EMJKKBRF327112.4G Dolphin keyboard

Q6136 W4500 Keyboard Installing your W4500 Keyboard English A 1. Install two AA batteries in your keyboard and one AA battery in your mouse. 2. Get the USB dongle from your keyboard and connect it to your computer’s USB port. 3. Press the power button for about two seconds to turn on your keyboard. B 1. Short press the power button to play or pause the music or video. 2. Rotate the upper layer knob clockwise to increase or counter-clockwise to decrease volume. 3. Rotate the bottom layer knob clockwise to zoom in or counter-clockwise to zoom out an image. 4. Press to go to the previous track in an active media player. 5. Press to go to the next track in an active media player. 6. Press to turn the sound on/off. 7. Press to launch the default browser in Windows OS. 8. Press to launch the default email client in Windows OS. A Keyboard Functions and Hotkeys B Español Polski Italiano Activity LED StatusDescription On and then off after 2 seconds Loading battery, turning on the keyboard On and then off after 3 seconds Turning off the keyboard Blinking Low battery USB dongle compartment Battery compartmentMouse Bottom side Top side Power button Upper layer knob Bottom layer knob Activity LED Previous track Next track Mute Launch browser Launch email client Battery compartment Français Deutsch 繁體中文 簡體中文 A 1. Installare due batterie AA nella tastiera e una batteria AA nel mouse. 2. Prelevare il dongle USB dalla tastiera ed inserirlo nella porta USB del computer. 3. Per accendere la tastiera, premere per un paio di secondi il pulsante di accensione. B 1. Premere rapidamente il pulsante di accensione per riprodurre o sospendere un file musicale o di un file video. 2. Ruotare la ghiera superiore in senso orario per aumentare o in senso antiorario per ridurre il volume. 3. Ruotare la ghiera inferiore in senso orario per ingrandire o in senso antiorario per ridurre le dimensioni di un’immagine. 4. Premere per passare alla riproduzione precedente. 5. Premere per passare alla riproduzione successiva. 6. Premere per attivare/disattivare l’audio. 7. Premere per avviare il browser predefinito nel sistema operativo Windows. 8. Premere per avviare il client di posta elettronica predefinito nel sistema operativo Windows. A 1. 請安裝兩顆 3 號（AA）電池於您的鍵盤中， 並安裝一顆 3 號（AA）電池於滑鼠中。 2. 從鍵盤中取出 USB 接收器，並插入電腦的 USB 連接埠。 3. 按住電源按鈕（power button）二秒來開啟 / 關閉鍵盤。 B 1. 按一下按鈕（同電源鈕）可控制多媒體程式 播放或暫停音樂或視訊。 2. 順時針旋轉上層旋鈕（upper layer knob）提高 系統音量，逆時針旋轉降低系統音量。 3. 順時針旋轉下層旋鈕（bottom layer knob）可 放大相片，逆時針旋轉可縮小相片。 4. 按下 前往目前媒體播放器的前一軌。 5. 按下 前往目前媒體播放器的下一軌。 6. 按下 開啟 / 靜音系統音量。 7. 按下 在 Windows 作業系統中開啟預設的 瀏覽器。 8. 按下 在 Windows 作業系統中開啟預設的 email 用戶端。 A 1. 請安裝兩節 5 號（AA）電池於您的鍵盤中， 並安裝一節 5 號（AA）電池於鼠標中。 2. 從鍵盤中取出 USB 接收器，並插入電腦的 USB 接口。 3. 按住電源按鈕（power button）兩秒來開啟 鍵盤。 B 1. 按一下按鈕（同電源鈕）可控制多媒體程序 播放或暫停音樂或視頻。 2. 順時針旋轉上層旋鈕（upper layer knob）提 高系統音量，逆時針旋轉降低系統音量。 3. 順時針旋轉下層旋鈕（bottom layer knob） 可放大照片，逆時針旋轉可縮小照片。 4. 按下 前往當前媒體播放器的前一軌。 5. 按下 前往當前媒體播放器的下一軌。 6. 按下 開啟/關閉系統聲音。 7. 按下 在 Windows 操作系統中開啟默認的 瀏覽器。 8. 按下 在 Windows 操作系統中開啟默認的 email 客戶端。 A 1. Legen Sie zwei AA-Batterien in die Tastatur und eine AA-Batterie in die Maus ein. 2. Nehmen Sie den USB-Dongle von Ihrer Tastatur und stecken Sie ihn in einen freien USB- Anschluss Ihres Computers. 3. Drücken Sie die EIN-/AUS-Taste (1) für ca. 2 Sekunden, um Ihre Tastatur ein-/auszuschalten. B 1. Drücken Sie die EIN-/AUS-Taste (1), um Musik oder Videos abzuspielen oder anzuhalten. 2. Drehen Sie den oberen Regler (2) in Uhrzeigerrichtung, um die Lautstärke zu erhöhen oder entgegen dem Uhrzeigersinn, um die Lautstärke zu senken. 3. Drehen Sie den unteren Regler (3) in Uhrzeiger- sinn, um ein Foto zu vergrößern oder entgegen dem Uhrzeigersinn, um es zu verkleinern. 4. drücken, um im Mediaplayer zum vorherigen Titel zu springen. 5. drücken, um im Mediaplayer zum nächsten Titel zu springen. 6. drücken, um den Ton ein-/auszuschalten. 7. drücken, um im Windows Betriebssystem den Standard-Browser zu laden. 8. drücken, um im Windows Betriebssystem das Standard E-Mail-Programm zu laden. A 1. Instale dos pilas AA en el teclado y una pila AA en el ratón. 2. Extraiga el transmisor USB del teclado y conéctelo a un puerto USB del equipo. 3. Mantenga pulsado el botón de encendido durante aproximadamente dos segundos para encender/ apagar el teclado. B 1. Pulse el botón de encendido para reproducir o efectuar una pausa durante la reproducción de música o vídeo. 2. Gire el mando superior hacia la derecha para aumentar el volumen del sistema o hacia la izquierda para reducirlo. 3. Gire el mando inferior hacia la derecha para acercar una fotografía o hacia la izquierda para alejarla. 4. Pulse el botón para seleccionar el elemento anterior de la lista de reproducción del reproductor multimedia activo. 5. Pulse el botón para seleccionar el elemento siguiente de la lista de reproducción del reproductor multimedia activo. 6. Pulse el botón para activar/desactivar el modo de silencio del control de volumen. 7. Pulse el botón para iniciar Internet Explorer en el sistema operativo Windows. 8. Pulse el botón para iniciar el cliente de correo electrónico predeterminado en el sistema operativo Windows. A 1. Installez deux piles dans le clavier et une pile dans la souris . 2. Récupérez le dongle USB de votre clavier et connectez-le à l’un des ports USB de votre ordinateur. 3. Appuyez sur le bouton Lecture/Pause pendant environ 2 secondes pour allumer ou éteindre le clavier. B 1. Appuyez légèrement sur le bouton Lecture/Pause pour lancer ou suspendre la lecture d’un fichier audio ou vidéo. 2. Tournez la molette rotative supérieure vers la droite/gauche pour augmenter/décroître le volume. 3. Tournez la molette rotative inférieure vers la droite/gauche pour effectuer un zoom avant/arrière sur une image. 4. Appuyez sur pour retourner au morceau/ chapitre précédent lors de la lecture d’un fichier multimédia. 5. Appuyez sur pour aller au morceau/chapitre suivant lors de la lecture d’un fichier multimédia. 6. Appuyez sur pour activer ou désactiver le son. 7. Appuyez su…

Text truncated - open the document above for the full version.

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Date: December 9, 2010 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: EMJKKBRF32711 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

No. 669, Ruey Kuang Road Neihu Taipei, Taiwan, R.O.C. Tel: 883-2-2798-9008 Fax: 886-2-8798-1565 Power of Attorney Date: December 9, 2010 To whom it may concern: We, the undersigned PRIMAX ELECTRONICS LTD. hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan Branch on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ----------------------------- C.T. Huang Compliance Dept. / Director Phone: 886-2-2798-9008 ext.1710 Fax: 886-2-8797-1565 Email: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT

LABEL LOCATION Label

Page 2 Page 3 Page 4 Page 5 Page 6

Report No.: RF991111D04 R1 1 Report Format Version 4.0.0 Cancels and replaces the report No.:RF991111D04 dated Dec. 6, 2010 FCC TEST REPORT REPORT NO.: RF991111D04 R1 MODEL NO.: KBRF32711, CO03-K, KW03 FCC ID: EMJKKBRF32711 RECEIVED: Nov. 11, 2010 TESTED: Nov. 26, 2010 ISSUED: Dec. 8, 2010 APPLICANT: PRIMAX ELECTRONICS LTD. ADDRESS: No. 669, Ruey Kuang Road, Neihu, Taipei, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 24 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF991111D04 R1 2 Report Format Version 4.0.0 Cancels and replaces the report No.:RF991111D04 dated Dec. 6, 2010 Table of Contents RELEASE CONTROL RECORD..............................................................................3 1. CERTIFICATION...........................................................................................4 2. SUMMARY OF TEST RESULTS...................................................................5 2.1 MEASUREMENT UNCERTAINTY................................................................5 3. GENERAL INFORMATION...........................................................................6 3.1 GENERAL DESCRIPTION OF EUT..............................................................6 3.2 DESCRIPTION OF TEST MODES................................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST...........................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL................8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...............................9 3.4 DESCRIPTION OF SUPPORT UNITS..........................................................9 4. TEST TYPES AND RESULTS.....................................................................10 4.1 CONDUCTED EMISSION MEASUREMENT..............................................10 4.2 RADIATED EMISSION MEASUREMENT...................................................10 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.................................10 4.2.2 TEST INSTRUMENTS................................................................................11 4.2.3 TEST PROCEDURES.................................................................................12 4.2.4 DEVIATION FROM TEST STANDARD.......................................................12 4.2.5 TEST SETUP..............................................................................................13 4.2.6 EUT OPERATING CONDITIONS................................................................13 4.2.7 TEST RESULTS..........................................................................................14 4.3 BAND EDGES MEASUREMENT................................................................19 4.3.1 LIMITS OF BAND EDGES MEASUREMENT.............................................19 4.3.2 TEST INSTRUMENTS................................................................................19 4.3.3 TEST PROCEDURE...................................................................................19 4.3.4 DEVIATION FROM TEST STANDARD.......................................................19 4.3.5 EUT OPERATING CONDITION..................................................................19 4.3.6 TEST RESULTS..........................................................................................19 5. PHOTOGRAPHS OF THE TEST CONFIGURATION..................................22 6. INFORMATION ON THE TESTING LABORATORIES................................23 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.......................................................24 Report No.: RF991111D04 R1 3 Report Format Version 4.0.0 Cancels and replaces the report No.:RF991111D04 dated Dec. 6, 2010 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release N/A Dec. 6, 2010 RF991111D04 R1 Addition mode name and brand name in section 1& 3.1 Dec. 8, 2010 Report No.: RF991111D04 R1 4 Report Format Version 4.0.0 Cancels and replaces the report No.:RF991111D04 dated Dec. 6, 2010 1. CERTIFICATION PRODUCT: 2.4G Dolphin keyboard MODEL NO.: KBRF32711 BRAND NAME: PRIMAX, ASUS CO03-K, KW03 BRAND NAME: Icon7 APPLICANT: PRIMAX ELECTRONICS LTD. TESTED: Nov. 26, 2010 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 The above equipment (Model: KBRF32711) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Jessica Cheng / Specialist ) APPROVED BY : , DATE: ( Ken Liu / Manager) Report No.: RF991111D04 R1 5 Report Format Version 4.0.0 Cancels and replaces the report No.:RF991111D04 dated Dec. 6, 2010 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD SECTION TEST TYPE AND LIMIT RESULT REMARK 15.207 Conducted Emission Test N/A Power supply is 3Vdc from batteries 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 12.209 PASS Minimum passing margin is –8.1dB at 4882.00MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty level…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
