Windows® XP Service Pack 3 or higher, Windows® Vista, Windows® 7 Note: For optimal performance, we recommend that you place the dongle on the front of the computer. Keyboard top #IconDescription 1 Calculator button. Press to open the open the calculator. 2 Application Switch button. Press to switch between open programs. 3 Play/Pause button. Press to start or pause CD or DVD playback. EscF1F2F3F4F5F6F7F8F9F10F11F12 Prt Scr Screen Insert Backspace Enter Enter AltCtrl Caps Lock Ta b AltCtrl Page Up Page Down + = _ - - - )( * * &^%$#@!~ ` _ / + Delete Scroll End Home Home 798 End 1 1 0 23 4 5 6 7 8 9 QP { [ { [ \ / WE R T Y U I O A : ; " ' SDFGHJ KL ZXCVB NM < , . > ? Ins 0 Del . 4 PgUp 3 PgDn Num Lock 65 2 ShiftShift Pause Break Lock 13121110 14 16 18 20 22 15 17 19 21 1 3 5 7 9 2 4 6 8 RF-RCMBO2_10-1280_MAN_V1_English.fm Page 5 Wednesday, December 15, 2010 8:59 AM 6 4 Stop button. Press to stop CD or DVD playback. 5 Previous track button. Press to go to the previous track on a CD or previous chapter on a DVD. 6 Next track button. Press to go to the next track on a CD or next chapter on a DVD. 7 Increase volume button. Press to increase the volume. 8 Decrease volume button. Press to decrease the volume. 9 Mute volume button. Press to mute the sound. Press again to unmute the sound. 10 Help button. Press to open online help for the currently active application. 11 Spelling button. Press to run the spell checker for the currently active program (if available). 12 Slideshow button. Press to enter slideshow mode in Wondows Picture and Fax Viewer. 13 Status LED. For more information, see “Keyboard status LED” on page 7. 14 E-mail button. Press to open your e-mail program. 15 Sleep button. Press to put your computer in sleep mode. Press again to wake your computer. 16 Home button. Press to go to your home page in a Web browser. 17 Search button. Press to open the Search window. 18 My Favorite button. Press to open the list of your favorite Web sites. 19 Back Web page button. Press to go to the previous page in a Web browser. 20 Forward Web page button.…

Text truncated - open the document above for the full version.

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Date: December 24, 2010 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: EMJDMORFE4UL2-D Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Power of Attorney Date: December 24, 2010 To whom it may concern: We, the undersigned PRIMAX ELECTRONICS LTD. hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan Branch on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ----------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT

Rocketfish 2.4G Wireless Dongle Model No.:RF-RCMBO2 FCC ID:EMJDMORFE4UL2-D IC:4251A-DMORFE4UL2D S/N:YYMDDAXXXXXX Rocketfish 2.4G Wireless Dongle Model No.:RF-RCMBO2 FCC ID:EMJDMORFE4UL2-D IC:4251A-DMORFE4UL2D S/N:YYMDDAXXXXXX 4:1

LABEL LOCATION Label

Page 2 Page 3

FCC ID: EMJDMORFE4UL2-D Report No.: RF991201D10 Operational Description The transmitter of the EUT (Rocketfish 2.4G Wireless Dongle) is powered by 5Vdc from host equipment. The type of antenna is Chip Antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF991201D10 1 Report Format Version 4.0.0 FCC TEST REPORT REPORT NO.: RF991201D10 MODEL NO.: RF-RCMBO2 (For Dongle) FCC ID: EMJDMORFE4UL2-D RECEIVED: Dec. 1, 2010 TESTED: Dec. 2 ~ 3, 2010 ISSUED: Dec. 24, 2010 APPLICANT: PRIMAX ELECTRONICS LTD. ADDRESS: No. 669, Ruey Kuang Road, Neihu, Taipei, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 29 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF991201D10 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD..............................................................................3 1. CERTIFICATION..........................................................................................4 2. SUMMARY OF TEST RESULTS..................................................................5 2.1 MEASUREMENT UNCERTAINTY...............................................................5 3. GENERAL INFORMATION..........................................................................6 3.1 GENERAL DESCRIPTION OF EUT............................................................6 3.2 DESCRIPTION OF TEST MODES..............................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.........................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................9 3.4 DESCRIPTION OF SUPPORT UNITS........................................................9 4. TEST TYPES AND RESULTS....................................................................10 4.1 CONDUCTED EMISSION MEASUREMENT............................................10 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT..........................10 4.1.2 TEST INSTRUMENTS..............................................................................10 4.1.3 TEST PROCEDURES...............................................................................11 4.1.4 DEVIATION FROM TEST STANDARD.....................................................11 4.1.5 TEST SETUP............................................................................................11 4.1.6 EUT OPERATING CONDITIONS..............................................................12 4.1.7 TEST RESULTS........................................................................................13 4.2 RADIATED EMISSION MEASUREMENT.................................................15 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................15 4.2.2 TEST INSTRUMENTS..............................................................................16 4.2.3 TEST PROCEDURES...............................................................................17 4.2.4 DEVIATION FROM TEST STANDARD.....................................................17 4.2.5 TEST SETUP............................................................................................18 4.2.6 EUT OPERATING CONDITIONS..............................................................18 4.2.7 TEST RESULTS........................................................................................19 4.3 BAND EDGES MEASUREMENT..............................................................24 4.3.1 LIMITS OF BAND EDGES MEASUREMENT............................................24 4.3.2 TEST INSTRUMENTS..............................................................................24 4.3.3 TEST PROCEDURE.................................................................................24 4.3.4 DEVIATION FROM TEST STANDARD.....................................................24 4.3.5 EUT OPERATING CONDITION................................................................24 4.3.6 TEST RESULTS........................................................................................24 5. PHOTOGRAPHS OF THE TEST CONFIGURATION.................................27 6. INFORMATION ON THE TESTING LABORATORIES...............................28 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB......................................................29 Report No.: RF991201D10 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release N/A Dec. 24, 2010 Report No.: RF991201D10 4 Report Format Version 4.0.0 1. CERTIFICATION PRODUCT: Rocketfish 2.4G Wireless Dongle BRAND NAME: Rocketfish MODEL NO.: RF-RCMBO2 APPLICANT: PRIMAX ELECTRONICS LTD. TESTED: Dec. 2 ~ 3, 2010 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 ANSI C63.10-2009 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Annie Chang / Senior Specialist ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No.: RF991201D10 5 Report Format Version 4.0.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD SECTION TEST TYPE AND LIMIT RESULT REMARK 15.207 Conducted Emission Test PASS Minimum passing margin is –14.65dB at 0.792MHz 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamen…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST
